A modern IoT data processing toolbox Michael Hausenblas Chief Data Engineer MapR Technologies

1. © 2015 MapR Technologies, confidential

3. © 2015 MapR Technologies, confidential© 2015 MapR Technologies, confidential
IoT—a superset of the Internet

4. © 2015 MapR Technologies, confidential
IoT—a superset of the Internet
What is the IoT?
“The idea of an all-encompassing and ubiquitous network of devices to
facilitate co-ordination and communication between the devices
themselves as well as between the devices and human end-users. The
involved devices are typically constrained devices such as RFID
sensors, but may also more sophisticated ones like smartphones.”

5. © 2015 MapR Technologies, confidential
IoT—a superset of the Internet
thin fat
stationary
mobile
devices and their deployment

6. © 2015 MapR Technologies, confidential
The IoT landscapeinfrastructuredataapps

7. © 2015 MapR Technologies, confidential
New and Existing
Devices
IoT Gateways Network/Wireless
Services
Backend Systems
Orientation iot.eclipse.org

8. © 2015 MapR Technologies, confidential
Categorization & use cases

9. © 2015 MapR Technologies, confidential
Categorization & use cases: Personal IoT
Scope is on a single person, for example a smartphone equipped
with GPS sensor or a fitness device that measures the heart and
sharing this data with her GP. One of the fastest growing, rather
consumer-oriented areas of IoT.
Use cases and apps
• Quantified self
• Smart jackets
• Personal digital assistant

10. © 2015 MapR Technologies, confidential
Categorization & use cases: Group IoT
Focuses on a small group of people, for example a family in the
context of a smart home where the deployed sensors capture
temperature and lighting conditions for optimal comfort. One of the
most challenging areas and yet early days.
Use cases and apps
• Smart homes
• Proactive/predictive car maintenance
• Interactive tourism

11. © 2015 MapR Technologies, confidential
Categorization & use cases: Community IoT
Considers a large group of people, potentially tens of thousands,
usually in the context of public infrastructure, such as smart cities.
Some immature from a commercial POV but potentially promising
IoT area.
Use cases and apps
• Smart cities
• Health care (monitoring, trackers)

12. © 2015 MapR Technologies, confidential
Categorization & use cases: Industrial IoT
Scope can be either within an organization or between
organizations and/or individuals. This is arguably the most
established and mature part of IoT, see also M2M.
Use cases and apps
• Smart factory
• Retailer supply chain
• Agriculture
• Waste management

13. © 2015 MapR Technologies, confidential
IoT lends itself to ‘Big Data’ approach
Scaling out on commodity hardware,
in a schema-on-read fashion,
over community-defined interfaces
• Volume: store all incoming sensor data for historical references
• Variety: dozens of data formats in use in the IoT world, none is relational
• Velocity: many devices generate data at a high rate; usually data streams

14. © 2015 MapR Technologies, confidential© 2015 MapR Technologies, confidential
My IoT toolbox

15. © 2015 MapR Technologies, confidential
Apache Kafka
• A high-throughput, distributed,
persistent publish-subscribe
messaging system
• Originates from LinkedIn
• Typically used as buffer/ de-coupling
layer in online stream processing
kafka.apache.org

16. © 2015 MapR Technologies, confidential
Fluentd
Data collector for unified logging layer
www.fluentd.org

17. © 2015 MapR Technologies, confidential
Apache Storm
• Distributed, fault-tolerant stream-
processing platform
• Guaranteed message processing;
takes care of replaying messages
on failure
• Concepts: tuples, streams,
spouts, bolts, topologies
storm.apache.org

18. © 2015 MapR Technologies, confidential
Apache Spark
spark.apache.org
Continued innovation bringing new functionality, such as:
• Tachyon (Shared RDDs, off-heap solution)
• BlinkDB (approximate queries)
• SparkR (R wrapper for Spark)
Spark SQL
(SQL/HQL)
Spark Streaming
(stream processing)
MLlib
(machine learning)
Spark (core execution engine—RDDs)
GraphX
(graph processing)
Mesos
file system (local, MapR-FS, HDFS, S3) or data store (HBase, Elasticsearch, etc.)
YARNStandalone

19. © 2015 MapR Technologies, confidential
Apache HBase
• Distributed, column-oriented NoSQL database built on top of HDFS
• Based on Google’s BigTable technology, CP
• Scales to 1,000s of commodity servers, billions of rows/ PB of data
• Low-latency get/put operations
hbase.apache.org

20. © 2015 MapR Technologies, confidential
drill.apache.org
Apache Drill
• Interactive analysis at scale,
with global and local schema
• Support evolving NoSQL data structures
• Self-service BI; use with or without
Hadoop
mapr.com/blog/how-use-sql-hadoop-drill-rest-
json-nosql-and-hbase-simple-rest-client

21. © 2015 MapR Technologies, confidential© 2015 MapR Technologies, confidential
Time series data

22. © 2015 MapR Technologies, confidential
OpenTSDB
OpenTSDB is a distributed time series database on top of HBase,
enabling you …
• to store & index, as well as
• to query & plot
… metrics at scale.
opentsdb.net

23. © 2015 MapR Technologies, confidential
OpenTSDB: key concepts
data point: (timestamp, value) + metric + tag: key=value  time series
(00:38, 56) mysql.com_delete schema=userdb

24. © 2015 MapR Technologies, confidential
read pathwrite path
OpenTSDB: high-level architecture
MapR-DB
HBase RPC: PUT, SCAN
TSD RPC
tcollector
tcollector
tcollector
app/metric
shell script
(alert, etc.)
TSD TSD TSD TSD
TSD RPC or HTTP
opentsdb.net/overview.html

25. © 2015 MapR Technologies, confidential
OpenTSDB with MapR
https://github.com/mapr-demos/opentsdb
message
queue
data points
users
tcollector MapR-DB
web app
buffering data for 1 hour in collector allows
1000x decrease in insertion rate

26. © 2015 MapR Technologies, confidential
OpenTSDB: interfacing
• HTTP API
• CLI (tsd, query, mkmetric, etc.)
• Java lib: asynchbase
• Improved collectors: scollector
• Dashboard: Grafana

27. © 2015 MapR Technologies© 2015 MapR Technologies
The Internet of Things architecture (iot-a)

28. © 2015 MapR Technologies
Key Requirements for an IoT Data Platform
• Deal with raw data natively
• Support a range of
workloads; streaming as
first-class citizen
• Ensure business continuity
• Provide secure and
privacy-aware operation
mapr.com/blog/key-requirements-iot-data-platform

29. © 2015 MapR Technologies, confidential
The IoT architecture (iot-a)
iot-a.info
MQ/SP
DFS
DB
input outputas-it-happens
outputinteractive
outputbatch

30. © 2015 MapR Technologies, confidential
Example iot-a
HDFS
HBase
input outputas-it-happens
outputinteractive
outputbatch
batch jobs
batch jobs

31. © 2015 MapR Technologies, confidential
A proof of concept from the automotive sector

32. © 2015 MapR Technologies, confidential
A proof of concept from the automotive sector

33. © 2015 MapR Technologies, confidential
Largest Biometric Database in the World
PEOPLE
1.2B
PEOPLE
uidai.gov.in/images/AadhaarTechnologyArchitecture_March2014.pdf

34. © 2015 MapR Technologies, confidential
Financial Services
Fraud detection
Personalized
offers
Fraud
investigation
tool
Fraud investigator
Fraud model
Recommendations
table
Clickstream
analysis
Online
transactions
MapR Distribution for Hadoop
Analytics
Interactive marketer

35. © 2015 MapR Technologies, confidential
Waste & Recycling Leader—Architecture
Truck
Truck
Truck
.
.
.
MapR
lat/lng
lat/lng
lat/lng
Online alerts
Batch processing
(MapReduce)
Tax
reduction
reporting
Shortest path graph
algorithm
(Titan)
Route
optimization
Real-time stream
processing
(Apache Storm)

36. © 2015 MapR Technologies, confidential
$50M$50M
in Free Training

37. © 2015 MapR Technologies
Q&A
@mhausenblas maprtech
