1. Fast, Agile, Resilient
for Emerging Workloads
X6: The sixth generation of EXA Technology
Alex Yost
Vice President, IBM PureSystems and System x
IBM Systems and Technology Group

2. Infrastructure Matters…
It drives virtually all business services
Agility
Speed
Efficiency
Infrastructure must:
•
•
•
•
Execute quickly and efficiently
Minimize costs and complexity
Foster innovation
Stay up and running
Economics
© 2014 IBM Corporation

3. IBM’s long history of x86 leadership
EXA
1st
VMware
development
partner
EXA2
1st
1st
x86 server with
100 #1
benchmarks
Intel co-innovation partner
© 2014 IBM Corporation
X3
X4
1st
hot-swap
memory
to surpass
1 million
tpmC
eX5
1st
scalable
memory
#1
market share
Largest
SAP HANA System
X6

4. Mission critical workloads are increasingly moving to x86
Enterprise
Resource Planning
Execute strategies and meet demand
Business
Analytics
Real-time trends and patterns
Database
Access core information
Virtualization
© 2014 IBM Corporation
IT optimization

5. Introducing the sixth generation of IBM Enterprise X-Architecture
FAST
AGILE
RESILIENT
Superior performance
43% lower solution cost
Up to 28% lower acquisition costs
Multiple generations of investment protection
3X the memory
More reliable
IBM System
x3950 X6
IBM System
x3850 X6
8-way rack
4-way rack
© 2014 IBM Corporation
IBM Flex System x880 X6
2- to 8-way compute node

6. FAST
Shift your business services into high gear
Scaling for new workloads
and business demands
3X more memory
Actionable information—
delivered faster
Scaling to support 8 CPUs
Higher solution performance
at 43% lower cost
New eXFlash memory-channel
storage
© 2014 IBM Corporation
FlashCache Storage Accelerator

7. FAST
Higher performance from Flash storage
directly on the memory bus
WriteNow • RAID • IBM FlashCache Storage Accelerator
DATA &
ANALYTICS
3X
LOWER
latency
CLOUD
2X
FLASH
© 2014 IBM Corporation
Better
awareness
FASTER
IT
optimization
Competitive
advantage
43% LOWER
solution cost

8. FAST
X6 Architecture + DB2 = Super Fast
DB2 optimized for high speed
analytics & transactions
99x faster analytics
using BLU Acceleration with X6
Architecture1
1.
2.
Leveraging X6 innovations
on memory, IO, and storage
2.3x increase for
transactional throughput
using eXFlash DIMM2
Based on internal tests comparing DB2 10.1 on a whitebox with XIV storage vs. DB2 10.5 with BLU Acceleration and X6 Architecture
Based on internal tests comparing DB2 10.5 with SSD vs. with eXFlash DIMM.
© 2014 IBM Corporation

9. AGILE
Modular design reduces cost
and protects your investment
Simplify deployment
Maximize performance
Up to 28% lower
acquisition costs
Handles what you need today
and in the future
© 2014 IBM Corporation

10. AGILE
Multiple generations on one server
Upgrade technology using
the modular “book” design
Eliminate
“server rip
and replace”
© 2014 IBM Corporation

11. RESILIENT
Meet the demands of
enterprise workloads
Advanced Page Retire
Processor High Availability
Rolling Firmware Update Upward
Integration Module for Standard
Hypervisors
RAS Upward Integration Module
for Standard Hypervisors
© 2014 IBM Corporation
•
•
•
•
Maximize application availability
Reduce support costs
Simplify maintenance
Manage more with existing tools
3X the memory and
still more reliable

12. X6: the ideal infrastructure for today’s enterprise applications
INFRASTRUCTURE SOLUTIONS
SAP
Business
Suite
SAP
HANA
© 2014 IBM Corporation
Microsoft
Hyper-V
VMware
vCloud
Suite
IBM
DB2 with BLU
Acceleration
Microsoft
SQL Data
Warehouse

13. SAP HANA and IBM momentum in big data and analytics
More than
2100 SAP
HANA
systems
shipped
Largest SAP
HANA system
in the world:
100TB
Investment
protection:
Add X6 to existing
eX5 clusters
Leadership
400TB
of IBM Systems in
SAP HANA
Enterprise Cloud
X6 is
optimized for
analytics:
I/O performance, memory
and core scalability
© 2014 IBM Corporation
in SAP
HANA
on EXA
technology

14. Get expert integrated knowledge
baked right into your cloud
IBM Platform Resource
Scheduler
Dynamic resource management for OpenStack to
optimize infrastructure utilization while reducing cost
IBM Flex System for
SmartCloud Orchestrator
Quickly deploy clouds with open standards-driven
support across OpenStack, networking and storage
IBM PureFlex System for
VMware vCloud Suite
Provides simplicity, performance and speed of
deployment of our PureFlex System into
vCloud and vCenter environments
© 2014 IBM Corporation

15. Workload optimized for big data
Purpose-built for Big Data
Aggregate
Analyze Data
IBM System x3650 M4 BD
• Industry’s highest total storage capacity of 3.5-inch drives for dual-socket x86 servers
• Up to 56 TB of storage spanning 14 drives for big data and storage-rich applications
• High performance: Intel Xeon E5-2600 v2 processors (up to 12 cores per CPU)
© 2014 IBM Corporation

16. can drive cloud and big data for your enterprise
Fast
Develop innovative products
and services
Achieve insight faster
Agile
Innovate products and
services
Multiple generations of
technology delivers up to
28% lower acquisition costs
Outperform your competitors
Resilient
More reliable with
3X the memory
© 2014 IBM Corporation
Cloud-enable mission critical
applications

18. The Next Generation
Database and X6
Sean Poulley
Vice President, Databases and Data Warehousing
IBM Software Group

19. What does the next generation of database look like?
ü The most advanced in-memory technology on the
market today
ü Hybrid columnar row based
ü Super fast for transactional and
analytic workloads
ü Leading NOSQL and SQL capabilities
ü Highly available, highly reliable, highly resilient, and
simplified with advanced workload capability
© 2014 IBM Corporation

20. DB2 with BLU Acceleration
Change the game for in-memory
§ In-memory columnar
processing
§ Dynamic memory
technology
§ Data skipping
§ Parallel vector processing
§ No need for indexes or
tuning
§ Create, load and go
§ Modular, flexible
system design
§ Clients reporting 10x
compression3
§ Compressed data
remains actionable
§ Very high compute and
storage density
§ Lowest TCA through
efficient
configurations
§ Lower license costs
with terabyte pricing
§ Upgrade with lower
cost, no overhead
© 2014 IBM Corporation
1Client-reported
testing results in DB2 10.5 early release program. Individual results will vary depending on individual workloads, configurations and conditions, including table size and content.

21. DB2 Performance
Change the game for Analytics and Super Fast Transactions
Super Fast Analytics
Super Fast Transactions
§ 99x faster analytics using BLU Acceleration
on X6 Architecture1
§ In-memory columnar processing
§ POPS (Proof of Perf Scalability) workload
§ IBM eXFlash DIMM technology
improves transaction throughput2
§ High-speed uncore I/O
§ Complex OLTP Workload
100
50
Throughput (tps)
150
Good
99x
200
2.3x
0
DB2 10.1 on w hitebox
1Based
2Based
DB2 10.5 w ith BLU Acceleleration w ith
X6 Architecture
on internal tests comparing DB2 10.1 on a whitebox with XIV storage vs. DB2 10.5 with BLU Acceleration on X6 Architecture
on internal tests comparing DB2 10.5 on X6 with SSD vs. with eXFlash DIMM
© 2014 IBM Corporation
Good
Elapsed time (min.)
250

22. Current System x clients are seeing remarkable results with BLU
Acceleration
“Our query process that used to take 7 minutes can now
be run in 20 seconds, an improvement of 21X. One of
the great benefits of BLU Acceleration is that this great
query performance came without any tuning!”
- Shohei Kato, Engineer
And…
OVER 1000 customers entitled to the power of BLU Acceleration !!!!!!!
© 2014 IBM Corporation
