Keisuke Suzuki
Software engineer
PlazmaDB
ペタバイトオーダのデータ分析
基盤を支える分散ストレージの
アーキテクチャとその運用

2. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Who am I?
Keisuke Suzuki
• Backend Engineer @ Treasure Data KK
– Ex. Fujitsu
• DB / Distributed system / Performance
optimization
• Twitter: @yajilobee

3. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Treasure Data
& PlazmaDB

4. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Arm Treasure Data eCDP

5. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
PlazmaDB
Streaming data
Bulk load
PlazmaDB
Metadata
(PostgreSQL)
AWS S3 /
Riak CS

6. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Daily Workload & Storage Size
Import Query Storage size
500 Billion Records / day
~ 5.8 Million Records / sec
5 PB (+5~10 TB / day)
55 Trillion Records
600,000 Queries / day
15 Trillion Records / day

7. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
PlazmaDB Features
- Columnar format
- Partitioned by time and optionally user defined column
- Schema less
- Partition index
- Partition optimization
- Merge partitions
- Realtime Storage & Archive Storage
- Transaction
- Read committed isolation

8. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
PlazmaDB Features
- Columnar format
- Partitioned by time and optionally user defined column
- Schema less
- Partition index
- Partition optimization
- Merge partitions
- Realtime Storage & Archive Storage
- Transaction
- Read committed isolation

9. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Log data
time orderid user region price ...
2018-01-01 10:00:00 1 1 ‘A’ 10000
2018-01-01 10:03:03 2 7 ‘C’ 40000
2018-01-01 10:23:03 3 6 ‘B’ 3000
2018-01-01 10:23:12 4 3 ‘A’ 5500
2018-01-01 11:04:44 5 1 ‘A’ 20000
2018-01-01 11:30:00 6 8 ‘C’ 3000
...
Many columns (attributes)
Accumulate
over time

10. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Analytical Query
SELECT
region,
SUM(price)
FROM
orders
WHERE time >= ‘2018-01-01 10:00’
AND time <= ‘2018-01-01 11:00’
GROUP BY
region
Few part of columns
Filter by time window
time orderid user region price ...
2018-01-01 10:00:00 1 1 ‘A’ 10000
2018-01-01 10:03:03 2 7 ‘C’ 40000
2018-01-01 10:23:03 3 6 ‘B’ 3000
2018-01-01 10:23:12 4 3 ‘A’ 5500
2018-01-01 11:04:44 5 1 ‘A’ 20000
2018-01-01 11:30:00 6 8 ‘C’ 3000
...

11. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
time orderid user region price ...
2018-01-01 10:00:00 1 1 ‘A’ 10000
2018-01-01 10:03:03 2 7 ‘C’ 40000
2018-01-01 10:23:03 3 6 ‘B’ 3000
2018-01-01 10:23:12 4 3 ‘A’ 5500
2018-01-01 11:04:44 5 1 ‘A’ 20000
2018-01-01 11:30:00 6 8 ‘C’ 3000
...
Inefficiency of Row Based Format
SELECT
region,
SUM(price)
FROM
orders
WHERE time >= ‘2018-01-01 10:00’
AND time <= ‘2018-01-01 11:00’
GROUP BY
region
Scan direction Scanned data

12. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
time orderid user region price ...
2018-01-01 10:00:00 1 1 ‘A’ 10000
2018-01-01 10:03:03 2 7 ‘C’ 40000
2018-01-01 10:23:03 3 6 ‘B’ 3000
2018-01-01 10:23:12 4 3 ‘A’ 5500
2018-01-01 11:04:44 5 1 ‘A’ 20000
2018-01-01 11:30:00 6 8 ‘C’ 3000
...
Columnar Format
SELECT
region,
SUM(price)
FROM
orders
WHERE time >= ‘2018-01-01 10:00’
AND time <= ‘2018-01-01 11:00’
GROUP BY
region
Scan direction Scanned data
Few part of columns
Filter by time window

13. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
2018-01-01 10:23:03 3 6 ...
2018-01-01 10:23:12 4 3 ...
PlazmaDB
PlazmaDB Partitions
2018-01-01 10:00:00 1 1 ...
2018-01-01 10:03:03 2 7 ...
2018-01-01 11:04:44 5 1 ...
{“time”: “2018-01-01 10:00:00”, “orderid”: 1, …},
{“time”: “2018-01-01 10:03:03”, “orderid”: 2, …}
Worker{“time”: “2018-01-01 10:23:03”, “orderid”: 3, …},
{“time”: “2018-01-01 10:23:12”, “orderid”: 4, …}
{“time”: “2018-01-01 11:04:44”, “orderid”: 5, …}
Application
Partition file: A S3/RiakCS Object
Send logs periodically
Convert to columnar
& Store a partition
Table is collection of partitions

14. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
2018-01-01 10:23:03 3 6 ...
2018-01-01 10:23:12 4 3 ...
Meta DB (PostgreSQL)
PlazmaDB Metadata
2018-01-01 10:00:00 1 1 ...
2018-01-01 10:03:03 2 7 ...
2018-01-01 11:04:44 5 1 ...
data_set_id path ...
1
1
1
2
2018-01-01 10:00:00 1 1 ...
2018-01-01 10:03:03 2 7 ...
PlazmaDB is Multi tenant
data_set_id: ID combination of User, Database, Table
Data set 1
Data set 2
AWS S3 / RiakCS

15. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
2018-01-01 10:23:03 3 6 ...
2018-01-01 10:23:12 4 3 ...
Meta DB (PostgreSQL)
Partition Index
2018-01-01 10:00:00 1 1 ...
2018-01-01 10:03:03 2 7 ...
2018-01-01 11:04:44 6 1 ...
data_set_id time_range path ...
1 [2018-01-01 10:00:00,
2018-01-01 10:03:03]
1 [2018-01-01 10:23:03,
2018-01-01 10:23:12]
1 [2018-01-01 11:04:44,
2018-01-01 10:04:44]
2
2018-01-01 10:00:00 1 1 ...
2018-01-01 10:03:03 2 7 ...
Data set 1
Data set 2
AWS S3 / RiakCS

16. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Partition Lookup
SELECT
region,
SUM(price)
FROM
orders -- assume this is data set 1
WHERE time >= ‘2018-01-01 10:00’
AND time <= ‘2018-01-01 11:00’
GROUP BY
region
Meta DB (PostgreSQL)
data_set_id time_range path ...
1 [2018-01-01 10:00:00,
2018-01-01 10:03:03]
1 [2018-01-01 10:23:03,
2018-01-01 10:23:12]
1 [2018-01-01 11:04:44,
2018-01-01 10:04:44]
2

17. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
2018-01-01 10:23:03 3 6 ‘B’ 3000
2018-01-01 10:23:12 4 3 ‘A’ 5500
time orderid user region price ...
2018-01-01 10:00:00 1 1 ‘A’ 10000
2018-01-01 10:03:03 2 7 ‘C’ 40000
Skip Partition Scan
SELECT
region,
SUM(price)
FROM
orders
WHERE time >= ‘2018-01-01 10:00’
AND time <= ‘2018-01-01 11:00’
GROUP BY
region
Scan direction Scanned data
2018-01-01 11:04:44 5 1 ‘A’ 20000
2018-01-01 11:30:00 6 8 ‘C’ 3000
...

18. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
How to find Partitions?
SELECT
region,
SUM(price)
FROM
orders -- assume this is data set 1
WHERE time >= ‘2018-01-01 10:00’
AND time <= ‘2018-01-01 11:00’
GROUP BY
region
Meta DB (PostgreSQL)
data_set_id time_range path ...
1 [2018-01-01 10:00:00,
2018-01-01 10:03:03]
1 [2018-01-01 10:23:03,
2018-01-01 10:23:12]
1 [2018-01-01 11:04:44,
2018-01-01 10:04:44]
2
Number of partitions in a data set can be
large (1M+) for large tables.
?

19. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Range Type and GiST Index of PostgreSQL
Meta DB (PostgreSQL)
data_set_id time_range path ...
1 [2018-01-01 10:00:00,
2018-01-01 10:03:03]
1 [2018-01-01 10:23:03,
2018-01-01 10:23:12]
1 [2018-01-01 11:04:44,
2018-01-01 10:04:44]
2
GiST Index
Range type
• Overlap operator
time_range && [2018-01-01 10:00, 2018-01-01 11:00]
Overlap is checked by index scan

20. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
User Defined Partition (Beta)
SELECT … FROM … WHERE time > … AND time <... AND region = ‘A’
Time Time
Region(userdefinedkey)
A
C
B

21. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
PlazmaDB
Partition Fragmentation
Data set 1
Data set 2
Presto worker
Hive worker
● Latency (30ms+)
● Get operation cost

22. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Data set 2
PlazmaDB
Data set 2
Data set 1
Realtime Storage & Archive Storage
Realtime Storage Archive Storage
Partitions
imported 1 hour
Merge
Data set 1

23. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Data set 2
PlazmaDB
Data set 2
Data set 1
Realtime Storage & Archive Storage
Realtime Storage Archive Storage
Partitions
imported 1 hour
Merge
Data set 1
Reduced to 1/20 - 1/100 partitions

24. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Streaming & Bulk data upload
Realtime Storage Archive Storage
Bulk loadStreaming data

25. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Fragmentation of Archive Storage
data_set_id time_range import_time ...
1 [... 10:00:00, ... 10:03:03] … 10:05:00
1 [... 10:23:03, ... 10:23:12] … 10:25:00
...
1 [... 20:30:00, ... 20:34:44] … 20:35:00
1 [... 10:00:44, ... 20:44:14] … 20:45:00
...
data_set_id time_range ...
1 [... 10:00:00, ... 11:00:00]
...
1 [... 10:00:44, … 11:00:00]
1 [... 15:04:38, ... 15:34:44]
1 [... 20:00:00, ... 21:00:00]
...
Realtime Storage Archive Storage
Delayed data Split by 1 hour window

26. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Remerge Partitions
Archive Storage

27. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Re: PlazmaDB features
- Columnar format
- Partitioned by time and optionally user defined column
- Schema less
- Partition index
- Partition optimization
- Merge partitions
- Realtime Storage & Archive Storage
- Transaction
- Read committed isolation

28. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Current PlazmaDB
& Future Challenges

29. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Data Volume
PlazmaDB
Meta DB (PostgreSQL)
Realtime Storage Archive Storage
AWS S3 / Riak CS
5 PB
GiST GiST
Partition
Metadata
Partition
Metadata
1 TB

30. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Monitoring
• Arm Treasure Data
– Detailed log analyze
• DataDog
– Metrics visualization

31. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Read Workload on Meta DB
• Metadata size ~ 1TB
• Shared Buffer size ~ 150GB
• But, Hot Data size is much
smaller than Shared Buffer
# of Read Requested on Data Set /day
#ofPartitionsRead/day

32. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Write Workload on Meta DB
200k transaction / min
~ 3k transaction / sec
3 MB / sec

33. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
PostgreSQL Auto VACUUM (FREEZE)
VACUUM FREEZE: Vacuum to prevent transaction ID wraparound failures
• Force full scan on relation (as of PostgreSQL 9.4)
– Hot data may be evicted to scan relations for vacuum
=> Read workload can be affected
– PostgreSQL 9.6 or later mitigate the problem
• The more transaction IDs are consumed, the more vacuum can be happened
– In our case, it happens every 2-3 day

34. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Impact of VACUUM FREEZE

35. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
GiST Index Bloat
100GB
150GB
50GB
200GB
B-tree
GiST
Bloat 30-40GB/month
Reindex (~20h)

36. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Metadata Table Partitioning
GiST
Partition
Metadata
One relation’s reindex becomes shorter and space saving

37. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Meta DB Scale out
DB1 DB2 DB3

38. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
More Partition Skip
SELECT
region,
SUM(price)
FROM
orders
WHERE time >= ‘2018-01-01 10:00’
AND time <= ‘2018-01-01 11:00’
AND user_age >= 20
AND user_age <= 30
GROUP BY
region
Meta DB (PostgreSQL)
data_set_id time_range path ...
1 [2018-01-01 10:00:00,
2018-01-01 10:03:03]
1 [2018-01-01 10:23:03,
2018-01-01 10:23:12]
1 [2018-01-01 11:04:44,
2018-01-01 10:04:44]
2
Scan partition & Filter

39. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
More Partition Skip
SELECT
region,
SUM(price)
FROM
orders
WHERE time >= ‘2018-01-01 10:00’
AND time <= ‘2018-01-01 11:00’
AND user_age >= 20
AND user_age <= 30
GROUP BY
region
Meta DB (PostgreSQL)
data_set_id time_range user_age_range
1 [2018-01-01 10:00:00,
2018-01-01 10:03:03]
[35, 40]
1 [2018-01-01 10:23:03,
2018-01-01 10:23:12]
[25, 30]
1 [2018-01-01 11:04:44,
2018-01-01 10:04:44]
2
Store metadata on frequently accessed columns

40. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Smart Partition Selection for Remerge
Remerge is resource consuming
• Current
– Data set size
– # of Partitions
• Idea
– Access frequency
– Data freshness
Fresh data is likely to be hot

41. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
Summary
- PlazmaDB: Storage Layer of Arm Treasure Data Analytics Platform
- Optimization for Analytical Queries
- Columnar + Time Partitioning + Partition Index
- Optimization for Streaming data
- Realtime & Archive Storage + Merge Partition
- Challenges
- Reduce impact of PostgreSQL VACUUM FREEZE
- GiST index management
- More Partition Optimization
- Enrich Metadata
- Smart Remerge

42. Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
We are Hiring!!
https://www.treasuredata.com/company/careers/

43. Thank You!
Danke!
Merci!
谢谢!
Gracias!
Kiitos!
Copyright 1995-2018 Arm Limited (or its affiliates). All rights reserved.
