(1)Objective: Binary Search Tree traversal (2 points) Use traversal.pptx as guidance to write a program to build a binary search tree Dictionary. I of BST have the same data from each input record. Download traversal-lab.pptx, inventory.txt, BinNode.java, BSTNode.java, BST.java, Dictionary.java . Perform specifications as follow: (a)Provide Add, Delete and Retrieve functions for user to access the database. Reject duplicate record when add a new record. (b)Modify BST.java to add printpostOrder, printpreOrder methods. (c)At the end, display inorder, postorder and preorder of the tree. Codes: /** Source code example for \"A Practical Introduction to Data Structures and Algorithm Analysis, 3rd Edition (Java)\" by Clifford A. Shaffer Copyright 2008-2011 by Clifford A. Shaffer */ /** ADT for binary tree nodes */ public interface BinNode { /** Get and set the element value */ public E element(); public void setElement(E v); /** @return The left child */ public BinNode left(); /** @return The right child */ public BinNode right(); /** @return True if a leaf node, false otherwise */ public boolean isLeaf(); } //******************************************************************** // StringTree.java // //******************************************************************** import java.util.*; public class StringTree { private Node root; //---------------------------------------------------------------- // Creates an initially empty tree. //---------------------------------------------------------------- public StringTree() { root = null; } //---------------------------------------------------------------- // Adds a string to the tree. //---------------------------------------------------------------- public void addString (String str) { root = addStringToSubTree(str, root); } //---------------------------------------------------------------- // Adds a string to the subtree with the given root node //---------------------------------------------------------------- private Node addStringToSubTree (String str, Node node) { Node result = node; if (node == null) result = new Node(str); // If the new string comes before the string in the node, add // the new string to the left child. Otherwise, add it to the // right child. else if (str.compareTo(node.value) < 0) node.left = addStringToSubTree(str, node.left); else node.right = addStringToSubTree(str, node.right); return result; } //---------------------------------------------------------------- // Prints the result of a depth-first traversal of the tree using // recursion. //---------------------------------------------------------------- public void traverseWithRecursion() { traverseWithRecursion(root); } //---------------------------------------------------------------- // Prints the elements in the specified tree using recursion. //---------------------------------------------------------------- private void traverseWithRecursion (Node node) { if (node != null) { traverseWithRecursion (node.left); System.

1. (1)Objective: Binary Search Tree traversal (2 points)
Use traversal.pptx as guidance to write a program to build a binary search tree Dictionary. I of
BST have the same data from each input record.
Download traversal-lab.pptx, inventory.txt, BinNode.java, BSTNode.java, BST.java,
Dictionary.java .
Perform specifications as follow:
(a)Provide Add, Delete and Retrieve functions for user to access the database. Reject duplicate
record when add a new record.
(b)Modify BST.java to add printpostOrder, printpreOrder methods.
(c)At the end, display inorder, postorder and preorder of the tree.
Codes:
/** Source code example for "A Practical Introduction to Data
Structures and Algorithm Analysis, 3rd Edition (Java)"
by Clifford A. Shaffer
Copyright 2008-2011 by Clifford A. Shaffer
*/
/** ADT for binary tree nodes */
public interface BinNode {
/** Get and set the element value */
public E element();
public void setElement(E v);
/** @return The left child */
public BinNode left();
/** @return The right child */
public BinNode right();
/** @return True if a leaf node, false otherwise */
public boolean isLeaf();
}
//********************************************************************
// StringTree.java
//
//********************************************************************
import java.util.*;
public class StringTree

2. {
private Node root;
//----------------------------------------------------------------
// Creates an initially empty tree.
//----------------------------------------------------------------
public StringTree()
{
root = null;
}
//----------------------------------------------------------------
// Adds a string to the tree.
//----------------------------------------------------------------
public void addString (String str)
{
root = addStringToSubTree(str, root);
}
//----------------------------------------------------------------
// Adds a string to the subtree with the given root node
//----------------------------------------------------------------
private Node addStringToSubTree (String str, Node node)
{
Node result = node;
if (node == null)
result = new Node(str);
// If the new string comes before the string in the node, add
// the new string to the left child. Otherwise, add it to the
// right child.
else
if (str.compareTo(node.value) < 0)
node.left = addStringToSubTree(str, node.left);
else
node.right = addStringToSubTree(str, node.right);
return result;
}
//----------------------------------------------------------------

3. // Prints the result of a depth-first traversal of the tree using
// recursion.
//----------------------------------------------------------------
public void traverseWithRecursion()
{
traverseWithRecursion(root);
}
//----------------------------------------------------------------
// Prints the elements in the specified tree using recursion.
//----------------------------------------------------------------
private void traverseWithRecursion (Node node)
{
if (node != null)
{
traverseWithRecursion (node.left);
System.out.print (node.value+" ");
traverseWithRecursion (node.right);
}
}
}
//********************************************************************
// Node for a binary tree of Strings.
//********************************************************************
class Node
{
public String value;
public Node left;
public Node right;
public Node (String value)
{
this.value = value;
this.left = left;
this.right = right;
}
}
/** Source code example for "A Practical Introduction to Data

4. Structures and Algorithm Analysis, 3rd Edition (Java)"
by Clifford A. Shaffer
Copyright 2008-2011 by Clifford A. Shaffer
*/
/** Binary tree node implementation: Pointers to children
@param E The data element
@param Key The associated key for the record */
import java.util.*;
class BSTNode implements BinNode {
private Key key; // Key for this node
private E element; // Element for this node
private BSTNode left; // Pointer to left child
private BSTNode right; // Pointer to right child
/** Constructors */
public BSTNode() {left = right = null; }
public BSTNode(Key k, E val)
{ left = right = null; key = k; element = val; }
public BSTNode(Key k, E val,
BSTNode l, BSTNode r)
{ left = l; right = r; key = k; element = val; }
/** Get and set the key value */
public Key key() { return key; }
public void setKey(Key k) { key = k; }
/** Get and set the element value */
public E element() { return element; }
public void setElement(E v) { element = v; }
/** Get and set the left child */
public BSTNode left() { return left; }
public void setLeft(BSTNode p) { left = p; }
/** Get and set the right child */
public BSTNode right() { return right; }
public void setRight(BSTNode p) { right = p; }
/** @return True if a leaf node, false otherwise */
public boolean isLeaf()
{ return (left == null) && (right == null); }
}

5. /** Source code example for "A Practical Introduction to Data
Structures and Algorithm Analysis, 3rd Edition (Java)"
by Clifford A. Shaffer
Copyright 2008-2011 by Clifford A. Shaffer
*/
import java.lang.Comparable;
/** Binary Search Tree implementation for Dictionary ADT */
class BST, E>
implements Dictionary {
private BSTNode root; // Root of the BST
int nodecount; // Number of nodes in the BST
/** Constructor */
BST() { root = null; nodecount = 0; }
/** Reinitialize tree */
public void clear() { root = null; nodecount = 0; }
/** Insert a record into the tree.
@param k Key value of the record.
@param e The record to insert. */
public void insert(Key k, E e) {
root = inserthelp(root, k, e);
nodecount++;
}
// Return root
public BSTNode getRoot()
{
return root;
}
/** Remove a record from the tree.
@param k Key value of record to remove.
@return The record removed, null if there is none. */
public E remove(Key k) {
E temp = findhelp(root, k); // First find it
if (temp != null) {
root = removehelp(root, k); // Now remove it

6. nodecount--;
}
return temp;
}
/** Remove and return the root node from the dictionary.
@return The record removed, null if tree is empty. */
public E removeAny() {
if (root == null) return null;
E temp = root.element();
root = removehelp(root, root.key());
nodecount--;
return temp;
}
/** @return Record with key value k, null if none exist.
@param k The key value to find. */
public E find(Key k) { return findhelp(root, k); }
/** @return The number of records in the dictionary. */
public int size() { return nodecount; }
private E findhelp(BSTNode rt, Key k) {
if (rt == null) return null;
if (rt.key().compareTo(k) > 0)
return findhelp(rt.left(), k);
else if (rt.key().compareTo(k) == 0) return rt.element();
else return findhelp(rt.right(), k);
}
/** @return The current subtree, modified to contain
the new item */
private BSTNode inserthelp(BSTNode rt,
Key k, E e) {
if (rt == null) return new BSTNode(k, e);
if (rt.key().compareTo(k) > 0)
rt.setLeft(inserthelp(rt.left(), k, e));
else
rt.setRight(inserthelp(rt.right(), k, e));
return rt;

7. }
/** Remove a node with key value k
@return The tree with the node removed */
private BSTNode removehelp(BSTNode rt,Key k) {
if (rt == null) return null;
if (rt.key().compareTo(k) > 0)
rt.setLeft(removehelp(rt.left(), k));
else if (rt.key().compareTo(k) < 0)
rt.setRight(removehelp(rt.right(), k));
else { // Found it
if (rt.left() == null) return rt.right();
else if (rt.right() == null) return rt.left();
else { // Two children
BSTNode temp = getmin(rt.right());
rt.setElement(temp.element());
rt.setKey(temp.key());
rt.setRight(deletemin(rt.right()));
}
}
return rt;
}
private BSTNode getmin(BSTNode rt) {
if (rt.left() == null) return rt;
return getmin(rt.left());
}
private BSTNode deletemin(BSTNode rt) {
if (rt.left() == null) return rt.right();
rt.setLeft(deletemin(rt.left()));
return rt;
}
private void printhelp(BSTNode rt) {
if (rt == null) return;
printhelp(rt.left());
printVisit(rt.element());
printhelp(rt.right());

8. }
private StringBuffer out;
public String toString() {
out = new StringBuffer(400);
printhelp(root);
return out.toString();
}
private void printVisit(E it) {
out.append(it + " ");
}
}
/** Source code example for "A Practical Introduction to Data
Structures and Algorithm Analysis, 3rd Edition (Java)"
by Clifford A. Shaffer
Copyright 2008-2011 by Clifford A. Shaffer
*/
/** The Dictionary abstract class. */
public interface Dictionary {
/** Reinitialize dictionary */
public void clear();
/** Insert a record
@param k The key for the record being inserted.
@param e The record being inserted. */
public void insert(Key k, E e);
/** Remove and return a record.
@param k The key of the record to be removed.
@return A maching record. If multiple records match
"k", remove an arbitrary one. Return null if no record
with key "k" exists. */
public E remove(Key k);
/** Remove and return an arbitrary record from dictionary.
@return the record removed, or null if none exists. */
public E removeAny();
/** @return A record matching "k" (null if none exists).
If multiple records match, return an arbitrary one.
@param k The key of the record to find */

9. public E find(Key k);
/** @return The number of records in the dictionary. */
public int size();
};
Text file :
CT16C1288B
DT14B1225F
MI15B1250A
MI15B1251A
HO03N1095A
HY07D1095BQ
KI04D2593C
DG12A1240AQ
HY03G2593BQ
TO30A1310A
HO03N1095AQ
HO01H1351C
HO01H1350C
FT18A1288B
LR15A1000A
BM12E1000A
VW02B3113A
NI23H1230AQ
LX03D2503A
LX03D2502A
LX03D2502A
VW22A3113B
VW22B3113A
Solution
import java.util.Scanner;
/* Class BSTNode */
class BSTNode
{

10. BSTNode left, right;
int data;
/* Constructor */
public BSTNode()
{
left = null;
right = null;
data = 0;
}
/* Constructor */
public BSTNode(int n)
{
left = null;
right = null;
data = n;
}
/* Function to set left node */
public void setLeft(BSTNode n)
{
left = n;
}
/* Function to set right node */
public void setRight(BSTNode n)
{
right = n;
}
/* Function to get left node */
public BSTNode getLeft()
{
return left;
}
/* Function to get right node */
public BSTNode getRight()
{
return right;

11. }
/* Function to set data to node */
public void setData(int d)
{
data = d;
}
/* Function to get data from node */
public int getData()
{
return data;
}
}
/* Class BST */
class BST
{
private BSTNode root;
/* Constructor */
public BST()
{
root = null;
}
/* Function to check if tree is empty */
public boolean isEmpty()
{
return root == null;
}
/* Functions to insert data */
public void insert(int data)
{
root = insert(root, data);
}
/* Function to insert data recursively */
private BSTNode insert(BSTNode node, int data)
{

12. if (node == null)
node = new BSTNode(data);
else
{
if (data <= node.getData())
node.left = insert(node.left, data);
else
node.right = insert(node.right, data);
}
return node;
}
/* Functions to delete data */
public void delete(int k)
{
if (isEmpty())
System.out.println("Tree Empty");
else if (search(k) == false)
System.out.println("Sorry "+ k +" is not present");
else
{
root = delete(root, k);
System.out.println(k+ " deleted from the tree");
}
}
private BSTNode delete(BSTNode root, int k)
{
BSTNode p, p2, n;
if (root.getData() == k)
{
BSTNode lt, rt;
lt = root.getLeft();
rt = root.getRight();
if (lt == null && rt == null)
return null;
else if (lt == null)
{

13. p = rt;
return p;
}
else if (rt == null)
{
p = lt;
return p;
}
else
{
p2 = rt;
p = rt;
while (p.getLeft() != null)
p = p.getLeft();
p.setLeft(lt);
return p2;
}
}
if (k < root.getData())
{
n = delete(root.getLeft(), k);
root.setLeft(n);
}
else
{
n = delete(root.getRight(), k);
root.setRight(n);
}
return root;
}
/* Functions to count number of nodes */
public int countNodes()
{
return countNodes(root);
}
/* Function to count number of nodes recursively */

14. private int countNodes(BSTNode r)
{
if (r == null)
return 0;
else
{
int l = 1;
l += countNodes(r.getLeft());
l += countNodes(r.getRight());
return l;
}
}
/* Functions to search for an element */
public boolean search(int val)
{
return search(root, val);
}
/* Function to search for an element recursively */
private boolean search(BSTNode r, int val)
{
boolean found = false;
while ((r != null) && !found)
{
int rval = r.getData();
if (val < rval)
r = r.getLeft();
else if (val > rval)
r = r.getRight();
else
{
found = true;
break;
}
found = search(r, val);
}
return found;

15. }
/* Function for inorder traversal */
public void inorder()
{
inorder(root);
}
private void inorder(BSTNode r)
{
if (r != null)
{
inorder(r.getLeft());
System.out.print(r.getData() +" ");
inorder(r.getRight());
}
}
/* Function for preorder traversal */
public void preorder()
{
preorder(root);
}
private void preorder(BSTNode r)
{
if (r != null)
{
System.out.print(r.getData() +" ");
preorder(r.getLeft());
preorder(r.getRight());
}
}
/* Function for postorder traversal */
public void postorder()
{
postorder(root);
}
private void postorder(BSTNode r)
{

16. if (r != null)
{
postorder(r.getLeft());
postorder(r.getRight());
System.out.print(r.getData() +" ");
}
}
}
/* Class BinarySearchTree */
public class BinarySearchTree
{
public static void main(String[] args)
{
Scanner scan = new Scanner(System.in);
/* Creating object of BST */
BST bst = new BST();
System.out.println("Binary Search Tree Test ");
char ch;
/* Perform tree operations */
do
{
System.out.println(" Binary Search Tree Operations ");
System.out.println("1. insert ");
System.out.println("2. delete");
System.out.println("3. search");
System.out.println("4. count nodes");
System.out.println("5. check empty");
int choice = scan.nextInt();
switch (choice)
{
case 1 :
System.out.println("Enter integer element to insert");
bst.insert( scan.nextInt() );
break;

17. case 2 :
System.out.println("Enter integer element to delete");
bst.delete( scan.nextInt() );
break;
case 3 :
System.out.println("Enter integer element to search");
System.out.println("Search result : "+ bst.search( scan.nextInt() ));
break;
case 4 :
System.out.println("Nodes = "+ bst.countNodes());
break;
case 5 :
System.out.println("Empty status = "+ bst.isEmpty());
break;
default :
System.out.println("Wrong Entry ");
break;
}
/* Display tree */
System.out.print(" Post order : ");
bst.postorder();
System.out.print(" Pre order : ");
bst.preorder();
System.out.print(" In order : ");
bst.inorder();
System.out.println(" Do you want to continue (Type y or n) ");
ch = scan.next().charAt(0);
} while (ch == 'Y'|| ch == 'y');
}
}
