09 flagship education projects 2012

Jerram Falkus
Construction Ltd
Flagship Community
Sector projects

Jerram Falkus Construction Ltd - Education Profile

Coleridge Primary School

Project: Coleridge Primary School
Address: Coleridge Primary School Crouch End Hill London N8 8DG
Client: The London Borough of Haringey
Contract Value: £4,931,528
Form of Contract: JCT With Contractor’s Design 2005
Duration: 54 weeks
Architect: Nicholas Hare Architects

The 2010 BCSE and 2011 Civic Trust Award Winning design, conversion and extension to
form a new primary school on the site of the former Hornsey School of Art. The existing school
stands on the west side of Crouch Hill and will become the new infant's school once this project is
completed.

The project consists of converting the existing five storey 1920’s building into school halls, dinning
hall, and kitchen, classrooms and offices. New single and two storey classroom wings are
constructed to provide light and spacious teaching accommodation. These will achieve balanced
daylight through the use of curtain walling and clerestorey windows.

A sophisticated central Building Management System (BMS) controls the completely new
mechanical and electrical installations to the entire site.


Brampton Manor School

Project: Brampton Manor School
Address: Brampton Manor School, Roman Road, London E6 3SQ
Client: Newham Transformation Partnership for The London Borough of
Newham
Contract Value: £8.80 million
Form of Contract: PfS Design & Build Contract
Architect: Edward Cullinan Architects

Design, conversion and extension of teaching areas, sports hall and gymnasium for
Newham Transformation Partnership Ltd The proposal for Brampton Manor includes new feature
enveloping to areas of the existing 1960s buildings. Dramatised and illuminated façades to the
east and west halls will promote the school's new facilities, using a robust palette of materials.

Internal reorganisation has created facilities to promote the school's Specialist Arts Status.
These include a professional theatre and performing arts spaces, new TV/audio studios and
media editing suites; a new fitness suite; and a reorganised and enhanced Special
Educational Needs (SEN) Unit. Additionally, we are providing extended and refurbished
classrooms for Design/Technology, art and ICT.

The scheme also includes two new glazed double storey circulation links across the west and
east courtyards that will provide display areas for artworks. The external courtyard areas
landscaped and provide break-out spaces.


Curwen Primary School

Project: Curwen Primary School
Address: Curwen Primary School, Atlas Road, London E13 0AG
Newham
Form of Contract: PfS Design & Build Contract
Duration: 85 weeks
Architect: ATP Group

Curwen Primary School was built in the 1970’s as a modern replacement of the original Victorian
school building on the site.

The existing school has low ceilings, even in the halls, and poor insulative qualities by today’s
high standards.

We undertook advanced enabling works including the provision of temporary accommodation and
a new permanent vehicle entrance and access ramp to allow half of the school to be decanted.
The works are being undertaken in two large well segregated phases.

The construction works includes the complete external refurbishment including new timber and
insulated render clad facades with polyester powder coated aluminium windows and doors. The


central core of the building is being replaced with a double height steel and glu-laminated timber
framed “Heart Space” providing gym and hall, dinning area, media/ICT area and library.

Classrooms are being enlarged and a new school kitchen provided. New WC’s, offices and stores
are being provided.

Externally, covered play spaces are provided to every classroom, with new hard and soft games
areas, nature garden, feature areas and car parking provided.


Essex Primary School

Project: Essex Primary School
Address: Essex Primary School, Sheridan Road, London E12 6QX
Newham
Form of Contract: PfS Design and Build Contract
Architect: Living Architects

Essex Primary School was originally built by Jerram Falkus in the 1970’s and we are therefore
delighted to have this opportunity to return to the school to carry out major refurbishment and
extension works.

The project works are multi-phased to reduce the impact on the occupied areas of the nursery,
infant and junior schools, and we have provided an eight-class temporary building to facilitate a
complex series of decants.

Construction works include demolition of the existing single storey school kitchens, and the
construction of a two-storey block with kitchens at ground level and staff rooms and offices over.
Classrooms are remodeled to provide enlarged teaching spaces with external access and
modern facilities. New WC’s, offices and stores are provided.

The existing Junior School hall is extended to provide a greater facility for games, exercise and
performances as well as assemblies and external events.


The entire Junior School is refurbished to provide a more aesthetically pleasing appearance,
upgraded insulation and renewable energy provision from solar thermal heating and photo-voltaic
panels on the roof.

New gas fired central heating is provided to the entire school, replacing the original electrically
heated installation.

Externally, new play and activity areas are provided, along with security fencing, playgrounds and
increased car parking.


St Benedict’s School, Heart of the School Extension

Project: St Benedict’s School, Heart of the School Extension
Address: Eaton Rise, Ealing, London W5 2ES
Client: The Trust of St Benedict’s Abbey
Form of Contract: JCT 1998 Without Quantities with Amendments 1 to 5
Duration: 56 weeks
Architect: Buschow Henley (London E2)

Description:

The RIBA Award winning two-stage negotiated project was secured following an
intensive first stage tender process and a very interactive second stage, during which we
worked closely with the Client’s Design Team to value engineer and risk-manage the
proposed design to within acceptable levels.


The project, which is currently on site (April 2008) involves demolishing the existing
single storey main entrance, circulation area, WC’s and offices, and the new
construction of a three storey building. The new building is to provide an impressive
main entrance and reception, new double height hall, new WC’s, 9 classrooms, chapel
and offices. It also acts as a link between three existing school buildings, all at differing
levels.

The substructure is piled with an insitu reinforced concrete ground and first floor.

Above first floor, the building is constructed of a combination of load bearing masonry
and cross-laminated timber panels on a glu-laminated timber frame. The building is
generally clad in insulated render or Eternit cladding panels.

The roof is generally flat, with single ply membrane and sedum covering (green roof
technology). Windows and external doors are Velfac composite units.

The building is extensively serviced, with comfort cooling and heating served by new
centralised plant. External works comprise new entrance road, pavings and street
furniture to courtyards.


University of Westminster - Harrow Campus

Project: University of Westminster - Harrow Campus
Address: Watford Rd, Northwich Park, Harrow, HA1 3TP
Client: The Quintin Hogg Trust c/o The University of Westminster
Form of Contract: JCT 1998 WCD Incorporating amendments 1 to 5 with
further Employer amendments.
Duration: 73 Weeks
Architect: ATP Architects

Description:

Completed 2 months ahead of schedule - 22 August 2005

The Design & Build development of two blocks (blocks ‘P’ and ‘Q’) of five storey
residential accommodation with a basement under block ‘Q’ and a link block with roof
plant rooms using reinforced concrete construction, structural steel roof level ring beams
and timber framed trusses. The buildings are masonry clad. Internal sub-divisions use
dry lined partitioning.


Broadwater Farm Children’s Centre

Project: Broadwater Farm Children’s Centre
Address: Adams Road, London N17
Client: London Borough of Haringey - Children’s Services
Form of Contract: PPC 2000 Partnering Form (Client’s Design)
Duration: 48 weeks
Architect: Gollifer Langston Architects

Pupil Age Range: 0-5 (Surestart)
Pupil Numbers: Maximum capacity 80
Occupied During Works: Yes (adjoining infants & junior school)

Description:

The RIBA award winning works for this partnered project entailed the two stage
negotiation and construction of a single storey steel framed stand alone
children’s centre:


Construction consisted of a new single storey steel frame with a two flat roofs at
differing levels and clerestorey glazing between them. One of the roofs was a
green “sedum” roof . the other was a single ply system.

The building was clad in cedar boarding on Metsec lightweight framing. Large
areas of powder coated aluminium curtain walling allowed natural light into the
class bases.

Mechanical and electrical services were contractor designed, with an emphasis
on passive stack ventilation.

The project included much needed safe external and covered play areas, with
the provision of safety play surfaces and play equipment

Out-Turn:

This innovative and environmentally aware project was completed on programme
even with a large element of extra works added to the contract.

The project was completed to the Client’s entire satisfaction and was value
engineered during the second stage negotiations to within their available budget.


Jerram Falkus Construction Ltd Additional
Education Sector Projects


Phoenix High School, Bloemfontein Rd, Hammersmith, W12
Design and construction of a five lane Swimming pool and two storey Technology Block for
London Borough of Hammersmith & Fulham
Borough Building Technical Services, Riverview House, Beavour Lane, London, W6 9AR
£ 4,450,000

Tysoe Avenue, Enfield
Construction of new Primary School for Enfield Council
Borough Construction Technical Services, Civic Centre, Silver Street, Enfield, EN1 3XA
£ 4,100,000

The Compton School, Summers Lane, Finchley, London N12
Design and construction of classroom and science block extension, gymnasium and restaurant
accommodation together with major internal alterations and refurbishment for Barnet Council
Borough Design Department, Barnet House, 1255 High Road, London N20 0EJ
£ 4,100,000

Lambeth College, Clapham Centre, Clapham Common Southside London SW4
Extension and refurbishment to teaching accommodation for Lambeth College
W S Atkins Building, Woodcote Grove, Ashley Road, Epsom, Surrey KT18 5BW
£ 4,000,000

Jack Tizard School, South Africa Road, London, W12
Design and Construction of a new SEN School for London Borough of Hammersmith & Fulham
Building Technical Services, London Borough of Hammersmith & Fulham, Riverview House,
Beavor Lane, London, W6 9AR
£ 3,040,000

Chingford Foundation School, London E17
New Sports Hall, ancillary and teaching accommodation for The Governors
ATP Group Partnership, Brook House, Coventry Road, Ilford IG1 4QR
£ 3,000,000

Crowland Primary School, Haringey, N15
Remedial and remodelling of a fire damaged primary school for Haringey Council
Barron and Smith, Canonbury Business Centre, 202-208 New North Road, London N1 7BJ
£ 2,690,000

Cavendish PRU, Compton Close, Ealing, W13
Construction of new pupil Referral Unit for Ealing Council
Babcock Infrastructure Services, 58 Uxbridge Road, Ealing W5 2ST
£ 2,400,000

Mile End Hospital, London, E1
Construction of an Education Centre for Tower Hamlets Primary Care Health Trust
Tangram Architects, Unit 3.2 The Leather Market, Weston Street London, SE1 3EX
£ 2,200,000


Felsted School, Felsted, Essex
Construction of a Music School for The Governors of Felsted School
Nicholas Hare Architects LLP, 3 Barnsbury Square, London, N1 1JL
£ 2,200,000

Broadwater Farm Nursery, Adams Road, London N17
Construction of Children’s Nursery building for Haringey Council
Gollifer Langston Architects, 48 Poland Street, London, W1F 7ND
£2,000,000

313 Billet Road, London E17
Design and construction of a new Nursery Building for the London Borough of Waltham Forest
Murphy Philipps Architects, 140 Old Street, London EC1V 9BJ
£ 1,700,000

Kintore Way Childrens Centre, Grange Road, London SE1
Sure Start School extension and refurbishment for Southwark Council
Cottrell & Vermuellen Architecture, 1b Lliffe Street, London SE17 3LJ
£ 1,650,000

Campsbourne School, Boyton Road, London N8
Classrooms refurbishment and construction of a dining block for Haringey Council
Greenhill Jennor Architects, 9 Northburgh Street, London EC1V 0AH
£ 1,600,000

Parkfield School Sure Start Centre, St David’s Place, Hendon NW4
Design and construction of a Sure Start Centre for Barnet Council
Borough Design Department, Barnet House, 1255 High Road, London N20 0EJ
£ 1,350,000

Enfield Country Upper School, Holly Lane, Enfield
Construction of Sixth Form Study and Language Centre for Enfield Council
Borough Construction Technical Services, Civic Centre, Silver Street, Enfield EN1 3XA
£1,200,000

Garratt Park School, Waldron Road, London SW18
Design and construction of a detached teaching block for Wandsworth Council
Wandsworth Council Design Services, The Town Hall, Wandsworth High Street, London SW18
2PU£ 1,050,000

Mission Grove School, Walthamstow, E17
Primary school extension and refurbishment for the London Borough of Waltham Forest
NPS London Limited, 3-4 Avocet House, Trinity Park, Trinity Way, Chingford, London E4 8TD
£ 990,000

St Joseph’s RC Primary School, Lanark Road, London W9
Construction of a new class base areas and a Nursery Annexe for The RC Archdiocese of
Westminster
Architects Co-Partnership, Northaw House, Coopers Lane, Northaw, Hertfordshire, EN6 4PS
£ 980,000


Greenleaf Primary School, Greenleaf Road, London, E17
Construction of a two storey teaching block for London Borough of Waltham Forest
NPS London Limited, 3-4 Avocet House, Trinity Park, Trinity Way, Chingford, London E4 8TD
£ 980,000

Chingford Hall Community Primary School, London, E4
Alterations and refurbishment for London Borough of Waltham Forest
Cullinan and Buck Architects Limited, Springbok Works, Bradbury Mews, London, N16 8JW
£ 980,000

Ladywell Children’s Centre, Rushey Mead, Lewisham, SE4
Refurbishment and extension to form a day-care Children’s centre for Lewisham Council
Hazle McCormack Young, 75 High Street, Tunbridge Wells, Kent TN1 1XZ
£ 940,000

Tiverton Primary School, London N15
Primary school extension and refurbishment for Haringey Council
London Borough of Haringey, Property and Contracts, 48-62 Station Road, London N22 7TY
£ 920,000

Netley Primary School, Netley Street, London NW1
Construction of an autistic unit and community building for the London Borough of Camden
Haverstock Associates, 10 Cliff Road Studios, Cliff Road, London NW1 9AN
£ 850,000

Charlotte Sharman Lodge, Southwark, SE11
The refurbishment and conversion of a Grade 2 Listed Building into a Breakfast and
After School Care Facility for Southwark Council
Southwark Building Design Service, 19 Spa Road, Bermondsey, London SE16 3QP
£ 830,000

Newham College of Further Education, High Street, South, London E6
Extension and conversion to forma Woman’s Business Centre for The College Governors
ATP Group Partnership, Brook Street, Coventry Road, Ilford IG1 4QR
£ 760,000

Lyndhurst Primary School, Grove Road, London SE5
Construction of a Teaching Block for Southwark Council
Southwark Building Design Services, 19 Spa Road, London SE16 3QN
£ 610,000

Castlebar Field, Carlton Road, London W5
Construction of a sports pavilion for Durstan House School
Redmond Ivie Architect, Barley Mow Centre, 10 Barley Mow Passage, London W4 4PH
£ 500,000

Eastfield Primary School, Eastfield Road, Enfield
Construction of a new dining hall for Enfield Council
Borough Construction Technical Services, Civic Centre, Silver Street, Enfield EN1 3XA
£ 510,000


Cumberland School, Barking Road, London, E16
Construction of a Dining Hall extension for Newham Council
Borough Property & Design Consultancy, City Gate House, 246-250 Romford Road,
London, E7 9HZ
£ 440,000

Barking College, Romford, Essex
Provision of a disability access lift for the College Governors
Perkins Ogden architects, Construct House, Winchester Road, Alresford, Hampshire
£ 270,000

1 London Road, London E13 0AT
Design and conversion of offices into temporary teaching accommodation for Newham Council
ATP Group Partnership, Brook House, Coventry Road, Ilford, Essex IG1 4QR
£ 220,000

St Josephs Primary School, London W9 1DF
Refurbishment and extension of school hall and ancillary areas for The School Governors
Architects Co-Partnership, Northaw House, Coopers Lane, Northaw, Herts EN6 4PS
£ 150,000


09 flagship education projects 2012

More Related Content

What's hot

Viewers also liked

09 flagship education projects 2012
