Routing Security	Daniel KarrenbergRIPE NCC<daniel.karrenberg@ripe.net>
Who is talking: Daniel Karrenberg•   1980s: helped build Internet in Europe     - EUnet, Ebone, IXes, ...     - RIPE•   19...
Who is talking: Daniel Karrenberg•   RIPE NCC    - started in 1992    - first Regional Internet Registry (RIR)    - Associa...
My Messages Today• Routing    security needs to be improved• The   sky is not falling• Industry   is moving• No   need for...
Outline•   Internet Routing     -   How it works     -   What makes it work in practice     -   What can go wrong today•  ...
The Internet               6
Part(s) of the Internet                          7
“Autonomous Systems”                       8
Packet Flow              9
Routing Information Flow (BGP)                                 10
Both Directions are Needed                             11
Choice and Redundancy                        12
Questions?
What makes it work                     14
Business Relationships                         15
Transmission Paths                     16
Routing Engineering                      17
Routing Engineering Methods•   Inbound Traffic     - Selectively announce routes.     - Very little control over preference...
Routing Engineering Principles•   Autonomous Decisions by each AS•   Local tools•   Local strategies•   Local knowlege•   ...
Questions?
What can go wrong•   Misconfiguration     - Announcing too many routes (unitentional transit)     - Originating wrong route...
Hijacking            22
Hijacking            23
Hijacking            24
Questions?
Examples•   YouTube & Pakistan Telecom (2008)•   A number of full table exports•   Various route leaks from China (2010)  ...
Outline•   Internet Routing     -   How it works     -   What makes it work in practice     -   What can go wrong today•  ...
Routing Hygiene•   Do not accept customer routes from peers or     upstreams•   Limit number of prefixes accepted per adjac...
Routing Hygiene•   Is applied locally / autonomously•   Has a cost•   Subservient to routing engineering     - No obstruct...
Resource Certification - Motivation•   Good practice:     - to register routes in an IRR     - to filter routes based on IRR...
Resource Certification - Definition   “Resource certification is a reliable method       for proving the association between ...
Between who and what?•   Resource Holders     - Regional Internet Registries     - Local Internet Registries     - End Use...
What Certification offers•   Proof of holdership•   Secure Inter-Domain Routing     - Route Origin Authorisation     - Pref...
The system             34
Proof of holdership        •   Public Key        •   Resources        •   Signature                         35
Route Origin Authorisation (ROA)        •   IP Prefixes        •   AS Numbers        •   Signature                        ...
Automated Provisioning using ROAs                                 Please route this part                                  ...
The road ahead•   Production launch for all RIRs on 1 January 2011•   Beta programme available in the LIR Portal now     -...
Obstacles•   Fear of loosing autonomy•   Cost•   Low threat perception•   Fear of loosing business advantage•   Fear of lo...
Questions?
Outline•   Internet Routing     -   How it works     -   What makes it work in practice     -   What can go wrong today•  ...
My Messages Today• Routing    security needs to be improved  - Accidents  do happen ... sometimes  - Hijackings do happen ...
My Messages Today• Industryis addressing the problems  - Local measures taken autonomously  - RPKI being deployed by RIRs ...
My Messages Today• No need for public policies at this point  - Not a strucutral problem     endangering Internet  - Mitig...
Outline•   Internet Routing     -   How it works     -   What makes it work in practice     -   What can go wrong today•  ...
The End!             Kрай             Y Diwedd                                       Fí                  Соңы             ...
Upcoming SlideShare
Loading in …5
×

Routing Security

1,602 views

Published on

Published in: Technology
  • Be the first to comment

Routing Security

  1. 1. Routing Security Daniel KarrenbergRIPE NCC<daniel.karrenberg@ripe.net>
  2. 2. Who is talking: Daniel Karrenberg• 1980s: helped build Internet in Europe - EUnet, Ebone, IXes, ... - RIPE• 1990s: helped build RIPE NCC - 1st CEO: 1992-2000• 2000s: Chief Scientist & Public Service - Trustee of the Internet Society: IETF, ... - Interests: Internet measurements, stability, trust & identity in the Internet, ... 2
  3. 3. Who is talking: Daniel Karrenberg• RIPE NCC - started in 1992 - first Regional Internet Registry (RIR) - Association of 6000+ ISPs - 70+ countries in “Europe & surrounding areas” - operational coordination - number resource distribution - trusted source of data - Motto: Neutrality & Expertise - not a lobby group! 3
  4. 4. My Messages Today• Routing security needs to be improved• The sky is not falling• Industry is moving• No need for public policies at this point 4
  5. 5. Outline• Internet Routing - How it works - What makes it work in practice - What can go wrong today• Risk Mitigation - Routing Hygiene - Resource certification & checks - Obstacles• Public Policy Considerations• Discussion 5
  6. 6. The Internet 6
  7. 7. Part(s) of the Internet 7
  8. 8. “Autonomous Systems” 8
  9. 9. Packet Flow 9
  10. 10. Routing Information Flow (BGP) 10
  11. 11. Both Directions are Needed 11
  12. 12. Choice and Redundancy 12
  13. 13. Questions?
  14. 14. What makes it work 14
  15. 15. Business Relationships 15
  16. 16. Transmission Paths 16
  17. 17. Routing Engineering 17
  18. 18. Routing Engineering Methods• Inbound Traffic - Selectively announce routes. - Very little control over preferences by other ASes.• Outbound Traffic - Decide which of the known routes to use.• Inputs - Cost - Transmission Capacity - Load - Routing State 18
  19. 19. Routing Engineering Principles• Autonomous Decisions by each AS• Local tools• Local strategies• Local knowlege• Business advantages• Autonomous Decisions by each AS• (One of the reasons for rapid growth of the Internet) 19
  20. 20. Questions?
  21. 21. What can go wrong• Misconfiguration - Announcing too many routes (unitentional transit) - Originating wrong routes• Malicious Actions - Originating wrong routes (hijacking) 21
  22. 22. Hijacking 22
  23. 23. Hijacking 23
  24. 24. Hijacking 24
  25. 25. Questions?
  26. 26. Examples• YouTube & Pakistan Telecom (2008)• A number of full table exports• Various route leaks from China (2010) YouTube Movie 26
  27. 27. Outline• Internet Routing - How it works - What makes it work in practice - What can go wrong today• Risk Mitigation - Routing Hygiene - Resource certification & checks - Obstacles• Public Policy Considerations• Discussion 27
  28. 28. Routing Hygiene• Do not accept customer routes from peers or upstreams• Limit number of prefixes accepted per adjacent AS• Use a routing registry - no global authoritative registry exists• Use own knowledge about topology - topology is constantly changing - distruptions can cause drastic changes 28
  29. 29. Routing Hygiene• Is applied locally / autonomously• Has a cost• Subservient to routing engineering - No obstruction - Maintain Autonomy• Cooperation - Trust - Community - Personal Relations 29
  30. 30. Resource Certification - Motivation• Good practice: - to register routes in an IRR - to filter routes based on IRR data• Problem: - only useful if the registries are complete - many IRRs exist, lacking standardisation• Result: - Less than half of all prefixes is registered in an IRR - Real world filtering is difficult and limited - Accidental leaks happen, route hijacking is possible 30
  31. 31. Resource Certification - Definition “Resource certification is a reliable method for proving the association between resource holders and Internet resources.” 31
  32. 32. Between who and what?• Resource Holders - Regional Internet Registries - Local Internet Registries - End Users• Internet Resources - IPv4 Address Blocks - IPv6 Address Blocks - AS Numbers 32
  33. 33. What Certification offers• Proof of holdership• Secure Inter-Domain Routing - Route Origin Authorisation - Preferred certified routing• Resource transfers• Validation is the added value! 33
  34. 34. The system 34
  35. 35. Proof of holdership • Public Key • Resources • Signature 35
  36. 36. Route Origin Authorisation (ROA) • IP Prefixes • AS Numbers • Signature 36
  37. 37. Automated Provisioning using ROAs Please route this part of my network: 192.0.2.0/24 Please sign a ROA for that resource using my AS number OK, I signed and published a ROA OK, that ROA is valid. I can trust this request 37
  38. 38. The road ahead• Production launch for all RIRs on 1 January 2011• Beta programme available in the LIR Portal now - You can create certificates and ROAs - Test key will be rolled over at launch date Feedback and input actively encouraged Mailing list: ca-tf@ripe.net 38
  39. 39. Obstacles• Fear of loosing autonomy• Cost• Low threat perception• Fear of loosing business advantage• Fear of loosing autonomy 39
  40. 40. Questions?
  41. 41. Outline• Internet Routing - How it works - What makes it work in practice - What can go wrong today• Risk Mitigation - Routing Hygiene - Resource certification & checks - Obstacles• Public Policy Considerations• Discussion 41
  42. 42. My Messages Today• Routing security needs to be improved - Accidents do happen ... sometimes - Hijackings do happen ... sometimes• The sky is not falling - It does not happen all the time - It does not affect large areas of the Internet 42
  43. 43. My Messages Today• Industryis addressing the problems - Local measures taken autonomously - RPKI being deployed by RIRs - RPKI based routing tools being developed - RPKI based routing protocols being studied in IETF 43
  44. 44. My Messages Today• No need for public policies at this point - Not a strucutral problem endangering Internet - Mitigation works - Mitigation being improved - Global coordination is working 44
  45. 45. Outline• Internet Routing - How it works - What makes it work in practice - What can go wrong today• Risk Mitigation - Routing Hygiene - Resource certification & checks - Obstacles• Public Policy Considerations• Discussion 45
  46. 46. The End! Kрай Y Diwedd Fí Соңы Finis Liðugt Ende Finvezh KiнецьKonec Kraj Ënn FundLõpp Beigas Vége Son Kpaj An Críoch ‫הסוף‬ EndirFine Sfârşit Fin Τέλος Einde Конeц Slut Slutt Pabaiga Amaia Loppu Tmiem Koniec Fim

×
