RIPE Atlas!                               A “Real Big” Measurement NetworkDaniel KarrenbergChief Scientist
RIPE TTM (used for DNSMON)                              2
Light Map             3
Intuition: 1000 Probes                          4
Intuition: 5000 Probes                          5
Intuition: 10k Probes                         6
Intuition: 20k Probes                         7
Intuition: 50k Probes                         8
Intuition: 10k Probes & 1 AS                                9
Ambitious Community Effort   Instead of building small, separate,     individual & private infrastructures,               ...
Ambitious Community Effort•  Individual   Benefits  -  Lessexpensive than rolling your own  -  More vantage points availabl...
Intuition -> Plan•    For accurate maps we need more probes•    Deploying very many TTM boxes too expensive•    Smaller pr...
Probe Deployments                     13
Probe Deployments                     14
Probe Deployments                     15
Probe Capabilities•    Version 0      -  Ping to fixed targets (IPv4 & IPv6) ✔      -  Traceroute to 1st two upstream hops ...
What you see is what you get                                17
Hosting = Credits = Measurements                                    18
Host Applications                     19
Hosting = Credits = Measurements                                    20
Hosting = Credits = Measurements                                updated hourly on                                         ...
Sponsorship = Credits = Measurements                                        22
Sponsorship = Credits = Measurements                                        23
Sponsorship = Credits = MeasurementsFor sponsorships see me during the meeting,or contact me: <daniel.karrenberg@ripe.net>...
Questions?
Spare Slides / Anticipated Questions     Spare Slides                                                         26
Why Hardware and not Software Probe ?•    Comparable and Reliable Measurements      -  Known and uniform environment      ...
Is this the RIPE Botnet ?•    No•    Architecture is security conscious -> MAT WG•    Probes do not offer services, no ope...
Private Measurements ?•    We are not offering this as a service for private and     confidential measurements•    All resu...
Relation to Other RIPE NCC Services ?My personal vision, to be discussed in MAT WG and with current users:•    TTM will be...
Measurement nodes – “Probes”•    Probe (v1 / generation 1):      -  Lantronix XPortPro      -  Very low power usage      -...
RIPE Atlas - Overall Architecture                                     32
RIPE Atlas - Security aspects•    Probes have hardwired trust material!     (registration server addresses / keys)•    The...
