Caching and tuning fun for high scalability Wim Godden Cu.be Solutions
Who am I ? <ul><li>Wim Godden (@wimgtr)
Owner of Cu.be Solutions (http://cu.be)
PHP developer since 1997
Developer of OpenX
Zend Certified Engineer
Zend Framework Certified Engineer
MySQL Certified Developer </li></ul>
Who are you ? <ul><li>Developers ?
System/network engineers ?
Managers ?
Caching experience ? </li></ul>
Caching and tuning fun for high scalability Wim Godden Cu.be Solutions
Goals of this tutorial <ul><li>Everything about caching and tuning
A few techniques </li><ul><li>How-to
How-NOT-to </li></ul><li>-> Increase reliability, performance and scalability
5 visitors/day -> 5 million visitors/day
(Don't expect miracle cure !) </li></ul>
LAMP
Architecture
Our base benchmark <ul><li>Apachebench = useful enough
Result ? </li></ul>
Caching
What is caching ?
What is caching ? select * from article join user on article.user_id = user.id order by created desc limit 10
Theory of caching if ($data == false) DB
Theory of caching DB
Caching techniques <ul>#1 : Store entire pages #2 : Store part of a page (block) #3 : Store data retrieval (SQL ?) #4 : St...
Modification frequency ?
Retrieval frequency ? </li></ul>
How to find cacheable data <ul><li>New projects : start from 'cache everything'
Existing projects : </li><ul><li>Look at MySQL slow query log
Make a complete query log (don't forget to turn it off !)
Check page loading times </li></ul></ul>
Caching storage - MySQL query cache <ul><li>Use it
Don't rely on it
Bad if you have : </li><ul><li>lots of insert/update/delete
lots of different queries </li></ul></ul>
Caching storage - Disk <ul><li>Data with few updates : good
Caching SQL queries : preferably not
DON'T  use NFS or other network file systems </li><ul><li>especially for sessions
locking issues !
high latency </li></ul></ul>
Caching storage - Disk / ramdisk <ul><li>Local </li><ul><li>5 Webservers -> 5 local caches
-> Hard to scale
How will you keep them synchronized ? </li><ul><li>-> Don't say NFS or rsync ! </li></ul></ul></ul>
Caching storage - Memcache <ul><li>Facebook, Twitter, Slashdot, … -> need we say more ?
Distributed memory caching system
Multiple machines ↔ 1 big memory-based hash-table
Key-value storage system </li><ul><li>Keys - max. 250bytes
Values - max. 1Mbyte </li></ul></ul>
Caching storage - Memcache <ul><li>Facebook, Twitter, Slashdot, … -> need we say more ?
Distributed memory caching system
Multiple machines ↔ 1 big memory-based hash-table
Key-value storage system </li><ul><li>Keys - max. 250bytes
Values - max. 1Mbyte </li></ul><li>Extremely fast... non-blocking, UDP (!) </li></ul>
Memcache - where to install
Memcache - where to install
Memcache - installation & running it <ul><li>Installation </li><ul><li>Distribution package
PECL
Windows : binaries </li></ul><li>Running </li><ul><li>No config-files
memcached -d -m <mem> -l <ip> -p <port>
ex. : memcached -d -m 2048 -l 172.16.1.91 -p 11211 </li></ul></ul>
Caching storage - Memcache - some notes <ul><li>Not fault-tolerant </li><ul><li>It's a cache !
Lose session data
Lose shopping cart data
... </li></ul></ul>
Caching storage - Memcache - some notes <ul><li>Not fault-tolerant </li><ul><li>It's a cache !
Lose session data
Lose shopping cart data
… </li></ul><li>Firewall your Memcache port ! </li></ul>
Memcache in code <?php $memcache =  new  Memcache(); $memcache->addServer( '172.16.0.1' , 11211); $memcache->addServer( '1...
Where's the data ? <ul><li>Memcache client decides (!)
2 hashing algorithms : </li><ul><li>Traditional </li><ul><li>Server failure -> all data must be rehashed </li></ul><li>Con...
Benchmark with Memcache
Memcache slabs <ul>(or why Memcache says it's full when it's not) <li>Multiple slabs of different sizes : </li><ul><li>Sla...
Slab 2 : 480 bytes (400 * 1.2)
Slab 3 : 576 bytes (480 * 1.2) (and so on...) </li></ul><li>Multiplier (1.2 here) can be configured
Store a lot of very large objects
-> Large slabs : full
-> Rest : free
-> Eviction of data ! </li></ul>
Upcoming SlideShare
Loading in...5
×

Caching and tuning fun for high scalability @ PHPTour

1,698

Published on

Caching has been a 'hot' topic for a few years. But caching takes more than merely taking data and putting it in a cache : the right caching techniques can improve performance and reduce load significantly. But we'll also look at some major pitfalls, showing that caching the wrong way can bring down your site. If you're looking for a clear explanation about various caching techniques and tools like Memcached, Nginx and Varnish, as well as ways to deploy them in an efficient way, this talk is for you. In this tutorial, we'll start from a Zend Framework based site. We'll add caching, begin to add servers and replace the standard LAMP stack, all while performing live benchmarks.

Published in: Technology
0 Comments
2 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
1,698
On Slideshare
0
From Embeds
0
Number of Embeds
2
Actions
Shares
0
Downloads
0
Comments
0
Likes
2
Embeds 0
No embeds

No notes for slide

Caching and tuning fun for high scalability @ PHPTour

  1. 1. Caching and tuning fun for high scalability Wim Godden Cu.be Solutions
  2. 2. Who am I ? <ul><li>Wim Godden (@wimgtr)
  3. 3. Owner of Cu.be Solutions (http://cu.be)
  4. 4. PHP developer since 1997
  5. 5. Developer of OpenX
  6. 6. Zend Certified Engineer
  7. 7. Zend Framework Certified Engineer
  8. 8. MySQL Certified Developer </li></ul>
  9. 9. Who are you ? <ul><li>Developers ?
  10. 10. System/network engineers ?
  11. 11. Managers ?
  12. 12. Caching experience ? </li></ul>
  13. 13. Caching and tuning fun for high scalability Wim Godden Cu.be Solutions
  14. 14. Goals of this tutorial <ul><li>Everything about caching and tuning
  15. 15. A few techniques </li><ul><li>How-to
  16. 16. How-NOT-to </li></ul><li>-> Increase reliability, performance and scalability
  17. 17. 5 visitors/day -> 5 million visitors/day
  18. 18. (Don't expect miracle cure !) </li></ul>
  19. 19. LAMP
  20. 20. Architecture
  21. 21. Our base benchmark <ul><li>Apachebench = useful enough
  22. 22. Result ? </li></ul>
  23. 23. Caching
  24. 24. What is caching ?
  25. 25. What is caching ? select * from article join user on article.user_id = user.id order by created desc limit 10
  26. 26. Theory of caching if ($data == false) DB
  27. 27. Theory of caching DB
  28. 28. Caching techniques <ul>#1 : Store entire pages #2 : Store part of a page (block) #3 : Store data retrieval (SQL ?) #4 : Store complex processing result #? : Your call ! </ul><ul>When you have data, think : <li>Creating time ?
  29. 29. Modification frequency ?
  30. 30. Retrieval frequency ? </li></ul>
  31. 31. How to find cacheable data <ul><li>New projects : start from 'cache everything'
  32. 32. Existing projects : </li><ul><li>Look at MySQL slow query log
  33. 33. Make a complete query log (don't forget to turn it off !)
  34. 34. Check page loading times </li></ul></ul>
  35. 35. Caching storage - MySQL query cache <ul><li>Use it
  36. 36. Don't rely on it
  37. 37. Bad if you have : </li><ul><li>lots of insert/update/delete
  38. 38. lots of different queries </li></ul></ul>
  39. 39. Caching storage - Disk <ul><li>Data with few updates : good
  40. 40. Caching SQL queries : preferably not
  41. 41. DON'T use NFS or other network file systems </li><ul><li>especially for sessions
  42. 42. locking issues !
  43. 43. high latency </li></ul></ul>
  44. 44. Caching storage - Disk / ramdisk <ul><li>Local </li><ul><li>5 Webservers -> 5 local caches
  45. 45. -> Hard to scale
  46. 46. How will you keep them synchronized ? </li><ul><li>-> Don't say NFS or rsync ! </li></ul></ul></ul>
  47. 47. Caching storage - Memcache <ul><li>Facebook, Twitter, Slashdot, … -> need we say more ?
  48. 48. Distributed memory caching system
  49. 49. Multiple machines ↔ 1 big memory-based hash-table
  50. 50. Key-value storage system </li><ul><li>Keys - max. 250bytes
  51. 51. Values - max. 1Mbyte </li></ul></ul>
  52. 52. Caching storage - Memcache <ul><li>Facebook, Twitter, Slashdot, … -> need we say more ?
  53. 53. Distributed memory caching system
  54. 54. Multiple machines ↔ 1 big memory-based hash-table
  55. 55. Key-value storage system </li><ul><li>Keys - max. 250bytes
  56. 56. Values - max. 1Mbyte </li></ul><li>Extremely fast... non-blocking, UDP (!) </li></ul>
  57. 57. Memcache - where to install
  58. 58. Memcache - where to install
  59. 59. Memcache - installation & running it <ul><li>Installation </li><ul><li>Distribution package
  60. 60. PECL
  61. 61. Windows : binaries </li></ul><li>Running </li><ul><li>No config-files
  62. 62. memcached -d -m <mem> -l <ip> -p <port>
  63. 63. ex. : memcached -d -m 2048 -l 172.16.1.91 -p 11211 </li></ul></ul>
  64. 64. Caching storage - Memcache - some notes <ul><li>Not fault-tolerant </li><ul><li>It's a cache !
  65. 65. Lose session data
  66. 66. Lose shopping cart data
  67. 67. ... </li></ul></ul>
  68. 68. Caching storage - Memcache - some notes <ul><li>Not fault-tolerant </li><ul><li>It's a cache !
  69. 69. Lose session data
  70. 70. Lose shopping cart data
  71. 71. … </li></ul><li>Firewall your Memcache port ! </li></ul>
  72. 72. Memcache in code <?php $memcache = new Memcache(); $memcache->addServer( '172.16.0.1' , 11211); $memcache->addServer( '172.16.0.2' , 11211); $myData = $memcache->get( 'myKey' ); if ($myData === false ) { $myData = GetMyDataFromDB(); // Put it in Memcache as 'myKey', without compression, with no expiration $memcache->set( 'myKey' , $myData, false , 0); } echo $myData;
  73. 73. Where's the data ? <ul><li>Memcache client decides (!)
  74. 74. 2 hashing algorithms : </li><ul><li>Traditional </li><ul><li>Server failure -> all data must be rehashed </li></ul><li>Consistent </li><ul><li>Server failure -> 1/x of data must be rehashed (x = # of servers) </li></ul></ul></ul>
  75. 75. Benchmark with Memcache
  76. 76. Memcache slabs <ul>(or why Memcache says it's full when it's not) <li>Multiple slabs of different sizes : </li><ul><li>Slab 1 : 400 bytes
  77. 77. Slab 2 : 480 bytes (400 * 1.2)
  78. 78. Slab 3 : 576 bytes (480 * 1.2) (and so on...) </li></ul><li>Multiplier (1.2 here) can be configured
  79. 79. Store a lot of very large objects
  80. 80. -> Large slabs : full
  81. 81. -> Rest : free
  82. 82. -> Eviction of data ! </li></ul>
  83. 83. Memcache - Is it working ? <ul><li>Connect to it using telnet </li><ul><li>&quot;stats&quot; command ->
  84. 84. Use Cacti or other monitoring tools </li></ul></ul>STAT pid 2941 STAT uptime 10878 STAT time 1296074240 STAT version 1.4.5 STAT pointer_size 64 STAT rusage_user 20.089945 STAT rusage_system 58.499106 STAT curr_connections 16 STAT total_connections 276950 STAT connection_structures 96 STAT cmd_get 276931 STAT cmd_set 584148 STAT cmd_flush 0 STAT get_hits 211106 STAT get_misses 65825 STAT delete_misses 101 STAT delete_hits 276829 STAT incr_misses 0 STAT incr_hits 0 STAT decr_misses 0 STAT decr_hits 0 STAT cas_misses 0 STAT cas_hits 0 STAT cas_badval 0 STAT auth_cmds 0 STAT auth_errors 0 STAT bytes_read 613193860 STAT bytes_written 553991373 STAT limit_maxbytes 268435456 STAT accepting_conns 1 STAT listen_disabled_num 0 STAT threads 4 STAT conn_yields 0 STAT bytes 20418140 STAT curr_items 65826 STAT total_items 553856 STAT evictions 0 STAT reclaimed 0
  85. 85. Memcache - backing up
  86. 86. Memcache - tip <ul>Page with multiple blocks ? -> use Memcached::getMulti() Warning : what if you get some hits and some misses ? </ul>
  87. 87. Updating data
  88. 88. Updating data LCD_Popular_Product_List
  89. 89. Adding/updating data $memcache->delete( 'LCD_Popular_Product_List' );
  90. 90. Adding/updating data
  91. 91. Adding/updating data - Why it crashed
  92. 92. Adding/updating data - Why it crashed
  93. 93. Adding/updating data - Why it crashed
  94. 94. Cache stampeding
  95. 95. Cache stampeding
  96. 96. Memcache code ? DB
  97. 97. Cache warmup scripts <ul><li>Used to fill your cache when it's empty
  98. 98. Run it before starting Webserver !
  99. 99. 2 ways : </li><ul><li>Visit all URLs </li><ul><li>Error-prone
  100. 100. Hard to maintain </li></ul><li>Call all cache-updating methods </li></ul><li>Make sure you have a warmup script ! </li></ul>
  101. 101. Cache stampeding - what about locking ? <ul>Seems like a nice idea, but... <li>While lock in place
  102. 102. What if the process that created the lock fails ? </li></ul>
  103. 103. LAMP... <ul>-> LAMMP -> LNMMP </ul>
  104. 104. Nginx <ul><li>Web server
  105. 105. Reverse proxy
  106. 106. Lightweight, fast
  107. 107. 8.3% of all Websites </li></ul>
  108. 108. Nginx <ul><li>No threads, event-driven
  109. 109. Uses epoll / kqueue
  110. 110. Low memory footprint
  111. 111. 10000 active connections = normal </li></ul>
  112. 112. Nginx - a true alternative to Apache ? <ul><li>Not all Apache modules </li><ul><li>mod_auth_*
  113. 113. mod_dav*
  114. 114. … </li></ul><li>Basic modules are available
  115. 115. Some 3 rd party modules (needs recompilation !) </li></ul>
  116. 116. Nginx - Configuration server { listen 80; server_name www.domain.ext *.domain.ext; index index.html; root /home/domain.ext/www; } server { listen 80; server_name photo.domain.ext; index index.html; root /home/domain.ext/photo; }
  117. 117. Nginx + PHP-FPM - performance ?
  118. 118. Reverse proxy time...
  119. 119. Varnish <ul><li>Not just a load balancer
  120. 120. Reverse proxy cache / http accelerator / …
  121. 121. Caches (parts of) pages in memory
  122. 122. Careful : </li><ul><li>uses threads (like Apache)
  123. 123. Nginx usually scales better (but doesn't have VCL) </li></ul></ul>
  124. 124. Varnish - backends + load balancing backend server1 { .host = &quot;192.168.0.10&quot;; } backend server2{ .host = &quot;192.168.0.11&quot;; } director example_director round-robin { { .backend = server1; } { .backend = server2; } }
  125. 125. Varnish - VCL <ul><li>Varnish Configuration Language
  126. 126. DSL (Domain Specific Language) </li><ul><li>-> compiled to C </li></ul><li>Hooks into each request
  127. 127. Defines : </li><ul><li>Backends (web servers)
  128. 128. ACLs
  129. 129. Load balancing strategy </li></ul><li>Can be reloaded while running </li></ul>
  130. 130. Varnish - whatever you want <ul><li>Real-time statistics (varnishtop, varnishhist, ...)
  131. 131. ESI </li></ul>
  132. 132. Varnish - ESI <ul>Perfect for caching pages </ul>In your article page output : <esi:include src=&quot;/news&quot;/> In your Varnish config : sub vcl_fetch { if (req.url == &quot;/news&quot;) { esi; /* Do ESI processing */ set obj.ttl = 2m; } elseif (req.url == &quot;/nav&quot;) { esi; set obj.ttl = 1m; } elseif …. … . }
  133. 133. Varnish with ESI - hold on tight !
  134. 134. Varnish - what can/can't be cached ? <ul><li>Can : </li><ul><li>Static pages
  135. 135. Images, js, css
  136. 136. Pages or parts of pages that don't change often (ESI) </li></ul><li>Can't : </li><ul><li>POST requests
  137. 137. Very large files (it's not a file server !)
  138. 138. Requests with Set-Cookie
  139. 139. User-specific content </li></ul></ul>
  140. 140. ESI -> no caching on user-specific content ? Logged in as : Wim Godden 5 messages TTL = 5min TTL=1h TTL = 0s ?
  141. 141. Under development <ul><li>Release date </li><ul><li>Beta : Dec 2011
  142. 142. Stable : Feb 2012 </li></ul></ul>
  143. 143. Tuning
  144. 144. PHP speed - some tips <ul><li>Upgrade PHP - every minor release has 5-15% speed gain !
  145. 145. Use an opcode cache </li></ul>
  146. 146. Caching storage - Opcode caching
  147. 147. PHP speed - some tips <ul><li>Upgrade PHP - every minor release has 5-15% speed gain !
  148. 148. Use an opcode cache
  149. 149. Profile your code </li><ul><li>XHProf
  150. 150. Xdebug </li></ul></ul>
  151. 151. KCachegrind is your friend
  152. 152. PHP speed - some tips <ul><li>Upgrade PHP - every minor release has 5-15% speed gain !
  153. 153. Use an opcode cache
  154. 154. Profile your code </li><ul><li>XHProf
  155. 155. Xdebug </li></ul><li>But : turn off profilers on production platforms ! </li></ul>
  156. 156. DB speed - some tips <ul><li>Use same types for joins </li><ul><li>i.e. don't join decimal with int </li></ul><li>RAND() is evil !
  157. 157. count(*) is evil in InnoDB without a where clause ! </li><ul><li>(and there are other examples of specific things to avoid) </li></ul><li>Persistent connect is not always good ! </li></ul>
  158. 158. Caching & Tuning @ frontend http://www.websiteoptimization.com/speed/tweak/average-web-page/
  159. 159. Frontend tuning <ul>1. You optimize backend 2. Frontend engineers messes up -> havoc on backend 3. Don't forget : frontend sends requests to backend ! SO... <li>Care about frontend
  160. 160. Test frontend
  161. 161. Check what requests frontend sends to backend </li></ul>
  162. 162. Tuning frontend <ul><li>Minimize requests </li><ul><li>Combine CSS/JavaScript files </li></ul></ul>
  163. 163. Tuning frontend <ul><li>Minimize requests </li><ul><li>Combine CSS/JavaScript files
  164. 164. Use CSS Sprites </li></ul></ul>
  165. 165. CSS Sprites
  166. 166. Tuning content - CSS sprites
  167. 167. Tuning content - CSS sprites 11 images 11 HTTP requests 24KByte 1 image 1 HTTP requests 14KByte
  168. 168. Tuning frontend <ul><li>Minimize requests </li><ul><li>Combine CSS/JavaScript files
  169. 169. Use CSS Sprites (horizontally if possible) </li></ul><li>Put CSS at top
  170. 170. Put JavaScript at bottom </li><ul><li>Max. no connections
  171. 171. Especially if JavaScript does Ajax (advertising-scripts, …) ! </li></ul><li>Avoid iFrames </li><ul><li>Again : max no. of connections </li></ul><li>Don't scale images in HTML
  172. 172. Have a favicon.ico (don't 404 it !) </li><ul><li>-> see my blog </li></ul></ul>
  173. 173. What else can kill your site ? <ul><li>Redirect loops </li><ul><li>Multiple requests </li><ul><li>More load on Webserver
  174. 174. More PHP to process </li></ul><li>Additional latency for visitor
  175. 175. Try to avoid redirects anyway
  176. 176. -> In ZF : use $this->_forward instead of $this->_redirect </li></ul><li>Watch your logs, but equally important...
  177. 177. Watch the logging process ->
  178. 178. Logging = disk I/O -> can kill your server !
  179. 179. Slashdot effect </li></ul>
  180. 180. Above all else... be prepared ! <ul><li>Have a monitoring system
  181. 181. Use a cache abstraction layer (disk -> Memcache)
  182. 182. Don't install for the worst -> prepare for the worst
  183. 183. Have a test-setup
  184. 184. Have fallbacks </li><ul><li>-> Turn off non-critical functionality </li></ul></ul>
  185. 185. <ul>Questions ? </ul>
  186. 186. <ul>Questions ? </ul>
  187. 187. Contact <ul><li>Twitter @wimgtr
  188. 188. Web http://techblog.wimgodden.be
  189. 189. Slides http://www.slideshare.net/wimg
  190. 190. E-mail [email_address]
  191. 191. Please...
  192. 192. Rate my talk : http://joind.in/4361 </li></ul>
  193. 193. <ul>Thanks ! </ul><ul>Please... Rate my talk : http://joind.in/4361 </ul>

×
