HTML5 and CSS3: Exploring   Mobile Possibilities
CSS Media Queries
width                 colorheight                color-indexdevice-width          monochromedevice-height         resoluti...
min-widthmax-widthorientation
<link rel="stylesheet"  href="pretty.css"  media="screen and (min-width: 500px)">
.nav {    width: 150px;}@media screen and (min-width: 500px) {    .nav {        width: 300px;    }}
@media screen and (min-width: 500px) and (max-width: 1024px) {    .nav {        width: 200px;    }}
@media screen and (min-width: 100px),@media handheld {    .nav {        width: 350px;    }}
@media only screen and (min-width: 100px) {    .nav {        width: 350px;    }}
@media not screen and (min-width: 100px) {    .nav {        width: 100%;    }}
@media screen and (orientation: landscape) {    .nav {        float: left;        width: 20%;    }    .main {        float...
@media screen and (orientation: portrait) {    .nav {        width: 100%;    }    .main {        width: 100%;    }}
<meta name="viewport"  content="width=device-width, maximum-scale=1.0">
CSS3 Media Queries and creating adaptive layouts
http://mediaqueri.es/
CSS Flex Box
<div class="flex-container">    <section class="col-1">I am column 1</section>    <section class="col-2">I am column 2</se...
.flex-container {    display: -moz-box;    display: -ms-box;    display: -webkit-box;    display: box;    -moz-box-orient:...
.col-1 {    -moz-box-flex: 1;    -ms-box-flex: 1;    -webkit-box-flex: 1;    box-flex: 1;}.col-2 {    -moz-box-flex: 1;   ...
.col-1 {    -moz-box-ordinal-group: 2;    -ms-box-ordinal-group: 2;    -webkit-box-ordinal-group: 2;    box-ordinal-group:...
flex- instead of box-
CSS Transitions
/* Shorthand version */#hello {    display: inline-block;    height: 20px;    opacity: 0.3;    -moz-transition: height 1s ...
/* Shorthand version */.menu-item {    position: relative;    display: inline-block;    border: 1px dashed #000;    paddin...
.love-me {    -webkit-transform: translate3d(0, 0, 0);}
CSS Animations
.animation-container {    height: 60px;    padding: 10px;    -moz-animation-name: movearound;    -moz-animation-duration: ...
@-webkit-keyframes movearound {    from {         width: 200px;         background: #f00;         opacity: 0.5;         -w...
CSS box-shadow and text-shadow
text-overflow: ellipsis
HTML5 Forms
New form types<input type="color">             <input type="range"><input type="date">              <input type="search"  ...
New form attributes<input type="text" autocomplete="off"><input type="text" autofocus><input type="submit" formaction="htt...
<input type="text" list="data-list"><input type="range" max="95"><input type="range" min="2"><input type="file" multiple><...
New form elements<input type="text" list="data-list"><datalist id="data-list">    <option value="Hugo Reyes">    <option v...
<keygen></keygen><meter min="0" max="10" value="7"></meter><input type="range" id="range"><output for="range" id="output">...
<input type="range" id="range"><output for="range" id="output"></output><script>    (function () {         var theForm = d...
http://www.quirksmode.org/html5/inputs.htmlhttp://www.quirksmode.org/html5/inputs_mobile.htmlhttp://wufoo.com/html5/
Link protocols
<a href="tel:+441111234567">tel: link</a><a href="sms:+441111234567">sms: link</a><a href="sms:+441111234567?body=Text%20m...
#browserlove
Web Storage
sessionStorage.setItem("Charming", "Piers Morgan");console.log(sessionStorage.getItem("Charming"));
localStorage.setItem("Job", "Show host");
var piersMorgan = {    "Transportation" : "Segway",    "Damage" : "Three broken ribs"};localStorage.setItem("piersMorgan",...
Web SQL   IndexedDB
Geolocation
if (navigator.geolocation) {    navigator.geolocation.getCurrentPosition(function (position) {        alert(position.coord...
Offline Web Applications
// Poll the navigator.onLine propertysetInterval(function () {    console.log(navigator.onLine);}, 1000);
<!DOCTYPE html><html manifest="offline.appcache"><head>...
CACHE MANIFEST# VERSION 10CACHE:offline.htmlbase.cssFALLBACK:online.css offline.cssNETWORK:/live-updates
History API
var url = "http://robertnyman.com",title = "My blog",state = {    address : url};window.history.pushState(state, title, ur...
window.history.replaceState(state, title, url);
Mobile Perf
weinre
position: fixedoverflow: scroll-webkit-overflow-scrolling: touchWeb Workers
Robert Nymanrobertnyman.com/speaking/ robnyman@mozilla.comrobertnyman.com/html5/    Twitter: @robertnymanrobertnyman.com/c...
