Theres a Rabbit                          on my Symfony                            RabbitMQ and Symfony2 Integration       ...
Who?Thursday, March 3, 2011
About Me                    •     Development Manager at TheNetCircle.com                    •     Blog: http://videlalvar...
About Me                    •     Developer at Liip                    •     Blog: http://videlalvaro.github.com/         ...
About Me                          Co-authoring               RabbitMQ in Action              http://bit.ly/rabbitmqThursda...
Why Do I need                           RabbitMQ?Thursday, March 3, 2011
OrThursday, March 3, 2011
Why Do I need                           Messaging?Thursday, March 3, 2011
An Upload Picture                           Form as seen by:Thursday, March 3, 2011
The UserThursday, March 3, 2011
I don’t want to wait                          till your app resizes                                my image!Thursday, Marc...
The Product OwnerThursday, March 3, 2011
Can we also notify the                    user friends when she                    uploads a new image?Thursday, March 3, ...
Can we also notify the                    user friends when she                    uploads a new image?       I forgot to ...
The SysadminThursday, March 3, 2011
Dumb! You’re delivering                    full size images!                 The bandwidth bill has                       ...
Dumb! You’re delivering                    full size images!                 The bandwidth bill has                       ...
The Developer in the                              other teamThursday, March 3, 2011
I need to call your PHP                   stuff but from PythonThursday, March 3, 2011
I need to call your PHP                   stuff but from Python                          And also Java starting next weekT...
YouThursday, March 3, 2011
FML!Thursday, March 3, 2011
Is there a solution?Thursday, March 3, 2011
RabbitMQ & AMQPThursday, March 3, 2011
AMQPThursday, March 3, 2011
AMQP                    • Advanced Message Queuing Protocol                    • Suits Interoperability                   ...
AMQP Model                    • Exchanges                    • Message Queues                    • Bindings               ...
AMQP Wire Protocol                    • Functional Layer                    • Transport LayerThursday, March 3, 2011
Message Flow                  http://www.redhat.com/docs/en-US/Red_Hat_Enterprise_MRG/1.0/html/Messaging_Tutorial/chap-Mes...
Exchange Types                    • Fanout                    • Direct                    • TopicThursday, March 3, 2011
http://www.redhat.com/docs/en-US/Red_Hat_Enterprise_MRG/1.0/html/Messaging_Tutorial/sect-Messaging_Tutorial-Initial_Concep...
http://www.redhat.com/docs/en-US/Red_Hat_Enterprise_MRG/1.0/html/Messaging_Tutorial/sect-Messaging_Tutorial-Initial_Concep...
http://www.redhat.com/docs/en-US/Red_Hat_Enterprise_MRG/1.0/html/Messaging_Tutorial/sect-Messaging_Tutorial-Initial_Concep...
Usage ScenariosThursday, March 3, 2011
Usage Scenarios                    • Batch ProcessingThursday, March 3, 2011
Usage Scenarios                    • Batch Processing                    • Image UploadingThursday, March 3, 2011
Usage Scenarios                    • Batch Processing                    • Image Uploading                    • Distribute...
Scenario                          Batch ProcessingThursday, March 3, 2011
RequirementsThursday, March 3, 2011
Requirements                    • Generate XMLThursday, March 3, 2011
Requirements                    • Generate XML                    • Distribution Over a ClusterThursday, March 3, 2011
Requirements                    • Generate XML                    • Distribution Over a Cluster                    • Elast...
Requirements                    • Generate XML                    • Distribution Over a Cluster                    • Elast...
DesignThursday, March 3, 2011
Publisher Code                 $conn = new AMQPConnection(HOST, PORT, USER, PASS, VHOST);                 $channel = $conn...
Publisher Code                 $conn = new AMQPConnection(HOST, PORT, USER, PASS, VHOST);                 $channel = $conn...
Publisher Code                 $conn = new AMQPConnection(HOST, PORT, USER, PASS, VHOST);                 $channel = $conn...
Publisher Code                 $conn = new AMQPConnection(HOST, PORT, USER, PASS, VHOST);                 $channel = $conn...
Publisher Code                 $conn = new AMQPConnection(HOST, PORT, USER, PASS, VHOST);                 $channel = $conn...
Publisher Code                 $conn = new AMQPConnection(HOST, PORT, USER, PASS, VHOST);                 $channel = $conn...
Consumer Code                 $conn = new AMQPConnection(HOST, PORT, USER, PASS, VHOST);                 $channel = $conn-...
Consumer Code                 $conn = new AMQPConnection(HOST, PORT, USER, PASS, VHOST);                 $channel = $conn-...
Consumer Code                 $conn = new AMQPConnection(HOST, PORT, USER, PASS, VHOST);                 $channel = $conn-...
Consumer Code                 $conn = new AMQPConnection(HOST, PORT, USER, PASS, VHOST);                 $channel = $conn-...
Consumer Code                 $conn = new AMQPConnection(HOST, PORT, USER, PASS, VHOST);                 $channel = $conn-...
Consumer Code                 $conn = new AMQPConnection(HOST, PORT, USER, PASS, VHOST);                 $channel = $conn-...
Consumer Code                 $conn = new AMQPConnection(HOST, PORT, USER, PASS, VHOST);                 $channel = $conn-...
Scenario                          Upload PicturesThursday, March 3, 2011
RequirementsThursday, March 3, 2011
Requirements                    • Upload PictureThursday, March 3, 2011
Requirements                    • Upload Picture                    • Reward UserThursday, March 3, 2011
Requirements                    • Upload Picture                    • Reward User                    • Notify User Friends...
Requirements                    • Upload Picture                    • Reward User                    • Notify User Friends...
Requirements                    • Upload Picture                    • Reward User                    • Notify User Friends...
DesignThursday, March 3, 2011
DesignThursday, March 3, 2011
DesignThursday, March 3, 2011
Publisher Code                 $channel->exchange_declare(upload-pictures, fanout, false,                 true, false);   ...
Publisher Code                 $channel->exchange_declare(upload-pictures, fanout, false,                 true, false);   ...
Publisher Code                 $channel->exchange_declare(upload-pictures, fanout, false,                 true, false);   ...
Publisher Code                 $channel->exchange_declare(upload-pictures, fanout, false,                 true, false);   ...
Publisher Code                 $channel->exchange_declare(upload-pictures, fanout, false,                 true, false);   ...
Consumer Code                 $channel->exchange_declare(upload-pictures, fanout,                             false, true,...
Consumer Code                 $channel->exchange_declare(upload-pictures, fanout,                             false, true,...
Consumer Code                 $channel->exchange_declare(upload-pictures, fanout,                             false, true,...
Consumer Code                 $channel->exchange_declare(upload-pictures, fanout,                             false, true,...
Consumer Code                 $channel->exchange_declare(upload-pictures, fanout,                             false, true,...
Consumer Code                 $channel->exchange_declare(upload-pictures, fanout,                             false, true,...
Consumer Code                 $consumer = function($msg){                      $meta = json_decode($msg->body, true);     ...
Consumer Code                 $consumer = function($msg){                      $meta = json_decode($msg->body, true);     ...
Consumer Code                 $consumer = function($msg){                      $meta = json_decode($msg->body, true);     ...
Consumer Code                 $consumer = function($msg){                      $meta = json_decode($msg->body, true);     ...
Consumer Code                 $consumer = function($msg){                      $meta = json_decode($msg->body, true);     ...
Scenario                          Distributed LoggingThursday, March 3, 2011
RequirementsThursday, March 3, 2011
Requirements                    • Several Web ServersThursday, March 3, 2011
Requirements                    • Several Web Servers                    • Logic Separated by Module/ActionThursday, March...
Requirements                    • Several Web Servers                    • Logic Separated by Module/Action               ...
Requirements                    • Several Web Servers                    • Logic Separated by Module/Action               ...
Requirements                    • Several Web Servers                    • Logic Separated by Module/Action               ...
DesignThursday, March 3, 2011
DesignThursday, March 3, 2011
DesignThursday, March 3, 2011
DesignThursday, March 3, 2011
DesignThursday, March 3, 2011
Publisher Code                 $channel->exchange_declare(logs, topic, false,                               true, false); ...
Publisher Code                 $channel->exchange_declare(logs, topic, false,                               true, false); ...
Publisher Code                 $channel->exchange_declare(logs, topic, false,                               true, false); ...
Publisher Code                 $channel->exchange_declare(logs, topic, false,                               true, false); ...
Consumer Code                           Get messages sent by host:                                   server1Thursday, Marc...
Consumer Code                 $channel->exchange_declare(logs, topic, false,                               true, false);  ...
Consumer Code                 $channel->exchange_declare(logs, topic, false,                               true, false);  ...
Consumer Code                 $channel->exchange_declare(logs, topic, false,                               true, false);  ...
Consumer Code                 $channel->exchange_declare(logs, topic, false,                               true, false);  ...
Consumer Code                           Get all error messagesThursday, March 3, 2011
Consumer Code                 $channel->exchange_declare(logs, topic, false,                               true, false);  ...
Consumer Code                 $channel->exchange_declare(logs, topic, false,                               true, false);  ...
Consumer Code                 $channel->exchange_declare(logs, topic, false,                               true, false);  ...
Consumer Code                 $channel->exchange_declare(logs, topic, false,                               true, false);  ...
Symfony IntegrationThursday, March 3, 2011
RabbitMQ BundleThursday, March 3, 2011
RabbitMQ Bundle                                  Goal:                            To be easy to useThursday, March 3, 2011
RabbitMQ Bundle                                        Publish a Message:                          $msg = array(user_id =>...
RabbitMQ Bundle                             Consume a Message:           $ ./app/console_dev rabbitmq:consumer -m 1 upload...
RabbitMQ Bundle                            Consume 50 Messages:           $ ./app/console_dev rabbitmq:consumer -m 50 uplo...
RabbitMQ Bundle                           Consume infinite* Messages:           $ ./app/console_dev rabbitmq:consumer -m -1...
RabbitMQ Bundle                                 Configuration:           # app/config/config.yml           rabbitmq.config:...
RabbitMQ Bundle                                 Configuration:           # app/config/config.yml           rabbitmq.config:...
RabbitMQ Bundle                                Configuration:           # app/config/config.yml           rabbitmq.config: ...
RabbitMQ Bundle                                    Using a Producer:           public function indexAction($name)         ...
RabbitMQ Bundle                               Consumer Class:           class UploadPictureConsumer extends ContainerAware...
RabbitMQ Bundle                                Recap:Thursday, March 3, 2011
RabbitMQ Bundle                                              Recap:                • Add an entry for the consumer/produce...
RabbitMQ Bundle                                              Recap:                • Add an entry for the consumer/produce...
RabbitMQ Bundle                                              Recap:                • Add an entry for the consumer/produce...
RabbitMQ Bundle                                              Recap:                • Add an entry for the consumer/produce...
RabbitMQ Bundle                              There’s more:Thursday, March 3, 2011
RabbitMQ Bundle                                There’s more:                • RPC clients and serversThursday, March 3, 2011
RabbitMQ Bundle                                There’s more:                • RPC clients and servers                • Ano...
RabbitMQ Bundle                                There’s more:                • RPC clients and servers                • Ano...
RabbitMQ Bundle                                           Fork it at                          http://github.com/videlalvar...
Why RabbitMQ?Thursday, March 3, 2011
RabbitMQ                    • Enterprise Messaging System                    • Open Source MPL                    • Writte...
Features                    • Reliable and High Scalable                    • Easy To install                    • Easy To...
Client Libraries                    • Java                    • .NET/C#                    • Erlang                    • R...
Docs/Support                    •     http://www.rabbitmq.com/documentation.html                    •     http://dev.rabbi...
One Setup for HAThursday, March 3, 2011
ConclusionThursday, March 3, 2011
Conclusion                    • FlexibilityThursday, March 3, 2011
Conclusion                    • Flexibility                    • ScalabilityThursday, March 3, 2011
Conclusion                    • Flexibility                    • Scalability                    • InteroperabilityThursday...
Conclusion                    • Flexibility                    • Scalability                    • Interoperability        ...
Questions?Thursday, March 3, 2011
Thanks!                                   Álvaro Videla                             http://twitter.com/old_sound          ...
