Node JS was built on Google's JavaScript V8 Engine and it was engineered to preform optimally for the web. Learn what Node JS's single thread event loop is and how it empowers Node to out preform its competitors.

1. Node JS
Understanding the Single Thread Event Loop
Rares Crisan
Lead Educator , BrainStation

2. About the Speaker
Rares Crisan
Rares Crisan is an experienced developer that has worked with many startup's in Toronto's growing
tech community. He also has a degree in Computer Science from Queen's and studied biomedical
engineering at UBC before completing a law degree at the UBC Peter A Allard Faculty of Law. Rares
like to merge an academic understanding of technology with the real world applications of it.

3. f
How Servers Work
What We’ll Cover
What is a thread and what is the
difference between a single thread
event loop and multithreading.
Multi Threading vrs
Single Thread
Performance
Gains and Costs
Understanding how server’s handle
large volumes of user requests and
why Node was created to solve this
problem
Node was design to optimally preform
as a web server, however, this does not
make Node suitable for every type of
application.

4. Web servers preform a very narrow range
of operations. For most servers, the slowest
operations are I/O events.
Servers.

5. The Web Server
The Web Server
There are many types of servers and they have many different roles in facilitating communication and data transfer. The first HTTP
web server was developed by Tim Berners-Lee in 1989 at CERN for the purpose of posting and sharing scientific information.Web
servers preform many similar operations responding to user data and page requests. A web servers functions may have not vastly
differentiated since its creation, but the volume of requests have increased considerably.

6. Server I/O
Server I/O
At their core, web servers are simply handling a large stream of short input requests and small output payloads. They do not need to
process complex algorithms or return large volumes of data. Improving the performance of a web server requires increasing the
frequency at which inputs can be processed and outputs can be returned
Some examples of I/O functions are:
Reading/Writing to file.
Database lookups
External Api Requests

7. A thread of execution is the smallest sequence of
programmed instructions that can be managed
independently by a scheduler
Threads.

8. Blocking I/O
Blocking I/O
Whenever a process needs to run some operations the instructions are broken down into threads. Threads are short instruction sets
that are run on the CPU. Schedulers are programs built into an OS that prioritize which threads are run and which resources they
require in order to run. Whenever a thread is running and using up a resources the CPU is blocked from handling any more threads
until the thread completes its execution and is switched off the CPU. During this time no other threads can be run on the CPU.

9. Multithreading
Multithreading
Multithreading is a technique used to split up threads across multiple cores of a CPU so that when one core becomes available the
next available thread in the queue is executed. The output generated by the thread is sent back to the process and then sent back to
wherever the data needs to go. This can speed up thread execution by reducing the amount of time any one core is blocked.
However, on a quad core computer, the most amount of threads that can be processed at a single time is four.

10. Single Thread Event Loop
The Single Thread Event Loop
Because web servers are designed to handle short, quick, and similar types of request, Node was built to serve those exact needs. It
is equivalent to the idea of pouring a coffee at a coffee shop; it does not take long to pour a single cup of coffee but it can take a long
time to clear a queue if 1000 people show up asking for coffee at once.
Time is lost processing requests when the CPU has to switch from one thread to another; referred to as context switching. The role
of an OS scheduler is to prioritize and move threads on and off the CPU. Node’s event loop relies on the asynchronous features of
JavaScript and utilizes callbacks so the next set of instructions and be added to the single thread after a response is returned from
a worker thread executing the original instructions. Thus, the Node is able to reduce time lost due to context switching.

11. Multithreading vrs Single

12. Node Architecture
Node Architecture
T
Node is built upon a multitude of other technologies, languages,
and design paradigms. The reason that Node libraries are built in
JavaScript is because Google’s V8 engine supports
asynchronous JavaScript code. Asynchronous code allows for
callback functions to be stored until needed, Thus, node can
continuously accept inputs and once a response returns, the
callback function can be retrieved from memory and placed on
the call stack to be executed. Ultimately, node is an event-driven
system, which is exactly how the JavaScript language works.
Node Still utilizes OS threads to run tasks such as file I/O or
database queries, however these threads are not part of the
single thread event loop. The completion of these worker threads
are what trigger the callback functions for a particular event

13. Node Architecture
Node Architecture
T

14. Node is designed to preform optimally with small
requests, but it’s design can come at a cost.
Performance.

15. Speed
Speed
T
From the graphs below you can see that Node is able to outperform .NET and PHP, but this trend also extends to
outperforming Rails, Django, and Nginx, for HTTP requests. Node’s speed even allows it to preform well when
handling real time updates of content via sockets.
*Note: The tests below are not perfect but they help give some visual guidelines on Node’s Performance
Source: http://www.salmanq.com/blog/net-and-node-js-performance-comparison/2013/03/ Source: http://www.kogonuso.com/2015/09/comparing-nodejs-vs-php-performance.html

16. Costs
Costs
T
Node’s biggest shortcoming is it’s inability to handle computationally intensive tasks. If an event running through the
event loop takes a large amount of time to execute (like a sorting a really large array), it will inevitably block the
event loop thread.
Another event that can make Node JS run extremely slow is running it on a server with a single core. If Node is
running on a single core, its single thread blocks other OS threads from operating on the CPU. One personal
example I have preformed was placing a PostGres Database on the same server as NodeJS and utilizing a single
core. Context switching is required to unload the Node Thread and load the DB query thread. The delay is
substantial to say the least.

17. Questions?

18. Thank you!
Follow @BrainStation and @rarescrisan on Twitter.
