This is a presentation I gave to a workshop I organized in UCD focused on Android. The talk is divided into two sections: - Android 101 - My experience trying to put together a facebook/foursquare/android mobile app -- I did not progress very far in this endeavour

1. Android Workshop UCD, 10th April 2010 #UCDDD

2. Objectives Android 101 Overview of the platform Some market information Development of Android based app Partial Walkthrough Two components: Server side Facebook, foursquare Mobile client Talks to server (or not!)

3. Android 101

4. Overview Background/history Android concepts Comments on APIs Comment on market

5. Background/History Android Inc developed vision for platform Acquired in 2005 by Google Launched November 2007 In conjunction with Open Handset Alliance Number of variants since 1.1, 1.5, 1.6, 2.0, 2.1 Google working with many handset manufacturers and operators HTC, Sony Ericsson, Motorola, LG

6. What is Android? Mobile Operating system Linux kernel v2.6.x Architecture for developing mobile applications Much work on developing concepts Mobile OS differs from desktop OS Large set of APIs Much functionality provided Dalvik VM Native Interface available late 09

7. Differences from THE OTHER ONE More open in general Although key parts kept closed No constraints on store… Except that they pay store is not available in Ire Technical Multitasking Until last Thurs Bluetooth Issues with multi-touch until recently

8. Perspective of App Developer Rich Java based framework Closer to Java SE than Java ME Good separation of UI and functionality Rapidly evolving platform Too fast in 09 Platform with rapidly growing user base Rapidly increasing number of apps Do not have Apple toll bridge Anything can be published

9. What does Android app look like Set of Java classes External jars need to be packaged Manifest describing application XML based descriptors of UI Typically Packaged into apk file For distribution in market and more generally Can be signed

10. Components Application comprised of different components Android defines 4 types of components Activities Services Broadcast receivers Content providers Somehow notion of main not always necessary When writing a service, for example

11. Activity Idea is somehow single action user is engaged in Part of a task Examples Choosing people from list of contact Entering some text Navigating around a map Application can comprise of one or more activities Typically more One activity initiates next activity

12. Activity Activities linked to views (somewhat) Android facilitates views which are decoupled Defined in XML and bundled with package Activity generally renders a specific view View designed for specific activity

13. Services Like daemons Run for some period of time providing service for activities Fetch network data or perform calculation Music playback Service runs in main thread Can initiate other threads if needed Can bind to running service

14. Broadcast receivers and Content Providers Broadcast receivers Listen for broadcast messages Time change, language change Do not have UI, but may engage with user Notification mechanism Can start activty Content Provider Enables an application to share its own data with another application

15. Definition of the application – manifest.xml Every application has file defining components Lists activities, services, etc Example: <?xml version="1.0" encoding="utf-8"?> <manifest . . . > <application . . . > <activity android:name="com.example.project.FreneticActivity" android:icon="@drawable/small_pic.png" android:label="@string/freneticLabel" . . . > </activity> . . . </application> </manifest>

16. Intents More complex (subtle?) notion Application can be invoked with different intents Eg from windows – file dragged onto app Behaviour of application depends on intent ACTION_CALL, ACTION_MAIN, ACTION_SYNC ACTION_MAIN most commonly used Manifest indicates which activity initiated on ACTION_MAIN

17. Tasks Activities from multiple applications can be combined into tasks Applications can be aware of activities extant in other applications Can invoke them with certain intent Typically such activities in a ‘suite’ A stack which retains user’s sequence of activities This is how user perceives application Note: application now ambiguous/overloaded

18. So what about processes? Lots of flexibility Activities, components, receivers and providers can be in single process Can be split quite arbitrarily over different processes Defined in manifest All process run as uid of application All components run in a single main thread of application Blocking! Need to ensure longer term tasks run in new thread

19. Lifecycles - Activity Three states for activity Active or running Visible in foreground on screen Paused Still visible, but not main focus When notification window open Stopped Not visible, retaining state More likely to be terminated

20. Activity Lifecycle – state changes Transitions void onCreate(Bundle savedInstanceState) void onStart() void onRestart() void onResume() void onPause() void onStop() void onDestroy()

21. Processes and lifecycles Android tends to use available resources Keeps things alive when in doubt Processes have one of 5 states: Foreground, visible, service, background, empty Process’s state may be linked to another process Service tied to foreground process When resources run low, lowest priority processes removed

22. Android APIs Mix of APIs from different sources Apache http libs, standard java se libs, xml, jsonlibs Android-specific APIs Phone APIs Telephony, contacts, location, bluetooth/wifi Interface APIs Gesture, speech Graphics Widgets, webkit, opengl

23. Android in the marketplace Android activity intense right now Over 50 devices in production or development Phones, tablets, e-readers, etc Sales of 60k units per day Adds up to 22m per annum iPhone sold 25m in 09 App store rocketing Apps doubled in Q110

24. Building an Android App

25. Building an Android App Overview What the (intended) app looked like Backend How this was realized Mobile client How this was implemented

26. Building an Android App Overview

27. Planned app… Integrate information from Facebook and Foursquare Facebook intended to provide rich network of relationships Foursquare to provide location aspects Idea Application targetted at group of people on weekend away Hen/Stag party obvious example

28. Intended workflow On the web… User goes to (stand alone) website Selects friends going on weekend away Facebook info Maps Facebook friends to Foursquare friends Somehow (?) Party going on tour stored in DB Both FB and FS uids stored …and over to mobile…

29. Intended workflow Users download mobile app Used for duration of visit App can be used to Check in Check in on FS View group history Upload photos Make comments for group Provide for richer group experience

30. Building an Android app Backend

31. Issues with development of backend Used Django framework Rapid development Used facebook and foursquare libraries for development Python/django libraries exist for both Multiple python facebook libraries exist Chose FB connect as main approach to talk to FB Django supports Oauthauthentiation based on this

32. Issues with development of backend FB Connect libraries were a little limiting Very premised on notion that friends (of interest) are only those subscribed to site Common way to use FB Connect I wanted to extract all friends of given user Had to use some of the more conventional FB capabilities More focused on apps in FB Raised question of whether app should be housed in FB in first place

33. Issues with development of backend Significant issue with mapping of FB users to FS users Although my friends on FS do have FB links (I don’t) Can iterate through friends lists to find matches Email remainder to sign up for FS Did not get this complete

34. Issues with development of backend Foursquare API is still basic Underestimated maturity of this as platform Thought I could get friends history To show how people moved during the weekend FS API only allows access to last place friend was observed My backend needed to keep check ins also To show fuller picture of weekend Python FS API v simple to use

35. Issues with development of backend Got basic capabilities working Authentication via FB Select list of FB friends going on weekend Get FS id of those who have simple mapping of FB to FS id In their FS profile Did not get important parts working Mobile API Photo support Poor design decisions when constructing DB

36. Building an Android App Mobile client

37. Android development Short overview of tools Very important Describe a little about how a simple Android app works Issues I had with FB, FS integration

38. Android – getting up and running Android SDK Base tools common to all versions of platform Emulator framework cmd line tools to deploy apps on device IDE – Eclipse preferred ADT plug in Provides Android libraries, hooks into emulator, deployment, etc Android Platform versions Install in SDK

39. Basic tools Main tool adb – flexible tool to enable host to talk to device Used to install package on device Put file on device Shell into device Show device logs – these include application error traces Other tools ddms – tool for connecting to on device process to debug apkbuilder – tool to generate android package (apk) Apk files used in market Can also be used to sign Tools for db management, libraries, etc

40. Eclipse plug-in ADT is Eclipse plug-in for Android development Can be installed directly from online resource Features include: Knowledge of Android libraries Suggestions for completion of names/methods Reasonable support for layout of views Drag and drop elements onto canvas Good support for manipulation of manifest Debugging support

41. External jars Possible to add external jars to application Often v useful for talking to network services Eg foursquare in this case Issue with jar for shipping app Jar must be included in package Unless it is known (how?) jar is available on device Addition of external jars straightforward in Eclipse

42. A basic activity Class MyActivity extends Activity implements xxxListenersxxx { private EditTextusernameText = null ; private EditTextpasswordText = null ; Private Button button = null ; @Override public void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.main); button = (Button)findViewById(R.id.Button01); button.setOnClickListener(this); } public void onClick(View v) { …. } }

43. Basic activity: reacting to event public void onClick(View v) { // do something when the button is clicked // put the values in username and password into some // strings edittext1 = (EditText)findViewById(R.id.EditText01); edittext2 = (EditText)findViewById(R.id.EditText02); String username = edittext1.getText().toString(); String password = edittext2.getText().toString(); }

44. Moving on to next activity Approach is straightforward Create an intent and tell Android Some code: Intent myIntent = new Intent(); myIntent.setClassName("com.android.samples", "com.android.samples.Animation1"); myIntent.putExtra("com.android.samples.SpecialValue", "Hello, Joe!"); // key/value pair, where key needs current package prefix. StartActivity(myIntent); Platform does manifest lookup to determine what to do

45. When new activity instigated… Can receive information from previous activity Transfer mechanism somewhat invisible Activity class has getIntent() method Used to determine how activity was called Some code: @Override public void onCreate(Bundle icicle) { super.onCreate(icicle); Integer category = this.getIntent().getIntExtra("category", -1);

46. More generally…moving data around Simple data can be transferred between activities using Bundles Android.app.Application can be extended Incorporating global application state Public/static fields/methods A bit clunky Persistent storage: Application preferences, files, sqlite DB

47. Issues with maps and keys MapView API requires keys for use Keys linked to developer and to application Unique key for each application For development phase… Android generates certificate for signing application automatically Not tied to certificate authority Submit hash of this certificate to obtain working key For release… Generate public/private key and use these to create certificate

48. Progress Did not really get through facebook and foursquare functions on device Foursquare api looks simple, easy to use on android Library exists for this Facebook connect for android project is work in progress Did not look at this

49. The 49thparallell Some upcoming activities UCD/EPITA Android Hackathon 14-16 April Startup Weekend – NDRC 7-9 May Opportunities day Invited Talk: ‘Mobile @ Google’ Dave Burke, Engineering Manager, Google 14 May

50. Q&A
