2. 2
CONFIDENTIAL March 17 2004
2
Thyroid hormones regulate biochemical
processes essential to growth and
development including:
Energy production from carbohydrate
Cardiovascular function
Nervous system reactivity
Digestive rate
Thyroid
3. 3
CONFIDENTIAL March 17 2004
3
Thyroid Status
Euthyroidism - hormone production
and release is normal
Hypothyroidism - hormone production
and release is abnormally low
Hyperthyroidism - hormone production
and release is abnormally high
4. 4
CONFIDENTIAL March 17 2004
4
Prevalence of Thyroid Disease
USA distribution
Hypothyroidism - common
– 2 - 15% of population
Hyperthyroidism - rare
– 0.3 - 0.6% of population
Distribution outside USA
Variable
5. 5
CONFIDENTIAL March 17 2004
5
Primary thyroid disease
The defect is with the thyroid gland itself
Secondary thyroid disease
The defect is with the pituitary gland
Tertiary thyroid disease
The defect is with the hypothalamus
Thyroid Disease
7. 7
CONFIDENTIAL March 17 2004
7
Additional thyroid disorders with gland
involvement only, having little effect on
hormone production
Goiter (enlargement)
Thyroid cancer
Thyroiditis (inflammation)
Thyroid Disease
8. 8
CONFIDENTIAL March 17 2004
8
98% of thyroid disease in the US is
hypothyroidism
Most are female
Most are primary
Most cases involve autoimmunity
This may be due to an abnormality in:
Hypothalamus
Pituitary gland
Thyroid gland
Hypothyroidism
9. 9
CONFIDENTIAL March 17 2004
9
Adults
Early symptoms
– Weakness, nervousness, cold intolerance, headache,
fatigue, heavy menstruation
Physical signs
– Thin brittle nails, thinning of hair, pale skin,
decreased reflexes
Late symptoms
– Slow speech, excessive weight gain, constipation,
absence of sweating, limb swelling, hoarseness,
difficulty breathing, chest pain, deafness, absence of
menstruation
Hypothyroidism
11. 11
CONFIDENTIAL March 17 2004
11
Hyperthyroidism
May be due to:
Graves’ disease
– Autoantibodies against components or regions of
the thyroid plasma membrane, possibly including
the receptor for TSH leading, after a complex
series of events, to hypersecretion of hormone
Toxic goiter
Excessive intake of thyroid hormones
Thyroiditis
TSH-producing pituitary tumors
12. 12
CONFIDENTIAL March 17 2004
12
Hyperthyroidism
Symptoms
Restlessness, nervousness, irritability,
fatigability
Unexplained weight loss despite a
ravenous appetite
Excessive sweating, intolerance of heat
Tremors
Difficulty focusing eyes
Diarrhea
Rapid and irregular heartbeat
13. 13
CONFIDENTIAL March 17 2004
13
Hyperthyroidism
Complications - serious
Heart failure
Severe wasting of muscles and bones
Eye damage
Psychosis
“Thyroid storm”
– Fever, heart failure, delirium
– Death ~2% of cases
14. 14
CONFIDENTIAL March 17 2004
14
Thyroid Hormone Production
Thyroid hormone synthesis is controlled
by the hypothalamus through a
hormone called TRH (thyroid releasing
hormone)
Thyroid
Pituitary
Hypothalamus
TRH
TSH
T3/T4
15. 15
CONFIDENTIAL March 17 2004
15
Thyroid/Pituitary Feedback Loop
Thyroid
Pituitary
Hypothalamus
TRH
TSH
T3/T4
Euthyroid Hypothyroid
TRH
TSH
T3/T4
Hyperthyroid
Low
High
TRH
TSH
T3/T4
Low
High
16. 16
CONFIDENTIAL March 17 2004
16
Access System Thyroid Assays
Hypersensitive TSH
Total T4
Free T4
Total T3
Free T3
Thyroid Uptake
Thyroglobulin*
Thyroglobulin
Antibody*
* Used as a Tumor Marker Assay
17. 17
CONFIDENTIAL March 17 2004
17
Thyroid Stimulating Hormone
TSH
Principal regulator of thyroid function
Released from the anterior pituitary
Glycoprotein hormone consisting of an
a and b chain
The b chain is responsible for the
immunological and biological specificity
18. 18
CONFIDENTIAL March 17 2004
18
TSH
TSH regulates the release of thyroid
hormones, thyroxine (T4) and
triiodothyronine (T3)
Thyrotropin-releasing hormone (TRH) from
the hypothalamus controls the secretion of
TSH from the pituitary
A negative feedback mechanism of the
hypothalamus monitors T3 and T4, adjusting
TRH secretion
19. 19
CONFIDENTIAL March 17 2004
19
TSH Assay Sensitivity
Analytical sensitivity
Lowest concentration that can be reliably
measured (detection limit)
– Determined as the dose on the curve which is 2 SD
from the RLU from the zero calibrator
Functional sensitivity
The concentration that can be measured all the
time, at less than or equal to 20% CV
20. 20
CONFIDENTIAL March 17 2004
20
TSH Assays
The first TSH assay was developed in
the 1950s
1st generation was developed in 1960
(detected hypo but not hyper)
2nd generation was developed in the
1980s using monoclonal antibodies
21. 21
CONFIDENTIAL March 17 2004
21
Definition of ‘Generation’
for TSH Assays
Generation limits
1st: functional sensitivity of 1.0 mIU/mL
2nd: functional sensitivity of 0.1 mIU/mL
3rd: functional sensitivity of 0.01 mIU/mL
3rd generation TSH has ~ a 10 fold
greater assay functional sensitivity than
second generation
22. 22
CONFIDENTIAL March 17 2004
22
TSH
Currently, the most effective measure of
thyroid activity is the hypersensitive 3rd
generation TSH assay
Can discriminate hyperthyroid from euthyroid
Less prone to interferences
Responsive to subtle changes in thyroid status
Very reliable, precise and consistent
throughout low end of measuring range
23. 23
CONFIDENTIAL March 17 2004
23
Suspect Hypothyroidism Suspect Hyperthyroidism
Elevated Normal Subnormal Undetectable
Free T4 and Diagnose Free T4 Free T4
Thyroid Antibody Panel*
Normal Elevated Subnormal Elevated
Diagnose Diagnose Diagnose
Evaluate
Diagnose
for Hypopituitarism
or Hypoadrenalism
Thyroid Diagnosis Using 3rd Generation Access HYPERsensitive TSH
Suspect Thyroid Disease*
24. 24
CONFIDENTIAL March 17 2004
24
Value of 3rd Gen in US Market
Challenge
Differentiation of subnormal vs.
nondetectable TSH not always top priority
Laboratories still using 2nd gen assay may
not see utility in reporting numeric values
<0.1
25. 25
CONFIDENTIAL March 17 2004
25
Value of 3rd Gen in US Market
Analytical performance at borderline
For 2nd gen assay, 0.1 is at lowest
detectable dose, where precision is poorest
For 3rd gen assay, 0.1 is in a robust
portion of curve with good precision, thus
providing better resolution for borderline
cases
BCI does not charge more for 3rd
generation
26. 26
CONFIDENTIAL March 17 2004
26
Thyroid Replacement Therapy
TSH is the most accurate indicator for
determination of the adequacy of
hormone replacement therapy
Thyroid hormone dosage should be
adjusted at similar time intervals until TSH
values are within the normal range
27. 27
CONFIDENTIAL March 17 2004
27
Thyroxine
Total T4
T4 is secreted from the thyroid gland
when stimulated by TSH
Total T4 is present in bound (99.97%)
and free (0.03%) forms
No intrinsic biological activity until
converted to T3
28. 28
CONFIDENTIAL March 17 2004
28
Total T4
Elevated levels
Graves’ disease
Hyperthyroidism
pregnancy
Decreased levels
Hypothyroid diseases
such as Hashimoto’s
thyroiditis
Alone, does not provide a diagnosis for
hyperthyroidism or hypothyroidism
29. 29
CONFIDENTIAL March 17 2004
29
Free T4
0.03% of T4 is not bound (Free T4)
Biologically active form of thyroxine
Decrease is diagnostic for hypothyroidism
Increase is diagnostic for hyperthyroidism
Normal range varies in pregnancy
Especially useful when levels of binding
proteins have influenced the Total T4
result
30. 30
CONFIDENTIAL March 17 2004
30
Triiodothyronine
Total T3
T3 has intrinsic biological activity
20% comes from thyroid gland
80% comes from de-iodination of T4
occurring in the cells
Total T3 is present in bound (99.6 -
99.8%) and free (0.2 - 0.4%) forms
31. 31
CONFIDENTIAL March 17 2004
31
Used to assess patients with
hyperthyroid appearance, normal FT4
and decreased TSH
The TSH negative feedback loop
responds more readily to T3 than to T4
Total T3
32. 32
CONFIDENTIAL March 17 2004
32
Total T3
Elevated levels
Graves’ disease
Hyperthyroidism
Pregnancy
T3 toxicosis
(selective T3
production)
Decreased levels
Hypothyroid states
such as Hashimoto’s
thyroiditis, neonatal
hypothyroiditis
Secondary
hypothyroid states
33. 33
CONFIDENTIAL March 17 2004
33
Free T3
0.2 - 0.4% of T3 is not bound (Free T3)
Major biologically active thyroid hormone
Decreased in hypothyroidism
Increased in hyperthyroidism
– 5% have only free T3 elevated
Especially useful when levels of binding
proteins have influenced the Total T3
result
34. 34
CONFIDENTIAL March 17 2004
34
Thyroid Uptake
Measures number of unbound sites on carrier
proteins, primarily Thyroid Binding Globulin
(TBG)
TU expressed as the % of the T4 added to the
reaction mixture which is bound
Used in FTI (free thyroxine index) calculation
Method of estimating free thyroid hormone prior
to availability of direct free hormone assays
36. 36
CONFIDENTIAL March 17 2004
36
Free Thyroxine Index
Method to estimate free thyroid hormone
(FT4) prior to development of direct free
hormone assays
FTI = T4 mg/dL x Thyroid Uptake %
Median of Reference Interval
Clinical significance
Increased in hyperthyroidism
Decreased in hypothyroidism
37. 37
CONFIDENTIAL March 17 2004
37
Thyroid Hormones - Summary
>99+% T3 and T4 in circulation is
bound
TBG (thyroid binding globulin)
Albumin
Pre-albumin
38. 38
CONFIDENTIAL March 17 2004
38
Thyroid Hormones - Summary
T3/T4 concentration and activity
T4 is 70 x higher in concentration than T3
T3 is 4 x more active than T4
T3 can be made from T4 by removing an
iodine molecule
Both are only active in their “free” form
– Less than 1% is free in the healthy state
– Concentration of free forms is diagnostic
39. 39
CONFIDENTIAL March 17 2004
39
Thyroid Testing
Purpose
Check overall
metabolic status
Differentiate
between different
types of thyroid
disease
Monitor/evaluate
therapy
TRH
TSH
T3/T4
40. 40
CONFIDENTIAL March 17 2004
40
Suspect Thyroid Disease
Hypothyroidism Hyperthyroidism
Thyroid Diagnosis Using Free T4 Estimate (T4 and Thyroid Uptake)
Subnormal Marginal Normal Normal Marginal Elevated
(Interferences?)
2nd Gen 2nd Gen 2nd Gen 2nd Gen
TSH TSH TSH Total T3 TSH
Normal Elevated Elevated Normal Normal Elevated Normal Subnormal
or borderline
Diagnose Diagnose Diagnose Diagnose Diagnose
FT4 FT4 TSH 3rd Gen TSH
and and or TRH &FT4
Auto ABs Auto ABs
Normal Subnormal Subnormal Normal
Diagnose Diagnose Diagnose Diagnose Diagnose
Evaluate
for Hypopituitarism
or Hypoadrenalism
41. 41
CONFIDENTIAL March 17 2004
41
Interpretation Difficulties
Results may be unreliable in the majority
of the candidate population
Pregnant women
Women on birth control
Individuals with nonthyroid illness
Individuals with malnutrition
Individuals with disalbuminemia
Persons with increased TBG
42. 42
CONFIDENTIAL March 17 2004
42
Interpretation Difficulties
Pituitary lag is major cause of apparent
clinical discrepancy
Development phase - TSH is sensitive, but
FT4 lags
Early treatment phase - FT4 is reliable, but
TSH lags by 6-8 weeks
Drug effects
Pregnancy/general health effects
43. 43
CONFIDENTIAL March 17 2004
43
Thyroid Hormones in Pregnancy
TSH and hCG have structural similarity
The a chains are similar to hCG (also FSH
and LH)
hCG rises to extremely high
levels during pregnancy
– 1 in 500 pregnant women experience TSH
receptor stimulation, causing a temporary, non-
autoimmune Graves disease, demonstrated by
decreased levels of TSH and high levels of free
T4 and free T3
TSH
hCG
44. 44
CONFIDENTIAL March 17 2004
44
When to Do Thyroid Testing in
Clinically Euthyroid Patients
Newborns
Goiter
History of chronic thyroiditis
History of radioiodine therapy
History of head and neck irradiation
Graves’ eye disease
Monitoring thyroid replacement/suppressive therapy
Atrial fibrillation or flutter
Prior history of thyroid medications
45. 45
CONFIDENTIAL March 17 2004
45
Other Circumstances When
Thyroid Testing May Be Appropriate
History of autoimmune disease
Personal history of non-thyroid autoimmune disease
(diabetes)
Familial history of thyroid or other autoimmune disease
Neonate of mother with history of autoimmune thyroid
disease
Personal history of depression
Unexplained major weight loss or gain
All patients over the age of 50
46. 46
CONFIDENTIAL March 17 2004
46
Testing ‘Well’ Patients
If the TSH level is normal, no further work-
up is needed, unless the patient becomes
symptomatic or suspicion for hypo is
strong
Medications do not affect TSH levels as
they do TT3 and TT4
If the TSH is high, it should be repeated
with a FT4 level
47. 47
CONFIDENTIAL March 17 2004
47
Testing ‘Well’ Patients
If only 1 test can be performed, TSH
would be best (for ambulatory well
patients)
Greater sensitivity for detecting thyroid
dysfunction
Patients with early thyroid failure or mild
hyperthyroidism often will have abnormal
TSH values with FT4 estimates in the normal
range
48. 48
CONFIDENTIAL March 17 2004
48
Suspect Thyroid Disease
It is recommended that patients
suspected of thyroid dysfunction on
clinical grounds have both FT4 and
TSH
If both the TSH and the FT4 are
normal thyroid disease is essentially
excluded
49. 49
CONFIDENTIAL March 17 2004
49
Hospitalized or NTI
(Non-Thyroidal Illness)
TSH levels may be transiently
abnormal in patients under the acute
stress of illness
FT4 may be a more reliable indicator
50. 50
CONFIDENTIAL March 17 2004
50
Pituitary Dysfunction
Due to Hypothalamic or Pituitary Disease
Normal TSH values, despite significant
reductions in FT4
These inappropriate TSH values are
presumably due to a reduction in TSH
bioactivity, frequently observed in such cases
A poor TSH response to TRH stimulation
testing will assist in confirmation of diagnosis
51. 51
CONFIDENTIAL March 17 2004
51
Want More Information?
Check out the
American
Thyroid
Association
web site
www.thyroid.org
