String-Matching Algorithms Advance algorithm

1. String-Matching Algorithms (UNIT-5)
1

2. 2
1. String Matching :
Let there is an array of text, T[1..n] of length ‘n’.
Let there is a pattern of text, P[1..m] of length ‘m’.
Let T and P are drawn from a finite alphabet .
Here P and T are called ‘Strings of Characters’.
Here, the pattern P occurs with shift s in text T,
if, 0 ≤ s ≤ n – m
and T[s+1..s+m] = P[1..m]
i.e., for 1 ≤ j ≤ m, T[s+j] = P[j]
If P occurs with shift s in T, it is a VALID SHIFT.
Other wise, we call INVALID SHIFT.

3. 3
The String-matching Problem is the problem of finding
all valid shifts with which a given pattern P occurs in a
given text T.
Ex-1 : Let text T : a b c a b a a b c a b a c
Let pattern P : a b a a
Find the number of valid shifts and ‘s’ values.
Answer : Only one Valid Shift. s = 3
The symbol * (read as ‘sigma-star’) is the set of all
finite-length strings formed using characters from
the alphabet .

4. 4
The zero-length string is called ‘Empty String’.
denoted by ‘ɛ’, also belongs to *.
The length of the string ‘x’ is denoted |x|.
The concatenation of two strings x and y, denoted xy
has length |x| + |y|.
A string ω is a prefix of a string x, denoted as ω ⊏ x,
if x = ω y for some string y ∊ *.
Here, note that if ω ⊏ x, then |w| ≤ |x|.
Similarly, a string ω is a suffix of a string x, denoted
as ω ⊐ x, if x = y ω for some string y ∊ *.
Here, note that if ω ⊐ x, then |w| ≤ |x|.

5. 5
Ex-2 : Let abcca is a string.
Here, ab ⊏ abcca and cca ⊐ abcca
Note-1: The empty string ɛ is both a suffix and
prefix of every string.
Note-2 : Both prefix and suffix are transitive
relations.
Lemma : Suppose that x, y, and z are strings
such that x ⊐ z and y ⊐ z.
Here, if |x| ≤ |y| then x ⊐ y.
if |x| ≥ |y| then y ⊐ x.
if |x| = |y| then x = y.

6. 6
2. The Naïve String-matching Algorithm :
This algorithm finds all valid shifts using a loop that
checks the condition P[1..m] = T[s+1..s+m] for each
of the n –m + 1 possible values of s.
NAÏVE-STRING-MATCHER(T,P)
1 n = T.length
2 m = P.length
3. for s = 0 to n – m
4. if P[1..m] = = T[s+1..s+m]
5 Print “Pattern occurs with shift s.”

7. 7
Ex-3 : Let T = acaabc & P = aab
Find the value of s.
Answer : The value of s = 2
Ex-4 : Let T = 000010001010001
P = 0001
Find the values of ‘s’.
Answer : The value of s = 1 & 5 & 11
Ex-5 : Let T = an and P = am
Answer : The values of s = 0 to n – m
i.e., s contains n – m + 1 values

8. 8
3. The Rabin-Karp Algorithm :
Let  = {0, 1, 2, … , 9}
Here each character is a decimal digit.
d = |  | = 10.
The string 31415 represents 31,415 in radix-d notation.
Let there is a text T[1..n].
Let there is a pattern P[1..m].
Let p denote the corresponding decimal value.
Let ts is the decimal value of the length –m substring
T[s+1..s+m], for s = 0,1,2,..n-m.
 ts = p iff T[s+1..s+m] = P[1..m]
 s is a valid shift iff ts = p

9. 9
Now, the value of p can be computed using
Horner’s rule as follows:
p = P[1..m] = P[1] P[2] P[3]…P[m]
So, p = P[m] + 10 (P[m-1] + 10 (P[m-2] + … +
10 (P[2] + 10 P[1])…)).
Similarly, one can compute t0 as follows :
t0 = T[m] + 10 (T[m-1] + 10 (T[m-2] + … +
10 (T[2] + 10 T[1])…)).
Here we can compute ts+1 from ts as follows :
ts+1 = 10 (ts – 10m-1 T[s+1 ]) + T[s+m+1].

10. 10
Let q is defined so that dq fits in one computer word
and the above recurrence equation can be written as :
ts+1 = (d (ts – T[s+1] h ) + T[s+m+1]) mod q.
Here, h  dm-1 (mod q)
i.e., h is the first digit in the m-digit text window.
Ex-6 : Let m = 5, ts = 31415
Let T[s+m+1] = 2
So, RHS = 10 (ts – 10m-1 T[s+1 ]) + T[s+m+1]
= 10 (31415 – 104 . 3) + 2 = 14150 + 2 = 14152

11. 11
The test ts  p (mod q) is a fast heuristic
test to rule out invalid shifts s.
For any value of ‘s’,
if ts  p (mod q) is TRUE
and P[1..m] = T[s+1..s+m] is FALSE
then ‘s’ is called SPURIOUS HIT.
Note : a) If ts  p (mod q) is TRUE
then ts = p may be TRUE
b) If ts  p (mod q) is FALSE
then ts ≠ p is definitely TRUE

12. 12
RABIN-KARP-MATCHER (T,P,d,q)
1 n = T.length
2 m = P.length
3 h = dm-1 (mod q)
4 p = 0
5 t0 = 0
6 for i = 1 to m // preprocessing
7 p = (dp + P[i]) mod q
8 t0 = (d t0 + T[i]) mod q
9 for s = 0 to n-m //matching
10 if (p = = ts )
11 if (P[1..m] = T[s+1..s+m])
12 print “Pattern occurs with shift” s
13 if (s < n – m)
14 ts+1 = (d (ts – T[s+1] h ) + T[s+m+1]) mod q.

13. 13
Ex-7 : Let T = 2 3 5 9 0 2 3 1 4 1 5 2 6 7 3 9 9 2 1
Let P = 3 1 4 1 5
Here n = 19 m = 5 d = 10
q = 13 h = 3
p = 0 t0 = 0
First for statement :
i = 1 : p = 3 t0 = 2
i = 2 : p = 5 t0 = 10
i = 3 : p = 2 t0 = 1
i = 4 : p = 8 t0 = 6
i = 5 : p = 7 t0 = 8

14. 14
Second for statement :
s p ts T p = = ts s < n – m ts+1
0 7 8 23590 FALSE TRUE 9
1 7 9 35902 FALSE TRUE 3
2 7 3 59023 FALSE TRUE 11
3 7 11 90231 FALSE TRUE 0
4 7 0 02314 FALSE TRUE 1
5 7 1 23141 FALSE TRUE 7
6 7 7 31415 TRUE S = 6 TRUE VM 8
7 7 8 14152 FALSE TRUE 4
8 7 4 41526 FALSE TRUE 5

15. 15
s p ts T p = = ts s < n – m ts+1
9 7 5 15267 FALSE TRUE 10
10 7 10 52673 FALSE TRUE 11
11 7 11 26739 FALSE TRUE 7
12 7 7 67399 TRUE S = 12 TRUE SH 9
13 7 9 73992 FALSE TRUE 11
14 7 11 39921 FALSE FALSE ---
Hence, there is only ONE VALID MATCH at s = 6
there is only ONE SPURIOUS HIT at s = 12

16. 16
4. The Knuth-Morris-Pratt Algorithm :
This algorithm is meant for ‘Pattern Matching’.
Here, the prefix function  for a pattern
encapsulates knowledge about how the pattern
matches against shifts of itself.
Ex-8 : Let the Text String T & Pattern P is :
T : 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
b a c b a b a b a c a c a c a
P : 1 2 3 4 5 6 7
a b a b a c a

17. 17
COMPUTE-PREFIX-FUNCTION (P) :
1. m = P.length
2. Let [1..m] be a new array
3. [1] = 0
4. k = 0
5. for q = 2 to m
6. while k > 0 and P[k+1]  P[q]
7. k = [k]
8. if P[k+1] = = P[q]
9. k = k + 1
10. [q] = k
11. return 

18. 18
Ex-8 (contd…)
P : 1 2 3 4 5 6 7
a b a b a c a
INIT : m = 7 [1] = 0 k = 0
Step : q = 2 :
Here, k = 0 & P[k+1] = a & P[q] = b
So, while : FALSE & if : FALSE
Hence, [2] = 0
Step : q = 3 :
Here, k = 0 & P[k+1] = a & P[q] = a
So, while : FALSE & if : TRUE k = 1
Hence, [3] = 1

19. 19
Step : q = 4 :
Here, k = 1 & P[k+1] = b & P[q] = b
So, while : FALSE & if : TRUE k = 2
Hence, [4] = 2
Step : q = 5 :
Here, k = 2 & P[k+1] = a & P[q] = a
So, while : FALSE & if : TRUE k = 3
Hence, [5] = 3
Step : q = 6 :
Here, k = 3 & P[k+1] = b & P[q] = c
So, while : TRUE  k = 1 ( = [3] )
& k = 1 & P[k+1] = b & P[q] = c
while : TRUE  k = 0 ( = [1] )
if : FALSE ([P[1] = = P[6])
Hence, [6] = 0

20. 20
Step : q = 7 :
Here, k = 0 & P[k+1] = a & P[q] = a
So, while : FALSE &
if : TRUE (P[1] = = P[7] )
k = 1
Hence, [7] = 1
Hence the  array is as follows :
q : 1 2 3 4 5 6 7
 : 0 0 1 2 3 0 1
Hence, this returns the value : 1

21. 21
KMP-MATCHER (T,P) :
1. n = T.length
2. m = P.length
3.  = COMPUTE-PREFIX-FUNCTION(P)
4. q = 0
5. for i = 1 to n
6. while q > 0 and P[q+1]  T[i]
7. q =  [q]
8. if P[q+1] = = T[i]
9. q = q + 1
10. if q = = m
11. print ”Pattern occurs with shift” i - m
12. q =  [q]

22. 22
Ex-8 contd..
KMP-Matcher (T,P) :
INIT : n = 15 m = 7  =1 q = 0
----------------------------------------------------------------------------------------
i q C1 C2 wh q=  [q] if q++ if print q=  [q]
-------------------------------------------------------------------
1 0 F T F --- F ---- F ---- ----
2 0 F F F --- T q = 1 F ---- ----
3 1 T T T q = 0 F ---- F ---- ----
4 0 F T F --- F ---- F ---- ----
5 0 F F F --- T q = 1 F ---- ----

23. 23
-----------------------------------------------------------------------------------------------
i q C1 C2 wh q=  [q] if q++ if print q=  [q]
-----------------------------------------------------------------------------------------------
6 1 T F F --- T q=2 F ---- ----
7 2 T F F --- T q=3 F ---- ----
8 3 T F F --- T q=4 F ---- ----
9 4 T F F --- T q=5 F ---- ----
10 5 T F F --- T q=6 F ---- ----
11 6 T F F --- T q=7 F shift 4 q=1
12 1 T T T q=0 F ---- F ---- ----
13 0 F F F ---- T q=1 F ---- ----
14 1 T T T q=0 F ---- F ---- ----
15 0 F F F ---- T q=1 F ---- ----
-----------------------------------------------------------------------------------------------
