This document provides information about EXCEPTIONAL Metals' metal roofing and wall panel products. It describes several standing seam metal roof systems including EM LokSeam, EM SuperLok, EM BattenLok HS, EM Ultra-Dek, and EM Double-Lok. It also describes the eco-FICIENT insulated metal roof and wall panel series, which provide insulation and energy efficiency. The document explains that EXCEPTIONAL Metals offers a full menu of metal products and accessories to balance performance and aesthetics for commercial and architectural applications.

1. Metal Roofing &Wall Panels
Engineered for lasting performance. Designed for outstanding aesthetics.

2. EXCEPTIONAL roofs
requireEXCEPTIONAL
details. Attention to detail means everything. At
EXCEPTIONAL®
Metals, we provide a
full menu of metal roofing products that
save time during installation, add striking
visual details and provide a secure fit for
unsurpassed protection, durability and
efficiency.

3. Contents
Standing Seam Metal Roof Systems 4-5
eco-FICIENT®
Series 6-9
Roof Panels 10-11
Wall Systems and Soffit Panels 12-14
Colors 15
Solutions that
deliver performance.
In the pages that follow, you can learn more about
the full menu of EXCEPTIONAL Metals products and
accessories, including our new eco-FICIENT®
Insulated
Series for commercial applications that require
outstanding R-Values. When it comes to metal roofing
designs and challenges, EXCEPTIONAL Metals offers
a wide range of unique products and accessories that
balance performance and aesthetics.
Relationships that
work for you.
As a division of Duro-Last®
, Inc. and partner of
MBCI, the industry-leading manufacturer of metal
roof and wall systems, EXCEPTIONAL Metals is
backed by relationships that work for customers.
Together, EXCEPTIONAL Metals and MBCI offer
metal roofing and wall panel systems that are
both aesthetically pleasing and structurally sound.
EXCEPTIONAL Metals and MBCI have more than
50 years of combined experience in manufacturing
industry-leading metal roofing products. And,
both companies have a nationwide presence and
contractor network to serve customers across
the United States.

4. 4
Standing Seam Metal Roof Systems
EXCEPTIONAL Metals offers vertical leg structural standing seam metal roof systems that blend
the aesthetics of an architectural panel with the strength of a structural panel. These panels have
earned multiple UL uplift ratings, which assure reliable performance. And, our roofing systems offer
versatility to solve even the most complex design challenges.
We also offer trapezoidal standing seam roof profiles, which are designed for strength, durability and
weatherability. These systems can be installed before or after the exterior walls are in place.
EM LokSeam®
is a snap-together, standing seam roof system that is ideal for roofs
with a minimum slope of 3:12. These panels can be installed over open framing
or a solid substructure and are capable of transitioning from roof to fascia with the
use of a rib cover. EM LokSeam does not require a solid substructure for support.
EM SuperLok®
is a mechanically field-seamed, vertical leg standing seam roof
system that is designed to withstand the most rigorous weather conditions.
EM SuperLok can be installed directly over purlins or bar joists, and does not
require a solid substructure for support.
EM LokSeam®
EM SuperLok®
Features
• Application: Roof
• Coverage Widths: 12˝, 16˝, 18˝
• Minimum Slope: 3:12
• Panel Attachment: Concealed Fastening
System, Standard and UL 90 Clips
• Gauge: 24 (standard); 22 (12˝, 16˝, 18˝); 26
(12˝) (optional)
• Finishes: Smooth (standard) and
Embossed Striated (optional)
• Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300,
Signature®
300 Metallic
• UL 580 Approved
Features
• Application: Roof
• Coverage Widths: 12˝ and 16˝
• Minimum Slope: ½:12
• Panel Attachment: Concealed Fastening
System; Low, High (fixed or floating),
Utility (no insulation clearance)
• Gauge: 24 (standard); 22, 26 (optional)
• Finishes: Smooth Striated (standard) and
Embossed Striated (optional)
• Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300,
Signature®
300 Metallic
• UL 580 Approved
18"
1¾"

5. 5
EM BattenLok®
HS is a mechanically field-seamed, high-strength structural
standing seam roof system that offers excellent functionality in a wide array of
paint finishes. This system can be installed directly over purlins or bar joists, and is
capable of transitioning from roof to fascia. EM BattenLok HS does not require
a solid substructure for support.
EM Ultra-Dek®
is a snap-together, trapezoidal-leg standing seam roof system that
carries Air Leakage and Water Penetration testing approvals. EM Ultra-Dek requires
a minimum slope of ¼:12, and is ideal for industrial, commercial and architectural
applications. EM Ultra-Dek can be erected on various types of construction.
EM Double-Lok®
is a mechanically field-seamed, trapezoidal-leg standing seam
roof system that offers design flexibility for industrial, commercial and architectural
applications. When used in retrofit applications, these panels increase energy
efficiency and longevity of the structure. EM Double-Lok is UL 90 and FM rated
with Miami Dade County approvals.
EM BattenLok®
HS
EM Ultra-Dek®
EM Double-Lok®
Features
• Application: Roof
• Coverage Widths: 12˝ and 16˝
• Minimum Slope: ½:12
• Panel Attachment: Concealed Fastening
System; Low, High (fixed or floating),
Utility (no insulation clearance)
• Gauge: 24 (standard) and 22 (optional)
• Finishes: Smooth or Embossed,
with Striations or Striations and
Pencil Ribs (16˝ only)
• Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300,
Signature®
300 Metallic
• UL 580 Approved
Features
• Application: Roof
• Coverage Widths: 12˝,18˝, 24˝
• Minimum Slope: ¼:12
• Panel Attachment: Concealed Fastening
System; Low, High (fixed or floating)
• Gauge: 24 (standard); 22, 26 (optional)
• Finishes: Smooth (standard) and
Embossed (optional)
• Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300,
Signature®
300 Metallic
• UL 580 Approved
Features
• Application: Roof
• Coverage Widths: 12˝, 18˝, 24˝
• Minimum Slope: ¼:12
• Panel Attachment: Concealed Fastening
System; Low, High (sliding and a
2˝ stand-off clip)
• Gauge: 24 (standard); 22, 26 (optional)
• Finishes: Smooth (standard) and
Embossed (optional)
• Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300,
Signature®
300 Metallic
• UL 580 Approved
18"
18"
Trapezoidal Standing Seam Roof Systems
2"
16"
With Striations

6. 6
EM eco-FICIENT®
Series
The EM eco-FICIENT®
CFR roof panel is ideal for architectural, commercial,
industrial and institutional applications. The EM eco-FICIENT CFR exterior
profile has a two-inch high standing seam with a Mesa profile. The interior
profile has a stucco-embossed Mesa pattern. EM eco-FICIENT CFR is
attached to the building structure with concealed clips to provide continuous
insulation and eliminate thermal bridges, providing unsurpassed weathertight
performance. Due to precisely engineered design features, this roof system
requires very little field reworking and can be easily and quickly installed.
Weathertightness warranties are available.
EM eco-FICIENT®
CFR
Features
• Application: Roof
• Coverage Widths: 42˝ (standard);
30˝, 36˝ (optional)
• Minimum Slope: ½:12
• Panel Attachment: Concealed
Fastening System
• Exterior Gauge: 24 and 22
• Interior Gauge: 26, 24, 22
• Exterior Finish: Stucco-embossed
• Interior Finish: Stucco-embossed
• Exterior Coatings: Signature®
200
and Signature®
300
• Interior Coatings: Igloo White (standard);
Non-standard colors are also available
• Thicknesses: 2˝, 2 ½˝, 3˝, 4˝, 5˝, 6˝
• Lengths: Recommended maximum
is 50´ panel
• R-Value: Varies up to 8.5/inch of panel
thickness at 40°F mean temperature
• UL 580 Approved
eco-FICIENT®
Insulated Roof and Wall Panels
EXCEPTIONAL Metals has introduced the eco-FICIENT®
Series to meet customer needs for superior
insulating and weathertight performance. EM eco-FICIENT Series roof and wall panels provide
excellent insulating properties along with efficient assembly and easy installation for a wide variety
of interior and exterior building applications.
6

7. 7
The EM eco-FICIENT®
Insulated BattenLok®
roof panel is ideal for architectural,
commercial, industrial, institutional and cold storage applications. The EM eco-
FICIENT Insulated BattenLok exterior profile has a two-inch high standing seam
with a Mesa profile. The interior profile has a stucco-embossed Mesa pattern.
EM eco-FICIENT Insulated BattenLok is attached to the building structure with
concealed clips to provide continuous insulation and eliminate thermal bridges.
Weathertightness warranties are available.
EM eco-FICIENT®
Insulated R Panel is a versatile option for architectural,
agricultural, commercial and industrial applications. These insulated metal
panels allow for fast assembly times and easy installation with a through-
fastened attachment. The standard exterior skin is smooth but can be embossed
upon request. The interior skin of the EM eco-FICIENT Insulated R Panel is roll-
formed with a standard stucco-embossed Mesa profile.
EM eco-FICIENT®
Insulated BattenLok®
EM eco-FICIENT®
Insulated R Panel
Features
• Application: Roof
• Coverage Widths: 42˝ (standard);
30˝, 36˝ (optional)
• Minimum Slope: ½:12
• Panel Attachment: Concealed
Fastening System
• Exterior Gauge: 24 and 22
• Interior Gauge: 26, 24, 22
• Exterior Finishes: Stucco-embossed
and Mesa profile
• Interior Finishes: Stucco-embossed
and Mesa profile
• Exterior Coatings: Galvalume Plus®
,
Signature®
200 and Signature®
300
• Interior Coatings: Igloo White (standard)
• Thicknesses: 2˝, 2 ½˝, 3˝, 4˝, 5˝, 6˝
• Lengths: Recommended
maximum is 50'
• R-Value: Varies up to 8.5/inch of panel
thickness at 40°F mean temperature
• UL 580 Approved
Features
• Application: Roof and Wall
• Coverage Width: 36˝
• Minimum Slope: 1:12
• Panel Attachment: Exposed
Fastening System
• Exterior Gauge: 26, 24, 22
• Interior Gauge: 26, 24, 22
• Exterior Finishes: Smooth and Embossed
• Interior Finishes: Stucco-embossed
and Mesa profile
• Exterior Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300, Applied
Finishes (for wall applications only)
• Interior Coatings: Igloo White (standard);
Non-standard colors are also available
• Thicknesses: 1 ½˝, 2˝, 2 ½˝, 3˝,
4˝, 5˝, 6˝
• Lengths: Recommended
maximum is 50'
• R-Value: Varies up to 8.5/inch of panel
thickness at 40°F mean temperature
• Orientation: Vertical or Horizontal
7

8. 8
EM eco-FICIENT®
Classic offers traditional styling and distinct vertical lines with
a wide array of gauge and finish options for a customized design in commercial
and industrial applications. The EM eco-FICIENT Classic is ideal for cold storage
facilities. The exterior and interior skins have a stucco-embossed Mesa profile.
The EM eco-FICIENT®
Grand V insulated wall panel has a flat appearance and a
concealed fastening system for a uniform look that is an excellent choice for high-
profile, vertical architectural applications. The interior skin has a light Mesa profile.
EM eco-FICIENT Grand V can also be combined with EM eco-FICIENT vertical or
horizontal panels for design creativity and unique architectural aesthetics.
EM eco-FICIENT®
Classic
EM eco-FICIENT®
Grand V
Features
• Application: Wall
• Width: 42˝
• Panel Attachment: Concealed
Fastening System
• Exterior Gauge: 26 (standard);
24, 22 (optional)
• Interior Gauge: 26 (standard);
24, 22 (optional)
• Exterior Finish: Stucco-embossed
• Interior Finishes: Stucco-embossed
and Mesa profile
• Exterior Coatings: Signature®
200,
Signature®
300, Applied Finishes
• Interior Coatings: Igloo White (standard);
Non-standard colors are also available
• Thicknesses: 2˝, 2 ½˝, 3˝, 4˝, 5˝, 6˝
• Lengths: Recommended maximum is 50´
• R-Value: Varies up to 8.5/inch of panel
thickness at 40°F mean temperature
• Orientation: Vertical
Features
• Application: Wall
• Widths: 24˝, 30˝, 36˝
• Panel Attachment: Concealed
Fastening System
• Exterior Gauge: 22
• Interior Gauge: 26 (standard);
24, 22 (optional)
• Exterior Finish: Stucco-embossed
• Interior Finishes: Stucco-embossed
and light Mesa profile
• Exterior Coatings: Signature®
200,
Signature®
300, Applied Finishes
• Interior Coatings: Igloo White (standard);
Non-standard colors are also available
• Thicknesses: 2˝, 2 ½˝, 3˝, 4˝
• Lengths: Recommended maximum is 32´
• Reveal Options: 1/8˝ (standard),
¼˝, ½˝, ¾˝, 1˝, 1 ½˝, 2˝, 2 ½˝, 3˝
• R-Value: Varies up to 8.5/inch of panel
thickness at 40°F mean temperature
• Orientation: Vertical
eco-FICIENT®
Insulated Metal Wall Panels
EM eco-FICIENT®
Series CONTINUED

9. 9
The EM eco-FICIENT®
Royal panel is designed for exterior wall applications, interior
wall partitions and interior ceilings. The versatility of this panel allows for a uniform
appearance from outside to inside and from room to room in partition applications.
The EM eco-FICIENT Royal panel has an aesthetically pleasing relatively flat exterior
while the interior skin has a Mesa profile. This product is an excellent choice for
commercial applications and is also ideal for cold storage facilities.
The EM eco-FICIENT®
Summit wall panel features a stucco-embossed light Mesa
profile with a wide array of coating options. The exterior skin of EM eco-FICIENT
Summit is profiled with minor striations for a flat appearance and a linear look
while blending with the panel side joints. The EM eco-FICIENT Summit panel is
ideal for architectural, commercial, industrial and institutional applications.
The EM eco-FICIENT®
Insulated 7.2 Panel allows for shorter assembly times
and easy installation, resulting in reduced construction labor costs and faster
completions. This product can be used for both interior and exterior applications,
and can be installed both vertically and horizontally for the same design flexibility
that is available with our single skin 7.2 Panel. The 7.2 Panel is attached with a
concealed fastening system that eliminates thermal short circuits.
EM eco-FICIENT®
Royal
EM eco-FICIENT®
Summit
EM eco-FICIENT®
Insulated 7.2 Panel
Features
• Application: Wall
• Widths: 36˝and 42˝
• Panel Attachment: Concealed
Fastening System
• Exterior Gauge: 26 (standard);
24, 22 (optional)
• Interior Gauge: 26 (standard);
24, 22 (optional)
• Exterior Finishes: Stucco-embossed
and Mesa profile
• Interior Finishes: Stucco-embossed
and Mesa profile
• Exterior Coatings: Signature®
200,
Signature®
300, Applied Finishes
• Interior Coatings: Igloo White (standard);
Non-standard colors are also available
• Thicknesses: 2˝, 2 ½˝, 3˝, 4˝, 5˝, 6˝
• Lengths: Recommended maximum is 50'
• R-Value: Varies up to 8.5/inch of panel
thickness at 40°F mean temperature
• Orientation: Vertical
Features
• Application: Wall
• Widths: 36˝and 42˝
• Panel Attachment: Concealed
Fastening System
• Exterior Gauge: 24 and 22
• Interior Gauge: 26 (standard);
24, 22 (optional)
• Exterior Finish: Stucco-embossed
• Interior Finishes: Stucco-embossed
and light Mesa profile
• Exterior Coatings: Signature®
200,
Signature®
300, Applied Finishes
• Interior Coatings: Igloo White (standard);
Non-standard colors are also available
• Thicknesses: 2˝, 2 ½˝, 3˝, 4˝
• Lengths: Recommended maximum is 40´
• R-Value: Varies up to 8.5/inch of panel
thickness at 40°F mean temperature
• Orientation: Vertical or Horizontal
Features
• Application: Wall
• Width: 36˝
• Panel Attachment: Offset double
tongue-and-groove with Concealed
Fastening System
• Exterior Gauge: 26, 24, 22
• Interior Gauge: 26, 24, 22
• Exterior Finishes: Smooth and Embossed
• Interior Finish: Stucco-embossed and
Mesa profile
• Exterior Coatings: Signature®
200,
Signature®
300; Applied Finishes
• Interior Coatings: Igloo White (standard)
• Thicknesses: 2 ½˝, 3˝, 4˝, 5˝, 6˝
• Lengths: Recommended maximum is 36'
• R-Value: Refer to thermal chart in
MBCI’s technical manual
• Orientation: Vertical or Horizontal

10. 10
The EM Craftsman™ Batten series is a snap-on batten roof system
that offers excellent water-shedding performance. The EM Craftsman
series is available in narrow, wide and high profiles as small (SB),
large (LB) and high (HB) batten products. The pan and batten are
manufactured separately to maximize design flexibility and provide
easier installation for difficult hip, valley, and slope changes without
the need for flashing. This system can be used for roof and mansard
only when installed over a water-proofed solid substructure with
a minimum roof slope of 3:12. The EM Craftsman series uses a
concealed clip that locks the batten to the panel while allowing for
expansion and contraction.
EM Craftsman™
Small Batten, Large Batten and High Batten
Features
• Application: Roof
• Coverage Widths:
12˝ and 16 ½˝
• Minimum Slope: 3:12
• Panel Attachment:
Concealed Fastening
System
• Gauge: 24 (standard);
26, 22 (optional)
• Finishes: Smooth
(standard) and
Embossed (optional)
• Coatings: Galvalume
Plus®
, Signature®
200, Signature®
300,
Signature®
300 Metallic
• UL 580 Approved
Roof Panels
Concealed Fastening Roof Panels
Small Batten Large BattenHigh Batten
The EM Slimline®
roof panel system offers a sleek contemporary profile that is ideal
for residential applications.
EM Slimline®
Features
• Application: Roof
• Coverage Width: 16˝
• Minimum Slope: 3:12
• Panel Attachment: Concealed
Fastening System
• Gauge: 29 (standard) and 26 (optional)
• Finishes: Striations (standard) and
Minor Rib Striations (optional)
• Coatings: Galvalume Plus®
and Signature®
200
• UL 580 ApprovedMinor Ribs w/Striations
12”Small Batten
12”

11. 11
Exposed Fastener Panels
The EM 5V Crimp roof panel offers a traditional appearance that is ideal for
residential or light commercial applications. These panels require a solid roof deck
with a waterproof membrane.
The EM PBR panel is a structural, exposed fastener panel that can be used for both
roof and wall applications. This versatile panel system is used in a wide variety of
architectural, agricultural, commercial and industrial applications.
EM Retro-R®
Panel is an exposed fastening system that is an excellent choice for
retrofit construction. This panel can be applied directly over an existing PBR or
R Panel roof to provide a new look and longer life.
The EM 7.2 Panel is a versatile exposed fastener panel system that is ideal for
commercial or industrial applications. The EM 7.2 Panel has a symmetrical rib that
provides excellent spanning and cantilever capabilities, making it an excellent
choice for carports and walkway canopies.
EM 5V Crimp
EM PBR
EM Retro-R®
Panel
EM 7.2 Panel
Features
• Application: Roof
• Coverage Width: 24˝
• Minimum Slope: 3:12
• Panel Attachment: Exposed
Fastening System
• Gauge: 29 (standard) and 26 (optional)
• Finish: Smooth (standard)
• Coatings: Galvalume Plus®
and Signature®
200
• Rib Spacing: 12" on center
• Rib Height: ½˝
• UL 580 Approved
Features
• Application: Roof and Wall
• Coverage Width: 36˝
• Minimum Slope: ½:12
• Panel Attachment: Exposed
Fastening System
• Gauge: 26 (standard); 29, 24,
22 (optional)
• Finishes: Smooth (standard) and
Embossed (optional)
• Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300
• Rib Spacing: 12˝ on center
• Rib Height: 1¼˝
• UL 580 Approved
Features
• Application: Roof and Wall
• Coverage Width: 36˝
• Minimum Slope: ½:12
• Panel Attachment: Exposed
Fastening System
• Gauge: 29 (standard)
• Finish: Smooth (standard)
• Coatings: Galvalume Plus®
and Signature®
200
• Rib Spacing: 12" on center
• Rib Height: 11
/16"
Features
• Application: Roof and Wall
• Coverage Width: 36˝
• Minimum Slope: ½:12
• Panel Attachment: Exposed
Fastening System
• Gauge: 24 (standard); 29, 26,
22 (optional)
• Finishes: Smooth (standard) and
Embossed (optional)
• Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300,
Signature®
300 Metallic
• Rib Spacing: 7.2" on center
• Rib Height: 1 ½˝
• UL 580 Approved

12. 12
Wall Systems and Panels
Soffit and Interior Wall Panels
Exposed Fastening Wall Panels
The EM Artisan®
Series wall panels feature uniform dimensions for a clean
appearance that allows designers to plan modules and follow wall curvatures
while eliminating complicated pieces. These versatile panels can be installed to
meet building lines — vertical, horizontal, perpendicular or skewed — making
them ideal for soffits and interior liners. EM Artisan Series panels use the positive
fastened method and are attached directly to the substructure, with the fastener
concealed behind the flush face.
The EM AVP wall panel features pencil ribs for improved aesthetics and greater
design flexibility. The panel also allows more insulation to be added behind the
panel for greater insulating value to meet energy codes and R-Value requirements.
EM Artisan®
Series
EM AVP Panel
Features
• Application: Wall
• Coverage Widths: 8˝, 10˝, 12˝
• Panel Attachment: Concealed
Fastening System
• Gauge: 24 (standard); 26, 22 (optional)
• Finishes: Smooth (standard) and
Embossed (optional)
• Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300,
Signature®
300 Metallic
Features
• Application: Wall
• Coverage Width: 36˝
• Panel Attachment: Exposed
Fastening System
• Gauge: 26 (standard); 22,
24, 29 (optional)
• Finishes: Smooth (standard) and
Embossed (optional)
• Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300
• Rib Spacing: 12" on center
• Rib Height: 11
/8˝
L12

13. 13
Concealed Fastening Wall Systems
EM FW-120 is a heavy gauge wall system that is ideal for architectural, commercial
and industrial buildings, providing large spanning capabilities, particularly in
composite wall applications. EM FW-120 is available in three profiles: a flat profile,
a profile with one bead and a profile with two beads. The EM FW-120 panel has
been tested by a certified independent laboratory in accordance with ASTM test
procedures for Air Infiltration and Water Penetration at the sidelap. Test results show
no air leakage at 1.57PSF and no water penetration at 6.24PSF differential pressure.
EM FW-120
Features
• Application: Wall and Fascia
• Coverage Width: 12˝
• Panel Attachment: Concealed
Fastening System
• Gauge: 24 (standard); 22, 20 (optional)
• Finishes: Smooth (standard) and
Embossed (optional)
• Coating: Signature®
300
The EM MasterLine 16 is a concealed fastener metal wall panel that provides
an interesting shadow line for enhanced aesthetics. This panel is primarily
designed for horizontal applications, but it can also be installed vertically to give
a distinguished architectural design. The panels are available with factory applied
mastic in the side laps. Panels may be attached to metal studs, with or without
sheathing, as well as to subgirts.
EM MasterLine 16
Features
• Application: Wall
• Coverage Width: 16˝
• Panel Attachment: Concealed
Fastening System
• Gauge: 24 (standard); 22,
20, 18 (optional)
• Finishes: Smooth (standard) and
Embossed (optional – 24 and
22 gauge only)
• Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300,
Signature®
300 Metallic
The EM Designer Series™ 12.0 Flat panel is an excellent choice for designs that
require a smooth or flat wall or fascia in new construction or retrofitting applications.
The EM Designer Series 12.0 Flat panel can be installed both vertically and
horizontally, providing the toughness of metal while creating an attractive, flexible
and functional wall or fascia panel. The EM Designer Series 12.0 Flat panel offers a
1¾-inch deep leg, providing the perfect cavity for rigid board insulation. The panel
features concealed fastened systems enhancing the appearance. One leg of the
panel is attached to the structure using a concealed clip and the other leg snaps
securely into the adjoining panel to lock them into position.
EM Designer™
Series – Flat
Features
• Application: Wall
• Width: 12˝
• Panel Attachment: Concealed
Fastening System
• Gauge: 24 (standard) and 22 (optional)
• Finishes: Smooth (standard) and
Embossed (optional)
• Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300,
Signature®
300 Metallic
FW-120-2
with Beads
16˝
.875˝

14. 14
The EM Designer™
Series 16.0 Fluted panel offers a continuous rib design with a
hidden sidelap where the panels join together, making it an attractive and effective
option for new construction or retrofitting applications. Ribs are four inches wide
and 3
/8 inch deep, providing interesting shadow lines along the length of the wall.
The panel legs are 1¾-inch deep, allowing ample space for rigid board, blanket
or batt insulation in the cavity. The panel features a concealed fastening system
enhancing the appearance. One leg of the panel is attached to the structure using
a concealed clip and the other leg snaps securely into the adjoining panel to lock
them into position.
The EM ShadowRib™
is a 3-inch deep panel that combines aesthetics, economy
and function to bring definition to metal structures. With multiple panel
attachment and coating options, the EM ShadowRib is a versatile tool for
designers. Structural strength in the EM ShadowRib panel is accomplished without
sacrificing appearance or design flexibility. It can be applied over light-gauge
framing, purlins, girts, structural steel and joists. The EM ShadowRib panel may be
secured to the structure from the outside of the building with the EM ShadowRib
concealed clip, or from inside the building with an expansion fastener. Both are
positive fastened methods that create a secure interlock between panel and
structure. The fluted face creates distinctive shadow lines.
EM Designer™
Series – Fluted
EM ShadowRib™
Features
• Application: Wall
• Width: 16˝
• Panel Attachment: Concealed
Fastening System
• Gauge: 24 (standard) and 22 (optional)
• Finishes: Smooth (standard) and
Embossed (optional)
• Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300,
Signature®
300 Metallic
Features
• Application: Wall
• Width: 16˝ Inside
• Panel Attachments: Inside Panel
Attachment – Concealed Fastening
System; Outside Panel Attachment –
EM ShadowRib™
Panel Clip
• Gauge: 24 (standard) and 22 (optional)
• Finishes: Smooth (standard) and
Embossed (optional)
• Coatings: Galvalume Plus®
,
Signature®
200, Signature®
300,
Signature®
300 Metallic
Concealed Fastening Wall Systems CONTINUED
14

15. 15
Signature®
300 Standard Colors | Kynar 500®
Hylar 5000®
Low Gloss
This fluorocarbon paint system combines ceramic pigmentation with polyvinylidene fluoride (70% of resin solids) for a
superior, long-lasting finish. This proprietary resin technology provides outstanding performance and performance with
excellent color retention, film erosion rate and chemical resistance. Copper and silver metallic are also available.
Signature®
200 Standard Colors | Siliconized Polyester
Signature®
200 is a thermoset coating system composed of polyester resin modified by copolymerization with a functional
silicone resin intermediate. With high-quality ceramic pigmentation, Signature®
200 offers optimum exterior protection plus
superior resistance to chemical corrosion and ultraviolet radiation. Signature®
200 represents the most sophisticated silicone
polyester coating system in the industry. Additional colors are available upon request, see the full selection at
www.exceptionalmetals.com.
Colors and Finishes
EXCEPTIONAL Metals offers one of the largest color selections in the industry. Each of our paint
colors qualifies as a “Cool Roof” on slope roofs above 2:12. Our applied finishes work as an ex-
cellent alternative to masonry or tilt-wall construction. Colors shown represent the actual color as
closely as possible. To ensure exact color for final approval, metal color chips are available.
Almond Bone White Brite Red Brownstone Classic Green Colonial Red Everglade
Harbor Blue Hunter Green Medium Bronze Midnight Bronze Natural Patina Pacific Blue Slate Gray
Snow White Spruce Tundra
Burnished Slate Charcoal Gray Coal Black Fern Green Hawaiian Blue Koko Brown Light Stone
Polar White Rustic Red Solar White

16. EXCEPTIONAL®
Metals,
a division of Duro-Last®
, Inc.
525 Morley Dr.
Saginaw, MI 48601
800-248-0280
www.exceptionalmetals.com
“Duro-Last” and “EXCEPTIONAL” Metals are registered trademarks owned by Duro-Last, Inc.
“MBCI,” “LokSeam,” “SuperLok,” “BattenLok,” “Artisan,” “eco-FICIENT,”
“Double-Lok,” “Ultra-Dek,” “Slimline,” “Retro-R,” “and “Signature,”
are registered trademarks owned by NCI Group Inc.
“Kynar 500” is a registered trademark owned by Arkema Group.
“Hylar 5000” is a registered trademark owned by Solvay Group.
“Galvalume Plus” is a registered trademark owned by BIEC International Inc.
EXCEPTIONAL Metals by MBCI Standing Seam Booklet 3.7.16_v3 - EM020001
