Spring IO '15 - Developing microservices, Spring Boot or Grails?

Microservices
Grails or Spring Boot?
Fátima Casaú
@fatimacasau / {PARADIGMA TECNOLÓGICO

About me
Fátima Casaú Pérez / @fatimacasau
Software Engineer for over 7 years ago
Java Architect & Scrum Master in Paradigma
Tecnológico
Specialized in Groovy & Grails environments
Recently, Spring Boot world
@fatimacasau /{PARADIGMA TECNOLÓGICO
Microservices, Grails or Spring Boot?
Picture: Cueva La Mora, Embalse García de Sola, Talarrubias (Badajoz)

Overview
Spring Boot, Groovy
GVM Tool
Example 1: Implement simple REST API
●
Spring Boot, Gradle, Groovy, Spring Data JPA
Example 2: Implement simple REST API
●
Grails
Other important Tips
Conclusions

Spring BootSpring Boot

Spring Boot
Standalone
Auto-configuration - CoC
No XML
Embedded Container and Database
Bootstrapping
Groovy!!
Run quickly - Spring Boot CLI
projects.spring.io/spring-boot

Groovy
Dynamic language
Optionally typed
@TypeChecked & @CompileStatic
Java Platform
Easy & expressive syntax
Powerful features
closures, DSL, meta-programming, functional programming, scripting,
...
www.groovy-lang.org

GVMGVM
Groovy enVironment ManagerGroovy enVironment Manager

GVM
Manage parallel versions
Multiple Software Development Kits
– Groovy, Grails, Gradle, Spring Boot, Vert.x, Griffon,...
Unix Sistems
– Linux, Mac OSX, CyWin, Solaris,..
Bash
Curl & Unzip available
gvmtool.net

GVM – How to ...
$ gvm help
$ curl s get.gvmtool.net | bash
$ gvm install groovy
$ gvm install groovy 2.4.0
$ gvm use grails 2.5.0
$ gvm current
$ gvm current gradle
$ gvm list springboot
$ gvm default groovy 2.4.0
$ gvm uninstall grails 2.4.4

Spring Boot App in a single Tweet with Groovy
HelloWorld.groovy
@Controller
class ThisWillActuallyRun {
   @RequestMapping("/")
   @ResponseBody
   String home() {
       "Hello World!"
   }
}
Spring Boot in a single tweet

Run the Spring Boot Groovy script
$ spring run helloWorld.groovy
  .   ____          _            __ _ _
/ / ___'_ __ _ _(_)_ __  __ _
( ( )___ | '_ | '_| | '_ / _` |
/  ___)| |_)| | | | | || (_| |  ) ) ) )
  '  |____| .__|_| |_|_| |___, | / / / /
=========|_|==============|___/=/_/_/_/
:: Spring Boot ::        (v1.2.2.RELEASE)
...
... : Root WebApplicationContext: initialization completed
in 4024 ms
...
... : Started application in 8.042 seconds (JVM running
for 15.542)
$ gvm current springboot
Using springboot version 1.2.2.RELEASE

Spring BootSpring Boot
Implement Simple REST APIImplement Simple REST API
Example 1:Example 1:

How to...
Create project with Gradle
Bootstraping
Create an entity
Create a repository
Create custom controller
Configure properties
Testing
Execute
Deploy

Gradle
Powerful build tool
Support multi-project
Dependency management (based on Apache Ivy)
Support and Integration with Maven & Ivy
repositories
Based on Groovy DSL
Build by convention
Ant tasks

Gradle
$ gvm install gradle
$ mkdir springbootexample
$ touch build.gradle
$ mkdir p src/main/java/example
$ gradle build
(Edit the file)

build.gradle
1  buildscript {
2  repositories {
3         mavenCentral()
4     }
5     dependencies {
6        classpath("org.springframework.boot:springbootgradleplugin:1.2.3.RELEASE")
7     }
8   }
9
10  apply plugin: 'groovy'
11  apply plugin: 'idea'
12  apply plugin: 'springboot'
13
14  jar {
15      baseName = 'helloworld'
16      version = '0.1.0'
17  }
18
19  repositories {
20      mavenCentral()
21  }
22
23  dependencies {
24      compile "org.springframework.boot:springbootstarterweb"
25      compile "com.h2database:h2"
26      compile "org.codehaus.groovy:groovyall:2.4.3"
27  }

Main ClassMain Class

Application main class
1  import org.springframework.boot.SpringApplication
2  import org.springframework.boot.autoconfigure.SpringBootApplication
3
4  @SpringBootApplication
5  public class Application {
6
7   public static void main(String[] args) {
8   SpringApplication.run(Application.class, args)
9   }
10 }
@Configuration
@EnableAutoConfiguration
@ComponentScan
@EnableWebMvc

Create an EntityCreate an Entity

build.gradle
1
2  //...
3
4  dependencies {
5      // include Spring Boot Starter Web
6      compile("org.springframework.boot:springbootstarterdatarest")
7      // include hibernate entity manager
8      compile("org.springframework.boot:springbootstarterdatajpa")
9      compile("com.h2database:h2")
11  }

Person.groovy
1
2
3
4
5 class Person {
6
7
8
9    long id
10
11
12
13   String firstName
14
15
16   String lastName
17
18
19   Integer age
20
21   @Override
22   String toString(){
23       "Person: [Name: $firstName, LastName: $lastName, Age: $age]"
24   }
25 }

Person.groovy
1 import javax.persistence.*
2 import javax.validation.constraints.*
3
4 @Entity
5 class Person {
6
7    @Id
8    @GeneratedValue(strategy=GenerationType.AUTO)
9    long id
10
11   @NotNull
12   @Size(max = 20)
13   String firstName
14
15   @Size(max = 50)
16   String lastName
17
18   @Max(100L)
19   Integer age
20
21   @Override
22   String toString(){
23       "Person: [Name: $firstName, LastName: $lastName, Age: $age]"
24   }
25 }

Create a REST RepositoryCreate a REST Repository

PersonRepository.groovy
1
2 import org.springframework.data.repository.CrudRepository
3
4 import org.springframework.stereotype.Repository
5
6 @Repository
7 interface PersonRepository extends CrudRepository<Person,Long> {
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 }

1 import org.springframework.data.jpa.repository.Query
3 import org.springframework.data.repository.query.Param
4 import org.springframework.stereotype.Repository
5
6 @Repository
8
9   List<Person> findByLastName(String name)
10
11  @Query("select p from Person p where p.firstName like %?1")
12  List<Person> findByFirstNameEndsWith(String firstname)
13
14  @Query("select p from Person p where p.firstName = :firstname or p.lastName =
15 :lastname")
16  List<Person> findByLastnameOrFirstname(@Param("lastname") String lastname,
17                                         @Param("firstname") String firstname)
18
19  @Query(value = "SELECT * FROM PERSON WHERE AGE BETWEEN ?1 AND ?2",
20         nativeQuery = true)
21  List<Person> findByAgeBetween(Integer from, Integer to)
22
23 }

4 import org.springframework.stereotype.RepositoryRestResource
5
6 @RepositoryRestResource(collectionResourceRel = "people", path = "people")
8
10
13
15 :lastname")
18
22
23 }

4 import org.springframework.stereotype.RepositoryRestResource
5
6 @RepositoryRestResource(exported = false)
8
10
13
15 :lastname")
18
22
23 }

Create a Custom Rest ControllerCreate a Custom Rest Controller

PersonController.groovy
1 import org.springframework.beans.factory.annotation.Autowired
2 import org.springframework.web.bind.annotation.PathVariable
3 import org.springframework.web.bind.annotation.RequestMapping
4 import org.springframework.web.bind.annotation.RestController
5
6 @RestController
7 class PersonController {
8
9    @Autowired
10    PersonRepository personRepository
11
12    @RequestMapping("/person/{id}/address")
13    Address personAddress(
14            @PathVariable("id") Long id
15    ){
16        personRepository.findOne(id).address
17    }
18
19 }

Spock FrameworkSpock Framework
TestingTesting

Spock Framework
Spock framework & specification
Expressive
Groovy DSL’s
Easy to read tests
Well documented
JUnit
Powerful assertions

Spock & Test Dependencies
1
2  //...
3
4  dependencies {
5      // include Spring Boot Starter Web
6      compile("org.springframework.boot:springbootstarterdatarest")
7      // include hibernate entity manager
8      compile("org.springframework.boot:springbootstarterdatajpa")
9      compile("com.h2database:h2")
11     compile ("org.codehaus.groovy.modules.httpbuilder:httpbuilder:0.7")
12     testCompile("org.springframework.boot:springbootstartertest")
13     testCompile("org.springframework:springtest")
14     testRuntime("org.spockframework:spockspring:0.7groovy2.0") {
15         exclude group: 'org.spockframework', module: 'spockcore'
16     }
17     testCompile("org.spockframework:spockcore:0.7groovy2.0") {
18         exclude group: 'org.codehaus.groovy', module: 'groovyall'
19     }
20  }

Example Spock Test
1 @WebAppConfiguration
2 @ContextConfiguration(loader = SpringApplicationContextLoader.class,classes =
3 [Application.class])
4 @IntegrationTest("server.port:0")
5 class PersonRestSpec extends Specification {
6
7     @Value("${local.server.port}")
8     String contextPath
9
10    @Value("${server.contextpath}")
11    String contextPath
12
13    @Autowired
14    PersonRepository personRepository
15
16    def "find a person via REST"(){
17       given: "an existing person"
18           RESTClient rest = new RESTClient("http://localhost:$port")
19           def person = personRepository.findAll()[0]
20       and: "people uri"
21           def uri = "$contextPath/people/${person.id}"
22       when:
23           def result = rest.get(path: uri)
24       then:
25           result.status == HttpStatus.OK.value()
26    }
27 }

Example Spock Test
1 @Unroll
2 def "create new person via REST with different params: #params"(){
3
4    setup: "people uri"
5        RESTClient rest = new RESTClient("http://localhost:$port")
6        def uri = "$contextPath/people"
7    expect: "status ok"
8        result == rest.post(requestContentType: JSON, path: uri, body: params).status
9    where: "different params"
10        result                      | params
11        HttpStatus.CREATED.value()  | [firstName:"fatima",lastName:"casau"]
12        HttpStatus.OK.value()       | [firstName:"fatima",lastName:"casau",age:29]
13        // this fails
14
15 }

Test failed exception

Pretty tests report

ConfigurationConfiguration

Configuration
Properties files
application.properties
YAML
application.yml
By profile
application-{profile}.properties
application-{profile}.yml
Classpath

YAML – Exmaple configuration file
1 spring:
2   profiles.active: default
3
4 spring:
5   profiles: default
6 # server config
7 server.contextpath: /springbootexample
8 # config properties
9 foo:
10   firstProperty: firstFooProperty
11   secondProperty: secondFooProperty
Common application properties:
http://docs.spring.io/spring-boot/docs/current/reference/html/common-application-properties.html

Access to configuration properties
1 @ConfigurationProperties(prefix = "foo")
2 class HelloController {
3
4    String firstProperty
5
6    @Value("${foo.secondProperty}")
7    String secondProperty
8
9    String getFirstProperty() {
10        return firstProperty
11   }

Execute & DeployExecute & Deploy

Execute (packaging Jar or War)
Using Gradle
Using Maven
In place
Create a war file
Gradle: some options in build.gradle
Maven:
$ gradle build && java jar build/libs/springbootexample0.1.0.jar
$ mvn package && java jar target/springbootexample0.1.0.jar
$ gradle bootRun
$ mvn springboot:run
apply plugin: 'war'
war {
baseName = 'myapp'
version = '0.5.0'
}
<packaging>war</packaging>

Deploy to the cloudDeploy to the cloud

Deploy to the cloud
“Bring your own container”
Jars ready to cloud PaaS
Heroku (install git & Heroku Toolbelt)
Procfile (project root)
Cloud Foundry (install cf command line tool and login in)
Openshift
Google API engine (somo modifications – Servlet 2.5)
$ cf push springbootexample p build/libs/springbootexample0.1.0.jar
$ cf apps
web: java Dserver.port=$PORT jar target/demo0.0.1SNAPSHOT.jar
$ git push heroku master

More examples:More examples:
https://github.com/spring-projects/spring-boot/tree/master/spring-boot-samples

GrailsGrails
Implement Simple REST APIImplement Simple REST API
Example 2:Example 2:

GrailsGrails

Grails
Powerful web application Framework
Java Platform (JVM)
Groovy-based
CoC (Convention over Configuration)
ORM/NoSql
Plugins
DSL's
Grails 3 built on Spring Boot

How to...
Create project → Bootstraping
Create an Entity
RESTful API
Create REST Controller
Create REST Custom Controller
Testing
Configuration
Execute
Deploy

Create ProjectCreate Project

Create Project - Bootstraping
$ grails createapp grails3apirest
build.gradle file by default
Main class Application.groovy by default
application.yml configuration by default
Layout & some view by default
i18n files by default
log configuration by default
Url mappings by default

Example HelloWorld
$ grails
| Enter a command name to run. Use TAB for completion:
grails> createcontroller HelloWorld
| Created grailsapp/controllers/grails3/rest/sample/HelloWorldController.groovy
| Created src/test/groovy/grails3/rest/sample/HelloWorldControllerSpec.groovy
grails>
Grails provides an interactive console
HelloWorldController.groovy class is created
Default controllers directory
Default packaging
package grails3.rest.sample
class HelloWorldController {
def index() { }
}
{ “Hello World" }
grails> runapp

Example HelloWorld
grails> runapp
> Configuring > 0/1 projects > root project > Resolving dependencies ':classpath
1/1 projects > Resolving dependencies ':agent' > Resolving dependencies ':versio
:compileJava UPTODATE
> Building 16% > :compileGroovy > Resolving dependencies ':compile' > Resolving
:compileGroovy UPTODATE
:processResources
:classes
:findMainClass
> Building 83% > :bootRun > Resolving dependencies ':runtime' > Resolving depend
:bootRun
Grails application running at http://localhost:8080
> Building 83% > :bootRun
gradle tasks

Example HelloWorld

Create an EntityCreate an Entity
(RESTful API)(RESTful API)

Create domain class
grails> createdomainclass Person
| Created grailsapp/domain/grails3/rest/sample/Person.groovy
| Created src/test/groovy/grails3/rest/sample/PersonSpec.groov
grails>
Person.groovy persistence class is created
Default domain directory
package grails3.rest.sample
class Person {
static constraints = {
}
}

Person.groovy
1 import grails.rest.Resource
2
3
4 class Person {
5
6    String firstName
7    String lastName
8    Integer age
9
10    static constraints = {
11        lastName maxSize: 20
12        firstName maxSize: 50
13        age nullable: true
14    }
15 } 16

Person.groovy
2
3 @Resource(uri='/people')
4 class Person {
5
6    String firstName
7    String lastName
8    Integer age
9
14    }
15 } 16

Person.groovy
2
3 @Resource(uri='/people', formats=['json', 'xml'])
4 class Person {
5
6    String firstName
7    String lastName
8    Integer age
9
14    }
15 } 16

Person.groovy
2
3 @Resource(uri='/people', readOnly=true)
4 class Person {
5
6    String firstName
7    String lastName
8    Integer age
9
14    }
15 } 16
RESTful API only with one annotation
Dynamic finders, where queries, criterias, … without repositories

Create REST ControllerCreate REST Controller

1 import grails.rest.RestfulController
2
3 class PersonController extends RestfulController{
4
5    static responseFormats = ['json', 'xml']
6
7    PersonController(){
8        super(Person)
9    }
10 } 11
RESTful Url mapping to controller by
convention
in URLMappings.groovy
"/people"(resources: 'person')
HTTP Method URI Grails Action
GET /people index
GET /people/create create
POST /people save
GET /people/${id} show
GET /people/${id}/edit edit
PUT /people/${id} update
DELETE /people/${id} delete

1 @Transactional(readOnly = true)
2 class PersonController {
3     static responseFormats = ['json', 'xml']
4
5     def index(Integer max) {
6         params.max = Math.min(max ?: 10, 100)
7         respond Person.list(params), model:[personCount:Person.count()]
8     }
9
10     def show(Person person) {
11         if(person) {
12             render status:404
13         }
14         else {
15             respond person
16         }
17     }
18
19 }
HTTP Method URI Grails Action
GET /people index
GET /people/create create
POST /people save
GET /people/${id} show
GET /people/${id}/edit edit
PUT /people/${id} update
DELETE /people/${id} delete
RESTful Url mapping to controller by
convention
in URLMappings.groovy
"/people"(resources: 'person')

TestingTesting

Testing
Spock Framework integrated by default
Similar use as Spring Boot
– Well integrated (more easy, more features)
– Test Mixins for Unit test. Support for:
●
Domains and constraints
●
Controllers and filters
●
Tag libraries
●
Url mappings
●
Metaprogramming
– Integration Tests
– Functional Tests (GEB integrated by default)
See
Documentation!

Configuration
Similar as Spring Boot
Built configuration: build.gradle file
Runtime configuration: grailsapp/conf/application.yml by default
Grails 2.0-style: grailsapp/conf/application.groovy
Access: grailsApplication.config.getProperty('foo.bar.hello')
Spring @Value annotation

Configuration per Environments
Easy use of configuration by environments
Commands by environment
– Default environments: grails [environment] [command name]
– Custom environments: grails Dgrails.env=[customenvname] [commandname]
– Programmatic env. detection, per env. bootstraping, generic per env. execution
# Default environments
environments:
    development:
        dataSource:
            dbCreate: createdrop
            url: jdbc:h2:mem:devDb;MVCC=TRUE;LOCK_TIMEOUT=10000;DB_CLOSE_ON_EXIT=FALSE
    test:
        dataSource:
            dbCreate: update
            url: jdbc:h2:mem:testDb;MVCC=TRUE;LOCK_TIMEOUT=10000;DB_CLOSE_ON_EXIT=FALSE
    production:
        dataSource:
            dbCreate: update
            url: jdbc:h2:prodDb;MVCC=TRUE;LOCK_TIMEOUT=10000;DB_CLOSE_ON_EXIT=FALSE
        properties:
           jmxEnabled: true
           initialSize: 5
        ...

Execute & Deploy
Gradle tasks (run & package)
Grails commands
– run-app environment by default 'development'
– package (executable war of jar)
– war environment by default: 'production' (to deploy in a Servlet Container)
provided "org.springframework.boot:springbootstartertomcat"
List of supported containers: https://grails.org/wiki/Deployment
$ grails [environment] runapp
$ grails package
$ grails war

Deploy to cloud
Since grails is build on Spring Boot and permits create
standalone applications. The way to deploy on to the cloud is
similar with Spring Boot

Other Important TipsOther Important Tips

Other important tips
HAL support
Easy integration with Spring Security
– (Grails Spring Security Core Plugin not Grails3 compatible (use Spring Security
Starter for Spring Boot)
GORM & GSP's in Spring Boot
– Your can use them outside of Grails since Grails 2.4
Grails Scaffolding
Grails autorealoading by default
Grails custom marshalling easily

ConclusionsConclusions

Conclusions
With Spring Boot
Groovy language posibility
Build with gradle or maven
Convention Over Configuration
GORM (posibility)
Spock framework (posibility)
Bootstrapping
Configuration (properties, YAML)
Configuration Per Environment
Easy way to execute & deploy
Deploy to the Cloud
HAL support
With Grails 3
Groovy language
Build with gradle by default
Convention Over Configuration ++
GORM by default
Spock framework by default & Text Mixins
Bootstrapping with many config by default
Configuration (properties, YAML, Groovy DSL's)
Config. Per env. (more flixible & more features)
Easy way to execute & deploy
Deploy to the Cloud
HAL support
Plugins Library
Scaffolding
and more...

That's allThat's all
Source code: Spring Boot -> https://github.com/fatimacasau/spring-boot-example.git
Source code: Grails 3 -> https://github.com/fatimacasau/grails3-rest-sample.git

Spring IO '15 - Developing microservices, Spring Boot or Grails?

More Related Content

What's hot

Viewers also liked

Similar to Spring IO '15 - Developing microservices, Spring Boot or Grails?

Recently uploaded

Spring IO '15 - Developing microservices, Spring Boot or Grails?
