The document discusses serverless computing, specifically focusing on the FN Project and Functions as a Service (FaaS). It highlights the benefits of serverless architecture, including reduced management overhead, quick deployment, and cost-effectiveness by charging users only for actual usage. Additionally, it outlines the features of FN Project, including its open-source nature and support for various runtime environments.

1. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Serverless Computing과 친해지기
[3rd] Oracle Developer Meetup
The Fn Project
Open Source Serverless Computing
김종규 (jonggyou.kim@oracle.com )

2. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
서버리스란?
애플리케이션
라이브러리
컨테이너
실행환경
운영 시스템

3. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
서버리스 아키텍처
“애플리케이션 개발을 위한 새로운 아키텍처”
• 시스템에 관해 신경 쓰지 않음.
• 서비스 준비시간이 매우 빠름
• 사용되는 시간만 지불

4. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
애플리케이션 아키텍처

5. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Function as a Service (FaaS)

6. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Function
서버리스 아키텍처의 중심

7. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
클라우드 애플리케이션 서비스 타입
Virtual Machine Container
Application Platform
as a Service (aPaaS)
Functions
(Serverless)
Oracle Compute
AWS EC2
Azure VM
IBM Softlayer
Docker, Rocket, RunC,
LXC, …
Oracle Application Container
Heroku, Bluemix,
Oracle Functions
AWS Lambda
OpenWhisk
Azure Functions

8. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
배포 대상 종속성
애플리케이션
라이브러리
컨테이너
실행환경
운영 시스템
Function
Container
VM
aPaaS
서비스 중심
코드에만 집중

9. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
코드, 코드, 코드
서버리스?

10. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
워크플로
서버리스?

11. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
유기적인 확장
서버리스?
time
users

12. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
저렴한 비용
서버리스?

13. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Functions-as-a-Service
• 서버리스 아키텍처의 중심
• Function
– 그 자체로 일을 수행할 수 있는 작은 단위
– 어떤 입력을 받고 기능을 수행한 다음 아웃풋을 내는 형태
• Functions-as-a-Service (FaaS)
– Function 하나가 FaaS 플랫폼의 하나의 유닛으로 배포
– 프로비져닝, 배포하고, 스케일 업/다운, 빌링, 인증, 인가, 보안등을 제공
– 매우 빠르고 스케일도 매우 클 수 있으며 어떤 언어나 플랫폼에서도 수행가능

14. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Functions-as-a-Service

15. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Functions 플랫폼 제공자

16. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
이상적인 Functions 플랫폼
• 오픈 소스 – 프로바이더에게 비종속적.
• 런타임 플랫폼에 자유 - laptop, server, cloud에서 모두 수행가능
• 쉬운 접근성 – 사용하기 쉽고 관리하기 쉬운 형태
• Docker 기반 – Docker 기반으로 수행
• 여러 툴 사용가능 - Kubernetes, Swarm, Mesos 등을 사용

17. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Fn Project
www.fnproject.io
An open source Functions Platform

18. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Fn Project
Fn Server FDK Fn Flow

19. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Fn Project – Fn Server

20. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Fn CLI
• fn init --runtime go
• fn run
• fn test
• fn deploy --app myapp
• fn call myapp myfunc
• → http://localhost:8080/r/myapp/myfunc

21. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
fn deploy details
• Builds container + bumps version
• Pushes container to registry
• Creates/updates function route
MyFunc:0.0.2
MyFunc:0.0.2 MyFunc:0.0.2
Your code
Fn Service
myfunc →
/r/myapp/myfunc:0.0.2
1 2 3

22. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Architecture

23. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Detailed Arch

24. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Fn Project – FDK (Function Development Kit)

25. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Fn Project – FDK (Function Development Kit)
JAVA GO

26. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Fn Project – FDK (Function Development Kit)
JAVA
GO

27. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Fn Project – Fn Flow

28. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Functions
항공 예약
book
cancel
호텔 예약
book
cancel
렌트카 예약
book
cancel
메일
send

29. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
개발/테스트/배포
클라우드에서
배포 및 테스트
•~ 30 초
로컬에서
배포 및
테스트
•~ 10 초
테스트 •~ 1 초

30. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Functions의 조립
항공 예약
book
cancel
호텔 예약
book
cancel
렌트카 예약
book
cancel
메일
send
종료
비행기 예약
호텔 예약
렌트카 예약
메일 전송
시작 yes
yes
yes
yes
no
no
no

31. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Fn Project – Fn Flow

32. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Serverless Architecture
Fn Project at Oracle
Functions-as-a-Service

33. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Serverless at Oracle
Trigger
Kafka Event Bus,
API Platform,
Database (DBaaS),
MySQL CS,
Cache,
WebHooks,
Events from Management Cloud
Messages on the Messaging Cloud
etc.

34. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
Serverless at Oracle
Schedule
Event
Policy
CI/CD
Objects
Functions Work Flow Scheduling &
Orchestrator

35. Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |Copyright © 2017, Oracle and/or its affiliates. All rights reserved. |
http://github.com/shiftyou/fnproject
실습때 다시 만나용~
