This document provides an overview of using Apache Pulsar as a streaming data source for Apache Flink SQL queries. It discusses how Pulsar can serve as a unified storage layer for both streaming and batch data. The document then demonstrates setting up a Pulsar source in Flink SQL, writing a continuous query over tweeted data to calculate tweet counts in tumbling windows, and sinking the results to another Pulsar topic. It concludes by providing references to documentation on Flink SQL, the Flink-Pulsar connector, and related resources.

1. © 2020 Ververica
1

2. © 2020 Ververica
2
2
● Caito Scherr
Introduction

3. © 2020 Ververica
3
3
● Caito Scherr
Introduction
3
● Caito Scherr
● Developer Advocate

4. © 2020 Ververica
4
● Caito Scherr
● Developer Advocate
● Ververica, GmbH
Introduction

5. © 2020 Ververica
5
● Caito Scherr
● Developer Advocate
● Ververica, GmbH
● Portland, OR, USA
Introduction

6. © 2020 Ververica
6
Introduction

7. © 2020 Ververica
7
Demo credit: Marta Paes
Introduction

8. © 2020 Ververica
8
Agenda
● Pulsar + Flink
● Where SQL comes in
● Demo: Pulsar + Flink SQL

9. © 2020 Ververica
9
● Pulsar + Flink
● Where SQL comes in
● Demo: Pulsar + Flink SQL
Agenda

10. © 2020 Ververica
10
Agenda
● Pulsar + Flink
● Where SQL comes in
● Demo: Pulsar + Flink SQL

11. © 2020 Ververica
11
>> What is Flink?
Pulsar + Flink
● Stateful
● Stream processing engine
● Unified batch & streaming

12. © 2020 Ververica
12
>> What is Flink?
Pulsar + Flink

13. © 2020 Ververica
13
>> What is Flink?
Pulsar + Flink

14. © 2020 Ververica
14
>> Why Pulsar + Flink?
Pulsar + Flink
“Batch as a special case
of streaming”
“Stream as a unified
view on data”

15. © 2020 Ververica
15
>> Pulsar: Unified Storage
● Pub/Sub messaging layer
(Streaming)
● Durable storage layer
(Batch)
Pulsar + Flink

16. © 2020 Ververica
16
now
bounded query
unbounded query
past future
bounded query
start of the stream
unbounded query
>> Flink: Unified Processing
● Reuse code and logic
● Consistent semantics
● Simplify operations
● Mix historic and real-time
● Pub/Sub messaging layer (Stream)
● Durable storage layer (Batch)
Pulsar + Flink

17. © 2020 Ververica
17
Unified Processing Engine
(Batch / Streaming)
Unified Storage
(Segments / Pub/Sub)
>> A Unified Data Stack
Pulsar + Flink

18. © 2020 Ververica
18
Flink 1.6+
2018
Streaming Source/Sink Connectors
Table Sink Connector
>> Pulsar + Flink History
Pulsar + Flink

19. © 2020 Ververica
19
Flink 1.6+
2018
Streaming Source/Sink Connectors
Table Sink Connector
>> Pulsar + Flink History
Pulsar + Flink
Flink 1.9+
Pulsar Schema + Flink Catalog
Table API/SQL as 1st class citizens
Exactly-once Source
At-least once Sink

20. © 2020 Ververica
20
Flink 1.6+
2018
Streaming Source/Sink Connectors
Table Sink Connector
>> Pulsar + Flink History
Pulsar + Flink
Flink 1.9+
Pulsar Schema + Flink Catalog
Table API/SQL as 1st class citizens
Exactly-once Source
At-least once Sink
Flink 1.12
Upserts
DDL Computed Columns, Watermarks. Metadata
End-to-end Exactly-once
Key-shared Subscription Model

21. © 2020 Ververica
21
Flink Runtime
Stateful Computations over Data Streams
Stateful
Stream Processing
Streams, State, Time
Event-Driven
Applications
Stateful Functions
Streaming
Analytics & ML
SQL, PyFlink, Tables
>> Why Flink SQL?
Pulsar + Flink

22. © 2020 Ververica
22
>> Why Flink SQL?
● Focus on business logic, not implementation
● Mixed workloads (batch + streaming)
● Maximize developer speed and autonomy
ML Feature Generation
Unified Online/Offline Model
Training
E2E Streaming Analytics
Pipelines
Pulsar + Flink

23. © 2020 Ververica
23
user cnt
Mary 2
Bob 1
SELECT user_id,
COUNT(url) AS cnt
FROM clicks
GROUP BY user_id;
Take a snapshot when the
query starts
A final result is
produced
A row that was added after the query
was started is not considered
user cTime url
Mary 12:00:00 https://…
Bob 12:00:00 https://…
Mary 12:00:02 https://…
Liz 12:00:03 https://…
The query
terminates
Where SQL Fits In >> A Regular SQL Engine

24. © 2020 Ververica
24
user cTime url
user cnt
SELECT user_id,
COUNT(url) AS cnt
FROM clicks
GROUP BY user_id;
Mary 12:00:00 https://…
Bob 12:00:00 https://…
Mary 12:00:02 https://…
Liz 12:00:03 https://…
Bob 1
Liz 1
Mary 1
Mary 2
Ingest all changes as
they happen
Continuously update the
result
The result is identical to the one-time query (at this point)
Where SQL Fits In >> A Streaming SQL Engine

25. © 2020 Ververica
25
● Standard SQL syntax and semantics (i.e. not a “SQL-flavor”)
● Unified APIs for batch and streaming
● Support for advanced time handling and operations (e.g. CDC, pattern matching)
UDF Support
Python
Java
Scala
Execution
TPC-DS Coverage
Batch
Streaming
+
Formats
Native Connectors
Apache Kafka
Elasticsearch
FileSystems
JDBC HBase
+
Kinesis
Metastore Postgres (JDBC)
Data Catalogs
Debezium
Where SQL Fits In >> Flink SQL In A Nutshell

26. © 2020 Ververica
26
>> 1a. Twitter Firehose
Demo

27. © 2020 Ververica
27
Demo >> 1b. Data?

28. © 2020 Ververica
28
Demo >> 2. SQL Client + Pulsar
CREATE CATALOG pulsar WITH (
'type' = 'pulsar',
'service-url' = 'pulsar://pulsar:6650',
'admin-url' = 'http://pulsar:8080',
'format' = 'json'
);
Catalog DDL

29. © 2020 Ververica
29
Not cool. 👹
Demo

30. © 2020 Ververica
30
Demo
CREATE TABLE pulsar_tweets (
publishTime TIMESTAMP(3) METADATA,
WATERMARK FOR publishTime AS publishTime - INTERVAL '5'
SECOND
) WITH (
'connector' = 'pulsar',
'topic' = 'persistent://public/default/tweets',
'value.format' = 'json',
'service-url' = 'pulsar://pulsar:6650',
'admin-url' = 'http://pulsar:8080',
'scan.startup.mode' = 'earliest-offset'
)
LIKE tweets;
Derive schema from the original topic
Define the source connector (Pulsar)
Read and use Pulsar message metadata
>> 3. Get relevant timestamp

31. © 2020 Ververica
31
Demo >> 4. Windowed aggregation
CREATE TABLE pulsar_tweets_agg (
tmstmp TIMESTAMP(3),
tweet_cnt BIGINT
) WITH (
'connector'='pulsar',
'topic'='persistent://public/default/tweets_agg',
'value.format'='json',
'service-url'='pulsar://pulsar:6650',
'admin-url'='http://pulsar:8080'
);
Sink Table DDL
INSERT INTO pulsar_tweets_agg
SELECT TUMBLE_START(publishTime, INTERVAL '10'
SECOND) AS wStart,
COUNT(id) AS tweet_cnt
FROM pulsar_tweets
GROUP BY TUMBLE(publishTime, INTERVAL '10'
SECOND);
Continuous SQL Query

32. © 2020 Ververica
32
Demo >> 5. Tweet count in windows

33. © 2020 Ververica
33
What Next? >> Flink SQL Cookbook

34. © 2020 Ververica
Resources
● Flink Ahead: What Comes After Batch & Streaming: https://youtu.be/h5OYmy9Yx7Y
● Apache Pulsar as one Storage System for Real Time & Historical Data Analysis:
https://medium.com/streamnative/apache-pulsar-as-one-storage-455222c59017
● Flink Table API & SQL:
https://ci.apache.org/projects/flink/flink-docs-master/dev/table/sql/queries.html#operatio
ns
● Flink SQL Cookbook: https://github.com/ververica/flink-sql-cookbook
● When Flink & Pulsar Come Together: https://flink.apache.org/2019/05/03/pulsar-flink.html
● How to Query Pulsar Streams in Flink:
https://flink.apache.org/news/2019/11/25/query-pulsar-streams-using-apache-flink.html
● What’s New in the Flink/Pulsar Connector:
● https://flink.apache.org/2021/01/07/pulsar-flink-connector-270.html
● Marta’s Demo: https://github.com/morsapaes/flink-sql-pulsar
34
@Caito_200_OK

35. © 2020 Ververica
● Pulsar Conference staff!!
● Marta Paes
35
Thank You!
@Caito_200_OK
Scan here for links
& resources
