Secure Boot
Survival Guide
Gary Lin
Software Engineer – SUSE Labs
glin@suse.com
什麼是 Secure Boot ?
先來談談 UEFI 吧!
UEFI
Hardware
Firmware
Unified Extensible Firmware Interface
OS
Based on http://en.wikipedia.org/wiki/Unified_Extensible_Firmware_Interface#mediaviewer/File:Efi-simple.svg
其實就跟 BIOS 一樣
啦!
BIOS 時代
BIOS Bootloader
UEFI 時代
UEFI UEFI Image
UEFI 的 Secure Boot 為
Windows 8 認証的必要
條件
所以說什麼是 Secure Boot ?
鎖
UEFI UEFI Image
Secure Boot
UEFI
Secure Boot
Verified
UEFI Image
?
Bootloader
UEFI
OS
db
db
PK
KEK
db
這些 key 是哪裡來的?
硬體出廠前預先載入的
UEFI
PK
KEK
db
UEFI CA
銅鑼灣只有一個浩南
UEFI 只有一個 CA
Microsoft UEFI CA
UEFI CA Signing Policy
● 入會費 $99
● 送審者需有 EV Certificate (2014/3 起 )
● 只接受產品等級的程式
● 不接受 GPLv3 授權的程式,如 Grub2
http://blogs.msdn.com/b/windows_hardware_certification/archive/2013/12/03/microsoft-uefi-ca-signing-policy-updates.aspx
http://farm3.staticflickr.com/2559/4199675334_66c3e3d61d.jpg
Linux 使用者 / 發行商有
什麼選擇?
方案一
不爽不要用
可是客戶要求 ...
方案二
隔開 UEFI 與 Grub2
shim (Matthew Garret)
PreLoader (James Bottomley)
shim
db
OS Vendor
load
db
AT Var
UEFI load Grub2
Vendor
Kernel
Vendor
AT: Authenticated
但是 ...
使用者還是不能隨意修改
方案二 改
自己的程式自己簽
UEFI Variables
● Authenticated Variable
● Runtime Service Variable
● Boot Service Variable
UEFI Variables
Boot Service Runtime Service Authenticated
UEFI - Read Yes Yes Yes
UEFI - Write Yes Yes Restricted
OS - Read No Yes Yes
OS - Write No Yes Restricted
* 此處指 Non-volatile Variables
Machine Owner Key
shim
db
OS Vendor
MOKList
BS Var
load
db
AT Var
UEFI load Grub2
MOK
Kernel
MOK
AT: Authenticated
BS: Boot Service
Grub2
Vendor
Kernel
MOK
Kernel
Vendor
Grub2
MOK
load load
load
load
load
shim
db
OS Vendor
MOKList
BS Var
mokutil --import
MOKNew
RT Var
Password
shim MokManager
MOKList
BS Var
load
3. verify
4.enroll
reboot
1. request
2.detect
Linux UEFI
RT: Runtime
簽章工具 -- pesign
● 針對 PE-COFF 的簽章工具
● 使用 Mozilla NSS 管理憑證
● 支援多重簽章
pesign 用法
● 初始化資料庫
– $ certutil -N -d certdb
● 載入公私鑰
– $ pk12util -d certdb -i mykey.p12
● 簽章
– $ pesign -n certdb -c mykey -s -i
myloader.efi -o myloader-signed.efi
For more details: http://en.opensuse.org/openSUSE:UEFI_Image_File_Sign_Tools
使用 shim+MOK 的
distro
● SUSE Enterprise Linux / openSUSE
● Red Hat Enterprise Linux / Fedora
● Ubuntu
● Alt Linux
● more
Secure Boot 不再是
Linux 的問題
我有 Secure Boot 我超強!
Hack In The Box 2014
Setup for Failure: More Ways to
Defeat SecureBoot
http://haxpo.nl/hitb2014ams-kallenberg-cornwell-kovah-butterworth/
Not So Secure
● 某 A 廠沒保護好關鍵的 UEFI
variable
● 某些廠商沒設定好 SPI Flash 的保
護機制
沒有絕對安全的系統
請時常注意安全更新
http://farm3.staticflickr.com/2698/4304968451_677b6a2cb5.jpg
photo credit: Marco Bellucci via photopin
photo credit: J. Star
https://www.flickr.com/photos/jstar/409405305/
References
● UEFI Forum
http://www.uefi.org/
● Wikipedia: UEFI
http://en.wikipedia.org/wiki/Unified_Extensible_Firmware_Interface
● Microsoft UEFI CA Signing Policy
http://blogs.msdn.com/b/windows_hardware_certification/archive/2013/12/03/microsoft-uefi-ca-signing-policy-updates.aspx
● Will your computer's "Secure Boot" turn out to be "Restricted Boot"?
http://www.fsf.org/campaigns/secure-boot-vs-restricted-boot
● shim
https://github.com/mjg59/shim
● preloader
http://git.kernel.org/cgit/linux/kernel/git/jejb/efitools.git
● Machine Owner Key
https://www.suse.com/communities/conversations/uefi-secure-boot-details/
● mokutil
https://github.com/lcp/mokutil
● pesign
https://github.com/vathpela/pesign
● Alt Linux UEFI Secure Boot mini-HOWTO
http://en.altlinux.org/UEFI_SecureBoot_mini-HOWTO
Backup
UEFI 的好處
● BSD 開放原碼授權的參考實作 (edk2)
● 以 C 為開發語言
● 多硬體架構支援,如 x86-64, IA-32,
IA-64, ARM, AArch64
● 模組化設計
