1. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 1
RedBack Networks Inc.
Business Plan
December 1996RedBack
Networks Inc.
2. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 2
Wideband Access Market is Ready
How will the Internet get fast and reliable enough
to support real consumer applications?
New applications need higher access speed
RBOCs must get data traffic off voice networks
Internet Traffic is now doubling every 51 days
3. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 3
Company Business
RedBack Networks mission is to lead in the
design, development, and production of
Wideband Access Switches
4. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 4
Why an Access Switch is Needed
Telephone
Access Network
Internet
Backbone
Connection Oriented
Usage Billed
Homogeneous
Secure
Service guarantees
1000s of subscribers
Connectionless
Flat-rate Billed
Heterogeneous
Firewall Security
Best Effort
1000s of networks
Connection Management
Address Management
Traffic Prioritization
Traffic Isolation
Privacy / Authentication
Local Servers
Access Switch
DSL Access Mux RouterWideband Access Switch
5. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 5
Central Office
Access Switch in ISP POP
Modem
Internet
Backbone
ISP POP
1000s of
Networks
100s of
Subscribers
1000s of
Subscribers
DSLAM Router
Wideband
Access
Switch
Metro
ATM
SONET
6. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 6
Access Switch in Central Office
Internet
Backbone
1000s of
Subscribers
1000s of
Networks
ISP POPCentral Office
DSLAM
DSLAM
Wideband
Access
Switch
Router
Metro
ATM
SONET
Corporate LANs
Wideband
Access
Switch
Modem
7. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 7
US Market Grows to
$200 Million in 2000
Access Switch Volumes 1997 1998 1999 2000
Total US ADSL Subs (k) 123 613 2,263 5,963
Subscribers per Access Switch 300 400 500 600
Installed Access Switches 410 1,533 4,526 9,938
Access Switch Market 410 1,123 2,994 5,412
Access Switch ASP $25,000 $30,000 $35,000 $37,000
US Access Switch Revenues ($Millions) $10 $34 $105 $200
Source: Dataquest
8. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 8
Worldwide Market Grows to
$334 Million in 2000
Access Switch Volumes 1997 1998 1999 2000
Total ADSL Subs (k) 280 1,230 4,145 10,395
Subscribers per Access Switch 300 400 500 600
Installed ADSL Access Switches 933 3,075 8,290 17,325
Total Access Switch Market 933 2,142 5,215 9,035
Access Switch ASP $25,000 $30,000 $35,000 $37,000
Access Switch Revenues ($Millions) $23 $64 $183 $334
Source: Dataquest
9. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 9
Customers
Internet Service Providers
National Backbone, Regional Access
Feedback: “Managing virtual circuits will be
our biggest problem.”
Telephone Companies
RBOCs, Independents
Feedback: “We won’t make money until we
can offer more than 500 lines in a CO.”
10. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 10
Marketing Approach
ISP
Telco
‘97 ‘98 ‘99
Develop
Product
Initial Sales
OEM Partners
Telco Market Development
Initial Sales
Leverage
ISP Success
Direct Sales
ISP Market Development
Expand Share
Expand Share
High ADSL
Line Densities
Wideband for the
price of Narrowband
11. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 11
Introducing: WASH 101
RedBack Networks Inc.
WASH 101
Access Concentration
Connection Management
IP Routing
ATM Switching
RedBack Networks Inc.
WASH 101
Access Concentration
Connection Management
IP Routing
ATM Switching
Subscriber
Interfaces
Trunk/Router
Interfaces
Up to 8 OC-3 Interfaces
12. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 12
WASH 101 Highlights
Supports thousands of Wideband subscribers
1 Million PPS forwarding rate
Sophisticated Traffic Management
Access Security features
Telco class
14. December 3, 1996 V.9
Proprietary Information RedBack Networks Inc.
Market Positioning
# of Users
Bandwidth
Cisco
Cascade
RedBack
Ascend
USR
POP
in
a
Box
15. 11/7/96 v1.0December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 15
ISP Access POP Detail
Router
FR & ATM
Switches
HSSI
Router
Narrowband
Access
Concentrator
Ethernet
DS0,
DS1
DS0,
n x DS0
FDDI
Physical
Line / Channels
Access
Switch HSSI or OC-3
DS3,
OC-3
ATM
xDSL Access Network
Thousands of
ATM Connections
Router DS1,
DS3,
OC-3
To Internet Backbone
FR & ATM
Switches
Frame
Relay
Network
DS1,
DS3,
Leased
Lines
16. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 16
Functions FR/ATM Narrowband Access Wideband Access
Switches Concentrators Switches - NEW !
Connection Consolidation Yes Yes
Address Management Yes Yes
Security Features Yes Yes
Scale : Number of Users 100 End Pts 100 (‘96); 1000 (‘97) 1000
Speed per user 1-10 Mbps 64-128 Kbps > 1 Mbps
Cost/User : All Access $450 $500
Cost/User : Access Switching $100-150 $50-100
Cost/User : 1 Mbps Channel $1000-1500 (limit of 150 users) $50-100
QoS Features Connection Packet, Connection,
Layer QoS Stream layer QoS
Packaging Telco Telco; Telco;
8 Feet High 8 Inches High
Examples Cascade Ascend Max TNT, RedBack WASH
Cisco-Stratacom Arris AX 1600
Fore, Sahara USR (200 users)
Product/Technology Comparison
17. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 17
Founding Team
Hardware & Systems, Gaurav Garg
Technology, Asher Waldfogel
Business Development, Gilles Concordel
4 Engineers from leading networking companies
VP Engineering search active
CEO, VP Sales searches begin in January
18. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 18
Schedule
OEM Partners ISP test Lab ISP FCS Telco Test Lab Telco FCS
First Proto Alpha Beta
First Round First Revenue Second Round Profitable
Business
Development
Engineering
Financial
1997 1998
Feature
Enhancement
Faster
Bigger
Chassis
19. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 19
Risks & Opportunities
Market Risk: ADSL Services are Delayed
Access Switch works with all versions of
ADSL physical layer
If ADSL doesn’t happen, technology can be
reapplied to Cable Modems
21. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 21
Deal
Raised $200K for 15% in September 1996
Raising $5 Million for 33% post-money in
January 1997
Sequoia Capital has committed to $2.5 Million
Looking for second active VC to invest $2.5 Million
Plan to raise additional $5 to $7.5 Million in
January 1998
22. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 22
Introducing: WASH 101
RedBack Networks Inc.
WASH 101
Power
Module
PCMCIA Slot LEDs
Console1 Ethernet Alarm RelayConsole2
Power
Module
LEDs LEDs
LEDs
LEDs LEDs
LEDs LEDs
24. 11/26/96 v0.5December 3, 1996V.9
Proprietary Information Redback Networks ConfidentialRedBack Networks Inc. 24
Central Office
Dial Access to ISP POP
Modem
Internet
Backbone
ISP POP
1000s of
Networks
100s of
Subscribers
1000s of
Subscribers
Voice
Switch
Router
Dial
Access
Switch
Metro
ATM
SONET
Editor's Notes
The demand for Internet services is very strong.
The number of US Internet users is over 12 Million now, growing to over 40 Million by 2000.
Dial modem speeds inhibit some network uses - it’s frustrating to wait nearly 6 minutes to get a 1 Megabyte file.
Modem sessions average 20 minutes while the telephone network is engineered for 3 minute calls - voice switch congestion is a serious problem that will cost over $1.5 Billion to repair.
The telcos are moving quickly to offer ADSL to move net traffic off the voice switches.- the leaders in a Joint Purchasing Consortium are Pac Bell, Ameritech, Bell South, and SBC. GTE, US West, and Bell Atlantic have also announced plans.
Wideband Services are Residential Internet and Telecommuting services faster than ISDN
Security and traffic isolation dictate that every subscriber needs his own connection. This means that there is a massive connection mapping problem to map 1000s of subscriber connections to a few ISP connections.
Traffic management is needed to keep all the lines busy - in both directions.
Switch packets and cells very fast
Map packets to connections
Setup and release many connections
Manage distributed subnets
Allocate network resources fairly
Know when to switch and when to route
The problem is carrying traffic to the Internet Service Provider Point of Presence.
For dial access today (there are over 4000 ISPs today, and about 20,000 POPS) an ISP puts a POP in each local calling area - about 20 POPs in the Bay Area for example. Subscribers dial from their modem to a modem in the ISP.
For ADSL access:
Subscriber modem connects to modem in DSLAM.
Digital Subscriber Loop Access Multiplexer (DSLAM) attaches to hundreds of ADSL Lines and inserts an ATM connection from each subscriber into the Metro ATM SONET Network
The Metro ATM SONET ring carries thousands of ATM circuits from all the metro COs to an ISP POP. Only a few of the 20 POPs from each service provider in the Bay Area need to add Wideband Switches.
The Wideband Access Switch connects thousands of ATM circuits to the Internet backbone and manages subscriber level access
Internet backbone carries IP traffic to exit point
Function of the various elements:
Each DSL Access Multiplexer (DSLAM) terminates hundreds of ADSL Lines and feeds ATM circuits into Access Switch
Wideband Access Switch manages thousands of ATM circuits, manages subscriber level access, equal access to multiple ISPs, and corporate remote access
ATM SONET rings carry thousands of ATM circuits from 10 to 100 COs to Internet Service Provider Point of Presence
Wideband Access Switch maps ATM circuits to Internet backbone
Internet backbone carries IP traffic to exit point
Two types of traffic:
Internet traffic is aggregated at the IP layer
Corporate LAN traffic is preserved as an end-to-end ATM service with enhanced service quality
Assumptions for the P&L projections:
While we are planning to offer products to the worldwide market, the following numbers are based on the North American market alone.
During the next two months, we will develop a Sales and Marketing plan for the rest of the world.
These numbers were derived from a Dataquest market analysis (June 1996)
Dataquest forecasts an additional 3.5 Million Cable Modem subscribers by 2000. This creates a $90 Million cable modem access switch market.
Details under development
Traffic Management
Preserve fairness while providing high utilization for 1000’s of users
Access Security
Packet level Authentication
Privacy
Spoofing prevention
Telco Class:
NEBS compliance
Network Management
To Summarize:
The WASH 101 is 10X faster than a MAX TNT
The WASH 101 is 10X smaller in size than a MAX TNT
The WASH 101 supports 1000 wideband users; The MAX TNT supports 1000 narrowband users
The WASH 101 costs half as much per user as the MAX TNT
The WASH 101 costs less than 1/10 per 1 Mbps port as the MAX TNT
Development Schedule
February 1997, Design Complete
June 1997, First Prototype
Major subsystems
DS3 Interface
Early Control software
October 1997, Second Integration
Platform
Control Software
OC3; HSSI or 100BT Interface
December 1997, FCS
Additional Software
February 1998
New forwarding subsystem
New ATM switching subsystem
Additional Interfaces
Problem is carrying traffic to the Internet Service Provider Point of Presence.
For dial access today (there are over 4000 ISPs today, and about 20,000 POPS) an ISP puts a POP in each local calling area - about 20 POPs in the Bay Area for example. Subscribers dial from their modem to a modem in the ISP.
For ADSL access:
Subscriber modem connects to modem in DSLAM.
Digital Subscriber Loop Access Multiplexer (DSLAM) attaches to hundreds of ADSL Lines and inserts an ATM connection from each subscriber into the Metro ATM SONET Network
The Metro ATM SONET ring carries thousands of ATM circuits from all the metro COs to an ISP POP. Only a few of the 20 POPs from each service provider in the Bay Area need to add Wideband Switches.
The Wideband Access Switch connects thousands of ATM circuits to the Internet backbone and manages subscriber level access
Internet backbone carries IP traffic to exit point
