ESAFORM 2023
Mariana Conde1,*, Sam Coppieters2, António Andrade-Campos1
1Department of Mechanical Engineering, TEMA - Centre for Mechanical Technology and Automation, LASI – Intelligent Systems Associate Laboratory, University of Aveiro, Portugal
2Department of Materials Engineering, KU Leuven, Belgium
*marianaconde@ua.pt
Parameter Identification of Swift law using a FEMU-based approach and an inno...vformxsteels
ESAFORM 2022
M. Conde1, J. Henriques1,
S. Coppieters2, A. Andrade-Campos1
1 TEMA, Department of Mechanical Engineering, University of Aveiro, Portugal
2 Department of Materials Engineering, Ghent Technology Campus, KU Leuven, Belgium
Parameter Identification of Swift law using a FEMU-based approach and an inno...vformxsteels
ESAFORM 2022
M. Conde1, J. Henriques1,
S. Coppieters2, A. Andrade-Campos1
1 TEMA, Department of Mechanical Engineering, University of Aveiro, Portugal
2 Department of Materials Engineering, Ghent Technology Campus, KU Leuven, Belgium
Federated Learning of Neural Network Models with Heterogeneous Structures.pdfKundjanasith Thonglek
Federated learning trains a model on a centralized server using datasets distributed over a large number of edge devices. Applying federated learning ensures data privacy because it does not transfer local data from edge devices to the server. Existing federated learning algorithms assume that all deployed models share the same structure. However, it is often infeasible to distribute the same model to every edge device because of hardware limitations such as computing performance and storage space. This paper proposes a novel federated learning algorithm to aggregate information from multiple heterogeneous models. The proposed method uses weighted average ensemble to combine the outputs from each model. The weight for the ensemble is optimized using black box optimization methods. We evaluated the proposed method using diverse models and datasets and found that it can achieve comparable performance to conventional training using centralized datasets. Furthermore, we compared six different optimization methods to tune the weights for the weighted average ensemble and found that tree parzen estimator achieves the highest accuracy among the alternatives.
Presentation by Dr Steffi Friedrichs, entitled: Nanotechnology at the Crossroads of Converging Technologies: Unveiling the Future of Innovation
presented at the meeting on 'Open Innovation for Materials Modelling, Design and Manufacturing', 19th – 20th October 2023, at the Luxembourg Institute of Science & Technology.
RS 2022
Implicit material modelling using AI techniques
and big data generation
Rúben Lourenço
Supervisory team: A. Andrade-Campos, Pétia Georgieva
Doctoral Programme in Mechanical Engineering
TEMA – Centre for Mechanical Technology and Automation
Towards virtual forming and AI Implicit material modelling using AI technique...vformxsteels
RS 2022
Rúben Lourenço
Supervisory team: A. Andrade-Campos, Pétia Georgieva
Doctoral Programme in Mechanical Engineering
TEMA – Centre for Mechanical Technology and Automation
Design and validation of a heterogeneous interior notched specimen for materi...Vform Xsteels
Currently, virtual manufacturing and simulation predictions are crucial in the design and development of engineering parts. However, its reliability largely depends on the adopted constitutive model and accuracy of the governing material parameters. A complex and robust phenomenological constitutive model requires the calibration of many parameters. This is a very time-consuming task, particularly when using classical procedures, which involves many homogeneous mechanical experiments and high costs.
Parameter Identification of Swift law using a FEMU-based approach and an inno...vformxsteels
ESAFORM 2022
M. Conde1, J. Henriques1,
S. Coppieters2, A. Andrade-Campos1
1 TEMA, Department of Mechanical Engineering, University of Aveiro, Portugal
2 Department of Materials Engineering, Ghent Technology Campus, KU Leuven, Belgium
Parameter Identification of Swift law using a FEMU-based approach and an inno...vformxsteels
ESAFORM 2022
M. Conde1, J. Henriques1,
S. Coppieters2, A. Andrade-Campos1
1 TEMA, Department of Mechanical Engineering, University of Aveiro, Portugal
2 Department of Materials Engineering, Ghent Technology Campus, KU Leuven, Belgium
Federated Learning of Neural Network Models with Heterogeneous Structures.pdfKundjanasith Thonglek
Federated learning trains a model on a centralized server using datasets distributed over a large number of edge devices. Applying federated learning ensures data privacy because it does not transfer local data from edge devices to the server. Existing federated learning algorithms assume that all deployed models share the same structure. However, it is often infeasible to distribute the same model to every edge device because of hardware limitations such as computing performance and storage space. This paper proposes a novel federated learning algorithm to aggregate information from multiple heterogeneous models. The proposed method uses weighted average ensemble to combine the outputs from each model. The weight for the ensemble is optimized using black box optimization methods. We evaluated the proposed method using diverse models and datasets and found that it can achieve comparable performance to conventional training using centralized datasets. Furthermore, we compared six different optimization methods to tune the weights for the weighted average ensemble and found that tree parzen estimator achieves the highest accuracy among the alternatives.
Presentation by Dr Steffi Friedrichs, entitled: Nanotechnology at the Crossroads of Converging Technologies: Unveiling the Future of Innovation
presented at the meeting on 'Open Innovation for Materials Modelling, Design and Manufacturing', 19th – 20th October 2023, at the Luxembourg Institute of Science & Technology.
RS 2022
Implicit material modelling using AI techniques
and big data generation
Rúben Lourenço
Supervisory team: A. Andrade-Campos, Pétia Georgieva
Doctoral Programme in Mechanical Engineering
TEMA – Centre for Mechanical Technology and Automation
Towards virtual forming and AI Implicit material modelling using AI technique...vformxsteels
RS 2022
Rúben Lourenço
Supervisory team: A. Andrade-Campos, Pétia Georgieva
Doctoral Programme in Mechanical Engineering
TEMA – Centre for Mechanical Technology and Automation
Design and validation of a heterogeneous interior notched specimen for materi...Vform Xsteels
Currently, virtual manufacturing and simulation predictions are crucial in the design and development of engineering parts. However, its reliability largely depends on the adopted constitutive model and accuracy of the governing material parameters. A complex and robust phenomenological constitutive model requires the calibration of many parameters. This is a very time-consuming task, particularly when using classical procedures, which involves many homogeneous mechanical experiments and high costs.
6th International Conference on Mechanical Engineering (MEN 2023)ijccmsjournal
6th International Conference on Mechanical Engineering (MEN 2023) will provide an excellent international forum for sharing knowledge and results in theory, methodology and applications impacts and challenges of Mechanical Engineering. The conference documents practical and theoretical results which make a fundamental contribution for the development of Mechanical Engineering.
On the selection of constitutive models for realistic numerical simulationsvformxsteels
TechMA 2022
M. Conde (a), *, S. Coppieters (b), A. Andrade-Campos (a)
(a) - Centre for Mechanical Technology and Automation (TEMA), Department of Mechanical Engineering, University of Aveiro; (b) - Department of Materials Engineering, KU Leuven(a) Aveiro, Portugal; (b) – Ghent, Belgium
* – marianaconde@ua.pt
On the selection of constitutive models for realistic numerical simulationsvformxsteels
TechMA 2022
M. Conde (a), *, S. Coppieters (b), A. Andrade-Campos (a)
(a) - Centre for Mechanical Technology and Automation (TEMA), Department of Mechanical Engineering, University of Aveiro; (b) - Department of Materials Engineering, KU Leuven(a) Aveiro, Portugal; (b) – Ghent, Belgium
IDENTIFICATION OF SWIFT LAW PARAMETERS USING FEMU BY A SYNTHETIC IMAGE DIC-BA...vformxsteels
ESAFORM 2022
J. Henriquesa,*, M. Condea
, A. Andrade-Camposa
, J. Xavierb
*Corresponding author: joaodiogofh@ua.pt
aTEMA, Department of Mechanical Engineering, University of Aveiro, Campus Universitário de Santiago,
3810-193 Aveiro, Portugal
bUNIDEMI, Department of Mechanical and Industrial Engineering, NOVA School of Science and Technology,
NOVA University Lisbon, 2829-516 Caparica, Portugal
IDENTIFICATION OF SWIFT LAW PARAMETERS USING FEMU BY A SYNTHETIC IMAGE DIC-BA...vformxsteels
25th International Conference on Material Forming
Braga, Portugal, 27-29 April 2022
J. Henriquesa,*, M. Condea
, A. Andrade-Camposa
, J. Xavierb
*Corresponding author: joaodiogofh@ua.pt
aTEMA, Department of Mechanical Engineering, University of Aveiro, Campus Universitário de Santiago,
3810-193 Aveiro, Portugal
bUNIDEMI, Department of Mechanical and Industrial Engineering, NOVA School of Science and Technology,
NOVA University Lisbon, 2829-516 Caparica, Portugal
5th International Conference on Trends in Mechanical Engineering (MECE 2021)meijjournal
5th International Conference on Trends in Mechanical Engineering (MECE 2021) will provide an excellent international forum for sharing knowledge and results in theory, methodology and applications impacts and challenges of Mechanical Engineering. The conference documents practical and theoretical results which make a fundamental contribution for the development of Mechanical Engineering. The aim of the conference is to provide a platform to the researchers and practitioners from both academia as well as industry to meet and share cutting-edge development in the field.
Authors are solicited to contribute to the conference by submitting articles that illustrate research results, projects, surveying works and industrial experiences that describe significant advances in the following areas, but are not limited to.
On the topology design of an innovative heterogeneous mechanical test for mat...vformxsteels
RS 2022
On the topology design of an innovative
heterogeneous mechanical test for material
mechanical characterization
Centre for Mechanical Technology and Automation (TEMA), Department of Mechanical Engineering, University of Aveiro,
Portugal
Univ. Bretagne Sud, UMR CNRS 6027, IRDL, F-56100 Lorient, France
Mafalda Gonçalves, Sandrine Thuillier, António Andrade-Campos
Doctoral Program in Mechanical Engineering
On the topology design of an innovative heterogeneous mechanical test for mat...vformxsteels
RS2022
Mafalda Gonçalves, Sandrine Thuillier, António Andrade-Campos
Centre for Mechanical Technology and Automation (TEMA), Department of Mechanical Engineering, University of Aveiro,
Portugal
Univ. Bretagne Sud, UMR CNRS 6027, IRDL, F-56100 Lorient, France
Mafalda Gonçalves, Sandrine Thuillier, António Andrade-Campos
1
6th International Conference on Materials Science and Engineering (MSE 2022)msejjournal
6th International Conference on Materials Science and Engineering (MSE 2022) will provide an excellent international forum for sharing knowledge and results in theory, methodology and applications impacts and challenges of Mathematics and Sciences. The conference documents practical and theoretical results which make a fundamental contribution for the development of Mathematics and Sciences.
6th International Conference of Advances in Materials Science and Engineering...ijccmsjournal
6th International Conference of Advances in Materials Science and Engineering (MATE 2023) will an excellent international forum for sharing knowledge and results in theory, methodology and applications impacts and challenges of Materials Science and Engineering.
The goal of this Conference is to bring together researchers and practitioners from academia and industry to focus on Materials Science and Engineering advancements, and establishing new collaborations in these areas. Original research papers, state-of-the-art reviews are invited for publication in all areas of Materials Science and Engineering.
International Conference on Computational Science & Applications (COMSAP 2023)ijdpsjournal
International Conference on Computational Science & Applications (COMSAP 2023) Computational science is interdisciplinary fields in which mathematical models are combined with scientific computing methods to study of a wide range of problems in science and engineering. Modelling and simulation tools find increasing applications not only in fundamental research, but also in real-world design and industry applications.The goal of this conference is to bring together researchers and practitioners from academia and industry to focus on understanding modern Computationalresearch trends and applications to establishing new collaborations in these areas.
Uncertainty quantification of inversely identified plastic material behavior ...vformxsteels
M Conde, S Coppieters, A Andrade-Campos
TEMA, Department of Mechanical Engineering, University of Aveiro, Portugal
Department of Materials Engineering, Ghent Technology Campus, KU Leuven, Belgium
Uncertainty quantification of inversely identified plastic material behavior ...vformxsteels
IDDRG 2022
M Conde1,*, S Coppieters2, A Andrade-Campos1
* marianaconde@ua.pt
1 TEMA, Department of Mechanical Engineering, University of Aveiro, Portugal
2 Department of Materials Engineering, Ghent Technology Campus, KU Leuven, Belgium
International Conference on Computational Science & Applications (COMSAP 2023)ijasuc
International Conference on Computational Science & Applications (COMSAP 2023) Computational science is interdisciplinary fields in which mathematical models are combined with scientific computing methods to study of a wide range of problems in science and engineering. Modelling and simulation tools find increasing applications not only in fundamental research, but also in real-world design and industry applications.The goal of this conference is to bring together researchers and practitioners from academia and industry to focus on understanding modern Computationalresearch trends and applications to establishing new collaborations in these areas.
Identification of anisotropic yield functions using an information-rich tensi...vformxsteels
Yi Zhang1, António Andrade-Campos2, Sam Coppieters1
1 Department of Materials Engineering, KU Leuven
2 Department of Mechanical Engineering, University of Aveiro, 3810-193
Aveiro, Portugal
More Related Content
Similar to Process-informed material model selection
6th International Conference on Mechanical Engineering (MEN 2023)ijccmsjournal
6th International Conference on Mechanical Engineering (MEN 2023) will provide an excellent international forum for sharing knowledge and results in theory, methodology and applications impacts and challenges of Mechanical Engineering. The conference documents practical and theoretical results which make a fundamental contribution for the development of Mechanical Engineering.
On the selection of constitutive models for realistic numerical simulationsvformxsteels
TechMA 2022
M. Conde (a), *, S. Coppieters (b), A. Andrade-Campos (a)
(a) - Centre for Mechanical Technology and Automation (TEMA), Department of Mechanical Engineering, University of Aveiro; (b) - Department of Materials Engineering, KU Leuven(a) Aveiro, Portugal; (b) – Ghent, Belgium
* – marianaconde@ua.pt
On the selection of constitutive models for realistic numerical simulationsvformxsteels
TechMA 2022
M. Conde (a), *, S. Coppieters (b), A. Andrade-Campos (a)
(a) - Centre for Mechanical Technology and Automation (TEMA), Department of Mechanical Engineering, University of Aveiro; (b) - Department of Materials Engineering, KU Leuven(a) Aveiro, Portugal; (b) – Ghent, Belgium
IDENTIFICATION OF SWIFT LAW PARAMETERS USING FEMU BY A SYNTHETIC IMAGE DIC-BA...vformxsteels
ESAFORM 2022
J. Henriquesa,*, M. Condea
, A. Andrade-Camposa
, J. Xavierb
*Corresponding author: joaodiogofh@ua.pt
aTEMA, Department of Mechanical Engineering, University of Aveiro, Campus Universitário de Santiago,
3810-193 Aveiro, Portugal
bUNIDEMI, Department of Mechanical and Industrial Engineering, NOVA School of Science and Technology,
NOVA University Lisbon, 2829-516 Caparica, Portugal
IDENTIFICATION OF SWIFT LAW PARAMETERS USING FEMU BY A SYNTHETIC IMAGE DIC-BA...vformxsteels
25th International Conference on Material Forming
Braga, Portugal, 27-29 April 2022
J. Henriquesa,*, M. Condea
, A. Andrade-Camposa
, J. Xavierb
*Corresponding author: joaodiogofh@ua.pt
aTEMA, Department of Mechanical Engineering, University of Aveiro, Campus Universitário de Santiago,
3810-193 Aveiro, Portugal
bUNIDEMI, Department of Mechanical and Industrial Engineering, NOVA School of Science and Technology,
NOVA University Lisbon, 2829-516 Caparica, Portugal
5th International Conference on Trends in Mechanical Engineering (MECE 2021)meijjournal
5th International Conference on Trends in Mechanical Engineering (MECE 2021) will provide an excellent international forum for sharing knowledge and results in theory, methodology and applications impacts and challenges of Mechanical Engineering. The conference documents practical and theoretical results which make a fundamental contribution for the development of Mechanical Engineering. The aim of the conference is to provide a platform to the researchers and practitioners from both academia as well as industry to meet and share cutting-edge development in the field.
Authors are solicited to contribute to the conference by submitting articles that illustrate research results, projects, surveying works and industrial experiences that describe significant advances in the following areas, but are not limited to.
On the topology design of an innovative heterogeneous mechanical test for mat...vformxsteels
RS 2022
On the topology design of an innovative
heterogeneous mechanical test for material
mechanical characterization
Centre for Mechanical Technology and Automation (TEMA), Department of Mechanical Engineering, University of Aveiro,
Portugal
Univ. Bretagne Sud, UMR CNRS 6027, IRDL, F-56100 Lorient, France
Mafalda Gonçalves, Sandrine Thuillier, António Andrade-Campos
Doctoral Program in Mechanical Engineering
On the topology design of an innovative heterogeneous mechanical test for mat...vformxsteels
RS2022
Mafalda Gonçalves, Sandrine Thuillier, António Andrade-Campos
Centre for Mechanical Technology and Automation (TEMA), Department of Mechanical Engineering, University of Aveiro,
Portugal
Univ. Bretagne Sud, UMR CNRS 6027, IRDL, F-56100 Lorient, France
Mafalda Gonçalves, Sandrine Thuillier, António Andrade-Campos
1
6th International Conference on Materials Science and Engineering (MSE 2022)msejjournal
6th International Conference on Materials Science and Engineering (MSE 2022) will provide an excellent international forum for sharing knowledge and results in theory, methodology and applications impacts and challenges of Mathematics and Sciences. The conference documents practical and theoretical results which make a fundamental contribution for the development of Mathematics and Sciences.
6th International Conference of Advances in Materials Science and Engineering...ijccmsjournal
6th International Conference of Advances in Materials Science and Engineering (MATE 2023) will an excellent international forum for sharing knowledge and results in theory, methodology and applications impacts and challenges of Materials Science and Engineering.
The goal of this Conference is to bring together researchers and practitioners from academia and industry to focus on Materials Science and Engineering advancements, and establishing new collaborations in these areas. Original research papers, state-of-the-art reviews are invited for publication in all areas of Materials Science and Engineering.
International Conference on Computational Science & Applications (COMSAP 2023)ijdpsjournal
International Conference on Computational Science & Applications (COMSAP 2023) Computational science is interdisciplinary fields in which mathematical models are combined with scientific computing methods to study of a wide range of problems in science and engineering. Modelling and simulation tools find increasing applications not only in fundamental research, but also in real-world design and industry applications.The goal of this conference is to bring together researchers and practitioners from academia and industry to focus on understanding modern Computationalresearch trends and applications to establishing new collaborations in these areas.
Uncertainty quantification of inversely identified plastic material behavior ...vformxsteels
M Conde, S Coppieters, A Andrade-Campos
TEMA, Department of Mechanical Engineering, University of Aveiro, Portugal
Department of Materials Engineering, Ghent Technology Campus, KU Leuven, Belgium
Uncertainty quantification of inversely identified plastic material behavior ...vformxsteels
IDDRG 2022
M Conde1,*, S Coppieters2, A Andrade-Campos1
* marianaconde@ua.pt
1 TEMA, Department of Mechanical Engineering, University of Aveiro, Portugal
2 Department of Materials Engineering, Ghent Technology Campus, KU Leuven, Belgium
International Conference on Computational Science & Applications (COMSAP 2023)ijasuc
International Conference on Computational Science & Applications (COMSAP 2023) Computational science is interdisciplinary fields in which mathematical models are combined with scientific computing methods to study of a wide range of problems in science and engineering. Modelling and simulation tools find increasing applications not only in fundamental research, but also in real-world design and industry applications.The goal of this conference is to bring together researchers and practitioners from academia and industry to focus on understanding modern Computationalresearch trends and applications to establishing new collaborations in these areas.
Similar to Process-informed material model selection (20)
Identification of anisotropic yield functions using an information-rich tensi...vformxsteels
Yi Zhang1, António Andrade-Campos2, Sam Coppieters1
1 Department of Materials Engineering, KU Leuven
2 Department of Mechanical Engineering, University of Aveiro, 3810-193
Aveiro, Portugal
Independent Validation of Generic Specimen Design for Inverse Identification ...vformxsteels
Yi Zhanga , S. Coppietersa,*, S. Gothivarekara, A. Van de Veldea , D. Debruynea
a Department of Materials Engineering, KU Leuven, Technology Campus Ghent, 9000 Gent, Belgium
Belgium,19 March 2021
Identification of the large strain flow curve of high strength steel via the ...vformxsteels
Niels Vancraeynest1, Steven Cooreman2 and Sam Coppieters1
1Elooi lab, Department of Materials Engineering, KU Leuven
2 Applications & Solutions department, ArcelorMittal Global R&D Gent
On the comparison of heterogeneous mechanical tests for sheet metal character...vformxsteels
IDDRG 2022
M. Gonçalves, M.G. Oliveira, S. Thuillier, A. Andrade-Campos
Centre for Mechanical Technology and Automation (TEMA),
Department of Mechanical Engineering
University of Aveiro, Portugal
Univ. Bretagne Sud, UMR CNRS 6027, IRDL
F-56100 Lorient, France
1
A nonlinear topology-based optimization approach for the design of a heteroge...vformxsteels
TechMA 2022
Mafalda Gonçalves, Sandrine Thuillier, António Andrade-Campos
Centre for Mechanical Technology and Automation, Department of Mechanical Engineering, University of Aveiro, Portugal
Univ. Bretagne Sud, UMR CNRS 6027, IRDL, F-56100 Lorient, France
On the design of a heterogeneous mechanical test using a nonlinear topology o...vformxsteels
ESAFORM 2022
M. Gonçalves, A. Andrade-Campos and S. Thuillier
25th International Conference on Material Forming
27-29th April 2022
Braga, Portugal
Centre for Mechanical Tecnology and Automation, Department of Mechanical Engineering, University of Aveiro, Portugal
Univ. Bretagne Sud, UMR CNRS 6027, IRDL, F-56100 Lorient, France
On the inverse identification of sheet metal mechanical behaviour using a het...vformxsteels
ESAFORM 2023
João Henriquesa,*, A. Andrade-Camposa
, J. Xavierb
aTEMA, Department of Mechanical Engineering, University of Aveiro, Campus
Universitário de Santiago, 3810-193 Aveiro, Portugal
bUNIDEMI, Department of Mechanical and Industrial Engineering, NOVA School of
Science and Technology, NOVA University Lisbon, 2825-149 Lisbon, Portugal
On the comparison of heterogeneous mechanical tests for sheet metal character...vformxsteels
ESAFORM 2023
M. Gonçalves, M.G. Oliveira, S. Thuillier, A. Andrade-Campos
Centre for Mechanical Technology and Automation (TEMA),
Department of Mechanical Engineering
University of Aveiro, Portugal
Univ. Bretagne Sud, UMR CNRS 6027, IRDL
F-56100 Lorient, France
The Virtual Fields Method to indirectly train ANNs for implicit constitutive ...vformxsteels
ESAFORM 2022
25th International Conference on Material Forming
R. Lourenço1,a, A. Andrade-Campos1,b, P. Georgieva2,c
1Dept. of Mechanical Engineering
Centre for Mechanical Technology and Automation, University of Aveiro, Portugal
2Dept. of Electronics Telecommunications and Informatics
Institute of Electronics and Informatics Engineering, University of Aveiro, Portugal
a
rubenl@ua.pt, bgilac@ua.pt, cpetia@ua.pt
27-29 April, Braga, Portugal
On the power of virtual experimentation in MT2.0:a VFORM-xSteels outlookvformxsteels
Sam Coppieters, A. Gil Andrade-Campos et al.
MatchID Global User Meeting
On the power of virtual experimentation in MT2.0 : a VFORM outlook
22 February2023 | Southampton, UK
On the comparison of heterogeneous mechanical tests for sheet metal character...vformxsteels
ESAFORM 2023
M. Gonçalves, M.G. Oliveira, S. Thuillier, A. Andrade-Campos 1 1,2 2 1
Centre for Mechanical Technology and Automation (TEMA),
Department of Mechanical Engineering
University of Aveiro, Portugal
Univ. Bretagne Sud, UMR CNRS 6027, IRDL
F-56100 Lorient, France
1
Process-informed material model selectionvformxsteels
ESAFORM 2023
Mariana Conde, Sam Coppieters, António Andrade-Campos
Department of Mechanical Engineering, TEMA - Centre for Mechanical Technology and Automation, LASI – Intelligent Systems Associate Laboratory, University of Aveiro, Portugal
Department of Materials Engineering, KU Leuven, Belgium
A nonlinear topology-based optimization approach for the design of a heteroge...vformxsteels
TechMA 2022
Mafalda Gonçalves, Sandrine Thuillier, António Andrade-Campos
Centre for Mechanical Technology and Automation, Department of Mechanical Engineering, University of Aveiro, Portugal
Univ. Bretagne Sud, UMR CNRS 6027, IRDL, F-56100 Lorient, France
On the topology design of a mechanical heterogeneous specimen using geometric...vformxsteels
IDDRG 2022
M. Gonçalves, S. Thuillier, A. Andrade-Campos
Centre for Mechanical Technology and Automation (TEMA), Department of Mechanical Engineering,
University of Aveiro, Portugal
Univ. Bretagne Sud, UMR CNRS 6027, IRDL, F-56100 Lorient, France
41st International Deep Drawing Research Group Conference, 6 - 10 June 2022, Lorient, France
On the design of a heterogeneous mechanical test using a nonlinear topology o...vformxsteels
ESAFORM 2022
M. Gonçalves, A. Andrade-Campos and S. Thuillier
25th International Conference on Material Forming
27-29th April 2022
Braga, Portugal
Centre for Mechanical Tecnology and Automation, Department of Mechanical Engineering, University of Aveiro, Portugal
Univ. Bretagne Sud, UMR CNRS 6027, IRDL, F-56100 Lorient, France
About
Indigenized remote control interface card suitable for MAFI system CCR equipment. Compatible for IDM8000 CCR. Backplane mounted serial and TCP/Ethernet communication module for CCR remote access. IDM 8000 CCR remote control on serial and TCP protocol.
• Remote control: Parallel or serial interface.
• Compatible with MAFI CCR system.
• Compatible with IDM8000 CCR.
• Compatible with Backplane mount serial communication.
• Compatible with commercial and Defence aviation CCR system.
• Remote control system for accessing CCR and allied system over serial or TCP.
• Indigenized local Support/presence in India.
• Easy in configuration using DIP switches.
Technical Specifications
Indigenized remote control interface card suitable for MAFI system CCR equipment. Compatible for IDM8000 CCR. Backplane mounted serial and TCP/Ethernet communication module for CCR remote access. IDM 8000 CCR remote control on serial and TCP protocol.
Key Features
Indigenized remote control interface card suitable for MAFI system CCR equipment. Compatible for IDM8000 CCR. Backplane mounted serial and TCP/Ethernet communication module for CCR remote access. IDM 8000 CCR remote control on serial and TCP protocol.
• Remote control: Parallel or serial interface
• Compatible with MAFI CCR system
• Copatiable with IDM8000 CCR
• Compatible with Backplane mount serial communication.
• Compatible with commercial and Defence aviation CCR system.
• Remote control system for accessing CCR and allied system over serial or TCP.
• Indigenized local Support/presence in India.
Application
• Remote control: Parallel or serial interface.
• Compatible with MAFI CCR system.
• Compatible with IDM8000 CCR.
• Compatible with Backplane mount serial communication.
• Compatible with commercial and Defence aviation CCR system.
• Remote control system for accessing CCR and allied system over serial or TCP.
• Indigenized local Support/presence in India.
• Easy in configuration using DIP switches.
CFD Simulation of By-pass Flow in a HRSG module by R&R Consult.pptxR&R Consult
CFD analysis is incredibly effective at solving mysteries and improving the performance of complex systems!
Here's a great example: At a large natural gas-fired power plant, where they use waste heat to generate steam and energy, they were puzzled that their boiler wasn't producing as much steam as expected.
R&R and Tetra Engineering Group Inc. were asked to solve the issue with reduced steam production.
An inspection had shown that a significant amount of hot flue gas was bypassing the boiler tubes, where the heat was supposed to be transferred.
R&R Consult conducted a CFD analysis, which revealed that 6.3% of the flue gas was bypassing the boiler tubes without transferring heat. The analysis also showed that the flue gas was instead being directed along the sides of the boiler and between the modules that were supposed to capture the heat. This was the cause of the reduced performance.
Based on our results, Tetra Engineering installed covering plates to reduce the bypass flow. This improved the boiler's performance and increased electricity production.
It is always satisfying when we can help solve complex challenges like this. Do your systems also need a check-up or optimization? Give us a call!
Work done in cooperation with James Malloy and David Moelling from Tetra Engineering.
More examples of our work https://www.r-r-consult.dk/en/cases-en/
Saudi Arabia stands as a titan in the global energy landscape, renowned for its abundant oil and gas resources. It's the largest exporter of petroleum and holds some of the world's most significant reserves. Let's delve into the top 10 oil and gas projects shaping Saudi Arabia's energy future in 2024.
Explore the innovative world of trenchless pipe repair with our comprehensive guide, "The Benefits and Techniques of Trenchless Pipe Repair." This document delves into the modern methods of repairing underground pipes without the need for extensive excavation, highlighting the numerous advantages and the latest techniques used in the industry.
Learn about the cost savings, reduced environmental impact, and minimal disruption associated with trenchless technology. Discover detailed explanations of popular techniques such as pipe bursting, cured-in-place pipe (CIPP) lining, and directional drilling. Understand how these methods can be applied to various types of infrastructure, from residential plumbing to large-scale municipal systems.
Ideal for homeowners, contractors, engineers, and anyone interested in modern plumbing solutions, this guide provides valuable insights into why trenchless pipe repair is becoming the preferred choice for pipe rehabilitation. Stay informed about the latest advancements and best practices in the field.
Overview of the fundamental roles in Hydropower generation and the components involved in wider Electrical Engineering.
This paper presents the design and construction of hydroelectric dams from the hydrologist’s survey of the valley before construction, all aspects and involved disciplines, fluid dynamics, structural engineering, generation and mains frequency regulation to the very transmission of power through the network in the United Kingdom.
Author: Robbie Edward Sayers
Collaborators and co editors: Charlie Sims and Connor Healey.
(C) 2024 Robbie E. Sayers
Immunizing Image Classifiers Against Localized Adversary Attacksgerogepatton
This paper addresses the vulnerability of deep learning models, particularly convolutional neural networks
(CNN)s, to adversarial attacks and presents a proactive training technique designed to counter them. We
introduce a novel volumization algorithm, which transforms 2D images into 3D volumetric representations.
When combined with 3D convolution and deep curriculum learning optimization (CLO), itsignificantly improves
the immunity of models against localized universal attacks by up to 40%. We evaluate our proposed approach
using contemporary CNN architectures and the modified Canadian Institute for Advanced Research (CIFAR-10
and CIFAR-100) and ImageNet Large Scale Visual Recognition Challenge (ILSVRC12) datasets, showcasing
accuracy improvements over previous techniques. The results indicate that the combination of the volumetric
input and curriculum learning holds significant promise for mitigating adversarial attacks without necessitating
adversary training.
Sachpazis:Terzaghi Bearing Capacity Estimation in simple terms with Calculati...Dr.Costas Sachpazis
Terzaghi's soil bearing capacity theory, developed by Karl Terzaghi, is a fundamental principle in geotechnical engineering used to determine the bearing capacity of shallow foundations. This theory provides a method to calculate the ultimate bearing capacity of soil, which is the maximum load per unit area that the soil can support without undergoing shear failure. The Calculation HTML Code included.
Hierarchical Digital Twin of a Naval Power SystemKerry Sado
A hierarchical digital twin of a Naval DC power system has been developed and experimentally verified. Similar to other state-of-the-art digital twins, this technology creates a digital replica of the physical system executed in real-time or faster, which can modify hardware controls. However, its advantage stems from distributing computational efforts by utilizing a hierarchical structure composed of lower-level digital twin blocks and a higher-level system digital twin. Each digital twin block is associated with a physical subsystem of the hardware and communicates with a singular system digital twin, which creates a system-level response. By extracting information from each level of the hierarchy, power system controls of the hardware were reconfigured autonomously. This hierarchical digital twin development offers several advantages over other digital twins, particularly in the field of naval power systems. The hierarchical structure allows for greater computational efficiency and scalability while the ability to autonomously reconfigure hardware controls offers increased flexibility and responsiveness. The hierarchical decomposition and models utilized were well aligned with the physical twin, as indicated by the maximum deviations between the developed digital twin hierarchy and the hardware.
Final project report on grocery store management system..pdfKamal Acharya
In today’s fast-changing business environment, it’s extremely important to be able to respond to client needs in the most effective and timely manner. If your customers wish to see your business online and have instant access to your products or services.
Online Grocery Store is an e-commerce website, which retails various grocery products. This project allows viewing various products available enables registered users to purchase desired products instantly using Paytm, UPI payment processor (Instant Pay) and also can place order by using Cash on Delivery (Pay Later) option. This project provides an easy access to Administrators and Managers to view orders placed using Pay Later and Instant Pay options.
In order to develop an e-commerce website, a number of Technologies must be studied and understood. These include multi-tiered architecture, server and client-side scripting techniques, implementation technologies, programming language (such as PHP, HTML, CSS, JavaScript) and MySQL relational databases. This is a project with the objective to develop a basic website where a consumer is provided with a shopping cart website and also to know about the technologies used to develop such a website.
This document will discuss each of the underlying technologies to create and implement an e- commerce website.
Hybrid optimization of pumped hydro system and solar- Engr. Abdul-Azeez.pdffxintegritypublishin
Advancements in technology unveil a myriad of electrical and electronic breakthroughs geared towards efficiently harnessing limited resources to meet human energy demands. The optimization of hybrid solar PV panels and pumped hydro energy supply systems plays a pivotal role in utilizing natural resources effectively. This initiative not only benefits humanity but also fosters environmental sustainability. The study investigated the design optimization of these hybrid systems, focusing on understanding solar radiation patterns, identifying geographical influences on solar radiation, formulating a mathematical model for system optimization, and determining the optimal configuration of PV panels and pumped hydro storage. Through a comparative analysis approach and eight weeks of data collection, the study addressed key research questions related to solar radiation patterns and optimal system design. The findings highlighted regions with heightened solar radiation levels, showcasing substantial potential for power generation and emphasizing the system's efficiency. Optimizing system design significantly boosted power generation, promoted renewable energy utilization, and enhanced energy storage capacity. The study underscored the benefits of optimizing hybrid solar PV panels and pumped hydro energy supply systems for sustainable energy usage. Optimizing the design of solar PV panels and pumped hydro energy supply systems as examined across diverse climatic conditions in a developing country, not only enhances power generation but also improves the integration of renewable energy sources and boosts energy storage capacities, particularly beneficial for less economically prosperous regions. Additionally, the study provides valuable insights for advancing energy research in economically viable areas. Recommendations included conducting site-specific assessments, utilizing advanced modeling tools, implementing regular maintenance protocols, and enhancing communication among system components.
1. Process-informed material
model selection
Mariana Conde1,*, Sam Coppieters2, António Andrade-Campos1
1Department of Mechanical Engineering, TEMA - Centre for Mechanical
Technology and Automation, LASI – Intelligent Systems Associate
Laboratory, University of Aveiro, Portugal
2Department of Materials Engineering, KU Leuven, Belgium
*marianaconde@ua.pt
2. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Introduction and framework
Virtualization of processes
Virtualization and
realistic simulations
• Adequate constitutive
model
• Accurately identified
parameters
Development and
manufacturing
• Precise results
• No delays
• No waste
Industries
• High quality
• Low costs
• High efficiency
Images source: https://unsplash.com/photos/jHZ70nRk7Ns ; https://unsplash.com/photos/SVUqHTVyn6w ; https://unsplash.com/photos/t9DooibgMEk
3. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Introduction and framework
Virtualization of processes
Virtualization and
realistic simulations
• Adequate constitutive
model
• Accurately identified
parameters
Development and
manufacturing
• Precise results
• No delays
• No waste
Industries
• High quality
• Low costs
• High efficiency
Images source: https://unsplash.com/photos/jHZ70nRk7Ns ; https://unsplash.com/photos/SVUqHTVyn6w ; https://unsplash.com/photos/t9DooibgMEk
4. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Introduction and framework
Virtualization of processes
Virtualization and
realistic simulations
• Adequate constitutive
model
• Accurately identified
parameters
Development and
manufacturing
• Precise results
• No delays
• No waste
Industries
• High quality
• Low costs
• High efficiency
Images source: https://unsplash.com/photos/jHZ70nRk7Ns ; https://unsplash.com/photos/SVUqHTVyn6w ; https://unsplash.com/photos/t9DooibgMEk
5. Isotropic
hardening
laws
Yield
functions
International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
Kinematic
hardening
laws
Damage
models
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Introduction and framework
Material constitutive models in the literature
6. Isotropic
hardening
laws
Yield
functions
International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
Kinematic
hardening
laws
Damage
models
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Introduction and framework
Material constitutive models in the literature
7. Isotropic
hardening
laws
Yield
functions
International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
Kinematic
hardening
laws
Damage
models
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Introduction and framework
Material constitutive models in the literature
12. Isotropic
hardening
laws
Yield
functions
International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
Kinematic
hardening
laws
Damage
models
Introduction and framework
Material constitutive models in the literature
More than 1300possible
combinations of models
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
13. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Introduction and framework
Material constitutive models selection in the literature
Brute-force
Direct comparison
Numerical and experimental data
Model calibration
Several different models
Laboured task
Requires specialized knowledge
Time consuming task
Experimental data generation and
analysis
Non-precise selection strategy
Geometrical measurement, load
displacement curve or yield loci plot
Limited analysis
Model, material, mechanical phenomenon
and mechanical process
Ben-Elechi et al. 2021; Chatziioannou et al. 2021; Prakash et al. 2020; Kilic et al. 2018; Hou et al. 2017; Barros et al. 2016; Lin et al. 2020; Moreira et al. 2014; Oliveira et al. 2007; Laurent et
al. 2009; Nedoushan et al. 2014; Tuo et al. 2021.
14. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Introduction and framework
Material constitutive models selection in the literature
Automatic
selection tool
Direct comparison
Numerical and experimental data
Model calibration
Several different models
Laboured task
Requires specialized knowledge
Time consuming task
Experimental data generation and
analysis
Non-precise selection strategy
Geometrical measurement, load
displacement curve or yield loci plot
Limited analysis
Model, material, mechanical phenomenon
and mechanical process
Ben-Elechi et al. 2021; Chatziioannou et al. 2021; Prakash et al. 2020; Kilic et al. 2018; Hou et al. 2017; Barros et al. 2016; Lin et al. 2020; Moreira et al. 2014; Oliveira et al. 2007; Laurent et
al. 2009; Nedoushan et al. 2014; Tuo et al. 2021.
15. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Application of the proposed solution
Unknown numerical material behaviour
How to model the material
behavior?
What constitutive models?
What material parameters?
16. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Application of the proposed solution
Unknown numerical material behaviour
• DP600 dual-phase steel
• AA3104 aluminium alloy
• Material parameters from literature
17. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Application of the proposed solution
Constitutive models and materials
DP600
Elastic
properties
E [Gpa] ν
210.000 0.300
Swift law K [Mpa] 𝜀0 n
979.460 0.00535 0.194
Voce law 𝜎y0 Q b
815.600 407.922 7.869
Yld2000-2d
criterion
𝛼1 𝛼2 𝛼3 𝛼4 𝛼5 𝛼6 𝛼7 𝛼8
a
1.011 0.964 1.191 0.995 1.010 1.018 0.977 0.935 6.00
A-F model C [Mpa] 𝛾
28896.000 121.000
18. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Application of the proposed solution
Constitutive models and materials
AA3104
Elastic
properties
E [Gpa] ν
68.950 0.330
Swift law K [Mpa] 𝜀0 n
363.128 0.000229 0.0275
Voce law 𝜎y0 Q b
351.260 62.400 27.205
Yld2000-2d
criterion
𝛼1 𝛼2 𝛼3 𝛼4 𝛼5 𝛼6 𝛼7 𝛼8
a
0.594 1.177 0.818 0.892 0.967 0.627 0.947 1.152 8.00
A-F model C [Mpa] 𝛾
22885.000 400.000
19. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Application of the proposed solution
Unknown numerical material behaviour
How to get more accuracy in
simulations?
What constitutive models
should I use to improve the
calibration?
Is kinematic hardening
relevant? Or anisotropy?
20. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Proposed solution
Process-informed material model selection
Sheet metal forming
simulation
Selected
constitutive
models
Material
parameters
Simulation
specifications
Measurements
of interest/critical
for the process
ANOVA analysis
Constitute models
importance ranking
Mechanical
process
configuration
Constitutive models (UMMDp)
21. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Proposed solution
Process-informed material model selection
Sheet metal forming
simulation
Selected
constitutive
models
Material
parameters
Simulation
specifications
Measurements
of interest/critical
for the process
ANOVA analysis
Constitute models
importance ranking
Mechanical
process
configuration
Constitutive models (UMMDp)
22. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Proposed solution
Process-informed material model selection
Sheet metal forming
simulation
Selected
constitutive
models
Material
parameters
Simulation
specifications
Measurements
of interest/critical
for the process
ANOVA analysis
Constitute models
importance ranking
Mechanical
process
configuration
Constitutive models (UMMDp)
23. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Proposed solution
Process-informed material model selection
Sheet metal forming
simulation
Selected
constitutive
models
Material
parameters
Simulation
specifications
Measurements
of interest/critical
for the process
ANOVA analysis
Constitute models
importance ranking
Mechanical
process
configuration
Constitutive models (UMMDp)
24. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Proposed solution
Process-informed material model selection
Sheet metal forming
simulation
Selected
constitutive
models
Material
parameters
Simulation
specifications
Measurements
of interest/critical
for the process
ANOVA analysis
Constitute models
importance ranking
Mechanical
process
configuration
Constitutive models (UMMDp)
25. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Proposed solution
Process-informed material model selection
Sheet metal forming
simulation
Selected
constitutive
models
Material
parameters
Simulation
specifications
Measurements
of interest/critical
for the process
ANOVA analysis
Constitute models
importance ranking
Mechanical
process
configuration
Constitutive models (UMMDp)
26. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Proposed solution
Process-informed material model selection
Sheet metal forming
simulation
Selected
constitutive
models
Material
parameters
Simulation
specifications
Measurements
of interest/critical
for the process
ANOVA analysis
Constitute models
importance ranking
Mechanical
process
configuration
Constitutive models (UMMDp)
27. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Proposed solution
Process-informed material model selection
Sheet metal forming
simulation
Selected
constitutive
models
Material
parameters
Simulation
specifications
Measurements
of interest/critical
for the process
ANOVA analysis
Constitute models
importance ranking
Mechanical
process
configuration
Constitutive models (UMMDp)
28. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Proposed solution
Process-informed material model selection
Sheet metal forming
simulation
Selected
constitutive
models
Material
parameters
Simulation
specifications
Measurements
of interest/critical
for the process
ANOVA analysis
Constitute models
importance ranking
Mechanical
process
configuration
Constitutive models (UMMDp)
29. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Implementation
Mechanical process configuration
Hole expansion test configuration
Blank with 0.8 mm thickness
R12
R12
55
50
Punch
Die
35
150
30. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Implementation
Simulation specifications
Abaqus/Standard software
Blank: 3D deformable shell
revolution
Tools: 3D analytical rigid shell
revolution
R12
R12
55
50
Punch
Die
31. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Implementation
Simulation specifications
Step-1:
Punch with displacement
condition
Blank fixed in outer edge
Die fixed
Punch
Die
32. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Implementation
Simulation specifications
Step-1:
Punch with displacement
condition
Blank fixed in outer edge
Die fixed
Punch
Die
33. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Implementation
Simulation specifications
Step-2:
Tools release
Springback observation
Punch
Die
34. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Implementation
Simulation specifications
Structured mesh
6400 elements
9 integration points along
thickness
S4R (4-node shell) elements
with reduced integration
35. Type of
constitutive
model
Forming
simulation
observable
International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Implementation
ANOVA approach
ANOVA
Independent variables (groups):
Isotropic hardening law
Yield criterion
Kinematic hardening law
Dependent variables:
Hole’s circularity
Maximum punch force
Springback factor
36. Type of
constitutive
model
Forming
simulation
observable
International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Implementation
ANOVA approach
ANOVA
The null hypothesis is that there is no difference among the groups’ means
The alternative hypothesis is that the averages are not all equal
If any group means is significantly different from the overall mean, the null
hypothesis is rejected. This is observed with the p-value
37. Type of
constitutive
model
Forming
simulation
observable
International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Implementation
ANOVA approach
ANOVA
The p-value is the probability of obtaining the observed results, assuming that
the null hypothesis is true
A p-value lower than 0.05 considers the statistical meaning of the analysed
group
The smaller the p-value is, the more significant is the result
38. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Implementation
3-way ANOVA analysis
Run Isotropic hardening law Yield function Kinematic hardening law
1 Voce’s law von Mises Not considered
2 Voce’s law von Mises A-F model
3 Voce’s law Yld2000-2D Not considered
4 Voce’s law Yld2000-2D A-F model
5 Swift’s law von Mises Not considered
6 Swift’s law von Mises A-F model
7 Swift’s law Yld2000-2D Not considered
8 Swift’s law Yld2000-2D A-F model
39. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Results
Simulations’ output Run 1 2 3 4 5 6 7 8
IHL V V V V S S S S
YF vM vM Y2000 Y2000 vM vM Y2000 Y2000
KHL None A-F None A-F None A-F None A-F
40. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
Factors Hole’s
circularity p-
value
Maximum
punch force p-
value
Springback
factor p-value
p-value
average
Ranking
DP600
Isotropic hardening law 7.131E-1 1.078E-8 2.534E-7 2.377E-1 2
Yield function 2.342E-4 1.436E-2 9.715E-1 3.287E-1 3
Kinematic hardening law 1.282E-1 8.716E-8 1.444E-6 4.274E-2 1
AA3104
Isotropic hardening law 2.020E-1 3.099E-4 9.909E-6 6.743E-2 2
Yield function 6.778E-4 8.624E-2 1.037E-5 2.898E-2 1
Kinematic hardening law 4.913E-1 2.881E-4 1.569E-5 1.639E-1 3
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Results
ANOVA analysis
41. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Results
DP600 Strain path changes
44 39
35
18
42. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Results
AA3104 Strain path changes
44 39
35
18
43. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
Factors Hole’s
circularity p-
value
Maximum
punch force p-
value
Springback
factor p-value
p-value
average
Ranking
DP600
Isotropic hardening law 7.131E-1 1.078E-8 2.534E-7 2.377E-1 2
Yield function 2.342E-4 1.436E-2 9.715E-1 3.287E-1 3
Kinematic hardening law 1.282E-1 8.716E-8 1.444E-6 4.274E-2 1
AA3104
Isotropic hardening law 2.020E-1 3.099E-4 9.909E-6 6.743E-2 2
Yield function 6.778E-4 8.624E-2 1.037E-5 2.898E-2 1
Kinematic hardening law 4.913E-1 2.881E-4 1.569E-5 1.639E-1 3
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Results
ANOVA analysis
44. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Results
Materials anisotropic behaviour
45. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
• A process-informed material constitutive model comparison
and selection strategy was proposed
• ANOVA was used to find a relation between the constitutive
models and the measurements of interest in a forming
simulation
• A model’s importance ranking was established based on the p-
values
• This information can conduct the model calibration procedure
in a more efficient way
• This methodology is limited to the process and material used
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Conclusions
Overall results
46. International ESAFORM Conference on Material Forming, April 19-21 2023, Kraków, Poland
• The hole expansion test was studied with a dual-phase steel
and an aluminium alloy
• For the steel, the most important model type was the
kinematic hardening law and the least important was the yield
function
• For the aluminum, the most important was the yield function,
whereas the least important was the kinematic hardening law
• This was expected by empirical knowledge and this automatic
strategy confirmed it
M. Conde, S. Coppieters, A. Andrade-Campos, Process-informed material model selection
Conclusions
Specific results
47. Process-informed material
model selection
Mariana Conde1,*, Sam Coppieters2, António Andrade-Campos1
1Department of Mechanical Engineering, TEMA - Centre for Mechanical
Technology and Automation, LASI – Intelligent Systems Associate
Laboratory, University of Aveiro, Portugal
2Department of Materials Engineering, KU Leuven, Belgium
*marianaconde@ua.pt
Editor's Notes
Demand of industries quality, low costs and efficiency
The development and manufacturing processes should have precise results, no delays and no waste
Virtualization and realistic simulation are required and for that it is necessary an adequate constitutive model and accurately identified parameters
Regarding the constitutive models, several models have been proposed in the literature (give examples of types,…)
Regarding the constitutive models, several models have been proposed in the literature (give examples of types,…)
Regarding the constitutive models, several models have been proposed in the literature (give examples of types,…)
Regarding the constitutive models, several models have been proposed in the literature (give examples of types,…)
Some models account for different types of mech phenomena such as Bauschinger effect, TRIP, springback,…
Some models account for different types of mech phenomena such as Bauschinger effect, springback, TRIP,…
Some models account for different types of mech phenomena such as Ratcheting, twinning,…
One thousand and three hundred combinations of models
Strategies: brute-force by comparing experimental data and find which is more adequate for a specific material and process mainly based on geometrical measurements [1], [13]–[22] and stress-strain curves or load-displacement curves and yield loci [1], [13], [15]–[18], [20]–[23]
Time-consuming-> mech experiments, model calibration, simulation and validation of mech process
Automatic&flexile tool is missing in industry and sceintific comunities
Strategies: brute-force by comparing experimental data and find which is more adequate for a specific material and process mainly based on geometrical measurements [1], [13]–[22] and stress-strain curves or load-displacement curves and yield loci [1], [13], [15]–[18], [20]–[23]
Time-consuming-> mech experiments, model calibration, simulation and validation of mech process
Automatic&flexile tool is missing in industry and sceintific comunities
The solution that we want to propose is a tool that will help simulation software users with unknown numerical material behaviour.
For instance the user wants to simulate a forming process and asks himself: How ? …? …?
He can start by looking for some models and general parameters in the literature for the material is working with.
The parameters were not calibrated exactly for the material he’s working with, but it can be adequate to detect the present mechanical phenomena.
So he can find the elastic properties, swift law, voce law, Yld2000-2d and Armstrong-Frederick model parameters for the DP600 steel.
And the same models for the aluminium alloy and their parameters
But how to get more accuracy in simulation? …? …?
This is where the proposed solution takes place.
Thus, we have a constitutive models data base to model the numerical behaviour of materials, for instance the UMMDp
We select some models
And use the material parameters from the literature
We choose the mechanical process that we want to work on and its configuration
And define the simulation specifications
With this we can do a sheet metal forming simulation
Then we can extract the some measurements of interest or critical aspects of the process
And we can use the ANOVA analysis to establish a relation between the different constitutive models and the measurements of interest
With the ANOVA results, we can establish a constitute models importance ranking
To validate this methodology we choose a hole expansion test with a blank of 0.8mm thickness
The process was simulated using Abaqus/Standard software with 3D deformable shell revolution for the blank and analytical rigid tools
In the first step, the punch is moved down with a displacement condition while the blank is fixed in the outer edge and the die is also fixed.
The imposed displacement is chosen in order to don’t reach rupture of the blank whatever the material model used.
In the second step, the tools are released and the springback is observed
A structured mesh was implemented using 6 thousand and 4 hundred S4R elements with 9 integration points along the thickness
Regarding the ANOVA approach, this is a statistical strategy that establish a relation between independent and dependent variables.
In this case, we have different types of constitutive models, such as isotropic hardening, … and different forming simulation observables such as the hole’s circularity, maximum punch force, …
We can say that the null hypothesis is that there is no difference among the group’s means
The alternative hyphothesis is that the averages are not all equal
If any group is significantly different from the overall mean, the null hypothesis is rejected. This can be observed with the p-value
The p-value is the probability of obtaining the observed results, assuming that the null hypothesis is true.
A p-value lower than 0.05 considers the statistical meaning of the analysed group.
The smaller the p-value, the more significant is the result
Thus, we simulated the hole expansion test with 8 different constitutive model combinations where we implemented either the Voce’s law or the Swift law, the von Mises of the Yld2000-2d or the kinematic A-F model, or no kinematic hardening model
These are the outputted results. Each plot has the analysed measurement of interest for each run and each material.
It can be observed that the hole’s circularity is dependent of the yld function used, as expected.
The maximum punch force is dependent of the isotropic and kinematic hardening laws, as well as the material used.
The springback factor is also dependent of both the isotropic and kinematic hardening laws.
Looking at the p-values, the greens are the values that are below 0.05 and the red are above.
For instance, it can be observed that the isotropic and kinematic hardening law have no statistical significance in the hole’s circularity.
Where as, depending on the material, the yld function can have no statistical significance in the springback factor of the steel and on the maximum punch force of the alluminium.
To better estimate the influence of each type of constitutive model in the mechanical process, we did the average of the p-values for the different measurements of interest. It can be seen that the kinematic hardening law is the model that most influences the simulation process, considering the DP600. But is the least influenceable when considering the Al.
We can look at the strain path changes using the Schmitt parameter and make similar conclusions.
The Schmitt parameters takes the value of 1 for monotonic, -1 for reversed and 0 for orthogonal strain paths.
It can be observed differences in the strain paths of the simulation using the DP.
Schmitt parameters is defined as the cosine of the angle in the strain space between the strain rate tensors during the pre-strain and subsequent strain path.
In the case of the Al, way less strain path changes are observed. This can be explained due to the smaller punch displacement imposed in the AL, compared to the DP. Different displacements were implemented because of the differences in the rupture of the materials.
Looking again at the p-values. For instance the type of model that least influences the DP simulation is the Yld function, showing the largest p-value average. On the contrary, this is the model that largest influence the simulation of the AL.
This can be confirmed by the differences in between the von Mises locus and the Yld2000-2d locus of the two materials
For the steel, …. Thus it is recommend to put more effort in the calibration of a kinematic hardening model and probably discard a complex yld function.
For the Al, … Hence, we recommend to calibrate a complex yld function and probably discard the calibration of a kinematic hardening law.
