Abengoa Hidrogeno focuses on developing innovative hydrogen and fuel cell technologies, emphasizing their role in sustainability and clean energy. The company operates various projects for hydrogen production, including electrolysis and reforming, with applications in automotive, energy storage, and industrial sectors. Additionally, they provide comprehensive engineering services across all stages of project development, contributing to the hydrogen economy's growth.

1. AH-15-023 Rev.00
Company presentation
Innovative technology solutions for
sustainability
Seville, April 1, 2015
ABENGOA
HIDROGENO

2. AH-15-023 Rev.00 2
H2 + ½ O2 → H2O +
Hydrogen as fuel
Hydrogen is a combustible gas; it can burn, in the presence of oxygen,
leading to thermal energy, with water as the only residue.
It is, therefore, a clean fuel, that does not emit CO2 when used.

3. AH-15-023 Rev.00 3
½ O2 + H2 → H2O
Fuel cells
Fuel cells are the most efficient way to produce electricity from
hydrogen. They are reliable, modular, scalable and clean.
They are to be found in different technologies, and are capable of
operating at different scales and temperatures.

4. AH-15-023 Rev.00 4
The Hydrogen Economy
Hydrogen and
fuel cells
Fuel for the
transport sector
Energy storage.
Power to Gas
Generation and
cogeneration
Integration
with
renewables
The Hydrogen Economy is based on the concept of using this clean and
sustainable fuel as an “energy vector”.

5. AH-15-023 Rev.00 5
Tomorrow is today
One of the main pillars of the Hydrogen Economy is the widespread use
of this gas as an alternative fuel for road transport.

6. AH-15-023 Rev.00 6
Hydrogen for the automotive industry
Different countries have already developed a positioning strategy in the
case of hydrogen as an alternative fuel; prominent among them, the
American strategy and the H2Mobility initiatives in Europe.

7. AH-15-023 Rev.00 7
Power to gas
The use of hydrogen from renewable sources, by means of a
methanation process, to produce a clean, sustainable and local “natural
gas” (methane) gives rise to the “Power to Gas” (P2G) initiatives.

8. AH-15-023 Rev.00 8
The German model
Qualitative representation of the energy flow in the UBA THGND 2050 Scenario

9. AH-15-023 Rev.00 9
Markets
Industrial
Automotive / transport
Renewable energy storage / P2G
Therefore, three existing major markets can be defined in the hydrogen
and fuel cell sector, with different strategies, volumes and future
growths.

10. AH-15-023 Rev.00 10
Abengoa Hidrógeno’s lines
 Abengoa Hidrógeno is a global player in hydrogen and fuel
cell technologies.
 It has proprietary technology and products for both
hydrogen production (reforming and electrolysis) and energy
production (electrical and thermal or polygeneration).
 The combination of the possibility of producing hydrogen
from electrical energy with the use of this gas to produce,
once again, said energy, results in products aimed at large
scale energy storage.
 Lastly, Abengoa Hidrógeno operates in particular niche
markets, by applying said technologies to specific industrial
sectors, such as aerospace or the defense sector, thereby
developing special projects.

11. AH-15-023 Rev.00 11
Abengoa Hidrógeno’s lines
Hydrogen Production
From
(bio)fuels
With water and
energy (renewable)
Energy Production
Electrical
(low temperature
fuel cell)
Polygeneration
(high temperature
fuel cell)
Reforming
Electrolysis
Polymer
electrode
membrane
fuel cell
(PEMFC)
Solid oxide /
molten
carbonate
fuel cells
(SOFC/MCFC)
Storage
Technologies
Special projects

12. AH-15-023 Rev.00 12
Projects
Hydrogen production: reforming
Plant for production of hydrogen by
reforming of ethanol, with a production
capacity of 900 kg/day.

13. AH-15-023 Rev.00 13
Hydrogen production: reforming
Projects
Plant for production of
hydrogen by reforming
of natural gas, with a
production capacity of
3,600 kg/day.

14. AH-15-023 Rev.00 14
Hydrogen production: electrolysis
Projects
Plant for production of hydrogen by
polymeric electrolysis (stack PEM, 140 kW),
with a production capacity of 65 kg/day.

15. AH-15-023 Rev.00 15
Hydrogen production: electrolysis
Projects
Hydrogen fueling station located in
Sanlucar la Mayor (Seville, Spain), with on-
site production by electrolysis with
renewable energy (photovoltaics).

16. AH-15-023 Rev.00 16
Hydrogen production: electrolysis
Projects
Hydrogen fueling station located in Seville
(Spain), with on-site production by
electrolysis.

17. AH-15-023 Rev.00 17
Hydrogen production: electrolysis
Projects
Plant for production of
hydrogen by PEM electrolysis
(6 MW) integrated with
renewable energies.

18. AH-15-023 Rev.00 18
Polygeneration: high temp.
Projects
300 kW cogeneration plant
using MCFC; detail of the
MBoP (pre-reforming and
heat exchange).

19. AH-15-023 Rev.00 19
Polygeneration: high temp.
Projects
300 kW cogeneration plant
using MCFC; construction of
the plant (civil works).

20. AH-15-023 Rev.00 20
Polygeneration: high temp.
Projects
300 kW cogeneration plant using
MCFC; EBoP (DC/AC electric module).

21. AH-15-023 Rev.00 21
Energy storage
Projects
Hydrogen-based energy
storage system: electrolyzer
(PV powered), metal
hydrides and PEM fuel cells;
in operation in Seville since
2010.

22. AH-15-023 Rev.00 22
Special projects
Projects
Bioethanol reforming
hydrogen production
system designed for use in
anaerobic plants (AIP
Plants) on board
conventional submarines
(SSK).

23. AH-15-023 Rev.00 23
Special projects
Projects
Prototype satellite with hydrogen-
based storage system: electrolyzer and
fuel cell, both of polymer technology.

24. AH-15-023 Rev.00 24
Projects
Abengoa Hidrógeno is capable of developing the entire EPC value
chain, from Conceptual Engineering to commissioning.
Thus, it has developed expertise, specifically in the field of
hydrogen and fuel cells, in:
• Process Engineering
• Control and Instrumentation
• Electrical Engineering
• Mechanical & Civil Engineering
• Legislation, Safety & Security
• Construction

25. AH-15-023 Rev.00 25
Projects
• Process Engineering
• Control and
Instrumentation
• Electrical Engineering
• Mechanical & Civil
Engineering
• Legislation, Safety &
Security
• Construction
Process engineering, related to plants
and systems that operate with
hydrogen and fuel cells. Material and
energy balances, fluid dynamic
simulations. P&ID, desulfurization
systems, water treatment.

26. AH-15-023 Rev.00 26
Projects
• Process Engineering
• Control and
Instrumentation
• Electrical Engineering
• Mechanical & Civil
Engineering
• Legislation, Safety &
Security
• Construction
Design of the process control system,
and its architecture. Control logic of
chemical and electrical processes.
Selection of valves, control actuators
and instrumentation. Programming of
the control system.

27. AH-15-023 Rev.00 27
Projects
• Process Engineering
• Control and
Instrumentation
• Electrical Engineering
• Mechanical & Civil
Engineering
• Legislation, Safety &
Security
• Construction
Defining of electrical requirements,
design of low and medium voltage
installations. Design of electrical
diagrams. Calculation of electric lines.
Electrical panel design.

28. AH-15-023 Rev.00 28
Projects
• Process Engineering
• Control and
Instrumentation
• Electrical Engineering
• Mechanical & Civil
Engineering
• Legislation, Safety &
Security
• Construction
Mechanical design of equipment
(chemical reactors, heat exchangers,
tanks, etc.). Structural calculations.
Calculation of ducts. Calculation and
sizing of ventilation systems. 3D
design. Preparation of “as built”
plans.

29. AH-15-023 Rev.00 29
Projects
• Process Engineering
• Control and
Instrumentation
• Electrical Engineering
• Mechanical & Civil
Engineering
• Legislation, Safety &
Security
• Construction
Application of the necessary
legislation, including the latest drafts
of regulations related to hydrogen
and fuel cells. Application of best
practices. Equipment certification and
classification.

30. AH-15-023 Rev.00 30
Projects
• Process Engineering
• Control and
Instrumentation
• Electrical Engineering
• Mechanical & Civil
Engineering
• Legislation, Safety and
Security
• Construction
Construction of process equipment.
Integration in containers and
structures, designed specifically for
their end use. Installation of
instrumentation and control. Supports
and structures. Piping & Tubing. Civil
works.

31. AH-15-023 Rev.00 31

32. AH-15-023 Rev.00
Innovative technology solutions for
sustainability
ABENGOA
HIDROGENO
