DESCRIPTION: Poly 74-Series Polyurethane Rubbers consist of two
parts (A and B), which, after mixing, cure at room temperature to
flexible, high-strength, mold rubbers. Poly 74-Series Rubbers make
durable, easy-releasing molds for casting plasters and waxes without
release agents. When Poly 74-Series molds are properly prepared, they
are also excellent for casting concrete and various resins, such as epoxy,
polyester, polyurethane and acrylic.
BEFORE USE: Thoroughly read Safety Data Sheets, product labels
and the“SAFETY”section in this Technical Bulletin.
MODEL PREPARATION: Porous models, such as wood, plaster, stone,
pottery or masonry must be sealed. Multiple coats of paste wax dried
and buffed will seal most surfaces. Potters soap can be used as a sealer
for plaster. Lacquer, paint, PVA, and Pol-Ease® 2350 Release Agent also
work well as sealers for many surfaces. The properly-sealed model
should then be coated with a release agent (e.g., Pol-Ease® 2300 Release
Agent). Alternatively, PolyCoat, a sealer and semi-permanent release
agent, can be used on most porous or non-porous models. Porous
models must be vented from beneath to prevent trapped air from
forming bubbles in the rubber.
Models made of sulfur-containing modeling clay (e.g., Roma Plastilina)
should be sealed with shellac. [CAUTION: When shellac is used as
the sealer, it must be thoroughly coated with release agent because
polyurethane rubbers bond tenaciously to shellac.]
Non-porous models (e.g., metals, plasticine, wax, glazed ceramics,
fiberglass and polyurethanes) should be coated with release agent such
as Pol-Ease® 2300 Release Agent or PolyCoat.
Poly 74-Series Polyurethane Rubbers Technical Bulletin
55 Hilton Street, Easton, PA 18042 | 800.858.5990 | 610.559.8620 | Fax 610.559.8626 | www.polytek.com | sales@polytek.com
If there is any question about the compatibility between the liquid
mold rubber and the prepared model surface, perform a test cure on an
identical surface to determine that complete curing and good release
are obtained.
MIXING AND CURING: Before use, be sure that Parts A and B are at room
temperature and that all tools are ready. Surface and air temperatures
should be above 60°F during application and for the entire curing
period.
Check mix ratio. Several Poly 74-Series Part Bs require stirring before
use (i.e., 74-20, 74-29, 74-30 and 74-40). Weigh Part B into a clean metal
or plastic mixing container and then weigh the appropriate amount of
Part A into the same container. Mix thoroughly. Hand mixing with a Poly
Paddle is best to avoid mixing air into the rubber. While mixing, scrape
- Make durable, long-lasting molds owing to strength and
elongation properties of cured rubber
- Pourable polyurethane rubbers that cure to soft to mid-
range hardnesses
- Easily thickened for brush-on applications
- No release agents needed when casting many plasters,
waxes and concretes
- Low-viscosity polyurethane rubbers capture detail from
intricate masters
PHYSICAL PROPERTIES
Product 74-20 74-24 74-29 74-30 74-30 Clear 74-30 HT 74-40 74-41 74-44 74-45 74-55
Mix Ratio By Weight 1A:2B 1A:1B 1A:1B 1A:1B 1A:1B 1A:1B 2A:1B 1A:1B 2A:1B 1A:1B 4A:1B
Shore Hardness A20 A25 A30 A30 A30 A30 A40 A40 A45 A45 A55
Pour Time 20 min. 20 min. 30 min.
25-30
min.
25-30 min.
25-30
min.
20 min. 20 min. 20 min. 30 min. 15 min.
Demold Time @ 73°F 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr.
Cured Color Yellow Amber Black
Amber/
Varies
Transparent
Amber
Amber/
Varies
Varies
Amber/
Varies
Gray Yellow Amber
Mixed Viscosity (cP) 800 2,000 2,800 2,000 2,000 2,000 3,400 2,000 3,500 2,000 4,000
Specific Volume (in3
/lb) 27.5 27.5 27.5 27.5 27.5 27.5 27.5 27.5 27.5 27.5 27.5
Specific Gravity 1.01 1.01 1.02 1.01 1.01 1.01 1.01 1.01 1.01 1.02 1.01
Elongation (%) 1,060 750 1,600 506 507 975 400 1,060 2,422 1,135 894
Tensile Strength (psi) 217 220 520 281 281 304 349 360 462 408 679
Die C Tear Strength (pli) 43 55 109 62 62 70 95 77 129 82 155
PRODUCT LINE FEATURES
the sides and bottom several times to ensure thorough mixing. Pour
the rubber as soon after mixing as possible for best flow and air bubble
release. Vacuum degassing helps to provide bubble-free molds, but is
usually not necessary.
Allow rubber to cure at room temperature, 77°F (25°C). Carefully demold
after approximately 16 hours. Final cure properties are obtained in
about seven days, but molds may be used with care after curing for 24-
48 hours. Heat accelerates the cure -- low temperatures slow the cure.
Avoid curing in areas where the temperature is below 60°F (15°C).
Both Parts A and B react with atmospheric moisture and, therefore,
should be resealed or used up as soon as possible after opening. Before
resealing, Poly Purge, a heavier-than-air, dry gas, can be sprayed into
open containers to displace moist air and extend storage life. For
55-gallon drums of Parts A and B, affix Drierite® cartridges on the small
bung during dispensing to protect product from moist air entering the
drum.
SOFTENING THE RUBBER: Add Poly 74/75 Part C Softener to 74-Series
products for a lower viscosity mix and a softer cured rubber. When Part
C is used, cure time is longer and there is some loss of strength in the
rubber and increased tendency to shrink after repeated castings. To
soften Poly 74-30 to Shore A15, mix 1A:1B:1C by weight. The quantity
of Part C required to soften other products varies and should be
determined through experimentation.
ACCELERATING THE CURE: Cure time can be shortened with the
addition of an Accelerator, such as Poly 74/75 Part X, or by adding heat.
Part X is most useful when making brush-on molds to decrease the time
needed between coats. By adding 3% Part X (by weight of the total
mix) to 74-30 or 74-29, the working time is reduced to approximately 8
minutes -- in the time it takes to mix the next batch, the previous layer
gels enough to apply the next coat. Demolding is possible in as little as
4 hours after the final layer is applied. Rapid curing with Part X allows a
shell or mother mold to be made in the same day. Exercise caution when
using Part X for poured molds since the rapid onset of gelling may trap
air bubbles on or near the surface of the master. Heat also accelerates
the cure. It is recommended not to exceed 140°F (60°C).
THICKENING FOR BRUSH-ON: Add Poly Fiber II or Fumed Silica to
mixed Parts A and B to thicken the liquid mix to a gel for application by
brush or trowel.
USINGTHE MOLD:Typically, no release agent is necessary when casting
plaster or wax in Poly 74-Series molds. For casting plaster: sponge, dip
or spray the mold with Pol-Ease® Mold Rinse and then pour plaster on
the wet mold to reduce air bubbles in the plaster and aid release. For
casting resin, first spray the mold with Pol-Ease® 2300 Release Agent
or PolyCoat. For casting concrete, use a form release, such as Pol-Ease®
2650 or 2601. Avoid solvent-containing releases since they can cause
mold distortion (i.e., shrinkage or swelling).
After repeated casting with certain resins, plaster and concrete, molds
may shrink slightly since these materials extract oils from the mold. The
proper selection of release agent and/or barrier coat can minimize this
effect. If shrinkage becomes evident, a light application of Pol-Ease®
Mold Dressing can help to restore the mold to its original dimensions.
Poly 74-Series molds last many years if stored undistorted on a flat, non-
porous surface in a cool, dry location out of direct sunlight. If occasional
outdoor use is required, add 0.5% UV Additive to the total mix weight
to reduce the characteristic surface degradation caused by sunlight.
Never store Poly 74-Series molds outside as UV exposure will eventually
degrade the rubber.
CLEAN UP: Wipe tools clean before the rubber cures. Denatured
ethanol is a good cleaning solvent, but is highly flammable and must
be handled with caution. Coat work surfaces with wax, Pol-Ease® 2300
Release Agent or PolyCoat so that cured rubber can be easily removed.
SAFETY: Before use, thoroughly read Safety Data Sheets and product
labels. Follow safety precautions and directions.
Part A: Keep out of reach of children. Avoid breathing fumes, vapors, or
mists.Usewithadequategeneralorlocalexhaustventilationtominimize
exposure levels. If needed, a NIOSH-approved respirator with organic
vapor cartridge may be used. If inhaled, remove victim to fresh air and
keep at rest in a position comfortable for breathing. Wear impervious
gloves, such as butyl rubber or nitrile rubber. Wash thoroughly with
soap and water after handling. Take off contaminated clothing and
wash before reuse. If skin irritation or rash occurs, get medical help.
Wear eye protection, such as chemical safety glasses/googles. If in eyes,
rinse cautiously with water for several minutes, removing contact lenses
if present and easy to do. If eye irritation occurs, get medical help.
Part B: Keep out of reach of children. Do not breathe fumes, vapors,
or mists. Use with adequate general or local exhaust ventilation to
minimize exposure levels. If needed, a NIOSH-approved respirator with
organic vapor cartridge may be used. If inhaled, remove victim to fresh
air and keep at rest in a position comfortable for breathing. Get medical
advice if you feel unwell. Wear impervious gloves, such as butyl rubber
or nitrile rubber. Wash thoroughly with soap and water after handling.
If skin irritation occurs, get medical help. Wear eye protection, such as
chemical safety glasses/googles. If in eyes, rinse cautiously with water
for several minutes, removing contact lenses if present and easy to do.
If eye irritation occurs, get medical help. If spilled, collect spillage and
avoid release to the environment.
SHELF LIFE: For best results, store products in unopened containers at
room temperature (60-90°F/15-32°C). Use products within six months.
Part Bs darken with age, but product performance is not affected.
DISCLAIMER: The information in this bulletin and otherwise provided
by Polytek® Development Corp. is considered accurate. However, no
warranty is expressed or implied regarding the accuracy of the data, the
results to be obtained by the use thereof, or that any such use will not
infringe any patent. Before using, the user shall determine the suitability
of the product for the intended use and user assumes all risk and liability
whatsoever in connection therewith.
55 Hilton Street, Easton, PA 18042 | 800.858.5990 | 610.559.8620 | Fax 610.559.8626 | www.polytek.com | sales@polytek.com
Accelerator:
Poly 74/75 Part X Accelerator
Sealers & Release Agents:
Pol-Ease® 2300 Release Agent
Pol-Ease® 2350 Release Agent
Pol-Ease® 2450 Release Agent
Pol-Ease® 2601 Release Agent
Pol-Ease® 2650 Release Agent
Pol-Ease® 2500 Release Agent
PolyCoat Sealer & Release Agent
Pol-Ease® Mold Dressing
Pol-Ease® Mold Rinse
Poly PVA Solution (Green or Clear)
Softener:
Poly 74/75 Part C Softener
Product Life Extender:
Poly Purge Aerosol Dry Gas
Thickeners:
Fumed Silica
Poly Fiber II
UV Stabilizer:
UV Additive
Reinforcement Material:
Tietex® Fabric
Poly 74-Series Polyurethane Rubbers | Technical Bulletin | Page 2
ACCESSORIES
April 28, 2021
DESCRIPTION: Poly 75-Series Liquid Rubbers consist of two parts (A
and B), which, after mixing, cure at room temperature to flexible rubber.
Molds made with Poly 75-Series products are excellent for casting
concrete, plaster and wax. In addition, Poly 75-Series molds can be
used to cast various resins and foams when properly prepared. Poly
75-Series Liquid Rubbers are formulated for good economy with high
performance and durability.
BEFORE USE: Thoroughly read Safety Data Sheets, product labels
and the“SAFETY”section in this Technical Bulletin.
MODEL PREPARATION: Porous models, such as wood, plaster, stone,
pottery or masonry must be sealed. Multiple coats of paste wax dried
and buffed will seal most surfaces. Potters soap can be used as a sealer
for plaster. Lacquer, paint, PVA, and Pol-Ease® 2350 Release Agent also
work well as sealers for many surfaces. The properly-sealed model
should then be coated with a release agent (e.g., Pol-Ease® 2300 Release
Agent). Alternatively, PolyCoat, a sealer and semi-permanent release
agent, can be used on most porous or non-porous models. Porous
models must be vented from beneath to prevent trapped air from
forming bubbles in the rubber.
Models made of sulfur-containing modeling clay (e.g., Roma Plastilina)
should be sealed with shellac. [CAUTION: When shellac is used as
the sealer, it must be thoroughly coated with release agent because
polyurethane rubbers bond tenaciously to shellac.]
Non-porous models (e.g., metals, plasticine, wax, glazed ceramics,
fiberglass and polyurethanes) should be coated with release agent such
as Pol-Ease® 2300 Release Agent or PolyCoat.
If there is any question about the compatibility between the liquid
mold rubber and the prepared model surface, perform a test cure on an
identical surface to determine that complete curing and good release
are obtained.
MIXING AND CURING: Before use, be sure that Parts A and B are at room
temperature and that all tools are ready. Surface and air temperatures
Poly 75-Series Liquid Rubbers Technical Bulletin
55 Hilton Street, Easton, PA 18042 | 800.858.5990 | 610.559.8620 | Fax 610.559.8626 | www.polytek.com | sales@polytek.com
should be above 60°F during application and for the entire curing
period.
Check mix ratio. Weigh Part B into a clean metal or plastic mixing
container and then weigh the appropriate amount of Part A into the
same container. Mix thoroughly. Hand mixing with a Poly Paddle is
best to avoid mixing air into the rubber. While mixing, scrape the sides
and bottom several times to ensure thorough mixing. Pour the rubber
as soon after mixing as possible for best flow and air bubble release.
Vacuum degassing helps to provide bubble-free molds, but is usually
not necessary.
Allow rubber to cure at room temperature, 77°F (25°C). Carefully demold
after approximately 16 hours. Final cure properties are obtained in
about seven days, but molds may be used with care after curing for 24-
48 hours. Heat accelerates the cure -- low temperatures slow the cure.
Avoid curing in areas where the temperature is below 60°F (15°C).
Both Parts A and B react with atmospheric moisture and, therefore,
should be resealed or used up as soon as possible after opening. Before
resealing, Poly Purge, a heavier-than-air, dry gas, can be sprayed into
open containers to displace moist air and extend storage life. For
55-gallon drums of Parts A and B, affix Drierite® cartridges on the small
bung during dispensing to protect product from moist air entering the
drum.
- Firm yet flexible mold rubbers
- Ideal for demanding, high-production casting and
forming of concrete
- Dimensionally stable - molds can last for years
- Abrasion resistant for long mold life
- Easy-to-use, forgiving formulations
PHYSICAL PROPERTIES
Product 75-59 75-60 75-65 75-70 75-75 75-79 75-80 75-90
Mix Ratio By Weight 1A:1B 1A:1B 1A:1B 1A:1B 2A:1B 2A:1B 2A:1B 2A:1B
Shore Hardness A60 A60 A65 A70 A75 A80 A80 A90
Pour Time 10 min. 10 min. 35 min. 40 min. 20 min. 20 min. 45 min. 10-15 min.
Demold Time @ 73°F 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr.
Cured Color Amber Amber Yellow Gray Amber Yellow Yellow Tan
Mixed Viscosity (cP) 2,500 1,200 3,000 3,000 4,000 2,000 5,000 6,000
Specific Volume (in3
/lb) 27 27 27 27 26 26 26 26
Specific Gravity 1.05 1.05 1.04 1.05 1.06 1.07 1.07 1.07
Elongation (%) 588 459 550 724 722 369 468 774
Tensile Strength (psi) 637 545 520 938 1,064 655 750 1,979
Die C Tear Strength (pli) 122 103 145 299 247 143 199 368
PRODUCT LINE FEATURES
gloves, such as butyl rubber or nitrile rubber. Take off contaminated
clothing and wash it before reuse. Contaminated work clothing should
be not allowed out of the work area. Wash skin thoroughly with soap
and water after handling. If skin irritation occurs, get medical help. Wear
eye protection, such as chemical safety glasses/googles. If in eyes, rinse
cautiously with water for several minutes, removing contact lenses
if present and easy to do. If eye irritation occurs, get medical help. If
spilled, collect spillage and avoid release to the environment.
SHELF LIFE: For best results, store products in unopened containers at
room temperature (60-90°F/15-32°C). Use products within six months.
Part Bs darken with age, but product performance is not affected.
DISCLAIMER: The information in this bulletin and otherwise provided
by Polytek® Development Corp. is considered accurate. However, no
warranty is expressed or implied regarding the accuracy of the data, the
results to be obtained by the use thereof, or that any such use will not
infringe any patent. Before using, the user shall determine the suitability
of the product for the intended use and user assumes all risk and liability
whatsoever in connection therewith.
55 Hilton Street, Easton, PA 18042 | 800.858.5990 | 610.559.8620 | Fax 610.559.8626 | www.polytek.com | sales@polytek.com
Accelerator:
Poly 74/75 Part X Accelerator
Sealers & Release Agents:
Pol-Ease® 2300 Release Agent
Pol-Ease® 2350 Release Agent
Pol-Ease® 2450 Release Agent
Pol-Ease® 2601 Release Agent
Pol-Ease® 2650 Release Agent
Pol-Ease® 2500 Release Agent
PolyCoat Sealer & Release Agent
Pol-Ease® Mold Dressing
Pol-Ease® Mold Rinse
Poly PVA Solution (Green or Clear)
Softener:
Poly 74/75 Part C Softener
Product Life Extender:
Poly Purge Aerosol Dry Gas
Thickeners:
Poly Fiber II
UV Stabilizer:
UV Additive
Reinforcement Material:
Tietex® Fabric
SOFTENING THE RUBBER: Add Poly 74/75 Part C Softener to 75-Series
products for a lower viscosity mix and a softer cured rubber. When
using Part C, cure time is longer and there is some loss of strength in
the rubber and increased tendency to shrink after repeated castings.
Determine the quantity of Part C required through experimentation.
ACCELERATING THE CURE: Cure time can be shortened with the
addition of an Accelerator, such as Poly 74/75 Part X, or by adding heat.
By adding 1% Poly 74/75 Part X (by weight of total mix) to Poly 75-80, the
working time is reduced to approximately 10 minutes and demolding is
possible in as little as 6 hours. Exercise caution when using Part X since
the rapid onset of gelling may trap air bubbles on or near the surface
of the model. Heat also accelerates the cure. It is recommended not to
exceed 140°F (60°C).
USINGTHE MOLD:Typically, no release agent is necessary when casting
plaster or wax in Poly 75-Series molds. For casting plaster: sponge, dip
or spray the mold with Pol-Ease® Mold Rinse and then pour plaster on
the wet mold to reduce air bubbles in the plaster and aid release. For
casting resin, first spray the mold with Pol-Ease® 2300 Release Agent
or PolyCoat. For casting concrete, use a form release, such as Pol-Ease®
2650 or 2601. Avoid solvent-containing releases since they can cause
mold distortion (i.e., shrinkage or swelling).
After repeated casting with certain resins, plaster and concrete, molds
may shrink slightly since these materials extract oils from the mold. The
proper selection of release agent and/or barrier coat can minimize this
effect. If shrinkage becomes evident, a light application of Pol-Ease®
Mold Dressing can help to restore the mold to its original dimensions.
Poly 75-Series molds last many years if stored undistorted on a flat, non-
porous surface in a cool, dry location out of direct sunlight. If occasional
outdoor use is required, Poly 75-59, 75-65 and 75-80 perform best and
UV resistance can be improved by adding Poly UV Additive. Add 0.5%
UV Additive to the total mix weight to reduce the characteristic surface
degradation caused by sunlight. Never store Poly 75-Series molds
outside as UV exposure will eventually degrade the rubber.
CLEAN UP: Wipe tools clean before the rubber cures. Denatured
ethanol is a good cleaning solvent, but is highly flammable and must
be handled with caution. Coat work surfaces with wax, Pol-Ease® 2300
Release Agent or PolyCoat so cured rubber can be removed.
SAFETY: Before use, thoroughly read Safety Data Sheets and product
labels. Follow safety precautions and directions.
Part A: Keep out of reach of children. Avoid breathing fumes, vapors
or mists. Use with adequate general or local exhaust ventilation to
minimize exposure levels. If needed, a NIOSH-approved respirator
with organic vapor cartridge may be used. If inhaled and breathing
is difficult, remove victim to fresh air and keep at rest in a position
comfortable for breathing. Wear impervious gloves, such as butyl
rubber or nitrile rubber. Take off contaminated clothing and wash
before reuse. Wash skin thoroughly with soap and water after handling.
If skin irritation occurs, get medical help. Wear eye protection, such as
chemical safety glasses/googles. If in eyes, rinse cautiously with water
for several minutes, removing contact lenses if present and easy to do. If
eye irritation occurs, get medical help.
Part B: Keep out of reach of children. Do not breathe fumes, vapors or
mists.Usewithadequategeneralorlocalexhaustventilationtominimize
exposure levels. If needed, a NIOSH-approved respirator with organic
vapor cartridge may be used. If inhaled, remove victim to fresh air and
keep at rest in a position comfortable for breathing. Wear impervious
December 10, 2020
Poly 75-Series Liquid Rubbers|Technical Bulletin|Page 2
ACCESSORIES
DESCRIPTION: Use Poly 81-Series rubbers to make firm molds, mold
facings, stamping tools, industrial parts, rollers, gaskets, mold shells,
bumpers or pads. Poly 81-Series rubbers consist of two liquid parts (A
and B), which, after mixing, cure at room temperature to tough, durable
rubbers.They offer low sensitivity to moisture, and low viscosity for easy
mixing and pouring.
BEFORE USE: Thoroughly read Safety Data Sheets, product labels
and the“SAFETY”section in this Technical Bulletin.
MODEL PREPARATION: Porous models, such as wood, plaster, stone,
pottery or masonry must be sealed. Multiple coats of paste wax dried
and buffed will seal most surfaces. Potters soap can be used as a sealer
for plaster. Lacquer, paint, PVA, and Pol-Ease® 2350 Release Agent also
work well as sealers for many surfaces. The properly-sealed model
should then be coated with a release agent (e.g., Pol-Ease® 2300 Release
Agent). Alternatively, PolyCoat, a sealer and semi-permanent release
agent, can be used on most porous or non-porous models. Porous
models must be vented from beneath to prevent trapped air from
forming bubbles in the rubber.
Models made of sulfur-containing modeling clay (e.g., Roma Plastilina)
should be sealed with shellac. [CAUTION: When shellac is used as
the sealer, it must be thoroughly coated with release agent because
polyurethane rubbers bond tenaciously to shellac.]
Non-porous models (e.g., metals, plasticine, wax, glazed ceramics,
fiberglass and polyurethanes) should be coated with release agent such
as Pol-Ease® 2300 Release Agent or PolyCoat.
If there is any question about the compatibility between the liquid
mold rubber and the prepared model surface, perform a test cure on an
identical surface to determine that complete curing and good release
are obtained.
MIXING AND CURING: Before use, be sure that Parts A and B are at room
temperature and that all tools are ready. Surface and air temperatures
should be above 60°F during application and for the entire curing
period.
Poly 81-Series Liquid Rubbers Technical Bulletin
Check mix ratio. Weigh Part B into a clean metal or plastic mixing
container and then weigh the appropriate amount of Part A into the
same container. Mix thoroughly. Hand mixing with a Poly Paddle is
best to avoid mixing air into the rubber. While mixing, scrape the sides
and bottom several times to ensure thorough mixing. Pour the rubber
as soon after mixing as possible for best flow and air bubble release.
Vacuum degassing helps to provide bubble-free molds, but is usually
not necessary.
Allow rubber to cure at room temperature, 77°F (25°C). Carefully demold
after approximately 16 hours. Final cure properties are obtained in
about seven days, but molds may be used with care after curing for 24-
48 hours. Heat accelerates the cure -- low temperatures slow the cure.
Avoid curing in areas where the temperature is below 60°F (15°C).
Both Parts A and B react with atmospheric moisture and, therefore,
should be resealed or used up as soon as possible after opening. Before
resealing, Poly Purge, a heavier-than-air, dry gas, can be sprayed into
open containers to displace moist air and extend storage life. For
55-gallon drums of Parts A and B, affix Drierite® cartridges on the small
bung during dispensing to protect product from moist air entering the
drum.
USINGTHE MOLD:Typically, no release agent is necessary when casting
plaster or wax in Poly 81-Series molds. For casting plaster: sponge, dip
or spray the mold with Pol-Ease® Mold Rinse and then pour plaster on
the wet mold to reduce air bubbles in the plaster and aid release. For
casting resin, first spray the mold with Pol-Ease® 2300 Release Agent
- Firm rubbers with Shore A90 or D45
- Hard, yet flexible
- Easy-to-use formulations
- Reproduce fine details
- Make tough, long-lasting molds, tools & parts
PHYSICAL PROPERTIES
Product 81-90 81-D45
Mix Ratio By Weight 100A:40B 100A:20B
Shore Hardness A90 D45
Pour Time 23 min. 19 min.
Demold Time @ 73°F 16 hr. 16 hr.
Cured Color Varies Varies
Mixed Viscosity (cP) 2,000 1,600
Specific Volume (in3
/lb) 26.6 26.4
Specific Gravity 1.06 1.08
Elongation (%) 463 327
Tensile Strength (psi) 1,550 1,426
Die C Tear Strength (pli) 357 380
PRODUCT LINE FEATURES
55 Hilton Street, Easton, PA 18042 | 800.858.5990 | 610.559.8620 | Fax 610.559.8626 | www.polytek.com | sales@polytek.com
55 Hilton Street, Easton, PA 18042 | 800.858.5990 | 610.559.8620 | Fax 610.559.8626 | www.polytek.com | sales@polytek.com
Sealers & Release Agents:
Pol-Ease® 2300 Release Agent
Pol-Ease® 2350 Release Agent
Pol-Ease® 2450 Release Agent
Pol-Ease® 2601 Release Agent
Pol-Ease® 2650 Release Agent
Pol-Ease® 2500 Release Agent
PolyCoat Sealer & Release Agent
Pol-Ease® Mold Dressing
Pol-Ease® Mold Rinse
Poly PVA Solution (Green or Clear)
Product Life Extender:
Poly Purge Aerosol Dry Gas
Thickeners:
Fumed Silica
Poly Fiber II
UV Stabilizer:
UV Additive
Reinforcement Material:
Tietex® Fabric
or PolyCoat. For casting concrete, use a form release, such as Pol-Ease®
2650 or 2601. Avoid solvent-containing releases since they can cause
mold distortion (i.e., shrinkage or swelling).
After repeated casting with certain resins, plaster and concrete, molds
may shrink slightly since these materials extract oils from the mold. The
proper selection of release agent and/or barrier coat can minimize this
effect. If shrinkage becomes evident, a light application of Pol-Ease®
Mold Dressing can help to restore the mold to its original dimensions.
Poly 81-Series molds last many years if stored undistorted on a flat, non-
porous surface in a cool, dry location out of direct sunlight. If occasional
outdoor use is required, add 0.5% UV Additive to the total mix weight
to reduce the characteristic surface degradation caused by sunlight.
Never store Poly 81-Series molds outside as UV exposure will eventually
degrade the rubber.
CLEAN UP: Wipe tools clean before the rubber cures. Denatured
ethanol is a good cleaning solvent, but is highly flammable and must
be handled with caution. Coat work surfaces with wax, Pol-Ease® 2300
Release Agent or PolyCoat so that cured rubber can be easily removed.
SAFETY:Before use, thoroughly read Safety Data Sheets and product
labels. Follow safety precautions and directions.
Part A: Keep out of reach of children. Avoid breathing fumes, vapors,
sprays, or mists. Use only outdoors or with adequate general or local
exhaust ventilation to minimize exposure levels. If needed, a NIOSH-
approved respirator with organic vapor cartridge may be used. If
inhaled and breathing is difficult, remove victim to fresh air and keep at
rest in a position comfortable for breathing. If experiencing respiratory
irritation, seek medical attention. Wear impervious gloves, such as butyl
rubber or nitrile rubber. Wash skin thoroughly with soap and water after
handling. If skin irritation or rash occurs, get medical advice or attention.
Wear eye protection, such as chemical safety glasses/googles. If in eyes,
rinse cautiously with water for several minutes, removing contact lenses
if present and easy to do. Store in a well-ventilated place and keep
container tightly closed.
Part B: Keep out of reach of children. Do not breathe fumes, vapors,
sprays, or mists. Use with adequate general or local exhaust ventilation
to minimize exposure levels. If needed, a NIOSH-approved respirator
with organic vapor cartridge may be used. If inhaled, remove victim to
fresh air and keep at rest in a position comfortable for breathing. Wear
impervious gloves, such as butyl rubber or nitrile rubber. Wash skin
thoroughly with soap and water after handling. Wear eye protection,
such as chemical safety glasses/googles. If in eyes, rinse cautiously with
water for several minutes, removing contact lenses if present and easy
to do. If eye irritation persists, get medical advice or attention. If spilled,
collect spillage and avoid release to the environment.
SHELF LIFE: For best results, store products in unopened containers at
room temperature (60-90°F/15-32°C). Use products within six months.
Part Bs darken with age, but product performance is not affected.
DISCLAIMER: The information in this bulletin and otherwise provided
by Polytek® Development Corp. is considered accurate. However, no
warranty is expressed or implied regarding the accuracy of the data, the
results to be obtained by the use thereof, or that any such use will not
infringe any patent. Before using, the user shall determine the suitability
of the product for the intended use and user assumes all risk and liability
whatsoever in connection therewith.
Poly 81-Series Liquid Rubbers | Technical Bulletin | Page 2
December 10, 2020
ACCESSORIES

More Related Content

What's hot

Poly 81-Series Liquid Rubbers
Poly 81-Series Liquid RubbersPoly 81-Series Liquid Rubbers
Poly 81-Series Liquid Rubbers
Polytek Development Corp

Polygel® Liquid Rubbers
Polygel® Liquid RubbersPolygel® Liquid Rubbers
Polygel® Liquid Rubbers
Polytek Development Corp

Poly Plasti-Flex Liquid Plastic
Poly Plasti-Flex Liquid PlasticPoly Plasti-Flex Liquid Plastic
Poly Plasti-Flex Liquid Plastic
Polytek Development Corp

PlatSil® Silicone Gels
PlatSil® Silicone GelsPlatSil® Silicone Gels
PlatSil® Silicone Gels
Polytek Development Corp

PolyPoxy® Epoxy Clay Series
PolyPoxy® Epoxy Clay SeriesPolyPoxy® Epoxy Clay Series
PolyPoxy® Epoxy Clay Series
Polytek Development Corp

Poly 15-Series Liquid Plastics
Poly 15-Series Liquid PlasticsPoly 15-Series Liquid Plastics
Poly 15-Series Liquid Plastics
Polytek Development Corp

Korolozyon Kontrol Teknolojileri
Korolozyon Kontrol TeknolojileriKorolozyon Kontrol Teknolojileri
Korolozyon Kontrol Teknolojileri
vizyonendustriyel1

Prime flex 900_mv_tds
Prime flex 900_mv_tdsPrime flex 900_mv_tds
Prime flex 900_mv_tds
primeresins

Summary
SummarySummary
Summary
christine731

Poly-Optic® 14-Series Casting Resins
Poly-Optic® 14-Series Casting ResinsPoly-Optic® 14-Series Casting Resins
Poly-Optic® 14-Series Casting Resins
Polytek Development Corp

EasyFlo Series Liquid Plastics
EasyFlo Series Liquid PlasticsEasyFlo Series Liquid Plastics
EasyFlo Series Liquid Plastics
Polytek Development Corp

PolyPoxy® Casting Epoxy Series
PolyPoxy® Casting Epoxy SeriesPolyPoxy® Casting Epoxy Series
PolyPoxy® Casting Epoxy Series
Polytek Development Corp


What's hot (13)

Poly 81-Series Liquid Rubbers
Poly 81-Series Liquid RubbersPoly 81-Series Liquid Rubbers
Poly 81-Series Liquid Rubbers

Polygel® Liquid Rubbers
Polygel® Liquid RubbersPolygel® Liquid Rubbers
Polygel® Liquid Rubbers

Halo Antislip
Halo AntislipHalo Antislip
Halo Antislip

Poly Plasti-Flex Liquid Plastic
Poly Plasti-Flex Liquid PlasticPoly Plasti-Flex Liquid Plastic
Poly Plasti-Flex Liquid Plastic

PlatSil® Silicone Gels
PlatSil® Silicone GelsPlatSil® Silicone Gels
PlatSil® Silicone Gels

PolyPoxy® Epoxy Clay Series
PolyPoxy® Epoxy Clay SeriesPolyPoxy® Epoxy Clay Series
PolyPoxy® Epoxy Clay Series

Poly 15-Series Liquid Plastics
Poly 15-Series Liquid PlasticsPoly 15-Series Liquid Plastics
Poly 15-Series Liquid Plastics

Korolozyon Kontrol Teknolojileri
Korolozyon Kontrol TeknolojileriKorolozyon Kontrol Teknolojileri
Korolozyon Kontrol Teknolojileri

Prime flex 900_mv_tds
Prime flex 900_mv_tdsPrime flex 900_mv_tds
Prime flex 900_mv_tds

Summary
SummarySummary
Summary

Poly-Optic® 14-Series Casting Resins
Poly-Optic® 14-Series Casting ResinsPoly-Optic® 14-Series Casting Resins
Poly-Optic® 14-Series Casting Resins

EasyFlo Series Liquid Plastics
EasyFlo Series Liquid PlasticsEasyFlo Series Liquid Plastics
EasyFlo Series Liquid Plastics

PolyPoxy® Casting Epoxy Series
PolyPoxy® Casting Epoxy SeriesPolyPoxy® Casting Epoxy Series
PolyPoxy® Casting Epoxy Series


Similar to Poly 74-Series Polyurethane Rubbers

CONCRETE MOLD MAKING STARTER KIT
CONCRETE MOLD MAKING STARTER KITCONCRETE MOLD MAKING STARTER KIT
CONCRETE MOLD MAKING STARTER KIT
Polytek Development Corp

PolyFoam Series
PolyFoam SeriesPolyFoam Series
PolyFoam Series
Polytek Development Corp

PolyPoxy® Laminating Epoxy Series
PolyPoxy® Laminating Epoxy SeriesPolyPoxy® Laminating Epoxy Series
PolyPoxy® Laminating Epoxy Series
Polytek Development Corp

PolyPoxy® Epoxy Clay Series
PolyPoxy® Epoxy Clay SeriesPolyPoxy® Epoxy Clay Series
PolyPoxy® Epoxy Clay Series
Polytek Development Corp

PolyPoxy® Epoxy Adhesive Series
PolyPoxy® Epoxy Adhesive SeriesPolyPoxy® Epoxy Adhesive Series
PolyPoxy® Epoxy Adhesive Series
Polytek Development Corp

Kast-Series Urethane Resins
Kast-Series Urethane ResinsKast-Series Urethane Resins
Kast-Series Urethane Resins
Polytek Development Corp

Summary
SummarySummary
Summary
christine731

Polyurethane Mold Making & Casting Rubbers
Polyurethane Mold Making & Casting RubbersPolyurethane Mold Making & Casting Rubbers
Polyurethane Mold Making & Casting Rubbers
Polytek Development Corp

ABOUT DURABOND
ABOUT DURABONDABOUT DURABOND
ABOUT DURABOND
daokim

Inverted Flat Roof Waterproofing - Mariseal 650 flash
Inverted Flat Roof Waterproofing - Mariseal 650 flashInverted Flat Roof Waterproofing - Mariseal 650 flash
Inverted Flat Roof Waterproofing - Mariseal 650 flash
Orfeas Aggelou

Mold Making for Chemical-Based Materials
Mold Making for Chemical-Based MaterialsMold Making for Chemical-Based Materials
Mold Making for Chemical-Based Materials
JeffreyMongrain


Similar to Poly 74-Series Polyurethane Rubbers (11)

CONCRETE MOLD MAKING STARTER KIT
CONCRETE MOLD MAKING STARTER KITCONCRETE MOLD MAKING STARTER KIT
CONCRETE MOLD MAKING STARTER KIT

PolyFoam Series
PolyFoam SeriesPolyFoam Series
PolyFoam Series

PolyPoxy® Laminating Epoxy Series
PolyPoxy® Laminating Epoxy SeriesPolyPoxy® Laminating Epoxy Series
PolyPoxy® Laminating Epoxy Series

PolyPoxy® Epoxy Clay Series
PolyPoxy® Epoxy Clay SeriesPolyPoxy® Epoxy Clay Series
PolyPoxy® Epoxy Clay Series

PolyPoxy® Epoxy Adhesive Series
PolyPoxy® Epoxy Adhesive SeriesPolyPoxy® Epoxy Adhesive Series
PolyPoxy® Epoxy Adhesive Series

Kast-Series Urethane Resins
Kast-Series Urethane ResinsKast-Series Urethane Resins
Kast-Series Urethane Resins

Summary
SummarySummary
Summary

Polyurethane Mold Making & Casting Rubbers
Polyurethane Mold Making & Casting RubbersPolyurethane Mold Making & Casting Rubbers
Polyurethane Mold Making & Casting Rubbers

ABOUT DURABOND
ABOUT DURABONDABOUT DURABOND
ABOUT DURABOND

Inverted Flat Roof Waterproofing - Mariseal 650 flash
Inverted Flat Roof Waterproofing - Mariseal 650 flashInverted Flat Roof Waterproofing - Mariseal 650 flash
Inverted Flat Roof Waterproofing - Mariseal 650 flash

Mold Making for Chemical-Based Materials
Mold Making for Chemical-Based MaterialsMold Making for Chemical-Based Materials
Mold Making for Chemical-Based Materials


More from Polytek Development Corp

Ultimate Top Coat
Ultimate Top CoatUltimate Top Coat
Ultimate Top Coat
Polytek Development Corp

TinSil® 70-10 Silicone Rubber Part A
TinSil® 70-10 Silicone Rubber Part ATinSil® 70-10 Silicone Rubber Part A
TinSil® 70-10 Silicone Rubber Part A
Polytek Development Corp

TinSil® 70-30 Silicone Rubber Part A
TinSil® 70-30 Silicone Rubber Part ATinSil® 70-30 Silicone Rubber Part A
TinSil® 70-30 Silicone Rubber Part A
Polytek Development Corp

TinSil® 70-20 Silicone Rubber Part A
TinSil® 70-20 Silicone Rubber Part ATinSil® 70-20 Silicone Rubber Part A
TinSil® 70-20 Silicone Rubber Part A
Polytek Development Corp

PlatSil® SiliFoam Part A
PlatSil® SiliFoam Part APlatSil® SiliFoam Part A
PlatSil® SiliFoam Part A
Polytek Development Corp

UV Additive
UV AdditiveUV Additive
Poly Wax 15
Poly Wax 15Poly Wax 15
TinSil® 80-Series Silicone Rubber Part A
TinSil® 80-Series Silicone Rubber Part ATinSil® 80-Series Silicone Rubber Part A
TinSil® 80-Series Silicone Rubber Part A
Polytek Development Corp

TinSil® Gel -10 Deadener
TinSil® Gel -10 DeadenerTinSil® Gel -10 Deadener
TinSil® Gel -10 Deadener
Polytek Development Corp

PolyPoxy® Quick Stick Adhesive Part A
PolyPoxy® Quick Stick Adhesive Part A PolyPoxy® Quick Stick Adhesive Part A
PolyPoxy® Quick Stick Adhesive Part A
Polytek Development Corp

Poly PVA Solution (Clear)
Poly PVA Solution (Clear)Poly PVA Solution (Clear)
Poly PVA Solution (Clear)
Polytek Development Corp

Poly-Sil® Silicone Fluid 50
Poly-Sil® Silicone Fluid 50Poly-Sil® Silicone Fluid 50
Poly-Sil® Silicone Fluid 50
Polytek Development Corp

PT Flex D60 Casting Resin Part A
 PT Flex D60 Casting Resin Part A PT Flex D60 Casting Resin Part A
PT Flex D60 Casting Resin Part A
Polytek Development Corp

PT Flex D60 Casting Resin Part A
PT Flex D60 Casting Resin Part APT Flex D60 Casting Resin Part A
PT Flex D60 Casting Resin Part A
Polytek Development Corp

Hydrogel® N Retarder
Hydrogel® N RetarderHydrogel® N Retarder
Hydrogel® N Retarder
Polytek Development Corp

TinSil® 70-30 Silicone Rubber Part A
TinSil® 70-30 Silicone Rubber Part ATinSil® 70-30 Silicone Rubber Part A
TinSil® 70-30 Silicone Rubber Part A
Polytek Development Corp

TinSil® 70-20 Silicone Rubber Part A
TinSil® 70-20 Silicone Rubber Part ATinSil® 70-20 Silicone Rubber Part A
TinSil® 70-20 Silicone Rubber Part A
Polytek Development Corp

Ultimate Top Coat
Ultimate Top CoatUltimate Top Coat
Ultimate Top Coat
Polytek Development Corp

UV Additive
UV AdditiveUV Additive
Poly Wax 15 Poly Skin-Wax
Poly Wax 15 Poly Skin-WaxPoly Wax 15 Poly Skin-Wax
Poly Wax 15 Poly Skin-Wax
Polytek Development Corp


More from Polytek Development Corp (20)

Ultimate Top Coat
Ultimate Top CoatUltimate Top Coat
Ultimate Top Coat

TinSil® 70-10 Silicone Rubber Part A
TinSil® 70-10 Silicone Rubber Part ATinSil® 70-10 Silicone Rubber Part A
TinSil® 70-10 Silicone Rubber Part A

TinSil® 70-30 Silicone Rubber Part A
TinSil® 70-30 Silicone Rubber Part ATinSil® 70-30 Silicone Rubber Part A
TinSil® 70-30 Silicone Rubber Part A

TinSil® 70-20 Silicone Rubber Part A
TinSil® 70-20 Silicone Rubber Part ATinSil® 70-20 Silicone Rubber Part A
TinSil® 70-20 Silicone Rubber Part A

PlatSil® SiliFoam Part A
PlatSil® SiliFoam Part APlatSil® SiliFoam Part A
PlatSil® SiliFoam Part A

UV Additive
UV AdditiveUV Additive
UV Additive

Poly Wax 15
Poly Wax 15Poly Wax 15
Poly Wax 15

TinSil® 80-Series Silicone Rubber Part A
TinSil® 80-Series Silicone Rubber Part ATinSil® 80-Series Silicone Rubber Part A
TinSil® 80-Series Silicone Rubber Part A

TinSil® Gel -10 Deadener
TinSil® Gel -10 DeadenerTinSil® Gel -10 Deadener
TinSil® Gel -10 Deadener

PolyPoxy® Quick Stick Adhesive Part A
PolyPoxy® Quick Stick Adhesive Part A PolyPoxy® Quick Stick Adhesive Part A
PolyPoxy® Quick Stick Adhesive Part A

Poly PVA Solution (Clear)
Poly PVA Solution (Clear)Poly PVA Solution (Clear)
Poly PVA Solution (Clear)

Poly-Sil® Silicone Fluid 50
Poly-Sil® Silicone Fluid 50Poly-Sil® Silicone Fluid 50
Poly-Sil® Silicone Fluid 50

PT Flex D60 Casting Resin Part A
 PT Flex D60 Casting Resin Part A PT Flex D60 Casting Resin Part A
PT Flex D60 Casting Resin Part A

PT Flex D60 Casting Resin Part A
PT Flex D60 Casting Resin Part APT Flex D60 Casting Resin Part A
PT Flex D60 Casting Resin Part A

Hydrogel® N Retarder
Hydrogel® N RetarderHydrogel® N Retarder
Hydrogel® N Retarder

TinSil® 70-30 Silicone Rubber Part A
TinSil® 70-30 Silicone Rubber Part ATinSil® 70-30 Silicone Rubber Part A
TinSil® 70-30 Silicone Rubber Part A

TinSil® 70-20 Silicone Rubber Part A
TinSil® 70-20 Silicone Rubber Part ATinSil® 70-20 Silicone Rubber Part A
TinSil® 70-20 Silicone Rubber Part A

Ultimate Top Coat
Ultimate Top CoatUltimate Top Coat
Ultimate Top Coat

UV Additive
UV AdditiveUV Additive
UV Additive

Poly Wax 15 Poly Skin-Wax
Poly Wax 15 Poly Skin-WaxPoly Wax 15 Poly Skin-Wax
Poly Wax 15 Poly Skin-Wax


Recently uploaded

5 Things You Need To Know Before Hiring a Videographer
5 Things You Need To Know Before Hiring a Videographer5 Things You Need To Know Before Hiring a Videographer
5 Things You Need To Know Before Hiring a Videographer
ofm712785

Skye Residences | Extended Stay Residences Near Toronto Airport
Skye Residences | Extended Stay Residences Near Toronto AirportSkye Residences | Extended Stay Residences Near Toronto Airport
Skye Residences | Extended Stay Residences Near Toronto Airport
marketingjdass

April 2024 Nostalgia Products Newsletter
April 2024 Nostalgia Products NewsletterApril 2024 Nostalgia Products Newsletter
April 2024 Nostalgia Products Newsletter
NathanBaughman3

chapter 10 - excise tax of transfer and business taxation
chapter 10 - excise tax of transfer and business taxationchapter 10 - excise tax of transfer and business taxation
chapter 10 - excise tax of transfer and business taxation
AUDIJEAngelo

CADAVER AS OUR FIRST TEACHER anatomt in your.pptx
CADAVER AS OUR FIRST TEACHER anatomt in your.pptxCADAVER AS OUR FIRST TEACHER anatomt in your.pptx
CADAVER AS OUR FIRST TEACHER anatomt in your.pptx
fakeloginn69

Improving profitability for small business
Improving profitability for small businessImproving profitability for small business
Improving profitability for small business
Ben Wann

anas about venice for grade 6f about venice
anas about venice for grade 6f about veniceanas about venice for grade 6f about venice
anas about venice for grade 6f about venice
anasabutalha2013

Attending a job Interview for B1 and B2 Englsih learners
Attending a job Interview for B1 and B2 Englsih learnersAttending a job Interview for B1 and B2 Englsih learners
Attending a job Interview for B1 and B2 Englsih learners
Erika906060

Brand Analysis for an artist named Struan
Brand Analysis for an artist named StruanBrand Analysis for an artist named Struan
Brand Analysis for an artist named Struan
sarahvanessa51503

Unveiling the Secrets How Does Generative AI Work.pdf
Unveiling the Secrets How Does Generative AI Work.pdfUnveiling the Secrets How Does Generative AI Work.pdf
Unveiling the Secrets How Does Generative AI Work.pdf
Sam H

RMD24 | Debunking the non-endemic revenue myth Marvin Vacquier Droop | First ...
RMD24 | Debunking the non-endemic revenue myth Marvin Vacquier Droop | First ...RMD24 | Debunking the non-endemic revenue myth Marvin Vacquier Droop | First ...
RMD24 | Debunking the non-endemic revenue myth Marvin Vacquier Droop | First ...
BBPMedia1

What is the TDS Return Filing Due Date for FY 2024-25.pdf
What is the TDS Return Filing Due Date for FY 2024-25.pdfWhat is the TDS Return Filing Due Date for FY 2024-25.pdf
What is the TDS Return Filing Due Date for FY 2024-25.pdf
seoforlegalpillers

Affordable Stationery Printing Services in Jaipur | Navpack n Print
Affordable Stationery Printing Services in Jaipur | Navpack n PrintAffordable Stationery Printing Services in Jaipur | Navpack n Print
Affordable Stationery Printing Services in Jaipur | Navpack n Print
Navpack & Print

Sustainability: Balancing the Environment, Equity & Economy
Sustainability: Balancing the Environment, Equity & EconomySustainability: Balancing the Environment, Equity & Economy
Sustainability: Balancing the Environment, Equity & Economy
Operational Excellence Consulting

Filing Your Delaware Franchise Tax A Detailed Guide
Filing Your Delaware Franchise Tax A Detailed GuideFiling Your Delaware Franchise Tax A Detailed Guide
Filing Your Delaware Franchise Tax A Detailed Guide
YourLegal Accounting

Cracking the Workplace Discipline Code Main.pptx
Cracking the Workplace Discipline Code Main.pptxCracking the Workplace Discipline Code Main.pptx
Cracking the Workplace Discipline Code Main.pptx
Workforce Group

Buy Verified PayPal Account | Buy Google 5 Star Reviews
Buy Verified PayPal Account | Buy Google 5 Star ReviewsBuy Verified PayPal Account | Buy Google 5 Star Reviews
Buy Verified PayPal Account | Buy Google 5 Star Reviews
usawebmarket

Exploring Patterns of Connection with Social Dreaming
Exploring Patterns of Connection with Social DreamingExploring Patterns of Connection with Social Dreaming
Exploring Patterns of Connection with Social Dreaming
Nicola Wreford-Howard

Role of Remote Sensing and Monitoring in Mining
Role of Remote Sensing and Monitoring in MiningRole of Remote Sensing and Monitoring in Mining
Role of Remote Sensing and Monitoring in Mining
Naaraayani Minerals Pvt.Ltd

Lookback Analysis
Lookback AnalysisLookback Analysis
Lookback Analysis
Safe PaaS


Recently uploaded (20)

5 Things You Need To Know Before Hiring a Videographer
5 Things You Need To Know Before Hiring a Videographer5 Things You Need To Know Before Hiring a Videographer
5 Things You Need To Know Before Hiring a Videographer

Skye Residences | Extended Stay Residences Near Toronto Airport
Skye Residences | Extended Stay Residences Near Toronto AirportSkye Residences | Extended Stay Residences Near Toronto Airport
Skye Residences | Extended Stay Residences Near Toronto Airport

April 2024 Nostalgia Products Newsletter
April 2024 Nostalgia Products NewsletterApril 2024 Nostalgia Products Newsletter
April 2024 Nostalgia Products Newsletter

chapter 10 - excise tax of transfer and business taxation
chapter 10 - excise tax of transfer and business taxationchapter 10 - excise tax of transfer and business taxation
chapter 10 - excise tax of transfer and business taxation

CADAVER AS OUR FIRST TEACHER anatomt in your.pptx
CADAVER AS OUR FIRST TEACHER anatomt in your.pptxCADAVER AS OUR FIRST TEACHER anatomt in your.pptx
CADAVER AS OUR FIRST TEACHER anatomt in your.pptx

Improving profitability for small business
Improving profitability for small businessImproving profitability for small business
Improving profitability for small business

anas about venice for grade 6f about venice
anas about venice for grade 6f about veniceanas about venice for grade 6f about venice
anas about venice for grade 6f about venice

Attending a job Interview for B1 and B2 Englsih learners
Attending a job Interview for B1 and B2 Englsih learnersAttending a job Interview for B1 and B2 Englsih learners
Attending a job Interview for B1 and B2 Englsih learners

Brand Analysis for an artist named Struan
Brand Analysis for an artist named StruanBrand Analysis for an artist named Struan
Brand Analysis for an artist named Struan

Unveiling the Secrets How Does Generative AI Work.pdf
Unveiling the Secrets How Does Generative AI Work.pdfUnveiling the Secrets How Does Generative AI Work.pdf
Unveiling the Secrets How Does Generative AI Work.pdf

RMD24 | Debunking the non-endemic revenue myth Marvin Vacquier Droop | First ...
RMD24 | Debunking the non-endemic revenue myth Marvin Vacquier Droop | First ...RMD24 | Debunking the non-endemic revenue myth Marvin Vacquier Droop | First ...
RMD24 | Debunking the non-endemic revenue myth Marvin Vacquier Droop | First ...

What is the TDS Return Filing Due Date for FY 2024-25.pdf
What is the TDS Return Filing Due Date for FY 2024-25.pdfWhat is the TDS Return Filing Due Date for FY 2024-25.pdf
What is the TDS Return Filing Due Date for FY 2024-25.pdf

Affordable Stationery Printing Services in Jaipur | Navpack n Print
Affordable Stationery Printing Services in Jaipur | Navpack n PrintAffordable Stationery Printing Services in Jaipur | Navpack n Print
Affordable Stationery Printing Services in Jaipur | Navpack n Print

Sustainability: Balancing the Environment, Equity & Economy
Sustainability: Balancing the Environment, Equity & EconomySustainability: Balancing the Environment, Equity & Economy
Sustainability: Balancing the Environment, Equity & Economy

Filing Your Delaware Franchise Tax A Detailed Guide
Filing Your Delaware Franchise Tax A Detailed GuideFiling Your Delaware Franchise Tax A Detailed Guide
Filing Your Delaware Franchise Tax A Detailed Guide

Cracking the Workplace Discipline Code Main.pptx
Cracking the Workplace Discipline Code Main.pptxCracking the Workplace Discipline Code Main.pptx
Cracking the Workplace Discipline Code Main.pptx

Buy Verified PayPal Account | Buy Google 5 Star Reviews
Buy Verified PayPal Account | Buy Google 5 Star ReviewsBuy Verified PayPal Account | Buy Google 5 Star Reviews
Buy Verified PayPal Account | Buy Google 5 Star Reviews

Exploring Patterns of Connection with Social Dreaming
Exploring Patterns of Connection with Social DreamingExploring Patterns of Connection with Social Dreaming
Exploring Patterns of Connection with Social Dreaming

Role of Remote Sensing and Monitoring in Mining
Role of Remote Sensing and Monitoring in MiningRole of Remote Sensing and Monitoring in Mining
Role of Remote Sensing and Monitoring in Mining

Lookback Analysis
Lookback AnalysisLookback Analysis
Lookback Analysis


Poly 74-Series Polyurethane Rubbers

  • 1. DESCRIPTION: Poly 74-Series Polyurethane Rubbers consist of two parts (A and B), which, after mixing, cure at room temperature to flexible, high-strength, mold rubbers. Poly 74-Series Rubbers make durable, easy-releasing molds for casting plasters and waxes without release agents. When Poly 74-Series molds are properly prepared, they are also excellent for casting concrete and various resins, such as epoxy, polyester, polyurethane and acrylic. BEFORE USE: Thoroughly read Safety Data Sheets, product labels and the“SAFETY”section in this Technical Bulletin. MODEL PREPARATION: Porous models, such as wood, plaster, stone, pottery or masonry must be sealed. Multiple coats of paste wax dried and buffed will seal most surfaces. Potters soap can be used as a sealer for plaster. Lacquer, paint, PVA, and Pol-Ease® 2350 Release Agent also work well as sealers for many surfaces. The properly-sealed model should then be coated with a release agent (e.g., Pol-Ease® 2300 Release Agent). Alternatively, PolyCoat, a sealer and semi-permanent release agent, can be used on most porous or non-porous models. Porous models must be vented from beneath to prevent trapped air from forming bubbles in the rubber. Models made of sulfur-containing modeling clay (e.g., Roma Plastilina) should be sealed with shellac. [CAUTION: When shellac is used as the sealer, it must be thoroughly coated with release agent because polyurethane rubbers bond tenaciously to shellac.] Non-porous models (e.g., metals, plasticine, wax, glazed ceramics, fiberglass and polyurethanes) should be coated with release agent such as Pol-Ease® 2300 Release Agent or PolyCoat. Poly 74-Series Polyurethane Rubbers Technical Bulletin 55 Hilton Street, Easton, PA 18042 | 800.858.5990 | 610.559.8620 | Fax 610.559.8626 | www.polytek.com | sales@polytek.com If there is any question about the compatibility between the liquid mold rubber and the prepared model surface, perform a test cure on an identical surface to determine that complete curing and good release are obtained. MIXING AND CURING: Before use, be sure that Parts A and B are at room temperature and that all tools are ready. Surface and air temperatures should be above 60°F during application and for the entire curing period. Check mix ratio. Several Poly 74-Series Part Bs require stirring before use (i.e., 74-20, 74-29, 74-30 and 74-40). Weigh Part B into a clean metal or plastic mixing container and then weigh the appropriate amount of Part A into the same container. Mix thoroughly. Hand mixing with a Poly Paddle is best to avoid mixing air into the rubber. While mixing, scrape - Make durable, long-lasting molds owing to strength and elongation properties of cured rubber - Pourable polyurethane rubbers that cure to soft to mid- range hardnesses - Easily thickened for brush-on applications - No release agents needed when casting many plasters, waxes and concretes - Low-viscosity polyurethane rubbers capture detail from intricate masters PHYSICAL PROPERTIES Product 74-20 74-24 74-29 74-30 74-30 Clear 74-30 HT 74-40 74-41 74-44 74-45 74-55 Mix Ratio By Weight 1A:2B 1A:1B 1A:1B 1A:1B 1A:1B 1A:1B 2A:1B 1A:1B 2A:1B 1A:1B 4A:1B Shore Hardness A20 A25 A30 A30 A30 A30 A40 A40 A45 A45 A55 Pour Time 20 min. 20 min. 30 min. 25-30 min. 25-30 min. 25-30 min. 20 min. 20 min. 20 min. 30 min. 15 min. Demold Time @ 73°F 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. Cured Color Yellow Amber Black Amber/ Varies Transparent Amber Amber/ Varies Varies Amber/ Varies Gray Yellow Amber Mixed Viscosity (cP) 800 2,000 2,800 2,000 2,000 2,000 3,400 2,000 3,500 2,000 4,000 Specific Volume (in3 /lb) 27.5 27.5 27.5 27.5 27.5 27.5 27.5 27.5 27.5 27.5 27.5 Specific Gravity 1.01 1.01 1.02 1.01 1.01 1.01 1.01 1.01 1.01 1.02 1.01 Elongation (%) 1,060 750 1,600 506 507 975 400 1,060 2,422 1,135 894 Tensile Strength (psi) 217 220 520 281 281 304 349 360 462 408 679 Die C Tear Strength (pli) 43 55 109 62 62 70 95 77 129 82 155 PRODUCT LINE FEATURES
  • 2. the sides and bottom several times to ensure thorough mixing. Pour the rubber as soon after mixing as possible for best flow and air bubble release. Vacuum degassing helps to provide bubble-free molds, but is usually not necessary. Allow rubber to cure at room temperature, 77°F (25°C). Carefully demold after approximately 16 hours. Final cure properties are obtained in about seven days, but molds may be used with care after curing for 24- 48 hours. Heat accelerates the cure -- low temperatures slow the cure. Avoid curing in areas where the temperature is below 60°F (15°C). Both Parts A and B react with atmospheric moisture and, therefore, should be resealed or used up as soon as possible after opening. Before resealing, Poly Purge, a heavier-than-air, dry gas, can be sprayed into open containers to displace moist air and extend storage life. For 55-gallon drums of Parts A and B, affix Drierite® cartridges on the small bung during dispensing to protect product from moist air entering the drum. SOFTENING THE RUBBER: Add Poly 74/75 Part C Softener to 74-Series products for a lower viscosity mix and a softer cured rubber. When Part C is used, cure time is longer and there is some loss of strength in the rubber and increased tendency to shrink after repeated castings. To soften Poly 74-30 to Shore A15, mix 1A:1B:1C by weight. The quantity of Part C required to soften other products varies and should be determined through experimentation. ACCELERATING THE CURE: Cure time can be shortened with the addition of an Accelerator, such as Poly 74/75 Part X, or by adding heat. Part X is most useful when making brush-on molds to decrease the time needed between coats. By adding 3% Part X (by weight of the total mix) to 74-30 or 74-29, the working time is reduced to approximately 8 minutes -- in the time it takes to mix the next batch, the previous layer gels enough to apply the next coat. Demolding is possible in as little as 4 hours after the final layer is applied. Rapid curing with Part X allows a shell or mother mold to be made in the same day. Exercise caution when using Part X for poured molds since the rapid onset of gelling may trap air bubbles on or near the surface of the master. Heat also accelerates the cure. It is recommended not to exceed 140°F (60°C). THICKENING FOR BRUSH-ON: Add Poly Fiber II or Fumed Silica to mixed Parts A and B to thicken the liquid mix to a gel for application by brush or trowel. USINGTHE MOLD:Typically, no release agent is necessary when casting plaster or wax in Poly 74-Series molds. For casting plaster: sponge, dip or spray the mold with Pol-Ease® Mold Rinse and then pour plaster on the wet mold to reduce air bubbles in the plaster and aid release. For casting resin, first spray the mold with Pol-Ease® 2300 Release Agent or PolyCoat. For casting concrete, use a form release, such as Pol-Ease® 2650 or 2601. Avoid solvent-containing releases since they can cause mold distortion (i.e., shrinkage or swelling). After repeated casting with certain resins, plaster and concrete, molds may shrink slightly since these materials extract oils from the mold. The proper selection of release agent and/or barrier coat can minimize this effect. If shrinkage becomes evident, a light application of Pol-Ease® Mold Dressing can help to restore the mold to its original dimensions. Poly 74-Series molds last many years if stored undistorted on a flat, non- porous surface in a cool, dry location out of direct sunlight. If occasional outdoor use is required, add 0.5% UV Additive to the total mix weight to reduce the characteristic surface degradation caused by sunlight. Never store Poly 74-Series molds outside as UV exposure will eventually degrade the rubber. CLEAN UP: Wipe tools clean before the rubber cures. Denatured ethanol is a good cleaning solvent, but is highly flammable and must be handled with caution. Coat work surfaces with wax, Pol-Ease® 2300 Release Agent or PolyCoat so that cured rubber can be easily removed. SAFETY: Before use, thoroughly read Safety Data Sheets and product labels. Follow safety precautions and directions. Part A: Keep out of reach of children. Avoid breathing fumes, vapors, or mists.Usewithadequategeneralorlocalexhaustventilationtominimize exposure levels. If needed, a NIOSH-approved respirator with organic vapor cartridge may be used. If inhaled, remove victim to fresh air and keep at rest in a position comfortable for breathing. Wear impervious gloves, such as butyl rubber or nitrile rubber. Wash thoroughly with soap and water after handling. Take off contaminated clothing and wash before reuse. If skin irritation or rash occurs, get medical help. Wear eye protection, such as chemical safety glasses/googles. If in eyes, rinse cautiously with water for several minutes, removing contact lenses if present and easy to do. If eye irritation occurs, get medical help. Part B: Keep out of reach of children. Do not breathe fumes, vapors, or mists. Use with adequate general or local exhaust ventilation to minimize exposure levels. If needed, a NIOSH-approved respirator with organic vapor cartridge may be used. If inhaled, remove victim to fresh air and keep at rest in a position comfortable for breathing. Get medical advice if you feel unwell. Wear impervious gloves, such as butyl rubber or nitrile rubber. Wash thoroughly with soap and water after handling. If skin irritation occurs, get medical help. Wear eye protection, such as chemical safety glasses/googles. If in eyes, rinse cautiously with water for several minutes, removing contact lenses if present and easy to do. If eye irritation occurs, get medical help. If spilled, collect spillage and avoid release to the environment. SHELF LIFE: For best results, store products in unopened containers at room temperature (60-90°F/15-32°C). Use products within six months. Part Bs darken with age, but product performance is not affected. DISCLAIMER: The information in this bulletin and otherwise provided by Polytek® Development Corp. is considered accurate. However, no warranty is expressed or implied regarding the accuracy of the data, the results to be obtained by the use thereof, or that any such use will not infringe any patent. Before using, the user shall determine the suitability of the product for the intended use and user assumes all risk and liability whatsoever in connection therewith. 55 Hilton Street, Easton, PA 18042 | 800.858.5990 | 610.559.8620 | Fax 610.559.8626 | www.polytek.com | sales@polytek.com Accelerator: Poly 74/75 Part X Accelerator Sealers & Release Agents: Pol-Ease® 2300 Release Agent Pol-Ease® 2350 Release Agent Pol-Ease® 2450 Release Agent Pol-Ease® 2601 Release Agent Pol-Ease® 2650 Release Agent Pol-Ease® 2500 Release Agent PolyCoat Sealer & Release Agent Pol-Ease® Mold Dressing Pol-Ease® Mold Rinse Poly PVA Solution (Green or Clear) Softener: Poly 74/75 Part C Softener Product Life Extender: Poly Purge Aerosol Dry Gas Thickeners: Fumed Silica Poly Fiber II UV Stabilizer: UV Additive Reinforcement Material: Tietex® Fabric Poly 74-Series Polyurethane Rubbers | Technical Bulletin | Page 2 ACCESSORIES April 28, 2021
  • 3. DESCRIPTION: Poly 75-Series Liquid Rubbers consist of two parts (A and B), which, after mixing, cure at room temperature to flexible rubber. Molds made with Poly 75-Series products are excellent for casting concrete, plaster and wax. In addition, Poly 75-Series molds can be used to cast various resins and foams when properly prepared. Poly 75-Series Liquid Rubbers are formulated for good economy with high performance and durability. BEFORE USE: Thoroughly read Safety Data Sheets, product labels and the“SAFETY”section in this Technical Bulletin. MODEL PREPARATION: Porous models, such as wood, plaster, stone, pottery or masonry must be sealed. Multiple coats of paste wax dried and buffed will seal most surfaces. Potters soap can be used as a sealer for plaster. Lacquer, paint, PVA, and Pol-Ease® 2350 Release Agent also work well as sealers for many surfaces. The properly-sealed model should then be coated with a release agent (e.g., Pol-Ease® 2300 Release Agent). Alternatively, PolyCoat, a sealer and semi-permanent release agent, can be used on most porous or non-porous models. Porous models must be vented from beneath to prevent trapped air from forming bubbles in the rubber. Models made of sulfur-containing modeling clay (e.g., Roma Plastilina) should be sealed with shellac. [CAUTION: When shellac is used as the sealer, it must be thoroughly coated with release agent because polyurethane rubbers bond tenaciously to shellac.] Non-porous models (e.g., metals, plasticine, wax, glazed ceramics, fiberglass and polyurethanes) should be coated with release agent such as Pol-Ease® 2300 Release Agent or PolyCoat. If there is any question about the compatibility between the liquid mold rubber and the prepared model surface, perform a test cure on an identical surface to determine that complete curing and good release are obtained. MIXING AND CURING: Before use, be sure that Parts A and B are at room temperature and that all tools are ready. Surface and air temperatures Poly 75-Series Liquid Rubbers Technical Bulletin 55 Hilton Street, Easton, PA 18042 | 800.858.5990 | 610.559.8620 | Fax 610.559.8626 | www.polytek.com | sales@polytek.com should be above 60°F during application and for the entire curing period. Check mix ratio. Weigh Part B into a clean metal or plastic mixing container and then weigh the appropriate amount of Part A into the same container. Mix thoroughly. Hand mixing with a Poly Paddle is best to avoid mixing air into the rubber. While mixing, scrape the sides and bottom several times to ensure thorough mixing. Pour the rubber as soon after mixing as possible for best flow and air bubble release. Vacuum degassing helps to provide bubble-free molds, but is usually not necessary. Allow rubber to cure at room temperature, 77°F (25°C). Carefully demold after approximately 16 hours. Final cure properties are obtained in about seven days, but molds may be used with care after curing for 24- 48 hours. Heat accelerates the cure -- low temperatures slow the cure. Avoid curing in areas where the temperature is below 60°F (15°C). Both Parts A and B react with atmospheric moisture and, therefore, should be resealed or used up as soon as possible after opening. Before resealing, Poly Purge, a heavier-than-air, dry gas, can be sprayed into open containers to displace moist air and extend storage life. For 55-gallon drums of Parts A and B, affix Drierite® cartridges on the small bung during dispensing to protect product from moist air entering the drum. - Firm yet flexible mold rubbers - Ideal for demanding, high-production casting and forming of concrete - Dimensionally stable - molds can last for years - Abrasion resistant for long mold life - Easy-to-use, forgiving formulations PHYSICAL PROPERTIES Product 75-59 75-60 75-65 75-70 75-75 75-79 75-80 75-90 Mix Ratio By Weight 1A:1B 1A:1B 1A:1B 1A:1B 2A:1B 2A:1B 2A:1B 2A:1B Shore Hardness A60 A60 A65 A70 A75 A80 A80 A90 Pour Time 10 min. 10 min. 35 min. 40 min. 20 min. 20 min. 45 min. 10-15 min. Demold Time @ 73°F 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. 16 hr. Cured Color Amber Amber Yellow Gray Amber Yellow Yellow Tan Mixed Viscosity (cP) 2,500 1,200 3,000 3,000 4,000 2,000 5,000 6,000 Specific Volume (in3 /lb) 27 27 27 27 26 26 26 26 Specific Gravity 1.05 1.05 1.04 1.05 1.06 1.07 1.07 1.07 Elongation (%) 588 459 550 724 722 369 468 774 Tensile Strength (psi) 637 545 520 938 1,064 655 750 1,979 Die C Tear Strength (pli) 122 103 145 299 247 143 199 368 PRODUCT LINE FEATURES
  • 4. gloves, such as butyl rubber or nitrile rubber. Take off contaminated clothing and wash it before reuse. Contaminated work clothing should be not allowed out of the work area. Wash skin thoroughly with soap and water after handling. If skin irritation occurs, get medical help. Wear eye protection, such as chemical safety glasses/googles. If in eyes, rinse cautiously with water for several minutes, removing contact lenses if present and easy to do. If eye irritation occurs, get medical help. If spilled, collect spillage and avoid release to the environment. SHELF LIFE: For best results, store products in unopened containers at room temperature (60-90°F/15-32°C). Use products within six months. Part Bs darken with age, but product performance is not affected. DISCLAIMER: The information in this bulletin and otherwise provided by Polytek® Development Corp. is considered accurate. However, no warranty is expressed or implied regarding the accuracy of the data, the results to be obtained by the use thereof, or that any such use will not infringe any patent. Before using, the user shall determine the suitability of the product for the intended use and user assumes all risk and liability whatsoever in connection therewith. 55 Hilton Street, Easton, PA 18042 | 800.858.5990 | 610.559.8620 | Fax 610.559.8626 | www.polytek.com | sales@polytek.com Accelerator: Poly 74/75 Part X Accelerator Sealers & Release Agents: Pol-Ease® 2300 Release Agent Pol-Ease® 2350 Release Agent Pol-Ease® 2450 Release Agent Pol-Ease® 2601 Release Agent Pol-Ease® 2650 Release Agent Pol-Ease® 2500 Release Agent PolyCoat Sealer & Release Agent Pol-Ease® Mold Dressing Pol-Ease® Mold Rinse Poly PVA Solution (Green or Clear) Softener: Poly 74/75 Part C Softener Product Life Extender: Poly Purge Aerosol Dry Gas Thickeners: Poly Fiber II UV Stabilizer: UV Additive Reinforcement Material: Tietex® Fabric SOFTENING THE RUBBER: Add Poly 74/75 Part C Softener to 75-Series products for a lower viscosity mix and a softer cured rubber. When using Part C, cure time is longer and there is some loss of strength in the rubber and increased tendency to shrink after repeated castings. Determine the quantity of Part C required through experimentation. ACCELERATING THE CURE: Cure time can be shortened with the addition of an Accelerator, such as Poly 74/75 Part X, or by adding heat. By adding 1% Poly 74/75 Part X (by weight of total mix) to Poly 75-80, the working time is reduced to approximately 10 minutes and demolding is possible in as little as 6 hours. Exercise caution when using Part X since the rapid onset of gelling may trap air bubbles on or near the surface of the model. Heat also accelerates the cure. It is recommended not to exceed 140°F (60°C). USINGTHE MOLD:Typically, no release agent is necessary when casting plaster or wax in Poly 75-Series molds. For casting plaster: sponge, dip or spray the mold with Pol-Ease® Mold Rinse and then pour plaster on the wet mold to reduce air bubbles in the plaster and aid release. For casting resin, first spray the mold with Pol-Ease® 2300 Release Agent or PolyCoat. For casting concrete, use a form release, such as Pol-Ease® 2650 or 2601. Avoid solvent-containing releases since they can cause mold distortion (i.e., shrinkage or swelling). After repeated casting with certain resins, plaster and concrete, molds may shrink slightly since these materials extract oils from the mold. The proper selection of release agent and/or barrier coat can minimize this effect. If shrinkage becomes evident, a light application of Pol-Ease® Mold Dressing can help to restore the mold to its original dimensions. Poly 75-Series molds last many years if stored undistorted on a flat, non- porous surface in a cool, dry location out of direct sunlight. If occasional outdoor use is required, Poly 75-59, 75-65 and 75-80 perform best and UV resistance can be improved by adding Poly UV Additive. Add 0.5% UV Additive to the total mix weight to reduce the characteristic surface degradation caused by sunlight. Never store Poly 75-Series molds outside as UV exposure will eventually degrade the rubber. CLEAN UP: Wipe tools clean before the rubber cures. Denatured ethanol is a good cleaning solvent, but is highly flammable and must be handled with caution. Coat work surfaces with wax, Pol-Ease® 2300 Release Agent or PolyCoat so cured rubber can be removed. SAFETY: Before use, thoroughly read Safety Data Sheets and product labels. Follow safety precautions and directions. Part A: Keep out of reach of children. Avoid breathing fumes, vapors or mists. Use with adequate general or local exhaust ventilation to minimize exposure levels. If needed, a NIOSH-approved respirator with organic vapor cartridge may be used. If inhaled and breathing is difficult, remove victim to fresh air and keep at rest in a position comfortable for breathing. Wear impervious gloves, such as butyl rubber or nitrile rubber. Take off contaminated clothing and wash before reuse. Wash skin thoroughly with soap and water after handling. If skin irritation occurs, get medical help. Wear eye protection, such as chemical safety glasses/googles. If in eyes, rinse cautiously with water for several minutes, removing contact lenses if present and easy to do. If eye irritation occurs, get medical help. Part B: Keep out of reach of children. Do not breathe fumes, vapors or mists.Usewithadequategeneralorlocalexhaustventilationtominimize exposure levels. If needed, a NIOSH-approved respirator with organic vapor cartridge may be used. If inhaled, remove victim to fresh air and keep at rest in a position comfortable for breathing. Wear impervious December 10, 2020 Poly 75-Series Liquid Rubbers|Technical Bulletin|Page 2 ACCESSORIES
  • 5. DESCRIPTION: Use Poly 81-Series rubbers to make firm molds, mold facings, stamping tools, industrial parts, rollers, gaskets, mold shells, bumpers or pads. Poly 81-Series rubbers consist of two liquid parts (A and B), which, after mixing, cure at room temperature to tough, durable rubbers.They offer low sensitivity to moisture, and low viscosity for easy mixing and pouring. BEFORE USE: Thoroughly read Safety Data Sheets, product labels and the“SAFETY”section in this Technical Bulletin. MODEL PREPARATION: Porous models, such as wood, plaster, stone, pottery or masonry must be sealed. Multiple coats of paste wax dried and buffed will seal most surfaces. Potters soap can be used as a sealer for plaster. Lacquer, paint, PVA, and Pol-Ease® 2350 Release Agent also work well as sealers for many surfaces. The properly-sealed model should then be coated with a release agent (e.g., Pol-Ease® 2300 Release Agent). Alternatively, PolyCoat, a sealer and semi-permanent release agent, can be used on most porous or non-porous models. Porous models must be vented from beneath to prevent trapped air from forming bubbles in the rubber. Models made of sulfur-containing modeling clay (e.g., Roma Plastilina) should be sealed with shellac. [CAUTION: When shellac is used as the sealer, it must be thoroughly coated with release agent because polyurethane rubbers bond tenaciously to shellac.] Non-porous models (e.g., metals, plasticine, wax, glazed ceramics, fiberglass and polyurethanes) should be coated with release agent such as Pol-Ease® 2300 Release Agent or PolyCoat. If there is any question about the compatibility between the liquid mold rubber and the prepared model surface, perform a test cure on an identical surface to determine that complete curing and good release are obtained. MIXING AND CURING: Before use, be sure that Parts A and B are at room temperature and that all tools are ready. Surface and air temperatures should be above 60°F during application and for the entire curing period. Poly 81-Series Liquid Rubbers Technical Bulletin Check mix ratio. Weigh Part B into a clean metal or plastic mixing container and then weigh the appropriate amount of Part A into the same container. Mix thoroughly. Hand mixing with a Poly Paddle is best to avoid mixing air into the rubber. While mixing, scrape the sides and bottom several times to ensure thorough mixing. Pour the rubber as soon after mixing as possible for best flow and air bubble release. Vacuum degassing helps to provide bubble-free molds, but is usually not necessary. Allow rubber to cure at room temperature, 77°F (25°C). Carefully demold after approximately 16 hours. Final cure properties are obtained in about seven days, but molds may be used with care after curing for 24- 48 hours. Heat accelerates the cure -- low temperatures slow the cure. Avoid curing in areas where the temperature is below 60°F (15°C). Both Parts A and B react with atmospheric moisture and, therefore, should be resealed or used up as soon as possible after opening. Before resealing, Poly Purge, a heavier-than-air, dry gas, can be sprayed into open containers to displace moist air and extend storage life. For 55-gallon drums of Parts A and B, affix Drierite® cartridges on the small bung during dispensing to protect product from moist air entering the drum. USINGTHE MOLD:Typically, no release agent is necessary when casting plaster or wax in Poly 81-Series molds. For casting plaster: sponge, dip or spray the mold with Pol-Ease® Mold Rinse and then pour plaster on the wet mold to reduce air bubbles in the plaster and aid release. For casting resin, first spray the mold with Pol-Ease® 2300 Release Agent - Firm rubbers with Shore A90 or D45 - Hard, yet flexible - Easy-to-use formulations - Reproduce fine details - Make tough, long-lasting molds, tools & parts PHYSICAL PROPERTIES Product 81-90 81-D45 Mix Ratio By Weight 100A:40B 100A:20B Shore Hardness A90 D45 Pour Time 23 min. 19 min. Demold Time @ 73°F 16 hr. 16 hr. Cured Color Varies Varies Mixed Viscosity (cP) 2,000 1,600 Specific Volume (in3 /lb) 26.6 26.4 Specific Gravity 1.06 1.08 Elongation (%) 463 327 Tensile Strength (psi) 1,550 1,426 Die C Tear Strength (pli) 357 380 PRODUCT LINE FEATURES 55 Hilton Street, Easton, PA 18042 | 800.858.5990 | 610.559.8620 | Fax 610.559.8626 | www.polytek.com | sales@polytek.com
  • 6. 55 Hilton Street, Easton, PA 18042 | 800.858.5990 | 610.559.8620 | Fax 610.559.8626 | www.polytek.com | sales@polytek.com Sealers & Release Agents: Pol-Ease® 2300 Release Agent Pol-Ease® 2350 Release Agent Pol-Ease® 2450 Release Agent Pol-Ease® 2601 Release Agent Pol-Ease® 2650 Release Agent Pol-Ease® 2500 Release Agent PolyCoat Sealer & Release Agent Pol-Ease® Mold Dressing Pol-Ease® Mold Rinse Poly PVA Solution (Green or Clear) Product Life Extender: Poly Purge Aerosol Dry Gas Thickeners: Fumed Silica Poly Fiber II UV Stabilizer: UV Additive Reinforcement Material: Tietex® Fabric or PolyCoat. For casting concrete, use a form release, such as Pol-Ease® 2650 or 2601. Avoid solvent-containing releases since they can cause mold distortion (i.e., shrinkage or swelling). After repeated casting with certain resins, plaster and concrete, molds may shrink slightly since these materials extract oils from the mold. The proper selection of release agent and/or barrier coat can minimize this effect. If shrinkage becomes evident, a light application of Pol-Ease® Mold Dressing can help to restore the mold to its original dimensions. Poly 81-Series molds last many years if stored undistorted on a flat, non- porous surface in a cool, dry location out of direct sunlight. If occasional outdoor use is required, add 0.5% UV Additive to the total mix weight to reduce the characteristic surface degradation caused by sunlight. Never store Poly 81-Series molds outside as UV exposure will eventually degrade the rubber. CLEAN UP: Wipe tools clean before the rubber cures. Denatured ethanol is a good cleaning solvent, but is highly flammable and must be handled with caution. Coat work surfaces with wax, Pol-Ease® 2300 Release Agent or PolyCoat so that cured rubber can be easily removed. SAFETY:Before use, thoroughly read Safety Data Sheets and product labels. Follow safety precautions and directions. Part A: Keep out of reach of children. Avoid breathing fumes, vapors, sprays, or mists. Use only outdoors or with adequate general or local exhaust ventilation to minimize exposure levels. If needed, a NIOSH- approved respirator with organic vapor cartridge may be used. If inhaled and breathing is difficult, remove victim to fresh air and keep at rest in a position comfortable for breathing. If experiencing respiratory irritation, seek medical attention. Wear impervious gloves, such as butyl rubber or nitrile rubber. Wash skin thoroughly with soap and water after handling. If skin irritation or rash occurs, get medical advice or attention. Wear eye protection, such as chemical safety glasses/googles. If in eyes, rinse cautiously with water for several minutes, removing contact lenses if present and easy to do. Store in a well-ventilated place and keep container tightly closed. Part B: Keep out of reach of children. Do not breathe fumes, vapors, sprays, or mists. Use with adequate general or local exhaust ventilation to minimize exposure levels. If needed, a NIOSH-approved respirator with organic vapor cartridge may be used. If inhaled, remove victim to fresh air and keep at rest in a position comfortable for breathing. Wear impervious gloves, such as butyl rubber or nitrile rubber. Wash skin thoroughly with soap and water after handling. Wear eye protection, such as chemical safety glasses/googles. If in eyes, rinse cautiously with water for several minutes, removing contact lenses if present and easy to do. If eye irritation persists, get medical advice or attention. If spilled, collect spillage and avoid release to the environment. SHELF LIFE: For best results, store products in unopened containers at room temperature (60-90°F/15-32°C). Use products within six months. Part Bs darken with age, but product performance is not affected. DISCLAIMER: The information in this bulletin and otherwise provided by Polytek® Development Corp. is considered accurate. However, no warranty is expressed or implied regarding the accuracy of the data, the results to be obtained by the use thereof, or that any such use will not infringe any patent. Before using, the user shall determine the suitability of the product for the intended use and user assumes all risk and liability whatsoever in connection therewith. Poly 81-Series Liquid Rubbers | Technical Bulletin | Page 2 December 10, 2020 ACCESSORIES
