Edge banding involves applying a thin material with heat-sensitive adhesive to the exposed edges of wood panels. This seals the edges, prevents moisture damage, and provides a finished look. Edge banding machines automate the process through steps like feeding, gluing, attaching, trimming, and buffing the edge banding. Industrial edge banding machines offer benefits like consistency, uptime, and minimal waste to provide significant cost savings over manual edge banding.

1. EDGE BANDING

2. Edge banding Definition:-
Edge banding is a thin material used to seal the exposed and raw edges
of plywood. Heat sensitive adhesive on one side is applied to the board while the
other side acts as a barrier against dirt and moisture. Edge banding is mainly done
to cover plywood sides in order to match a cabinet’s finished look.

3. Why Edge banding
Makes wood more durable
Stops the wood from warping
Prevents humidity from seeping into the wood
Strengthens the wood
Adds value to the end product

4. Types of Boards used in Panel Processing
Ply Board
Particle Board
MDF ( Medium Density Fibre ) Board
HDF ( High Density Fibre ) Board

5. Edge Banding Procedure
Machine Infeed
Premilling
Edge Feeding
Glue Application
Edge banding Attachment
GuillotineCutting
Pressure Rollers
EndTrimming
Top & BottomTrimming
Corner Rounding
Radius Scrapper
Glue Scrapper
CleaningAgent
Buffing

6. Edge banding machine Models
IMA
Novimat L12
Novimat L20
HOLZHER
Artea
Auriga
Sprint
Lumina
Industrial
Accura
Lumina

7. USP of Holzher
Glu Jet
iTronic
fa.s.t SettingTechnology
SYNCHRO Edge Feeding

8. Glu JetTechnology

9. iTronic
AdaptiveTrimming Blade
Automatic Pressure Unit
Automatic Glu quantity Control
Automatic Cleaning Unit
Glue quantity indicator

10. iTronic Contd
Adaptive cutting knife: Whether thin edge or thick veneer edge - always the
right power.
Adaptive pressure unit: Solid wood or thin edge - the pressure combination
always fits.
Automatic glue quantity control: MDF or chipboard - always perfect glue
application.
Automatic rinsing routine: Clean at the touch of a button.
Residual adhesive quantity monitoring: Always know what's still possible.

11. Why Industrial Machines?
Ensure Interchangeability
Predictive Maintenance
Machine Availability
Consistence Quality & Quantity
Minimum wastage of raw materials
Future Proof Investment
Can run 3shifts/Day

12. Sample Savings on Edge banding
Particulars Quantity Savings
Over hanging 45mm Each Side 45X4=180mm per Panel
Production/Day 10,000 Panels 10,000X180=1800m
Working Days in a
year
300 300X1800=5,40,000m
Average Cost of PVC INR 15 5,40,000X15=81,00,000
Total Savings in aYear (INR) INR 80,00,000 (80 Lakhs)

13. Product Specification
Technical Details Accura Auriga Sprint Lumina Lumina ( I ) Artea
Feed Speed (m/min) 10-20 (25) 10 10-18 10-20(25) 9
MinimumWorkpiece
length (mm)
140 160 160 140 180/210
MinimumWorkpiece
Width (mm)
60 60 60 60 70
WorkpieceThickness
(mm)
8-60 8-60 8-60 8-60 8-50
EdgeWidth (mm) 0.4-8 0.4-8 0.4-8 0.4-8 0.4-5
