This Slide describe my final year project. It was based on One Touch Alarm for women saftey. We used 8085, GPS And GSM Module to Create it. I hope it would be beneficial for Electronics And Computer science students

1. 1One Touch Security System For Womens
Done By
1. Nihal P.S
2. Aswani
3. Anusree
4. Akhila
5. Vishnunath

2. One Touch Security System
One Touch Security System For Womens 2

3. Introduction
In the light of recent outrage in Delhi which shook
the nation and woke us to the safety issues for
women’s, people are finding up in different ways to
defend. Here we introduce a device which ensures
the protection of women. This helps to identify
protect and call on resources to help the one out of
dangerous situations. Anytime you senses danger,
all you had to do, is hold on the button of the
device.
3One Touch Alarm For Women Safety

4. Objective
To provide highly reliable security
system for the saftey of womens.
Implementation of a real time
monitoring device can solve the
problem up to a limit
4One Touch Security System For Womens

5. Proposed System
 Our proposed system is specially for women safety and
overcomes the disadvantages of existing systems
 In this proposed system when women feels danger it
can be intimated immediately to control room and
assigned contacts
5One Touch Security System For Womens

6. BLOCK DIAGRAM
Switch 8051
Serial
Interface
Power
Supply
GSM/GPS
6One Touch Security System For Womens
Buzzer

7. Power Supply
 Step down transformer
 Rectification (Bridge rectifier)
 Regulation (7805)
 Filtering
One Touch Security System For Womens 7

8. 8051 Microcontroler
One Touch Security System For Womens 8
• AT89S52
• 8 Bit CPU
• 4K ROM
• 16 Bit Program counter
• Internal RAM Of 128 bytes
• 32 I/O Pins
• Four 8-bit Ports
• Low cost

9. Serial Interface (MAX232)
9One Touch Security System For Womens

10. Serial Interface (MAX232)
 Produced by maxim
 16 pin IC Used in RS232 communication system
 It is an integrated circuit which converts the signals
from the RS232 serial port to the proper signal which
are used in the TTL compatible digital logic circuits.
10One Touch Security System For Womens

11. One Touch Security System For Womens 11
Circuit Diagram

12. Circuit Diagram Description
 Bridge Rectifier
 Microcontroller 8051
 Voltage Regulator (7805)
 Serial Interface (MAX232)
 Piezo Electric Buzzer
 Serial Port (DB9)
 GPS&GSM Module (SIM908)
One Touch Security System For Womens 12

13. Advantages Disadvantages
 Easy to use
 Fast transmission of data
 Can inform multiple contacts
at a same time
 Portable device
 No need to pair with smart
phones like existing devices
 Initial cost is high
 Depends With network signal
13One Touch Security System For Womens

14. Further Applications
 Useful for women’s safety
 Can be used for children tracking during school times
 Useful for elders or physically challenged peoples
during pilgrims or sabarimala season
14One Touch Security System For Womens

15. Conclusion
The proposed design will deal with critical issues faced
by women in the near past and will help to solve them
with technological ideas. While the society may or
may not change for the enhanced, the power to be
autonomous, self-assured and truly free can come with
arming oneself with the best possible device. This
system can overcome the fear that scares every woman
in the country about her safety and security
15One Touch Security System For Womens

16. 16One Touch Security System For Womens
