Migrating and Running DBs on Amazon RDS for Oracle

© 2016 Pythian 1
Migrating and Running DBs
on Amazon RDS for Oracle
MARIS ELSINS
Lead Database Consultant

© 2016 Pythian 2
Maris Elsins
Lead Database Consultant
At Pythian since 2011
Located in Riga, Latvia
Oracle [Apps] DBA since 2005
Speaker at conferences since 2007
@MarisDBA elsins@pythian.com
http://bit.ly/getMOSPatchV2

© 2016 Pythian 3
Migrating and Running DBs on
Amazon RDS for Oracle
Mining AWR V2: Trend Analysis
Today: 17:55, Hall 9

© 2016 Pythian 5
ABOUT PYTHIAN
Pythian’s 400+ IT professionals
help companies adopt and
manage disruptive technologies
to better compete

© 2016 Pythian 6
Systems currently
managed by Pythian
EXPERIENCED
Pythian experts
in 35 countries
GLOBAL
Millennia of experience
gathered and shared
over 19 years
EXPERTS
11,800 2400

© 2016 Pythian 7
• Intro...
• Sizing...
• Migrating...
• Running and Monitoring...
• When things go bad...
AGENDA

© 2016 Pythian 8
… these are just few of my
observations
• Why Cloud?
• Choosing between cloud vendors
• Terminology
• Complete pricing guide
• The right way to do anything
I mean it!
NOT ON AGENDA

© 2016 Pythian 9
DISCLAIMER
OK, YOU CAUGHT ME ...
I may have a few “Ouch!” slides in
the presentation, that probably will
make you think Oracle RDS is no
good.
It's not the intention.
I honestly think Oracle RDS is a
great service for the appropriate
workload, and if it's done right.

© 2016 Pythian 10
BEFORE WE START ...
Can I comment or ask questions
during the presentation?
Photo by Day Donaldson / CC BY 2.0

© 2016 Pythian 11
INTRODUCTION
... to RDS for Oracle

© 2016 Pythian 12
AWS RDS FOR ORACLE
INTRODUCTION - REGIONS
https://aws.amazon.com/about-aws/global-infrastructure/

© 2016 Pythian 13
INTRODUCTION
WHAT IS RDS
• Relational Database Service
• PaaS (DBaaS)
• Managed by AWS
– Setup / Provisioning
– Backups
– Maintenance / Patching
– Alerting
– DR
– ...
• SSH Access / SQL*Net connectivity

© 2016 Pythian 14
• 11gR2:
– 11.2.0.2.v3 - 11.2.0.2.v7
– 11.2.0.3.v1 - 11.2.0.3.v4
– 11.2.0.4.v1 - 11.2.0.4.v9
• 12cR1:
– 12.1.0.1.v1 - 12.1.0.1.v6
– 12.1.0.2.v1 - 12.1.0.2.v5
• Engine versions differ by included patches
– PSU / DST / GG / + critical one-offs
INTRODUCTION
DB ENGINES
http://docs.aws.amazon.com/AmazonRDS/latest/UserGuide/Appendix.Oracle.PatchComposition.html
What if I need a specific
one-off?

© 2016 Pythian 15
INTRODUCTION
DATABASE EDITIONS
https://aws.amazon.com/rds/oracle/details/
Edition License Included Bring Your Own License
SE One ✓ ✓
SE Two ✓ ✓
SE ✓
EE ✓

© 2016 Pythian 16
INTRODUCTION
LICENSING
• Two important sources:
– Licensing Oracle Software in the Cloud Computing Environment
– Virtual Cores by Amazon EC2 and RDS DB Instance Type
• Virtual cores != Virtual CPUs (vCPUs)
– vCPU is actually a HyperThread
• Core Factor of 0.5 applies to "Virtual cores"
• Max sizing for SE:
– SE: 16 Virtual Cores | 32 vCPU
– SE: One/Two: 8 Virtual Cores | 16 vCPU

© 2016 Pythian 17
INTRODUCTION
LICENSING EXAMPLE
• Oracle EE
• 16 vCPU = 8 virtual cores
• 8 virtual cores * 0.5 (core factor) = 4 Licences

© 2016 Pythian 18
INTRODUCTION
INSTANCE CLASSES AND TYPES
https://aws.amazon.com/rds/oracle/details/
• Instance Classes (available for RDS)
– Standard - Latest Generation (db.m4.{type})
– Standard - Previous Generation (db.m3.{type})
– Memory Optimized - Current Generation (db.r3.{type})
– Micro instances (db.t1.{type})
• Types: micro - small - ... - xlarge - ... - 10xlarge
– vCPUs: 1 - 40
– Memory: 1 - 160 GiB
– PIOPS-Optimized: Yes / No
– Network Performance: Low to Moderate - 10 Gigabit
Pay attention to these
when choosing the
storage type!

© 2016 Pythian 19
INTRODUCTION
STORAGE TYPES
http://docs.aws.amazon.com/AmazonRDS/latest/UserGuide/CHAP_Storage.html
Magnetic General Purpose SSD Provisioned IOPS
• Spinning disks
• Previous gen / obsolete
• Pay per Use + Size
• ~ 100 IOPS
• 1MiB IO size
• SSD
• Cheap & Low Latency
• 3 IOPS * 1GiB
• Pay per Size
• Up to 160 MiB/s
• Accounted IO size = 32K
• Burstable
• SSD
• Expensive & Low
Latency
• 10 IOPS * 1GiB
• Pay per Size + PIOPS
• Up to 500 MiB/s (or
320MiB/s ???)
• Accounted IO size = 32K
This is super - complicated, read this!
The documentation
is not very clear
PIOPS =
Provisioned IO per Second

© 2016 Pythian 20
• P-IOPS
• GP-SSD
• Magnetic
INTRODUCTION
STORAGE - WHAT ABOUT COST OF 120G AND 1200 IOPS?
https://calculator.s3.amazonaws.com/index.html
My favourite :)
Burstable!
No IOPS
guarantee

© 2016 Pythian 21
INTRODUCTION
STORAGE-RELATED LIMITATIONS
• Different limits apply based on
– Instance Type
– Storage Type
– Storage Size
– PIOPS
• For example:
– EBS Throughput (Mbps) per Instance
– EBS Throughput (Mbps) per EBS Volume
– Max IOPS per Instance
– Max IOPS per Volume
– PIOPS you reserved and paid for
– IOPS differ depending on the size of the IO
I guess I'll have to do some
real benchmarking !

© 2016 Pythian 22
INTRODUCTION
OPTION GROUPS - OPTIONS
http://docs.aws.amazon.com/AmazonRDS/latest/UserGuide/Appendix.Oracle.Options.html
Option Option ID
Oracle Application Express APEX, APEX-DEV
Oracle Enterprise Manager OEM, OEM_AGENT
Oracle Label Security OLS
Oracle Native Network Encryption NATIVE_NETWORK_ENCRYPTION
Oracle SSL SSL
Oracle Statspack STATSPACK
Oracle Time Zone Timezone
Oracle Transparent Data Encryption TDE
Oracle UTL_MAIL UTL_MAIL
Oracle XML DB XMLDB

© 2016 Pythian 23
• Option group
– Defines the set of enabled options
– can be assigned to multiple RDS instances
• Default options groups:
– “default:oracle-ee-11-2” and “default:oracle-ee-12-1”
– has no options enabled by default
– Can't be modified
• Separate PROD, QA, TEST, …
INTRODUCTION
OPTION GROUPS

© 2016 Pythian 24
INTRODUCTION
PARAMETER GROUPS
• Parameter Groups
– Defines the init parameters
• Remember, you don't have access to “/ as sysdba”
• How do I run “alter system …”
– Can be assigned to multiple instances
– Some parameters are derived from instance settings
• i.e. DB_NAME={DbName}
• Default parameter groups can't be changed
– Even modifiable settings require reboot.
– We used a workaround in few cases - a logon trigger

© 2016 Pythian 25
• MEMORY_TARGET = {DBInstanceClassMemory*3/4}
– AMM means hugepages are not used
– Swapping is possible
AWS RDS FOR ORACLE
SOME PARAMETERS I FOUND INTERESTING …
Swap usage MB
Connection pool
misconfiguration
Ouch !

© 2016 Pythian 26
• DB_FILE_MULTIBLOCK_READ_COUNT not set (128)
– IO size up to 1MiB issues by the DB
AWS RDS FOR ORACLE
Ouch !
A single 1MiB-IO (128 data blocks) from the DB ...
… Is handled by 4 256K-IOs on SSD and ...
… Is accounted as 32 32K-IOs by AWS
Used for IOPS calculation
By AWS

© 2016 Pythian 27
• UNDO_RETENTION not set (the default is 900 seconds)
• We're using parameter group “default.oracle-ee-11.2”
AWS RDS FOR ORACLE
Ouch !
• Suddenly:
– “expdp … consistent=y”
– ORA-31693: Table data object "XYZ"."BLAH_BLAH" failed to
load/unload and is being skipped due to error:
ORA-02354: error in exporting/importing data
ORA-01555: snapshot too old: rollback segment number 82 with name
"_SYSSMU82_540458409$" too small

© 2016 Pythian 28
SIZING...
the Oracle RDS

© 2016 Pythian 29
SIZING IT CORRECTLY
IT'S NOT VERY SIMPLE...
• Instance size (CPU / RAM) is
Important:
– Size it too big - cost-efficiency reduces
– Size it too small - performance suffers
• Storage size (GB / IOPS) is Important:
– Size it too big - cost-efficiency reduces
– Size it too small - performance suffers

© 2016 Pythian 30
• How to check the current usage?
– sar - CPU/RAM/IO ?
• 10 minute intervals for past workloads
• Difficult to derive IOPS info
– SGA sizing
– iostat ?
– data from storage?
• What if it's not 1-to-1 move to RDS?
– 1DB with 20+ schemas -> 4 RDS instances?
SIZING IT CORRECTLY
TOOLS
Peak load?

© 2016 Pythian 31
• CPU is simple
– sar 1 99999 > cpu_usage.lst
• Provides CPU usage % for every issue
– ASH ?
• Probably still not granular enough (binary indicator)
• Good to for deriving the proportions of CPU usage
– v$sesstat / v$sysstat could be sampled too
• … we didn't go this way ...
SIZING IT CORRECTLY
CPU IS SIMPLE

© 2016 Pythian 32
SIZING IT CORRECTLY
CPU DISTRIBUTION AMONG SCHEMAS
• Using ASH to derive max CPU usage per hour by
schema
– (but again it ignores “spikes”)
select username, avg(CPUTIME_S), avg(DBTIME_S), avg(CPUTIME_PCT_OF_4CPU), avg(DBTIME_PCT_OF_4CPU),
min(CPUTIME_S), min(DBTIME_S), min(CPUTIME_PCT_OF_4CPU), min(DBTIME_PCT_OF_4CPU),
max(CPUTIME_S), max(DBTIME_S), max(CPUTIME_PCT_OF_4CPU), max(DBTIME_PCT_OF_4CPU)
from (select d.sample_time, u.username, 14400 AVAILABLE_TIME, CPUTIME_S, DBTIME_S,
round(CPUTIME_S/14400*100,1) CPUTIME_PCT_OF_4CPU, round(DBTIME_S/14400*100,1) DBTIME_PCT_OF_4CPU
from (select snap_id, trunc(min(sample_time),'HH24') sample_time, user_id,
10*count(decode(event,null,1,null)) CPUTIME_S, 10*count(*) DBTIME_S
from dba_hist_active_sess_history
where sample_time>= trunc(sysdate-31)
group by snap_id, user_id) d,
dba_users u
where d.user_id=u.user_id)
group by username order by 1;

© 2016 Pythian 33
SIZING IT CORRECTLY
CPU DISTRIBUTION AMONG SCHEMAS

© 2016 Pythian 34
• IO is not simple
– Differently-sized IO done by database
• 8K to 1024K
• … 1 to 32 RDS-IOs per 1 DB-IO
– Identifying spikes is difficult
• AWR (DBA_HIST_IOSTAT_DETAIL)
• SMALL_READ_MEGABYTES / LARGE_READ_MEGABYTES
• SMALL_READ_REQS / LARGE_READ_REQS
SIZING IT CORRECTLY
IO IS NOT SIMPLE
Peak load?

© 2016 Pythian 35
SIZING IT CORRECTLY
IO IS NOT SIMPLE
• Sampling ASM statistics:
– asm_metrics.pl by Bertrand Drouvot
– https://bdrouvot.wordpress.com/2013/10/04/...
• 1-second sampling:
23:00:03 Kby Avg AvgBy/ Kby Avg AvgBy/
23:00:03 DBINST DG Reads/s Read/s ms/Read Read Writes/s Write/s ms/Write Write
23:00:03 ----------- ----------- ------- ------- ------- ------ ------ ------- -------- ------
23:00:03 INST1 146 1360 9.1 9539 435 5578 25.5 13131
23:00:03 INST1 DATA 146 1360 9.1 9539 171 4096 61.7 24528
23:00:03 INST1 RECO 0 0 0.0 0 6 216 86.3 36864
23:00:03 INST1 REDO 0 0 0.0 0 258 1266 0.2 5025
23:00:03 INST2 245 2104 8.3 8794 2109 23955 97.5 11631
23:00:03 INST2 DATA 245 2104 8.3 8794 1998 21648 102.7 11095
23:00:03 INST2 RECO 0 0 0.0 0 3 1968 116.9 671744
23:00:03 INST2 REDO 0 0 0.0 0 108 339 0.1 3214

© 2016 Pythian 36
$ cat process.sh
DG=$2
FILE=$1
grep $2 $1 | awk '{RIO=0; WIO=0; IO=0; if ($7>32768) RIO=($5-($4*32))/32; if ($11>32768)
RIO=($9-($8*32))/32;IO=$4+$8+RIO+WIO; print $1,$2,$4,$5,$7,$8,$9,$11,RIO,WIO,IO;}' | awk '{if ($1==PREV_TIM)
{IO+=$11} else {print PREV_TIM,IO; IO=$11; PREV_TIM=$1}}'| cut -c 1-7,9- | awk '{if ($1==PREV_TIM) {IO+=$2} else
{AVGIOPS=IO/10; print PREV_TIM,AVGIOPS; IO=$2; PREV_TIM=$1}}'
$ process.sh asm_metrics_per_second_20150309_2300.txt DATA
23:00:0 4965.02
23:00:1 18455.1
23:00:2 14806.9
23:00:3 1460.35
23:00:4 1002.33
23:00:5 1600.22
SIZING IT CORRECTLY
IO IS NOT SIMPLE

© 2016 Pythian 37
SIZING IT CORRECTLY
IO IS NOT SIMPLE
What happens to the
spikes if you provision
less IOPS?

© 2016 Pythian 38
• Choose the instance and the storage type based on
– Max IOPS
– HDD size
– Max CPU usage
– RAM requirement
• Workloads vary too much
– getting it exactly right may be tricky
– But at least you shouldn't size it much too large
• Benchmark / Load Test
SIZING IT CORRECTLY
IO IS NOT SIMPLE
https://aws.amazon.com/rds/oracle/details/, http://docs.aws.amazon.com/AmazonRDS/latest/UserGuide/CHAP_Storage.html

© 2016 Pythian 39
MIGRATING ...
to Oracle RDS

© 2016 Pythian 40
MIGRATING TO ORACLE RDS
MIGRATION OPTIONS
• Offline options:
– Oracle Data Pump
– Oracle Export/Import Utilities
– Oracle SQL*Loader
– Oracle Materialized Views
• Additional options (logical replication):
– Data Migration Service (DMS)
– Oracle GoldenGate (GG)
http://docs.aws.amazon.com/AmazonRDS/latest/UserGuide/Oracle.Procedural.Importing.html

© 2016 Pythian 41
$ expdp system/***@SOURCE DUMPFILE=data.dmp DIRECTORY=DATA_PUMP_DIR LOGFILE=data.log
flashback_time=systimestamp schemas=USER1
$ sqlplus SYS@SOURCE as sysdba
SQL> create database link TARGET connect to oracle_master identified by * using 'TARGET';
SQL> exec DBMS_FILE_TRANSFER.PUT_FILE(source_directory_object => 'DATA_PUMP_DIR',
source_file_name => 'data.dmp', destination_directory_object => 'DATA_PUMP_DIR',
destination_file_name => 'data.dmp', destination_database => 'TARGET')
$ impdp oracle_master/***@TARGET DUMPFILE=data.dmp DIRECTORY=DATA_PUMP_DIR
LOGFILE=data_imp_1.log
$ sqlplus oracle_master@TARGET
SQL> exec utl_file.fremove('DATA_PUMP_DIR','data.dmp');
SQL> exec utl_file.fremove('DATA_PUMP_DIR','data_imp_1.log');
ORACLE DATA PUMP
http://docs.aws.amazon.com/AmazonRDS/latest/UserGuide/Oracle.Procedural.Importing.html
Make sure you have
enough space on your
RDS instance!

© 2016 Pythian 42
ORACLE GOLDENGATE
• Option A
• Option B
http://docs.aws.amazon.com/AmazonRDS/latest/UserGuide/Appendix.OracleGoldenGate.html

© 2016 Pythian 43
• Simple version of Logical Replication
– Also capable of converting between different types of DBs
– Schema migration in a few clicks
• New tool (announced on 15 Mar 2016)
• A few limitations
– Unclarity about the initial load
– Lack of "SCN"
– Can't adjust the migration task after starting it
– DDL is not captured
– Some data types not supported
• It should be good enough for simple cases
DMS (DATA MIGRATION SERVICE)
http://docs.aws.amazon.com/dms/latest/userguide/CHAP_Source.Oracle.html#CHAP_Source.Oracle.Configuration

© 2016 Pythian 45
LIFE WITHOUT "SYSDBA"
http://docs.aws.amazon.com/AmazonRDS/latest/UserGuide/Appendix.Oracle.CommonDBATasks.html
• Only SQL*Net Connectivity
• Master Username
– Limited set of privileges
• Common DBA Tasks for Oracle DB Instances
– Review them carefully, and prepare !
– Some tasks are done differently ...
• killing a session
• exec rdsadmin.rdsadmin_util.kill(..., ..., ...);
• Creating an AWR report
• DBMS_WORKLOAD_REPOSITORY.AWR_REPORT_TEXT
– RDSADMIN.RDSADMIN_UTIL

© 2016 Pythian 46
• No host access
– Prevents setting up some types of monitoring
• Cron jobs
• Certain 3rd party monitoring agents
• What's available?
– Cloudwatch monitoring + alerts
• 1 minute interval / difficult to correlate different metrics
– Enhanced monitoring (no alerts)
• 1s - 60s monitoring interval
– OEM Option (11g DB Control / Database Express 12c )
– OEM_AGENT Option !! (Announced Sep, 2016)
– Custom monitoring over SQL*Net (Avail)
MONITORING
http://docs.aws.amazon.com/AmazonRDS/latest/UserGuide/Appendix.Oracle.CommonDBATasks.html

© 2016 Pythian 52
Monitoring - OEM_AGENT
I haven't tried this yet, but
knowing the DB Express 12 is
more limited than DB Control -
It's a good thing we have it
now!
Standalone EM 12c CC is
required!

© 2016 Pythian 54
AWS RDS FOR ORACLE
EXAMPLE 1: LATENCY ISSUES
• In the middle of the migration project
– One database was moved to Oracle RDS
– Another interfacing system remained on-premise
• A batch job runs a LOT SLOWER
– Tracing reveals row-by-row processing between 2 DBs
– A local DB <-> RDS
– Latency issue, each network round-trip took a lot longer.

© 2016 Pythian 55
AWS RDS FOR ORACLE
EXAMPLE 2: ACCESS TO DATA
• A tiny OBIEE Database (40G)
– Db.m4.xlarge
– 4 vCPU + 16G RAM
• The problem
– IO slowness
– Beyond point where IOPS is reasonable to increase to
• The Solution
– Upgrade to Db.r3.xlarge (memory optimized)
– 4vCPU + 30.5 RAM
– Set parameter _serial_direct_reads=never

© 2016 Pythian 56
• A sudden execution plan change for a popular query
•
AWS RDS FOR ORACLE
EXAMPLE 3: A QUERY PLAN CHANGE

© 2016 Pythian 57
-- Create the procedure that will be used to collect the execution plans
create or replace procedure PERF.XXSTABILITY_CAPTURE_PLANS is
cur sys_refcursor;
cursor clist is with raw_sqlids as (select sql_id from v$sqlarea
where sql_id in (select sql_id from v$active_session_history
where sample_time>=sysdate-1/24 and sql_plan_hash_value>0
and machine like '%-hesvc-app0%')
and plan_hash_value>0 and executions>2
union
select sql_id from v$sqlarea
where sql_id in (select sql_id from v$open_cursor where
sid in (select sid from v$session where machine like '%-hesvc-app0%'))
and plan_hash_value>0 and executions>2 and parsing_schema_name not in
('ANONYMOUS','APEX_030200','APEX_040000','APEX_SSO','APPQOSSYS',
'CTXSYS','DBSNMP','DIP','EXFSYS','FLOWS_FILES','MDSYS','OLAPSYS','ORACLE_OCM','ORDDATA','ORDPLUGINS','ORDSYS','OUTLN','OWBSYS
','SI_INFORMTN_SCHEMA','SQLTXADMIN','SQLTXPLAIN','SYS','SYSMAN','SYSTEM','TRCANLZR','WMSYS','XDB','XS$NULL')),
sqlids as (select distinct ''''||sql_id||'''' sql_id, trunc((rownum-1)/200) rn from raw_sqlids)
select listagg(s.sql_id,',') within group (order by s.sql_id) as sql_id_filter from sqlids s group by s.rn;
c clist%rowtype;
BEGIN
for c in clist loop
OPEN cur FOR SELECT VALUE(P) FROM table(dbms_sqltune.select_cursor_cache(basic_filter=>'sql_id
in('||c.sql_id_filter||')', attribute_list=>'ALL')) P;
DBMS_SQLTUNE.LOAD_SQLSET(load_option=>'MERGE',sqlset_name => 'XXSTABILITY_EXECUTION_PLANS', populate_cursor => cur);
CLOSE cur;
end loop;
Commit;
END;
/
AWS RDS FOR ORACLE
EXAMPLE 3: PRESERVING GOOD EXECUTION PLANS

© 2016 Pythian 58
-- Create the Scheduler Job which will run on every hour's 47th minute
Begin
Dbms_scheduler.create_job
(job_name => 'COLLECT_XXSTABILITY_PLANS',
job_type => 'STORED_PROCEDURE',
job_action => 'PERF.XXSTABILITY_CAPTURE_PLANS',
start_date => SYSDATE,
repeat_interval => 'FREQ=HOURLY; INTERVAL=1; BYMINUTE=47;',
enabled => TRUE);
End;
/
-- Loading the baseline from SELECT_SQLSET for a specific sql_id and plan
VARIABLE cnt NUMBER
EXECUTE :cnt := DBMS_SPM.LOAD_PLANS_FROM_SQLSET( -
sqlset_name => 'XXSTABILITY_EXECUTION_PLANS', -
basic_filter => 'sql_id=''dtzsc12fbbjk2'' and plan_hash_value=2896891279');
AWS RDS FOR ORACLE
EXAMPLE 3: PRESERVING EXECUTION PLANS

© 2016 Pythian 59
AWS RDS FOR ORACLE
EXAMPLE 4: COMBINED MAINTENANCE
• Combined maintenance - 30 minutes allocated
– Take a snapshot
– Change the instance size
• Oops!
– Snapshot takes just few seconds
• … before it's copied to S3
– “Creating Snapshot” for 45 minutes

© 2016 Pythian 61
• Simple to use, but not suitable for massive workloads
– Consider Oracle DB on EC2
• Difficult to size (especially storage)
– Load testing and Benchmarking
– 3000 IOPS or less -> Use gp2 (General Purpose SSD) volumes
• Get the config right from the beginning
– Changing certain things require downtime
• Practice being an Oracle RDS DBA
– Some things are different
SUMMARY
Oracle RDS

Migrating and Running DBs on Amazon RDS for Oracle

Recommended

Recommended

More Related Content

What's hot

What's hot (20)

Similar to Migrating and Running DBs on Amazon RDS for Oracle

Similar to Migrating and Running DBs on Amazon RDS for Oracle (20)

More from Maris Elsins

More from Maris Elsins (18)

Recently uploaded

Recently uploaded (20)

Migrating and Running DBs on Amazon RDS for Oracle
