1) The document outlines the procedure for magnetic particle testing (MPT), including an intro on the pros and cons of videos, the MPT test procedure, and samples of MPT reports and certificates. 2) It discusses the theory behind MPT and lists advantages like detecting surface and subsurface flaws on large or complex parts rapidly while also noting disadvantages like requiring smooth surfaces and certain materials. 3) Key aspects of MPT codes are outlined such as personnel certification, acceptance criteria, and repair requirements.

1. Ahmad Khanji

2. Ground Rules

3. Outlines
1) Intro ( Videos – Pros & Cons )
2) Code Application
3) Magnetic Particles Test Procedure
4) MPT Report Sample
5) Magnetic Particles Inspection Certificate Sample
, As per ( SNT - TC – 1A ) of ASNT.
6) MPT Examination Technique ( ASME , Sec V )
7) ASNT published papers

4. True - or - False
• MPT can detect subsurface cracks 12 mm
below surface
• MPT can be used for Steel alloys with a
chromium content of 10.5 % Cr .
• MPT devices utilizing AC current is used to
detect surface flaws
• In a longitudinal magnetism technique , cracks
parallel to the lines of force will not show

5. Theory

6. + & -
Advantages disadvantages
Can be applied on large surface areas Only applies for ferromagnetic
materials
Can be used to inspect complex parts Magnetic field alignment is essential
Can be applied rapidly Requires relatively smooth surface
Can detect surface and subsurface
flaws
Can’t be applied on painted surfaces
Flaws are produced on the surface Demagnetization is usually necessary
Costs are relatively cheap

7. Video

8. MPT’s Code Components
• Scope
• Certification or competency of Personnel
• Relevant Vs Irrelevant indications
• What is a liner , round indications
• Acceptance criteria
• Repair requirements
• Out of Scope Items testing
