1. Operators in C++
Dr. karam Hatim
University of Mosul

2. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 2
Introduction
• Operator represents an action.
• For example + is an operator
that represents addition.
• An operator works on two or more operands
and produce an output.
• For example 3+4+5 here + operator works on three
operands and produce 12 as output.

3. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 3
Operators Types
• Arithmetic operator
• Relational and logical operator
• Bitwise operator

4. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 4
Arithmetic operators
+ - *
/ %

5. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 5
Examples about /
8 / 2 =
24 / 4 =
5 / 2 =
5.0 / 2 =
5/ 2.0 =
int / int = int
Double / int = double
Int / double =double
4
6
2
2.5
2.5

6. Examples about %
5 % 2 =
8 % 5=
14 % 10=
7 % 5 =
5 % 7=
5.0 % 2=
5 % 2.0 =
int % int
int % double
double % int
1
3
4
2
0

7. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 7
Mixed operation

8. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 8
Complete example

9. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 9
Increment ++/ Decrement --
X=10;
• y=x++;
• y=++x;
X=10;
• y=x--;
• y=--x;
What is the difference??
y=10 x=11
y=11 x=11
y=10 x=9
y=9 x=9

10. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 10
Expressions
• If all operands are same type
• Example: 2 + 3 * 5
12.8 * 17.5 - 34.50
• Mixed expression:
− Has operands of different data types
2 + 3.5
6 / 4 + 3.9
5.4 * 2 – 13.6 + 18 / 2

11. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 11
Mixed Expressions
• Evaluation rules:
− If operator has same types of operands
• Evaluated according to the type of the
operands
− If operator has both types of operands
• Integer is changed to floating-point
• Operator is evaluated
• Result is floating-point

12. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 12
Type Conversion (Casting)
• Implicit type coercion:
when value of one type is automatically
changed to another type.
• Cast operator:
provides explicit type conversion
static_cast<dataTypeName>(expression)

13. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 13
Example: Type Conversion

14. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 14
Relational and Logical Operators

15. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 15
Logical operator

16. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 16
Bitwise Operators
• There are six bitwise Operators:
• & and
• | or
• ^ xor
• ~ not
• << shift left
• >> shift right

17. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 17
Example of Bitwise Operators

18. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 18
Operator Precedence in C++
• This determines which operator
needs to be evaluated first if an
expression has more than one
operator.
• Operator with higher precedence at
the top and lower precedence at the
bottom.

19. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 19
Unary Operators ++ – – ! ~
Multiplicative * / %
Additive + –
Shift << >> >>>
Relational > >= < <=
Equality == !=
Bitwise AND &
Bitwise XOR ^
Bitwise OR |
Logical AND &&
Logical OR ||
Assignment = += -= *= /= %= > >= < <= &= ^= |=

20. C++ Programming: From Problem Analysis to Program Design, Fourth Edition 20
Thanks
