Kx5002
•
0 likes•24 views
This document summarizes the specifications of a capacitive sensor product. It has an adjustable sensing range of 15 mm, is ATEX approved for hazardous areas, and connects to intrinsically safe circuits with a maximum voltage of 15V and current of 50mA. It features a non-flush mountable brass and PTFE housing, has a switching frequency of 40Hz, and connects via a 6m PVC cable.
Report
Share
Report
Share
Download to read offline
![Product characteristics
Capacitive sensor
Metal thread M34 x 1.5
Cable
ATEX approval
Group II, category 1D/1G
Sensing range 15 mm; adjustable; [nf] non-flush mountable
Electrical data
Connection to certified intrinsically safe circuits with the max. values U = 15 V / I =
50 mA / P = 120 mW
Electrical design
8.2 DC; (1kΩ)Nominal voltage [V]
7.5...15 DCSupply voltage [V]
< 1.0 disabled; (> 2.2 mA enabled)Current consumption [mA]
IProtection class
Outputs
Normally closedOutput function
40Switching frequency [Hz]
Range
15, adjustableSensing range [mm]
Accuracy / deviations
water = 1 / glass approx. 0.4 / ceramics approx. 0.2 / PVC approx. 0.2Correction factors
1...15Hysteresis [% of Sr]
-15...15Switch-point drift [% of Sr]
Environment
-20...60Ambient temperature [°C]
IP 65Protection
Tests / approvals
DMT 01 ATEX E 020Approval
II 1G Ex ia IIB T6 Ga
II 1D Ex ia IIIC T90 °C Da
Marking of the unit
EMC 2007IEC 60947-5-2:
838MTTF [Years]
Safety classification
375.64Internal capacitance [nF]
3Internal inductance [µH]
Mechanical data
non-flush mountableMounting
Brass white bronze coated; active face: PTFEHousing materials
KX5002
Capacitive sensorsKX-2015-N/NI/6M/1D/1G](https://image.slidesharecdn.com/kx5002-170706112518/85/Kx5002-1-320.jpg)
![0.629Weight [kg]
Displays / operating elements
yellowOutput status indication LED
Electrical connection
PVC cable / 6 m; 3 x 0.5 mm²Connection
Wiring
Core colours
brownBN
blueBU
green/yellowGN/YE
Remarks
1Pack quantity [piece]
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — GB — KX5002 — 13.08.2012
KX5002
