1. JavaFX
canoo

2. About me
Java Champion
JavaOne Rockstar
Canoo Engineering AG
JCP Expert Group
JUG Dortmund
Star Wars
www.guigarage.com@hendrikEbbers canoo

3. Hello Worldwww.guigarage.com@hendrikEbbers canoo

4. Hello Worldwww.guigarage.com@hendrikEbbers canoo
JavaFX is PLAIN JAVA
NO JavaFX Script
Write it with any Java IDE
... or go oldschool
never use this one ;)

5. Hello Worldwww.guigarage.com@hendrikEbbers canoo
1 - Create a Class
2 - Extend Javafx.application.application
3 - Have Fun

6. Hello Worldwww.guigarage.com@hendrikEbbers canoo
public class HelloWorld extends Application {
@Override
public void start(Stage primaryStage) {
StackPane myPane = new StackPane(new Button("Hello World"));
primaryStage.setScene(new Scene(myPane));
primaryStage.show();
}
public static void main(String[] args) {
launch(args);
}
}

7. Hello Worldwww.guigarage.com@hendrikEbbers canoo
Stage
Scene
StackPane
Button
Scenegraph
contains

8. Hello Worldwww.guigarage.com@hendrikEbbers canoo
public class Demo extends javafx.application.Application {
@Override public void init() {}
@Override public void start(javafx.stage.Stage stage) {}
@Override public void stop() {}
public static void main(String[] parameters) {
launch(parameters);
}
}
application.init() application.start(Stage) application.stop()
stage.close()

9. stuck in the IDE
www.guigarage.com@hendrikEbbers canoo

10. stuck in the IDE
www.guigarage.com@hendrikEbbers canoo
Netbeans Project Eclipse Project

11. stuck in the IDE
www.guigarage.com@hendrikEbbers canoo

12. stuck in the IDE
www.guigarage.com@hendrikEbbers canoo
😥
😭
😱
😰
😵

13. stuck in the IDE
www.guigarage.com@hendrikEbbers canoo
😥 😓 😨 😰 😵 😭 😱

14. stuck in the IDE
www.guigarage.com@hendrikEbbers canoo
?

15. Project
management
www.guigarage.com@hendrikEbbers canoo

16. www.guigarage.com@hendrikEbbers canoo
Describe the application in an
Environment independent way
Project
management

17. www.guigarage.com@hendrikEbbers canoo
1 - Define Java Version in Build file
2 - Define Dependencies in Build File
I like to to this in a
static way…
Project
management

18. www.guigarage.com@hendrikEbbers canoo
JavaFX and Maven
Project
management
a perfect match

19. www.guigarage.com@hendrikEbbers canoo
Project
management
<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
xsi:schemaLocation="http://maven.apache.org/POM/4.0.0
http://maven.apache.org/xsd/maven-4.0.0.xsd">
<modelVersion>4.0.0</modelVersion>
<groupId>com.guigarage</groupId>
<artifactId>javafx-application</artifactId>
<version>1.0-SNAPSHOT</version>
<properties>
<maven.compiler.target>1.8</maven.compiler.target>
<maven.compiler.source>1.8</maven.compiler.source>
<project.build.sourceEncoding>UTF-8</project.build.sourceEncoding>
</properties>
</project>

20. www.guigarage.com@hendrikEbbers canoo
You have to choose
Project
management

21. www.guigarage.com@hendrikEbbers canoo
Native Builds
Project
management
Providing a JAR to customers sucks
Since Java 8 we can go
Native
EXE & DMG

22. www.guigarage.com@hendrikEbbers canoo
Native Builds
Project
management
JavaPackager is part of JDK
Oracle Provides ANT support
Maven & Gradle Support
by Community

23. www.guigarage.com@hendrikEbbers canoo
Native Builds
Project
management

24. www.guigarage.com@hendrikEbbers canoo
Native Builds
Project
management
simply add nativecontent to your project

25. www.guigarage.com@hendrikEbbers canoo
Test Support
Project
management
USe TestFX to write JavaFX test
Tests automatically boot
your UI
Headless Tests
supported

26. Build pipeline

27. Build pipeline
Deploying an productive app
... from your local machine is like ...

28. Build pipeline
Deploying an productive app
. . . from your local machine is like

29. Build pipeline
Deploying an productive app
. . . from your local machine is like

30. Build pipeline
Deploying an productive app
. . . from your local machine is like

31. Build pipeline
Deploying an productive app
. . . from your local machine is like

32. Build pipeline
Just to make sure you get it ...

33. Build pipeline
Deploying an productive app
. . . from your local machine is like

34. Build pipeline
Deploying an productive app
. . . from your local machine is like
All together now

35. Build pipeline
Deploying an productive app
... from a Build server is like ...

36. Build pipeline
Deploying an productive app
. . . from your local machine is like

37. Build pipeline
Using a Build server is quite easy
It's really the same than for any other Java project
Remember: JavaFX == Java
choose your favorite

38. Build pipeline
Works for Open Source, Too
It only takes 5 minutes to setup a Travis Build
for your GitHub repo
+

39. Build pipeline
Native Builds
You need build notes for the different platforms
Build server
Linux build
node
Mac build
node
Windows
build node
trigger builds

40. JavaFX on
Mobile

41. www.guigarage.com@hendrikEbbers canoo
JavaFX Mobile
Simply Install IDE Plugin
Create a new Project
Run JavaFX on
Mobile

42. www.guigarage.com@hendrikEbbers canoo
WAIT!
DON'T We stuck in the IDE now????
JavaFX on
Mobile

43. www.guigarage.com@hendrikEbbers canoo
Gradle Build

44. questions?
