2. Outline:
How Browser Works?
What is the DOM?
What is the Node?
The DOM structure Model.
Example of DOM
How Can Access the Nodes?
Adding Text Node to the Page
Advantages and Disadvantages.
4. How Browser Works?
Source code (plain text) will be parsed into DOM tree.
With DOM tree will parse the content on the screen accordingly (css,
javascript...)
DOM tree is a data represented in tree structure.
Source
Code
DOM
Parser
DOM
Tree
Render
Engine
Web
Page
5. What is the DOM?
Document Object Model is a platform and language neutral
interface that allow program and script to dynamically
access and update the content, structure and style of
document.
The DOM is an application programming interface (API) for
HTML and XML documents.
DOM is being developed by W3C, lets the programmer to
access, modify HTML pages and XML docments.
6. What is the Node?
•DOM is a tree of nodes of various types.
•Nodes
Text Node Attribute Node
Element Node
7. The DOM Structure Model
<html>
<head>
<title>Hello World!</title>
</head>
<body>
<h1>Heading 1</h1>
<p>Paragraph </p>
<h2>Heading 2</h2>
<p>Heading 1</p>
</body>
</html>
HTML
bodyhead
title
Hello World
H1 P H2 P
Heading 1 Heading 2Paragraph Paragraph
DOM Tree Visualizer: https://gojs.net/latest/samples/DOMTree.html
#document
8. Child, Sibling, Parent
body
H1 P H2 P
#text #text #text #text
Last child
Firstchild
Firstchild
Firstchild
Firstchild
previousSibling
NextSibling
previousSibling
NextSibling
previousSibling
NextSibling
parentNode
parentNode
parentNode
parentNode
9. Child, Sibling, Parent
body
H1 P H2 P
#text #text #text #text
So, How can access the text in
Header2?!
Firstchild
nextSibling nextSibling
Firstchild
10. How can access the nodes?
By their name or Id (it will allow you to work with one element, and it's the
easiest way)
GetElementByName(NodeName)
GetEllemtById(IdName)
By Tag Name (GetElementsByTagName), it will return array of nodes
By their relation to parent, child, sibling
(nextSibling,previousSibling,parentNode,lastchild, firstchild, childNode) , childNode[0] ==
first child
11. Adding text Node to the Page
Create New Node
-var newNode = document.createElement("p");
Create Text Node
-var textNode = document.createTextNode("hello world");
Link Text Node with New Node
-NewNode.appendChild(textNod);
Link Node to the DOM tree -Document.getElementById("id").appendChild(newNode)
12. Advantages and Disadvantages of DOM
Advantages:
Robust API for the DOM tree
Easy to modify the data structure and extract data.
Can be written with any language
Disadvantages:
Store the entire document in the memory.
Based on DOM can written with any language, method naming convention don't
follow standard java programming convension
