Arduino programming

1. Two Day Workshop
on
Introduction to Arduino
Programming
27-02-2024 Introduction to Arduino Programming

2. • What Is Arduino?
27-02-2024 Introduction to Arduino Programming

3. 27-02-2024 Introduction to Arduino Programming

4. 27-02-2024 Introduction to Arduino Programming

5. Arduino Uno Kit
27-02-2024 Introduction to Arduino Programming

6. Turn ON and OFF an LED after Particular delay
27-02-2024 Introduction to Arduino Programming
// the setup function runs once when you press reset or power the board
void setup()
{
pinMode(13, OUTPUT);//Initialize the output pin
}
// the loop function runs over and over again forever
void loop()
{
digitalWrite(13, HIGH); // Turn the LED on
delay(1000); // Wait for a second.
digitalWrite(13, LOW); // Turn OFF LED
delay(1000); // Wait for a second.
}

7. 27-02-2024 Introduction to Arduino Programming

8. • Controlling LED using a Switch
27-02-2024 Introduction to Arduino Programming
int buttonState = 0;
void setup()
{
pinMode(2, INPUT);
pinMode(13, OUTPUT);
}
void loop()
{
// read the state of the pushbutton value
buttonState = digitalRead(2); // check if pushbutton is pressed.
if (buttonState == HIGH)
{ // turn LED on
digitalWrite(13, HIGH);
}
else
{ // turn LED off
digitalWrite(13, LOW);
}
delay(10); // Delay a little bit to improve simulation performance
}

9. 27-02-2024 Introduction to Arduino Programming

10. To read an analog input on analog pin 0 connected to
onboard pot, and display it on the serial monitor of the
Arduino Software (IDE).
void setup()
{
pinMode(A0, INPUT); // Set analog pin A0 as input
pinMode(13, OUTPUT); // Set digital pin 13 as output
//Where LED is connected
Serial.begin(9600); // Set the baud rate for serial monitor
}
void loop() {
int a=analogRead(A0); // Read analod values on pin A0
// and store it in variable a
analogWrite(13,a); // Write the values of a to
// LED which varies its brightness
Serial.println(a); //Print the values on Serial monitor
}
27-02-2024 Introduction to Arduino Programming

11. 27-02-2024 Introduction to Arduino Programming

12. Control of Servo Motor
#include <Servo.h>
int pos = 0;
Servo servo_9;
void setup()
{
servo_9.attach(9, 500, 2500);
}
void loop()
{ // sweep the servo from 0 to 180 degrees in steps
for (pos = 0; pos <= 180; pos += 1)
{ // tell servo to go to position in variable 'pos'
servo_9.write(pos);
delay(15); // Wait for 15 millisecond(s)
}
for (pos = 180; pos >= 0; pos -= 1) // tell servo to go to position in variable 'pos'
servo_9.write(pos);
delay(15); // Wait for 15 millisecond(s)
}
}
27-02-2024 Introduction to Arduino Programming

13. 27-02-2024 Introduction to Arduino Programming
