1. Enabling The Effective Sharing of
Medical Images over Wide Area and
Wireless Networks

2. PRESENTER AND AGENDA
PRESENTER
AGENDA
Daniel Kumi
Director, New Market Development
• Who and Why Aspera?
daniel@asperasoft.com • WAN & Wireless Transport
• Transfers to/out of the Cloud
• Healthcare Applications
• PACS to PACS
• Health Information Exchange
• On-Demand Access
• Possible Integrations—Hopkins,
McKesson, Vital, WU School of medicine
• Aspera-Intel Discussion

3. ASPERA’S MISSION
Creating next-generation transport technologies
that move the world’s digital assets at maximum speed,
regardless of file size, transfer distance and network conditions.

4. Aspera: moving the world’s digital assets at
maximum speed
50% YOY growth in revenue and employees
Over 10,000 licenses sold, and over 1,500 customers world wide
Expanded to Asia PAC and Latin America through direct and channel
Patents issued or pending in 32 countries
Continuing to innovate: fasp3™, fasp-MC™, mobile transport, cloud enablement

5. Aspera Ecosystem of Partners

6. Life Sciences
Life Sciences

7. BIG DATA TRANSFER CHALLENGE

8. What Happened to my Bandwidth?
WAN
1000 Mbps
Seattle • 170ms RTT
• 0.001% packet loss rate Paris
WAN Throughput is 1000Mbps
Max TCP Throughput ~29Mbps
Where’s my 970Mbps?
At 29Mbps
50GB transfer will take 4 hrs
1TB transfer will take 3.3 days

9. BIG-DATA and WAN TRANSFER WITH TCP
TCP WAS DESIGNED IN THE EARLY 80’S
• When data was small & bandwidth was limited
• Fantastic for reliable data delivery
• Not fast enough for big-data
TCP IS THE ENGINE THAT DRIVES
• FTP, HTTP & HTTPS
• RSYNC, SCP & DICOM
• CIFS & NFS
TCP DOES NOT LIKE NETWORK LATENCY/ RTT
• Geographic distance increases latency
• Network congestion increases latency
TCP DOES NOT LIKE PACKET LOSS
• Loss is caused by congestion
• Different network capacity
• Wireless and satellite communications

10. So if TCP doesn’t work, what’s the answer?
The Aspera Solution

11. Same WAN Scenario with Aspera
WAN
1000 Mbps
• 170ms RTT
Seattle • 0.001% packet loss rate Paris
WAN is 1000Mbps
Max TCP Throughput ~29Mbps
Max Aspera Throughput ~995Mbps (gain of x34)
ROI measured in $$ cost of not using 971Mbps
At 995 Mbps
• 50GB transfer will take ~4 hrs
• 1TB transfer will take 3.3 days
• 50GB transfer will take ~7 mins
• 1TB transfer will take 2.4 hrs

12. FASP™ — HIGH-PERFORMANCE DATA TRANSPORT
MAXIMUM LINE-RATE WAN TRANSFER SPEED
• Transfer performance scales with bandwidth independent
of transfer distance and resilient to packet loss
• Optimal end-to-end throughput efficiency
CONGESTION AVOIDANCE AND POLICY CONTROL
• Automatic, full utilization of available bandwidth
• On-the-fly prioritization and bandwidth allocation
UNCOMPROMISING SECURITY AND RELIABILITY
• Secure, user/endpoint authentication
• AES-128 cryptography in transit & at-rest
SCALABLE MANAGEMENT, MONITORING AND CONTROL
• Real-time progress, performance and bandwidth utilization
• Detailed transfer history, logging, and manifest
ENTERPRISE-CLASS FILE DELIVERY
• Transfers up to thousands of times faster than FTP/HTTP(S)
• Precise and predictable transfer times
• Extreme scalability (concurrency and throughput)

13. FASP vs TCP PERFORMANCE
fasp Bandwidth ROI
FTP: Limited by Distance & Packet Loss, Not B/W
FTP Across US US – EU US – ASIA Satellite
1 GB 1 – 2 hrs 2 – 4 hrs 4 – 20 hrs 8 – 20 hrs
10 GB 15 – 20 hrs 20 – 40 hrs Impractical Impractical
100 GB Impractical Impractical Impractical Impractical
Aspera: Scales Linearly with Bandwidth
fasp™ 2 Mbps 10 Mbps 45 Mbps 100 Mbps 200 Mbps 1 Gbps
1 GB 70 min. 14 min. 3.2 min. 1.4 min. 42 sec. 8.4 sec.
10 GB 11.7 hrs 140 min. 32 min. 14 min. 7 min. 1.4 min.
100 GB 23.3 hrs 5.3 hrs 2.3 hrs 1.2 hrs 14 min.
Distance & Packet Loss Independent

14. 6 Gbps Scalable WAN Throughput
~6Gbps Big-Data Throughput x3000 improvement vs. TCP
• Latency independent • 1TB data moved in 20 min
• Loss independent • 2 days with TCP over LAN conditions
Scale to ~10Gbps with IQ Accelerator

15. High Speed Mobile Data Transfer with fasp-AIR™
fasp-AIR SDK – maximum data transfer speed and predictability for
mobile devices
• Embeddable software library allows app developers to integrate superior
transport capabilities to their own applications such as faster and more
predictable downloads/uploads.
• Available for Android and iOS on Aspera Developer Network
• Designed for wireless networks with high latency, high packet loss environments
• Integrated transfer queuing, pause, resume and progress reporting
• Achieves significant performance improvements for upload and download
speeds over 3G, 4G and 802.11 g/n.

16. fasp-AIR Benchmarks on Verizon 4G
In some cases (highlighted in orange), speeds will vary
greatly, depending on available bandwidth and the underlying
condition of the wireless network.

17. GETTING IN AND OUT OF THE CLOUD
KNOWING WHEN TO CHOSE THE RIGHT TOOL

18. FIRST MAJOR BOTTLENECKS: WAN TRANSFER

19. SECOND MAJOR BOTTLENECKS: LOCAL HTTP I/O
1st Bottleneck - WAN
2nd Bottleneck — Data Center

20. CHALLENGES OF STORING BIG FILES IN THE CLOUD?
BEWARE THE OBJECT STORE:
• Not like traditional NAS or SAN
• Bigger, better, but possibly much more complex
• a.k.a. Google File System, Amazon S3, Hadoop Distributed File System
• Simple read/write of data “blobs”, indexed by a key
• Multiple replicas are distributed across storage for durability and optimized for access
• Should work well for storing large numbers of files
UNDERSTAND CHUNKS, BLOCKS and BLOBS
• You need to deal with chunks, blocks and blobs
• “Chunk” sizes are small (64 MB/128 MB)
• Large media files must be “chunked” (1TB file = transporting and reassembling 10,000+ chunks!)
• Multi-chunk APIs impede workflow and are complex
• Data I/O use the standard HTTP(s) protocol
• VERY SLOW at distance
• Single HTTP stream slow even locally (<100 Mbps).
M&E/ BIG-DATA SERVICES WILL NEED A HIGH-SPEED BRIDGE TO THE CLOUD
• Large files moved at full bandwidth capacity with global access
• Overcome the WAN and storage bottleneck
• Support files of any size or quantity
• Transparent to the end user/data owner (GUI, command line, API, browser, etc.)
• No hardware to support B2B, B2C, C2B workflow

21. S3 & BIG-DATA: UNDERSTAND THE CONTRAINTS

22. S3 & BIG-DATA: MEET ASPERA’s DIRECT-TO-S3
client cargo downloader
point-to-point mobile apps
connect plug-in

23. ASPERA DIRECT-TO-S3 — LINE RATE ACCESS TO THE CLOUD
UNRIVALED ASPERA PERFORMANCE
• Built on Aspera fasp™ technology for maximum transfer speed
• Regardless of file size, transfer distance and network conditions
• Precise bandwidth control ensures the available bandwidth is utilized to achieve maximum transfer speeds, while
being fair to other business-critical network traffic
SEAMLESS INTEGRATION WITH S3
• Integrated with S3 multi-part HTTP for maximum “last foot” performance
• Simple configuration of S3 credentials, for both shared and dedicated docroot
• Transfers directly into S3 are seamless and transparent to user
ENTERPRISE-GRADE SECURITY AND RELIABILITY
• Secure authentication with encryption in transit & at rest (AES-128, FIPS 140-2, HIPPA Compliant)
• Packet-level data integrity verification
• Automatic resume of partial or failed transfers
• Full support for AWS S3 Service-side-encryption at rest
INTEROPERATES WITH ALL ASPERA HOST OPTIONS
• Any platform (Windows, Linux, MAC, UNIX, iOS, Android)
• Any Aspera Clients (CLI, Desktop, Point-to-Point, Mobile, Web, Embedded)
• Any Aspera Servers (Enterprise, Connect, faspex)

24. Aspera fasp™ software environment

25. ASPERA DEVELOPER NETWORK
A complete set of SDKs provides developers with guides, reference information, and sample code to assist them with
integrating Aspera technology into their own applications. Aspera fasp™ technology can be used in desktop, network-
based, and web applications in place of FTP, HTTP, or custom TCP-based copy protocols.
ASPERA TRANSFER APIs ASPERA MOBILE APIs
Aspera Web Services Android SDK
A SOAP based web service API that allows initiation, Aspera Android SDK provides a Java API to transfer files using
monitoring and controlling of fasp based file transfers. fasp-AIR™.
iPhone SDK
Aspera Web Aspera iPhone SDK provides an Objective C API to transfer files
Javascript API exposed by Aspera Connect client. It allows
using fasp-AIR.
integration of fasp based file transfers into web
applications.
ASPERA APPLICATION APIs
Connect 2.8 developer Preview 2
Introducing the new Connect 2.8 developer preview! faspex™ Web API
Integrate the functionality of Aspera Connect 2.8, a fasp- The Aspera faspex Web API provides a set of services that enables
based file transfer client, into your own web applications, users to create and receive digital deliveries via a Web interface, while
while customizing it to your unique brand. taking advantage of fasp high-speed transfer technology.
fasp Manager
A class library that allows intiations, monitoring and OTHER INFORMATION
controlling of fasp based file transfers.
Supporting Tools and Libraries
Aspera Multicast SDK Supporting tools and libraries let you perform other common tasks
A Java class library that allows initiation and management surrounding file transfers.
of IP multicast based data transmissions using Aspera General Reference
fasp-MC™.
Reference on error codes, log file locations, configuration files
and more.

26. BIG-DATA: ACCESSED & DELIVERED BY ASPERA
Media File transfer

27. HEALTHCARE APPLICATIONS

28. High-Speed Transfers Between DICOM Devises: Example:
Archive-to-Archive Transfers (fasp3 socket-based solution)
DICOM DICOM
PACS, Archive… PACS, Archive…
Usual Usual
DICOM DICOM
(TCP) (TCP)
Regular sockets Regular sockets
selected by fasp selected by fasp
Socket fasp3 fasp3 Socket
Sender Receiver

29. Aspera Fasp Sockets Overview
Client Application FASP-Pipe Proxy Application
FASP-Pipe Proxy
Server Data Source
Client
Java Java
.NET Stream F F Stream
FASP FASP A T
C/C++ A .NET
Socket TCP
WebSocket
Server S WAN S C TCP
HTML 5 P FASP FASP P P C/C++
WS Data 3 Message
Message 3
SSE Data Socket

30. Use Case : On-Demand Access to Medical Images
Image Access Over Wireless or WAN links
• Doctors will download medical images on demand
• Images are kept ONLY in memory (compliance to regulations)
• Aspera server would interface to WADO server to pull DICOM images using http/https requests to
WADO server.
• Option for Direct Access to Images Using fasp

31. Use Case : Server-Side Rendering & Remote Viewing of Medical
Images Over WAN and Wireless Networks
• Server side rendering, and delivery of rendered images to Viewing applications.
• Thin Client
• Thick Client

32. Use Case : Health Information Exchange
• Drop in Replacement of HTTP with fasp for XDS-I

33. POSSIBLE INTEGRATIONS

34. Possible Integration
• Peake Healthcare --Joint Venture Between Johns Hopkins and Harris Corporation
• McKesson
• Vital (MINT Use case)
• Washington University School of Medicine

35. ASPERA-INTEL DISCUSSION

36. THANK YOU!
Daniel Kumi
Director, New Market Development
daniel@asperasoft.com
