Industrial-Man is a manufacturing company located in Shenzhen, China that has over 20 years of experience in rapid prototyping and manufacturing. They provide services such as CNC machining, vacuum casting, die casting, 3D printing, and injection molding across a variety of materials using over 50 machines. Industrial-Man has a long history of working with automotive, electronics, medical, and other industries on projects ranging from prototyping to mass production.

1. Headquarters: No.1 Langxia Industrial Zone, Songgang, Bao'an District, Shenzhen, China 518105
深圳市宝安区松岗街道朗下社区朗下工业区一号
http://www.gyrmodel.com sales10@gyrmodel.com

3. 公司企业文化 2015年 公司搬迁至宝安松岗，占地面积10000平方米。
Moved to Songgang aera with 10000 square meter in 2015.
2013年 湖北工业人汽车设计制造基地建立，基地占地面积5万平方米。
Automobile design and manufacture base founded in HuBei of 50,000 ㎡
.
2011年 公司试制作RP间设备增至90余台，年营业额达到3000多万人民币。
Machines increased to 90, and annual sales reached to 80 million RMB.
2009年 公司成为西北工业大学教学实习基地。
Became The educational practice base of NWPU.
2008年， 为苹果、索尼等公司践行项目试制，并与国内多家知名汽车企业建立合作关系。
Tested projects for Sony & Apple, also cooperated with renowed Chinese Auto Companies.
2007年 与日本知名模型制造企业EMTOPIA签订技术交流协议。
Signed the activities of technical exchanges with Japan EMTOPLIA.
2006年 与西安交通大学共同建立快速成型制研基地。
Estabilshed Research base of rapid prototyping with Xi'an Jiaotong University.
2005年 公司成为中国机械制造工艺协会快速原型制造分会理事企业。
Member of China association of machinery manufacturing process of rapid prototyping.
2004年 公司迁到宝安西乡，改名为深圳市工业人快速成型技术有限公司。
Moved factory to Bao'an, established Hongkong office & Changed name to Industrial Man.
2003年 工业人成为深圳工业机械行业理事会企业。
Member of China Shenzhen Machinery Association(SZMA).
2000年 率先购买第一台进口CNC设备，成为中国领先购买快速成型制造设备的企业。
Imported first CNC machines and become the leading prototyping manufactures.
1997年 成立深圳市工业人模型设计有限公司。
Established Shenzhen Industrial Man Model Design Company.

4. Highly Experienced Engineers
Internationally Recognised
Technology Diversity
Western Managed
Secure Facilities & Processes
QA/QC < 0.1 Reject Rate
ISO Certified Quality
Competitve Pricing
Honesty& Intergrity
ABS,ABS+GF,ABS+PC
POM(Derlin), PP, PC,PMMA(Acrylic),PVC
PEI,PBT,PTFI
Aluminum (6061,6063,7075...)
Brass, Copper, Brass
Satinless Steel (301,302,303,304...)
Similiar ABS, Resin, Nylon
PE, PA(Nylon), PA+GF,PPS
Polishing,Painting
Chroming,Andizing, Brushing, Silk
Creening,Water Transfering
Laser Cutting,Leather Covering
Texture, Sanblasting
Gilding, UV Painting...

5. 50 sets CNC Machining - high Efficiency
Massive Bed Sizes-3,4 & 5 Axis Milling
3500mm * 2500mm * 1200mm
3-5 Axis vertical and horizontal milling

6. Vacuum casting is the technique used to create multiple
injection moulded quality parts from a silicone tool, typically
produce around 25 castings depending upon the geometry and
complexity of the part.
Materials range from elastomerics through to glass-filled, high
impact polyurethanes and have an average shrinkage value of
+/- 0.3mm. Maximum size: 1000*800*800mm
Tolerance:100mm/+/-0.20mm
Vacuum castings can be manufactured in an array of pantone
colours, surface finishes, materials and can also be tapped,
drilled, insert moulded and over-moulded.

7. Equipment Aluminum Steel Brass
CNC Machining
Center
CNC Lathing/Turning
Wire EDM
Cast Forging

10. Equipment List
Type Qty Size Speed Axis Brand
CMM 2 2500×1500×1000mm 700×800×600mm / 3 Renishaw
PMI Master PRO 1 / / / Oxford
CNC Machining (Plastic) 8 2100×1200×550mm/ 1800×700×500mm 12000RPM 3 CNC Mill
CNC Machining (Plastic) 12 1000×600×500mm 8000PRM 3
CNC Machining (Plastic) 16 600×500×100mm/ 850×600×150mm 30000PRM 3 Everwin
CNC Machining (Plastic) 16 900×600×500mm/ 1200×800×150mm 50000PRM 3
Vacuum Casting 4 1800×3000×1200mm/ 400×350×600mm Vacuum Casting / /
Vac Cast Oven 2 2000×3000×1500mm /1000×1000×1000mm Vac Cast Oven / /
RIM 1 180kg / / /
UV Oven 1 1000×800×400mm / / /
Paint Curtain 1 3000×2000×1500mm / / /
CNC Mill & Turning 20 580×400×270mm/850×650×300mm / 3 /
CNC Mill & Turning 3 500×520×210mm / 4 /
CNC Mill & Turning 7 1800×1200×370mm/ 1200×800×370mm / 3 /
CNC Lathe 4 Ф125mm/Ф115mm/Ф80mm / 2 /
EDM 4 / / / /
Wire Cutter 1 700×420mm / / /
5 Axis CNC Machining
Injection Molding
1
5
/
150T/250T/500T/800T/1000T
/
/
5
/
Belotti

11. INDUSTRIAL-MAN COMMON PlASTIC MACHINING MATERIALS SELECTION GUIDE
ABS Polycarbonate (PC) Acrylic (PMMA) Acetal (POM) Nylon (PA) Polypropylene (PP) ALUMINIUM
Description Low-cost
engineering plastic
offers exceptional
mechanical and
surface strength for
a wide range of
parts used in high-
impact applications.
Tough and durable,
transparent
engineering
thermoplastic notable
for its high impact
resistance,
temperature
resistance and optical
properties.
Amorphous
thermoplastic
material with very
good optical
properties. Acrylic is
often used as a glass
substitute.
POM is an engineering
Thermoplastic often
used for precision
components that
require high stiffness,
low friction and
excellent dimensional
stability.
Comprise the
largest family of
engineering plastics
with a very wide
range of
applications.
Nylons are
generally Strong,
Tough and Wear
Resistant.
Semi-opaque
thermoplastic widely
used. Polypropylene
has good resistance to
fatigue. PP offers a
combination of
outstanding physical,
chemical, mechanical,
thermal and electrical
properties
Most widely used
non-ferrous metal.
Soft, Durable,
Lightweight, Ductile
and Malleable.
appearance ranging
from Silvery to dull
grey, depending on
the surface
roughness.
Applications General Household
items, Toys,
Automotive Parts,
kitchen Appliances,
Computer Parts,
Laboratory
Equipment,
Phone/Fax machine
parts,
Electrical/Electronic
enclosures, Aircraft
and automotive
interior trims
Automotive headlamp
Lenses and Safety
Shields,
Medical/Healthcare
apparatus, Automotive
Applications,
Construction Industry,
Sporting Goods,
Appliances, Casing and
housings,
Electrical/Electronic
components,
Connectors, Compact
Discs.
Automotive light
covers, Lighting
fixtures, Clear
Bottles and
Container, Lenses,
Shop-fittings,
Aircraft glazing,
Novelty display
cases, Signs,
Appliances, Modern
furniture, Jewelry
items,
Medical/Healthcare
Applications.
Gears, Bearings, Screws,
Pump parts, Electronic
components, Insulators,
Medical parts,
Furniture hardware,
Valve bodies, Zippers,
Underwater
applications.
Ideal for wear
applications such as
Bearings and Gears,
Sporting Goods,
Fishing line,
Automotive Parts,
Tanks, Engineering
Parts, Power Tools,
Intake Manifolds.
Appliance housings,
Food Packaging,
Medical and
Laboratory
applications, Pump
Components, Casings
with Living Hinges,
Automotive parts,
Food Containers,
Industrial Applications,
Loudspeaker drive
units, Household
Goods.
Large number of
components for
Automobiles, Aircraft,
Trucks, Trains.
Packaging application
like beverage cans,
foils. Construction
industry, Wide range
of household items,
Consumer
Electronics, Heat
sinks for electronic
appliances.
Finish
Available
Smooth Finish,
Sand Blast, Polished
Finish, Painted or
Grey Primered,
Electroplated
Smooth Finish, Sand
Blast, Mirror Polish,
Vapor Polish ,
Translucent finish
Smooth Finish,
Mirror Polish, Flame
Polish ,Translucent
Finish, Painted or
Tinted finish
Smooth Finish, Sand
Blast, Polished finish
Smooth Finish,
Sand Blast
Smooth Finish, Sand
Blast
Polished, Mirror
Polish, Brushed
Polish, Bead Blast,
Anodising, Painting,
Powder Coating.

15. Die Casting is the go to option for manufacturing
aluminum, zinc and magnesium parts in volume. Our
engineering team are highly experienced with the
productionof die cast parts and will be able to assist you
throughout the entire process. We also offer tool design,
drawing and validation services to help prior to production.
We have a range of on site and subcontracted finishing
options including CNC Machining, threading, tapping,
anodizong, painting and power coating.
In house technological diversity and experience to deliver
quality production parts on time, every time. Offer
pakaging and assembly after production.

16. Grill Fixture Dashboard Fixture Dashboard Over Molding

19. Consumer Electronics
Automotive
Medical
Other

20. STATR YOUR PROJECT WITH INDUSTRIAL-MAN
sales10@gyrmodel.com
