Ignite 2017 - Windows Server Feature Release

TRANSFORM MONOLITHS TO MICROSERVICES
New code and transforming existing code
CONTAINERIZE EXISTING APPLICATIONS
Containerize for portability, efficiency and reliability
ACCELERATE NEW APPLICATIONS
Agile cloud native app development

Modernize Traditional
Applications at
Fox MediaCloud
Part of Fox Entertainment Group
Dmitry Erman
Executive Director, Development and
Architecture
Ghosted
Premiering Sunday, October 1
Using Docker Enterprise Edition

1 Billion +
Subscribers
500 +
Channels
170 +
Countries
That Level Of Demand Means
Constant Innovation
● Speed to market
● Elasticity and reliability
● Improving CI/CD
Cloud is critical to our success moving
forward.
Challenges to overcome
● A majority of our budget goes towards
maintaining the status quo.
● Limited resources to port everything
quickly
● Architecture constraints

Existing
Application
Convert to a
container
with Docker
EE
The quickest way to cut into that budget
Modern
Infrastructure
Built on premise, in the
cloud, or as part of a
hybrid environment.
App
What’s Included
• 1 week onsite support /3 weeks remote
• Deploy Docker EE to cloud or on prem
infrastructure
• Containerize one application
• End-to-end app deploy using Docker EE
• App operations using Docker EE
Accomplishments in 3 Days
• Portability across multiple infrastructures
• Reduce/Eliminate deployment downtime
• Improve application density
• Embrace DevOps/CICD
• Baked in DR strategy
By Docker, Avanade, Microsoft
MTA was the quickest way to cut into that budget
and accelerate our path to the cloud

The Broadcast Affiliate Portal App allows Fox affiliate TV
stations around the country to pick the promotional content they
would like to air.
App Details
FMC Portal Load Balancer
HTTP
HTTP
FMC Portal FMC Portal
FMC
Portal
DB
Okta &
other
services
Redis
● N-tier ASP.NET 3.5+ applications / MSSQL
2012
● 25% Max CPU Utilization on these servers
● 2 vm’s running 5-6 IIS Apps
● Windows Server 2012
Challenges
● Deploying and maintaining this application
involves lots of manual process
● DR isn’t part of the overall structure, app just gets
rebuilt and redeployed. Downtime required.

FMC Portal Load Balancer
Worker_0
10.X.X.2
Worker_1
10.X.X.3
Worker_2
10.X.X.4
FMC Portal
DB
Web Redis
Okta &
other
services
Load Balancer
Manager_0
10.X.X.5 UCP
DTR
Overlay
Network
HTTP
HTTP
HTTP
HTTP
HTTP
HTTP
App went from running on prem on
Windows Server 2012, To fully
containerized application running in
Azure on Windows Server 2016
With no changes to
the application code
● Portal is now containerized
as is the redis instance
attached to it
● DB and Auth still remains
external.
● DR is no longer concern as
the app is now containerized
an orchestrated by Docker
Swarm.
RedisWeb RedisWeb Redis
Using Docker EE

FMC
Portal
Before After
• 3 weeks to get code into
production
• No app redundancy or DR
• Security fixes are
resolved same day but
require downtime
• Time to Scale is 1+ weeks
Completed in 3 Days
• Deploy in minutes
• Built in redundancy easily into
design/architecture
• Groundwork for CI/CD built
into the platform
• No downtime for security
fixes
• Time to Scale now takes
minutes

What’s Next For
Fox
• Build production multi-cloud with Azure
• Deploy POC app to new environment
• Identify additional app targets
The path is pretty straight forward…

Existing
Application
Convert to
container
Move to cloud
or refresh HW
Modern
Infrastructure
Modern
Methodologies
Integrate with
DevOps and Agile
programming
Modern
Microservices
Add new services
or start peeling
off services from
monolith code base

ConvertTo-Dockerfile `
-RemotePath 192.168.1.5c$ `
-OutputPath c:newDockerFile `
-Artifact IIS
# escape=`
FROM microsoft/aspnet:windowsservercore-10.0.14393.693
SHELL ["powershell", "-Command", "$ErrorActionPreference = 'Stop'; $ProgressPreference = 'SilentlyContinue';"]
RUN Remove-Website 'Default Web Site';
# Set up website: iis-env
RUN New-Item -Path 'C:iisiis-env' -Type Directory -Force;
RUN New-Website -Name 'iis-env' -PhysicalPath 'C:iisiis-env' -Port 8090 -Force;
EXPOSE 8090
COPY ["iis-env", "/iis/iis-env"]

https://www.powershellgallery.com/packages/Image2Docker/
https://github.com/docker/communitytools-image2docker-win

Visual Studio 2017 Container tools

Popular Container Runtimes:
• Windows
• Linux

Popular Container Management Layers:
• Docker
• Linux Containers (LXC)

 Container Orchestrator
Popular Container Orchestrators:
• Docker Swarm
• Kubernetes
• Service Fabric
• OpenShift
What do container orchestrators provide?
 High reliability Declarative model for multi-host apps
 Desired state reconciliation  Health monitoring
 Security features Dynamic scaling (And more!)

But these concepts apply to other
orchestration solutions, too.

Host 1 (Windows) Host 2 (Windows) Host 3 (Linux)

Host 2 (Windows) Host 3 (Linux)Host 1 (Windows)
[HOST 1] C:> docker swarm init

[HOST 1] C:> docker swarm join <JOIN-TOKEN>

Front-end Service: web
Back-end
Service: db
Overlay Network: hello-net

Back-end
Service: db

Back-end
Service: db
[HOST 1] C:> docker service scale web=3

http://swarm.host2/http://swarm.host1/ http://swarm.host3/

1. Host mode publishing
2. Ingress routing mesh
 Optimal for production
 Optimal for developer scenarios

Host mode service publishing
Publishing info for web:
http://swarm.host1:5032/

http://swarm.host2/
http://swarm.host1/ http://swarm.host3/

http://swarm.host2/
http://swarm.host1/ http://swarm.host3/
What if a container or host fails?

2. Ingress routing mesh*
*New! With Windows Server version 1709

ingress network
Ingress routing mesh

ingress network
What if a container or host fails?

ingress network

2. Ingress routing mesh*
Let’s take one
more look…
*New! With Windows Server version 1709

What do container orchestrators provide?
 High reliability Declarative model for multi-host apps
 Desired state reconciliation  Health monitoring
 Security features Dynamic scaling (And more!)
…

networking platform additions
• Multiple network drivers; NAT, Transparent, L2-Bridge, L2-Tunnel, Overlay
• Virtualized network components; Host Network Service
• Networking plugins: LibNetwork Plugin (Docker), CNI Plugin (Kubernetes)
• Support for orchestration abstractions:
• Container/service port publishing
• [Swarm mode] Routing mesh
• [Kubernetes] Pods
• And more!
Thank you!
sdn_feedback@microsoft.com

Windows Server, Linux and mainframe
on-prem and cloud
Self healing, rolling updates and health checks
E2E security, image scanning, signing, secrets
Granular role based and LDAP/AD access
control
Frictionless deployment experience
https://dockertrial.com

Preview Support for
Windows Server Containers
Control plane runs on Linux nodes,
Kubelet/kube-proxy run on Windows
Network is achieved using L3 routing
Only One Container Per Pod
https://aka.ms/ignite17/acs-k8-win
https://aka.ms/ignite17/k8-gettingstarted
BRK3147 - Kubernetes on Windows
BRK3181 - Modernizing application delivery and agility with containers, Kubernetes, and Microsoft Azure

Support for Windows Server containers,
Hyper-V isolation and Linux containers!
Image deployment and activation
Volume driver support
Networking and DNS discovery
Resource governance
BRK2190 - Orchestrating one million containers with Azure Service Fabric

Preview of Azure Functions Runtime
