The document discusses IBM Power Systems and how they can power a smarter planet through smarter systems. It provides examples of how Power Systems are used in smarter healthcare, energy, money, cities, and telecom. It highlights the technology leadership and performance of Power7 and Power7+ systems and their ability to optimize workloads, virtualize without limits, provide resiliency without downtime, optimize energy usage, and integrate value through software.

1. IBM Power Systems Power your planet. Smarter Systems for a Smarter Planet

3. Source: IDC Quarterly Server Tracker Q309 release, November 2009 UNIX Server Rolling Four Quarter Average Revenue Share POWER4 Dynamic LPARs POWER6 Live Partition Mobility POWER5 Micro-Partitioning Customers are moving to higher value … as shown by the largest shift of customer spending in UNIX History

4. successful Power Migration Factory migrations to date. There were over 500 Power migrations during 2009, with more than 90% from Sun and HP customers (including x86 consolidation). In 4Q09 alone, Power achieved nearly 200 competitive migrations. 2,100

5. Our vision Designed, integrated systems are part of the transformational story of the next decade.

6. IBM Systems & Technology lay the foundation Workload Optimization Deep Understanding of Client Needs Approach challenge from the client’s perspective A Comprehensive Portfolio A family of “fit-for-purpose” servers, storage & system software Technology Leadership Investing in future technology for differentiation and sustained leadership

7. Providing an integrated solution of systems, software and services Systems designed for a smarter planet New Delivery Models will offer multiple delivery options: managed services, outsourcing, cloud and system offerings Integrated Service Management will enable a fully virtualized infrastructure providing rapid deployment and lower cost Workload Optimizing Systems will deliver systems that optimize for specific client workloads Integrated Services Integrated Software Integrated Systems

9. Instrumented. Interconnected. Intelligent. There are one billion transistors per human, each costing one ten-millionth of a cent. The information created by a trillion networked things grows exponentially. Algorithms and systems turn mountains of data into actions that make the world better. Smarter.

10. Smarter Healthcare Health systems can connect people to information, to experts and to each other and can act proactively to better manage and deliver preventive and therapeutic care. 30% Percentage of total data in the world used for medical images

11. The challenge To accelerate the understanding of the molecular basis of cancer through the application of genome analysis technologies, especially large-scale genome sequencing. The solution Leveraged the performance and virtualization of POWER7 systems to provide researchers with more flexibility and efficiency in analysis across a range of research projects. Using POWER7 to better understand cancer The POWER7 architecture has enabled us to pursue a broader range of research problems on a single system than was possible before … -- Dr. B. Kim Andrews Manager of Research Computing 50% of the roughly 30,000 identified genes have functions that are unknown.

12. Smarter Energy With little or no intelligence to balance loads or monitor energy flows, enough electricity is lost annually to power India, Germany and Canada for an entire year. 15% Reduction in power usage during peak hours by consumers connected to smart grid systems

13. The world’s first “smart grid” country Enemalta and Water Services Corporation uses Power Systems to provide Malta with smarter energy and water management The challenge: Malta depends entirely on foreign fuel oil for the production of all of its electricity and for more than half of its water supply, which filters through an energy-intensive desalination process. The solution: After the transformation of both utilities, data from intelligent meters can be analyzed to help lower costs, adopt efficient and sustainable consumption patterns and cut greenhouse gas emissions. Citizens can make smarter decisions about how and when they use power 250,000 interactive meters will monitor electricity usage in real time, set variable rates, and reward customers who consume less energy and water.

14. Smarter Money Power Systems performance, security and availability are capabilities that provide the world’s largest banks with the ability to move today’s money - intangible, invisible information - from a paycheck to a bank to a retailer and back into another business account. Smarter Cities Cities large and small depend on the ability of Power Systems to sift through the data needed to not only solve crimes and respond to emergencies, but to help prevent them. Power Systems help manage traffic, share information across city agencies, keep citizens informed and give them access to services. Smarter Telecom Telcos are using Power Systems to deliver new services dynamically to an exploding number of devices - and Power’s scalability means that new services can be added quickly, new clients can be billed accurately, and costs can be reduced with consolidation.

15. Organizations are moving from “what” to “how” How do I infuse intelligence into a system for which no one enterprise or agency is responsible? How do I bring all the necessary constituents together? How do I make the case for budget? How do I get a complex solution through procurement? How do I coalesce support with citizens? Where should I start? How fast should I move? “ ”

16. Clients are working with IBM to find answers Queensland Motorways leads the way to smart traffic management with IBM Power Systems and SAP The challenge: Implement new free flow tolling Central System to transform QML’s business operations for efficiencies and to set a platform for growth. The solution: Optimized infrastructure, intelligent data mirroring, and increased interconnectedness that helped achieve highest service levels and increased efficiencies 25% total cost of ownership savings due to a fully integrated system that gives citizens total mobility around the city of Brisbane, Australia. In all my years in the workforce I have never been associated with a system implementation that has been as professionally delivered with such commitment. Jeremy Turner - CFO, Queensland Motorways Ltd.

18. Power your planet. Smarter systems for a Smarter Planet.

21. POWER7 continues to break the rules with more performance SPECint_rate Itanium HP rx6600 SPARC Sun T5440 x86 HP DL585 POWER7 Power 750 with PowerVM The highest performing 4-socket system on the planet Power 750

22. The most energy efficient 4-socket system on the planet The first Energy Star certified RISC system Performance Per Watt Most energy efficient systems Power 750 Itanium HP rx6600 SPARC Sun T5440 x86 HP DL585 POWER7 Power 750 with PowerVM

24. Source: Capacity based on IBM Sizing of typical ERP landscape and IBM estimates of system utilization. Pricing from www.hp.com US$447,969 US$387,760 At equal capacity for two 32 core IBM Power 750 Express systems compared to two HP DL785 G6‘s and nine HP DL380 G6 systems leveraging the higher utilization and virtualization efficiency capabilities of Power. The IBM Power 750 Express configuration saves 75% of the space, 90% of the network connections, and 72% of the systems to manage. Lower TCA

25. Number of Sun SPARC Enterprise T2000’s that can be consolidated into a single IBM Power 750 4 socket system saving 95% of the cores for software licensing, 97% on floor space, and 95% on energy. 92 to 1

26. used yearly by the 91,920* Sun SPARC Enterprise T2000 servers shipped since 2005 above what would be used yearly if consolidated into 1,000 IBM Power 750s at the rate of 92 to 1. That’s enough electricity to supply 34,500 homes for a year. 345 million kilowatt-hours 91,920 Sun T2000s 1,000 IBM Power 750s Source: IDC Server Tracker; Wikipedia estimate of average annual household energy use of 10,000 kwH

30. Super Power indeed. Number of HP Integrity Superdome 64-core systems utilized at 30% that can be consolidated into a single IBM Power 780 modular high-end system utilized at 80% saving 87% of the cores for software licensing, reduces floor space required from 80 square feet to just 7.6, and reduces energy costs by 92%. 8 to 1

31. 84% Reduction in energy usage moving from POWER5 to POWER7. Savings extend to floor space, software license costs, and maintenance. Increase your performance and capacity. With room to spare to consolidate x86 workloads POWER5 570 systems 64 cores @ 1.9 GHz 30% utilization 4 50% effective capacity increase 84% reduction in energy usage ~$250K maintenance savings over 3 years > $1M savings in software licensing Power 770 24 cores @ 3.5 GHz 60% utilization 1

32. IBM Capacity on Demand buys one core of POWER7 performance with up to 8GB of memory on an IBM Power 770 using On/Off Capacity on Demand. If you need to add a temporary Linux server to run a new application server front-end for a few days, would you rather spend thousands on yet another x86 server or just use the Power capacity you need for less than $100 for a business week? US $16 per day

36. Power is Virtualization without Limits Performance without penalty - all benchmarks published in a virtualized environment Consolidate AIX & i databases with Linux application servers on one system or a system pool Up to 32x the VM size & 8x the memory of VMware and D ynamically add & remove VM resources unlike VMware Live Partition Mobility with VM’s of any size up to entire system unlike VMware Drive systems to over 90% utilization for maximum ROI

37. All 3 operating environments available with POWER7 The future of UNIX “ For the second year in a row, AIX scored the highest reliability ratings among 15 different server operating system platforms” - ITIC 2009 Total integration with i “ Costs for use of Power Systems and IBM i 6.1 average 41 % less than x86 servers and Microsoft Windows” - ITG 2010 Scalable Linux ready for x86 consolidation Queensland Motorways replaced legacy Windows x86 traffic management systems with new SAP running Linux on Power

38. PowerHA SystemMirror for AIX and i provide active/standby datacenter and multi-site disk clustering solutions for resiliency PowerHA pureScale provides active/active high performance data transfer, cluster coordination, and centralized locking and is built-into DB2 pureScale PowerVM Live Partition Mobility enables planned system downtime without application downtime Power is Resiliency without Downtime

39. Power is Dynamic Energy Optimization POWER7 delivers up to 3 - 4X the performance with less energy than POWER6 Increased consolidation drives higher utilization and more energy savings EnergyScale™ intelligently and dynamically optimizes performance for energy efficiency IBM Systems Director Active Energy Manager helps lower energy usage per system and across systems

40. Physical assets & virtual resources at your fingertips with easy health monitoring & reporting, as well as updates & optimization VMControl™ for automation of virtualization management to minimize time to provision images and manage system pools Easy integration with enterprise service management tools from Tivoli as well as other third party providers Power is Management with Automation Server and virtualization management integrated with network and storage management for complete resource control

41. Express Edition Included with every Power System Standard Edition Express + virtual images, energy, network IBM Systems Director Editions Enterprise Edition Standard + manages systems pools, Tivoli additions

42. IBM Systems Director Editions IBM Smart Analytics System IBM DB2 pureScale IBM Lotus Domino Consolidation on Power IBM Rational Developer for Power IBM WebSphere Application Server Parallelization SAP on IBM DB2 and Power Systems Power is Integrated Value

46. Power is... Workload-Optimizing Systems Virtualization without Limits Resiliency without Downtime Dynamic Energy Optimization Management with Automation Integrated Value

47. Power your planet. Smarter systems for a Smarter Planet.

51. Consolidation onto POWER7 can deliver significant savings. Ninety-two Sun SPARC Enterprise T2000 servers can be consolidated into a single IBM Power 750 Express system, saving 95% of the cores for software licensing, 97% on floorspace, and 95% on energy. Calculation Summary : the Power 750 has 30.93 better SPECjbb2005 performance than the Sun T2000. Assuming a 3x virtualization factor for greater consolidation - then 92 Sun Fire T2000 servers could be consolidated onto one Power 750 Express server (30.93 * 3 = 92.8 servers rounded to 92 T2000 servers) Substantiation 1. SPEC and the benchmark names SPECrate, SPECint, and SPECjbb are registered trademarks of the Standard Performance Evaluation Corporation. Competitive benchmark results stated reflect results published on www.spec.org as of February 08, 2010. The comparison presented below is based on a consolidation of a legacy 8-core Sun SPARC Enterprise T2000 UltraSPARC T1 servers into a 32 core IBM Power 750. For the latest SPEC benchmark results, visit http:// www.spec.org . 2. SPECjbb2005 results are: POWER7 : IBM Power 750 Express with 4 chips, and 32 cores and four threads per core with a result of 2,300,000 bops and 71,875 bops/jvm submitted to SPEC on February 8, 2010. SPARC : Sun Microsystems Sun SPARC Enterprise T2000 with 1 chip, 8 cores and 4 threads per core with a result of 74,356 bops and 18,591 bops/jvm * The virtualized system count and energy savings were derived from several factors: - A performance ratio factor of 30.93X was applied to the virtualization scenario. The performance factor is the SPECjbb2005 result of the Power 750 Express divided by the result of the competitive Sun SPARC Enterprise T2000 server. - A virtualization factor of 3X was applied to the virtualization scenario using utilization assumptions derived from an Alinean white paper on server consolidation. The tool assumes 19% utilization of existing servers and 60% utilization of new servers. Source - www.ibm.com/services/us/ cio / optimize / opt_wp_ibm_systemp.pdf . Space calculation: The Sun T2000 is 2U in height and 21 can fit into a 42U rack. The 750 is 4U in height. Power consumption figures of 1950W for the IBM Power 750 and 450W for the Sun T2000 were based on the maximum rates published by IBM and Sun Microsystems, respectively. This information for the Power 750 is in "Model 8233-E8B server specifications" available at http://www-01.ibm.com/common/ssi/index.wss - search for Power 750. Sun T2000 Maximum AC power consumption of 450 WATTs was sourced from Sun SPAC Enterprise T2000 Servers site planning guide at http://docs.sun.com/app/docs/doc/819-2545-11 as of 2/9/2010. 18,591 74,365 Yes 1 8 4 Sun File T2000 77,467 2,478,929 Yes 4 32 32 IBM Power 750 Express bops/JVM bops HW Threading Processor chips Cores JVM Instances HW System Name 97.8% 95.2% 95.6% Savings with Power 750 Express 184 41,400 736 1,368,150 92 8 2 450 74,365 Sun File T2000 4 1950 32 1,380,000 1 32 4 1950 2,478,929 IBM Power 750 Express Total Rack Space Total Watts Total Cores Total Perf Systems Cores Rack space Max Watts SPECjbb2005 System Name

55. The modular enterprise class POWER systems have continued to deliver significant improvements year over year. With the Power 770 server, clients can consolidate four POWER5™ processor-based Power 570 systems onto one Power 770. In fact, it only takes two nodes and moving to the Power 770 still has an effective capacity increase of 50%. Substantiation : 84% Less Energy > 50% Capacity 87% Less Space Advantage / Savings 20,800 92.9 30% 309.8 16 64 IBM System p® 570 (x4) 3200 156.7 60% 261.19 2 24 IBM Power 770 Maintenance WATTs Effective Performance Utilization rPerf Nodes Cores System Name
