This document summarizes a presentation on understanding the internals of Git. It discusses key Git concepts like Git being distributed, content-addressable, and operating as both a database and a graph. It outlines paradigm shifts in thinking of commits as separate from sharing. The document then dissects common Git operations like branching, committing, fetching, merging, rebasing, and pushing to demonstrate how they manipulate the underlying graph. It also provides advice on commands to recover from errors like reset, reflog, and interactive rebasing.

1. INSIDE
GIT

2. GIT INSIDE OUT
MICHAEL NADEL
▸Developer @ Pine River Capital Management
▸New(ish) to .NET
▸3-year Git practitioner
▸Please reach out!
▸michael.nadel@gmail.com
▸@mnadel

3. GIT INSIDE OUT
GIT IS HARD
▸Linus Torvalds, creator of Git (and Linux)
▸Initial revision of “git”, the information manager from hell
▸I didn’t really expect anyone to use it because it’s so hard
to use.
▸Andrew Morton, lead Linux kernel developer
▸Git is expressly designed to make you feel less intelligent
than you thought you were.

4. GIT INSIDE OUT
THE CHALLENGE WITH GIT
▸Plenty of rope
▸Paradigm shifts
▸Distributed
▸Content-addressable filesystem

5. GIT INSIDE OUT
WHY INSIDE OUT?

6. GIT INSIDE OUT
AGENDA
▸Paradigm shifts
▸Conceptual models
▸Overview of internals
▸Dissect common operations

7. GIT INSIDE OUT
DISTRIBUTED
▸No central authority (except by convention)
YOUR REPO/CLONE OTHERS’ REPOS
CLONE
FETCH
PUSH

8. GIT INSIDE OUT
COMMITTING != SHARING
▸Separate concerns
▸Crafting your history
▸Publishing your history
▸Richer workflows
▸Commit, commit, commit, squash, push
▸Reorder, push subset
▸Enforced code reviews

9. GIT INSIDE OUT
CONTENT ADDRESSABLE
▸Version control is an abstraction on top of a primitive
key/value store
▸hash-object
▸cat-file
▸Prove
▸cat-file performs no magic

10. GIT INSIDE OUT
CONTENT ADDRESSABLE
▸Given arbitrary content

11. GIT INSIDE OUT
CONTENT ADDRESSABLE
▸Git primitive: hash-object

12. GIT INSIDE OUT
CONTENT ADDRESSABLE
▸Git returns its key (SHA1 hash of contents)

13. GIT INSIDE OUT
CONTENT ADDRESSABLE
▸Git primitive: cat-file

14. GIT INSIDE OUT
CONTENT ADDRESSABLE
▸Git returns the original content

15. GIT INSIDE OUT
CONTENT ADDRESSABLE
▸Final proof!

16. GIT INSIDE OUT
CONTENT ADDRESSABLE FILESYSTEM
▸Instead of text, how about your filesystem?

17. GIT INSIDE OUT
CONCEPTUAL MODELS
▸Git as a Database
▸Store, retrieve, search your source code & its history
▸Git as a Graph
▸CRUD operations are performed against a graph of
commits

18. GIT INSIDE OUT
GIT AS A DATABASE
▸CRUD, search operations
▸Data types
▸Commit
▸Tree
▸Blob
Structured text
byte[]

19. GIT INSIDE OUT
DB TYPE - COMMIT

20. GIT INSIDE OUT
DB TYPE - COMMIT

21. GIT INSIDE OUT
DB TYPE - COMMIT

22. GIT INSIDE OUT
DB TYPE - TREE

23. GIT INSIDE OUT
DB TYPE - TREE

24. GIT INSIDE OUT
DB TYPE - TREE

25. GIT INSIDE OUT
DB TYPE - TREE

26. GIT INSIDE OUT
DB TYPE - BLOB

27. GIT INSIDE OUT
CONTENT ADDRESSABLE FILESYSTEM
93b6
ae3e
7bbc63b7
4e3c 3ca5

28. GIT INSIDE OUT
GIT AS A GRAPH
▸What operations must I perform to get the graph to look the
way I want?

29. GIT INSIDE OUT
GIT COMMANDMENTS
▸Git is immutable
▸No updates, only appends
▸Git is a directed acyclic graph (DAG)
▸Directed: can only traverse in a single direction
▸Acyclic: no cycles — traversals only visit a node once
▸Every command is an operation on the graph

30. GIT INSIDE OUT
GIT IS IMMUTABLE
PREVIOUS SNAPSHOTCURRENT SNAPSHOT

31. ▸Branch
▸Commit
▸Fetch
▸Merge
▸Push
▸Rebase
GIT INSIDE OUT
DISSECT COMMON OPERATIONS

32. GIT INSIDE OUT
REFS, HEADS, BRANCHES
▸Ref is a pointer to a commit
▸Branch is a ref
▸HEAD is a pointer to your current branch
▸Branches have “namespaces”

33. GIT INSIDE OUT
BRANCH (BEFORE)
▸A branch is a ref
▸A ref is a pointer to a commit

34. GIT INSIDE OUT
BRANCH (AFTER)
▸A branch is a ref
▸A ref is a pointer to a commit

35. ▸Heads contain your branches
▸Remotes contain remote
branches (eg origin)
▸“Namespaces” are directories
▸Branches are 40-byte files
containing a SHA1 hash of a
commit object
GIT INSIDE OUT
BRANCH IMPLEMENTATION

36. GIT INSIDE OUT
COMMIT (BEFORE)
▸A commit references its parent
▸HEAD, branch point at commit

37. GIT INSIDE OUT
COMMIT (AFTER)
▸Add a new node
▸Advance branch

38. GIT INSIDE OUT
FETCH (BEFORE)
▸Fetch brings remote objects into repo
▸Refs, commits
▸But Git is immutable

39. ▸Graft remote commits into graph
▸Updates refs in remote namespace
GIT INSIDE OUT
FETCH (AFTER)

40. GIT INSIDE OUT
MERGE (BEFORE)
▸Merge is just a commit object
▸But which refers to two parents

41. GIT INSIDE OUT
MERGE (AFTER)
▸Creates new commit with two parents
▸Current branch, other branch
▸Advance branch

42. GIT INSIDE OUT
FAST-FORWARD MERGE (BEFORE)
▸Type of merge
▸Is there a traversal from your branch to the other’s?

43. GIT INSIDE OUT
FAST-FORWARD MERGE (AFTER)
▸Simplest merge
▸Pointer manipulation only

44. GIT INSIDE OUT
REBASE (BEFORE)
▸Type of merge
▸Without merge commit objects

45. GIT INSIDE OUT
REBASE (AFTER)
▸Replay your commits onto the other branch

46. GIT INSIDE OUT
PUSH
▸Two-step process
▸“Reverse” fetch — push commits, refs
▸Attempt a fast-forward merge

47. GIT INSIDE OUT
PUSH
▸What will happen if you push?
▸How do you recover?

48. GIT INSIDE OUT
SAVING YOURSELF - RESET

49. GIT INSIDE OUT
SAVING YOURSELF - REFLOG

50. GIT INSIDE OUT
SAVING YOURSELF - INTERACTIVE
REBASE

51. GIT INSIDE OUT
RECAP - CONCEPTUAL MODELS
▸Duality of Git
▸As a database
▸As an immutable DAG
▸Reasoning through problems
▸Launch SmartGit & observe the result of commands
against the DAG

52. GIT INSIDE OUT
RECAP - “OH SHIT!” COMMANDS
▸git reflog
▸git reset
▸—soft won’t affect your workspace
▸—hard will make your workspace reflect where your
HEAD moved to (you can lose work)
▸git rebase -i

53. GIT INSIDE OUT
RESOURCES
▸https://git-scm.com/book/en/v1/Git-Internals
▸https://github.com/pluralsight/git-internals-pdf/releases
▸https://pinboard.in/u:mnadel/t:git/
▸http://www.syntevo.com/smartgit/
▸Free for open source projects
▸Also: https://www.sourcetreeapp.com/
▸michael.nadel@gmail.com
