This drawing shows a gear puller tool used to remove cotter pins. It was drawn by K. Thorpe on November 20, 2014 at a scale of 8:1. The gear puller has several rounded features including the jaws that grip the gear, with dimensions provided in inches. It will be used to assist the removal of cotter pins from mechanical components.

1. DRAWN BY: K.THORPE
DATE:
SCALE: 8:1
DRAWING TITLE: GEAR PULLER - COTTER PIN
CCTC FILESRAPIDPHOTOGEAR PULLER - COTTER PIN.DWG
11/20/2014 DRAWING NO: 6 OF 6
SIZE:
A
CENTRAL CAROLINA TECHNICAL COLLEGE
ENGINEERING GRAPHICS TECHNOLOGY
CHECKED BY:
GRADE:
SCALE: 4:1
.6300
.3700
.0849
.0020
.0880
.1200
30°
R.0900
R.0470
R.0600 TYP.
R.1030 TYP.
R.0444 TYP.
R.0100 TYP.
R.0300
