Ge logiq e
•
0 likes•114 views
The GE Logiq e is a portable ultrasound system with a laptop form factor. It has imaging modes including B-Mode, M-Mode, Color Doppler, and Power Doppler. Features include a 15" color LCD, backlit keyboard, integrated speakers, onboard patient data management, and lithium-ion battery. Probes include convex, linear, and sector probes ranging from 1.5-13 MHz for various applications like vascular, OB/GYN, and small parts imaging.
Report
Share
Report
Share
Download to read offline
![System overview:
A battery-powered portable version of the Logiq
line by GE with a good balance between features
and price. The Logiq e replaced the older Logiq book
with a more standard laptop style form factor.
Applications:
Vascular
OB/GYN
Abdominal
MSK
Veterinary
Urology
Small parts
Emergency
Imaging modes:
B-Mode
M-Mode
Color Doppler
Power Doppler
PW Doppler
CW Doppler
Freehand 3D
Features:
15" color LCD monitor
1 probe port
Backlit keyboard
Integrated speakers
ATO [Automatic Tissue Optimization]
