FIXXUS Presentation
- 1.
- 2. THE PROBLEM • Many facilities built in in the 60s and 70s. • Insulated Metal panels – aging oven baked polyester finish wears, peels, flakes • Concrete – Porous; cracks and spalls • Damage and corrosion painted over, or covered up with FRP or SS panels • Severe deterioration requires replacement and the cycle begins again.
- 3. THE PROBLEM As finishes deteriorate, cleaning and maintenance efforts increase Finish dulls and Harsher chemicals scratches, making and more abrasion the surface in turn deteriorate rougher and more the surface faster porous Sanitation crews work longer and Rougher harder scrubbing, surfaces with more collect more Eventually, USDA will require chemicals, more dirt and grime water, etc. the plant to hang plastic on the walls to prevent contamination
- 4. THE PROBLEM Facilities ask Paint Vendors to provide Finishes solutions, which deteriorate they do to the best of their ability After numerous repetitions, plants decide to replace the panels, or cover them up and cycle Food Safety risks increase to Ineffective begins again. the point that painting (which USDA / FDA results in peeling inspectors require or flaking paint) With pre-stressed corrections concrete, there are few options, if any. Touch up paint or hang plastic over production areas
- 5.
- 6. SOME SOLUTIONS 1) Painting (Industrial Enamel, epoxy, urethanes, Reinforcing linings) 2) Cover with FRP 3) Cover with Stainless Steel 4) Replace panels * All options either create problems or restart the cycle
- 7. SOME SOLUTIONS The Painting Cycle – Just A Temporary Fix
- 8.
- 9.
- 10. SOME SOLUTIONS - More Temporary Measures
- 11. SOME SOLUTIONS Just Cover Up Problems…
- 12. SOME SOLUTIONS Just Cover Up Problems…
- 13. THE BEST SOLUTION Engineered Sanitation for Interior Walls and Ceilings Twelve (12) Year Case History 69 Projects in 35 Sites for 19 Clients Reduces Risk Best Long-Term Alternative Installed Quickly Cost Effective Reduces Sanitation Costs Seamless and Safe
- 14. THE SYSTEMS FIXXUS Sanitary Systems NO product contamination from deteriorating construction materials REDUCE Liability • Seal joints between construction materials • Eliminate caulking • Stop water or air infiltration • Eliminate pockets or ledges where water gathers • Fill gaps where bacteria and insects hide These issues are THE regulatory focus in the Food Processing Industry.
- 15. THE SYSTEMS BEFORE FIXXUS Typical conditions Small Freezer Structure, Poultry processing in GA
- 16. Sister Panels AFTER FIXXUS remove dents Duct Penetratio n Sealed Floor Terminatio Concrete Concrete Gloss Door n Sealed Curb Column Finish Rehab Sealed Sealed
- 17. THE SYSTEMS •FIXXUS PanelRehabilitation -FIXXUS Sister Panel System •FIXXUS Concrete Solutions -FIXXUS Double Tee Ceiling Rehab -FIXXUS Sanitary Curbing
- 18. THE SYSTEMS INSULATED METAL PANELS •Transitions Panel / Curb Joint •Flexible •Stops Corrosion •Eliminates Harborage Site
- 19. THE SYSTEMS SISTER PANEL SYSTEM When Good Panels Go Bad… FIXXUS Installs New Skins Prior to Finishes..
- 20. THE SYSTEMS SISTER PANELSYSTEM •Alternative to Panel Replacement •No Vapor Space for Bacteria Mold or Algae •Waterproof & Monolithic
- 21. THE SYSTEMS CONCRETE SOLUTIONS Is This Growing Behind Your FRP?
- 22. THE SYSTEMS CONCRETE SOLUTIONS •Seamless Hygienic Surface •Flexible / Crack Bridging •Eliminates Vapor Space •Installed Over a Weekend
- 23. THE SYSTEMS DOUBLE TEE CEILINGS Risk of Adulteration Overhead
- 24. THE SYSTEMS DOUBLE TEE CEILINGS •Cost Effective •Structural Repair •Low Risk Solution •Cleanable
- 25. THE SYSTEMS SANITARY CURBING •Seamless Barrier Between Curb and Processing •Stops Water Penetration •Flexible and Ultra Strong
- 26. HOW TOUGH ISIT?
- 27. FIXXUS SOLUTIONS "We don’t have the hard numbers, but how could it not be more efficient than what we had? Just look at it!" – Plant Engineer FIXXUS Panel Rehabilitation FIXXUS Concrete Solutions FIXXUS Fluid Applied Roofing FIXXUS Flexible Flooring FIXXUS Freezer Rehab FIXXUS Consulting FIXXUS Worldwide Services
- 28. Kevin Gooding kgooding@fixxus.com 336-669-3247 Twelve (12) Year Case History 69 Projects in 35 Sites for 19 Clients Reduces Risk Best Long-Term Alternative Installed Quickly Cost Effective Reduces Sanitation Costs Seamless and Safe
