1. EMBEDDED-SIM
Evolving Technology
Prepared by
S Sandeep Kumar
(199x1a04c7)

2. Conclusion
&
The End
What is a sim ?
Evolution of Sim
cards
What is an E-sim ?
Differences between
Sim & E-Sim
Outline of Presentation

3. SIM

4. SIM stands for - Subscriber Identity Module.
In general these sim card acts as a bridge/portal
between a mobile device & a network operator.
It is a piece of plastic that slots into your
smartphone(Mobile phone) which helps you to
connect to a mobile network and lets you to make
calls, send/receive messages.
Every sim card has some private information
stored in it.
About SIM

5. All physical sim card has some unique IMSI number
stored in it.
IMSI number (It is of 13-14 digits)
This Unique number helps the subscriber to connect
to the network provider
Apart from IMSI number, a sim card also stores
some data related to network operator &
authorization.
(IMSI - International Mobile Subscriber Identity)
IMSI
Ex: Id - 40510278345215
Country code Network
operator code
Unique ID
About SIM
Connected to airtel Connected to Jio
Connected to Vodafone
IMSI Division for Network Operators
IMSI

6. As every subscriber has a unique id now, it makes it
easy for the station to connect calls or messages
based on his/her request.
These SIM cards have their carrier/Operator profiles
stored in it permanently.
All these physical cards have their private data fixed
because of which a duplicate copy cannot be made.
Station
#A01
#C11
#D05
#B23
#B12
#E44
#E18
#C13
#A17
#F89
Id - 14357839947422 Id - 24567332156744
About SIM

7. EVOLUTION OF
SIM CARDS

8. Smartphones are becoming slimmer day by day.
The main strategy of any smartphone company is to
minimize the size of existed components & add some
other new features to them, like
Increase the display screen of mobile.
Increase the quality of the camera.
Embed IR sender&receiver within a mobile.
Increase the durability of a mobile phone.
All the above features can be implemented if and only
if the size of pre-existed components is minimized,like
Decrease the size of the sim card.
Removal of the headphone jack.
-waterproof
-dustproof..etc
Features
Evolution of SIM card

9. 1991 2012
2003
1996 2016
Full size SIM card
Nano SIM card
Micro SIM card
Mini SIM card
E-SIM card
Soft-SIM
(Still on research)
Size of SIM card was reduced over the past 25-years
One of the Evolutionary step is the introduction of E-SIM
A nano Sim is 40x smaller than Full size sim card.
An E-sim is 30x smaller than the nano sim.
This E-sim saves 90% of space compared to nano
sim(Including the SIM slot and contacts)
Evolution of SIM card

10. E-SIM

11. The term E-SIM stands for Embedded-SIM card.
sometimes it is also called as eUICC.
So this E-SIM is soldered on the motherboard of
devices.
Which means it comes in the form of integrated
SIM chip that cannot be removed from a device
Therefore, we can say that an E-Sim is a non
removable SIM hardware integrated in the device
(embedded Universal Circuit Card)
About E-SIM

12. All E-SIM's works on the basis of up growing
technology Cloud computing
This means an E-sim is capable of downloading the
Network operator/Service provider profile from the
cloud.
This is the E-Sim revolution
Allowing users to connect any device to any service
provider, with just a few clicks.
Allowing to transfer the E-SIM profile over the air to
the device.
Allowing the subscriber to get rid of old physical
SIM cards.
About E-SIM
Download
profile from
Airtel
VODAFONE
JIO

13. Can access -
AIRTEL (or) JIO (or) VODAFONE (or) BSNL
About E-SIM
E-SIM
E-SIM card
Can access -
Only AIRTEL NETWORK
Can access -
Only JIO NETWORK
Can access -
Only VODAFONE NETWORK
Physical SIM card

14. SIM
E-SIM

15. SIM E-SIM
It is removable
Comes in various sizes
You have to order a new SIM card
every time if you want to change
carrier/Service provider
If your phone gets damaged you can
move SIM to other mobile & use
(Standard, Mini, Micro, Nano)
It is not removable
Comes as a part of the phone (or)
mother board
You can simply activate the plan
and carrier you like right from your
phone
If your phone gets damaged you
loose your SIM as well as contacts
in it.
SIM vs E-SIM

16. CONCLUSION

17. The development of E-SIM had a great impact on the
Electronics Industry
Many devices (like smartwatches...,) are coming
with E-sims built-in.
This E-SIM revolution is the future, which may last for
some generations.
Conclusion
Samsung galaxy watch
Samsung S21
Thinkpad Slim 3i

18. for the attention
