Company Presentation

2. Enventive Growth
 Years of existence: 10.
 First product delivery: 2005.
 Average growth over last 7 years: 70%
 Profitable, no debt, among fastest growing MCAD
Companies.

3. Examples of clients using Enventive
Automotive = 75% of Enventive market

4. Examples of clients using Enventive

5. Optimizing design for robustness When ? How ?
• Intensive time pressure to get
a.s.a.p in production and on the
market (solve costly Problems).
Voice of
Customer
• Sometimes forgotten due to time
Tolerance and pressure constraints.
Analysis
Product Problem • Results not interpreted and valued.
Requirement Resolution Simply sent to customer for
Specifications justification.
• Complex problems Require
Conceptual Production engineering change requests or
Design Release tooling changes, meaning time and
(Initial prototypes) (Hard Tooling) costs.
• The probability to have problems in
Detail Design
Pilot Program
production/assembly/usage is much
(Further prototypes higher
and testing) (Soft Tooling)
Tolerance • Tolerance analysis is a bottleneck in
Analysis Product Release the development & industrialisation
to Manufacturing process.

6. Solution Desired by Customers
 Managers want pushbutton tolerance NO MATH STRUCTURE IN CAD SYSTEM
analysis from CAD system Plane defined by X,Y,Z
Coordinates of points.
 This solution does not currently exist
 CAD mathematical structure inadequate
for tolerance analysis.
 Because of the CAD limitations, extremely
difficult to develop a CAD-based Plane defined by X,Y,Z
Coordinates of points.
pushbutton solution.
No mathematical relationships
between the surfaces

7. Process change: pre-CAD Tolerance Analysis-Based Design Optimization.
• Process capabilities taken into
account early in investigation.
• Diverse types of complex analyses: Voice of
• Complex kinematics. Customer
• Complex ISO tolerancing. Traditional
• Physical aspects (forces, Tolerance
contacts): need for DOE and Product Analysis
prototypes reduced. Problem
Requirement Resolution
Specifications
• Structured Transfer Function
optimization (focused on costs):
 Number of contributors.
 Sensitivities. Conceptual Production
 Tolerances Design Release
 Process Capabilities (Initial prototypes) (Hard Tooling)
 Tolerances on small impacts Tolerance
contributors. Analysis-Based
Design Optimization
• Design reliability justification from Detail Design
(Further prototypes Pilot Program
consultation phase. (Soft Tooling)
 Customer Confidence. and testing)
• Ease of use and of deployment Traditional
Tolerance Product Release
among engineers (no full time Analysis
specialist required). to Manufacturing

8. 4 bars Mechanism:

9. Finger in friction on complex profile:

10. Latch system operating in 3D including transmission by cable:

11. Hydraulic Brake Pedal System:

12. Multi Variate Statistical Optimisation of Spring submitted to a weight:

13. Stroke & Efficiency driven by conduit routing:

14. Sealing System:

15. Hydraulic Flap Assembly:

16. Accuracy Optimization on gear based mechanisms:

17. Comments from Enventive Users…
“We can conceptualize design concepts ten times faster in Enventive than we can with our native CAD
system…
Rather than seeking to simply avoid problems, by using tolerance-based optimization early in the product
development process, well up-front of traditional CAD, we’re able to use Enventive to target and achieve
optimized design solutions and aggressively establish competitive product offerings.”
Yves Le Pottier – Electrical Device Supplier
“I cannot leave a discussion of Enventive without mentioning it is fun to use. The software is graphically
based. Sketches and graphical representations of the parts drive the models. This, coupled with the easy
to use interface, creates “Stack-up Junkies” who want to do the analysis because the software helps
them easily visualize the impact a design change can have on the product.”
Eric Pattok – Delphi Steering Systems
“Our engineering team has been able to use Enventive after 4 days of training. We have been able to
correct some design mistakes that were done in the past due to the limitations of the tools we were
using. In the end, our customer praised us for the speed and professionalism with which we have been
able to complete and present the DFSS phase on this project.”
Pedro Lopes – Ficosa International
