Ec hmx cs_tx_christking_school
•
0 likes•198 views
In order for Christ the King Cathedral School in #Texas to expand, they had to relocate the practice football field:
Report
Share
Report
Share
Download to read offline
![Project Concerns
Several issues during the project created
concerns with how effective the project results
would be. During mulch application, HydraCM
mulch was mistakenly applied at a rate of
2500 lbs/acre instead of the recommended
3000 lbs/acre leading to concerns on how the
mulch would perform. Also, just 2 days after
the mulch application, the project site
received 2-3 inches of rain, followed a week
later by another heavy rain.
Results
Even with all the rain, HydraCM held its
ground, and no signs of erosion or rilling
occurred. Within days, the vegetation was
growing, and by the end of week two the field
could handle mowing. Ashton Walden with
Ashton Walden Landscaping, the installation
contractor, was pleasantly surprised by the
performance of HydraCM. “I had not used
HydraCM mulch before. In the past I have
only used wood mulches. I was skeptical on
not adding more tackifier to the mix. With
other wood mulches with tackifier I always
needed to add more tackifier, but this
[HydraCM] didn’t need it.” Walden was also
pleased with how it sprayed, and claimed he
would use it again. Wanjura believed that the
HydraCM mulch aided with the establishment
of the grass. “We have planted in the same
area before with seed alone and it took 5-6
months before the stand was established
enough to be mowed.” In addition to quick
vegetation establishment, the use of the
HydraCM mulch and seed was at least 5-10
times less expensive than placing sod.
0
1
2
3
4
5
RelativeExpense
HydraCM Sod
Cost Savings with HydraCM
For more information on this project, contact North American Green at 800-772-2040
14649 Hwy 41 North • Evansville, IN 47725 • 800-772-2040 • 812-867-6632 • Fax: 812-867-0247
www.nagreen.com • www.vmax3.com
The quick establishment of the vegetation can be
