The Drager Julian Plus Anaesthetic Machine was tested and found to be in good working condition. All components including the ventilator, monitor, fresh gas mixer, and backup battery passed self-tests and functionality checks. The machine's ventilator modes, flow meter, pressure gauges and monitor were verified and found to be in good working order. The system was deemed to be fully functional at the time of testing, with the only note being that it did not include a vaporiser unit.

1. Drager Julian Plus Anaesthetic
Machine
D O M:

2. Specifications
• Drager PM8060 Vitara Patient Monitor and
Module Rack
• Software version:- 3.02

3. Report
• Power up and self test ok.
• Ventilator, Electronic, Fresh Gas Mixer, System Compliance
and Patient leakage check all passed.
• All ventilator modes working okay, flow meter (digital) and
pressure gauges in good working order.
• Verified minute volume (MV) with tidal Volume (TV) and
frequency (BPM) - ok.
• Multi parameter monitor in good working order.
• System in good condition and fully functional at the time of
test.
• Backup battery operational.
• Please note there is no vaporiser with this unit

4. Images
