Boiler draft needs to be measured at 7 different locations in a boiler. Accurate draft measurement can reduce emissions, improve boiler efficiency and reduce your energy bills Manas Microsystems manufactures Digital Draft Indicators / Transmitters. These digital instruments are more accurate and easier to read, compared to the mechanical gauges with analog indicators. The mechanical gauges are of no use for control purposes as they cannot deliver any signal, while digital instruments can! Manas Draft measuring instruments are very economical compared to sophisticate electronic gauge transmitters and are comparable in price with mechanical gauges. In addition, the instruments can pay you back quickly in the form of saving energy due to perfect combustion.

1. Draft Gauge Indicator
www.manasmicro.com
Manas Microsystems
Technology | Excellence | Trust

2. www.manasmicro.com
Introduction
• Boiler draft needs to be usually measured at seven different locations in a boiler
• Accurate draft measurement can reduce emissions, improve boiler efficiency and
reduce your energy bills.
• Digital Draft Indicators / Transmitters are more accurate and easier to read,
compared to the mechanical gauges with analog indicators.
• The instruments can pay you back quickly in the form of saved energy due to
perfect combustion.

3. www.manasmicro.com
Features of Draft Gauge Indicator
• Wide range, ±50 mmwc to ± 750 mmwc
• Digital readout and DC output provided for control
purpose
• Draft transmitter can be mounted on the field
avoiding long piping lengths, eliminating large
costs
• Temperature compensation for span & zero
provided
• Accuracy much better as compared to mechanical
gauges

4. www.manasmicro.com
Applications of Draft Gauge Indicator
• To measure and control furnace draft
• In Boiler application used to increase combustion efficiency.
• Also to maintain safe operating conditions in a boiler.
• Used at FD fan outlet (cold air) Air heater inlet
• Used at Boiler outlet (Flue gas)
• F
