Deep dive into Android’s audio latency problem
- 2. Deep dive into Android’s audio latency problem
- 3. Severity of the problem
- 6. In this talk, we will demystify together where exactly those time difference went to!
- 7. Some numbers, for perspective • Acceptable latency for musicians • Vocals : 3ms - voice is literally “in your head” • Drums & Percussions : 6ms - you sit right in front of them • Guitars : 12ms - may take time in the effect chains • Keyboards : 23ms - goes through several sound chambers’ acoustics Sound On Sound : Optimising The Latency Of Your PC Audio Interface https://www.soundonsound.com/techniques/optimising-latency-pc-audio-interface#para7
- 8. Some numbers, for perspective • Simple Reaction Time (SRT) Factors influencing the latency of simple reaction time David L. Woods, John M. Wyma, E. William Yund, Timothy J. Herron, and Bruce Reed https://www.ncbi.nlm.nih.gov/pmc/articles/PMC4374455/
- 9. Some numbers, for perspective • Rhythm game’s highest (perfect) judgements, by player’s research • Dynamix 59ms • Deemo 50ms • Jubeat 41ms • Bang Dream! 40ms • Sound Voltex 33ms • Arcaea 25ms • Pop’n Music 25ms • Chunithm, Taiko no Tatsujin 33ms • VOEZ 30ms • Beatmania IIDX 20ms • Cytus 70ms • DDR 15ms Data compiled by @Sta_Light_ https://twitter.com/Sta_Light_/status/1020704143231500289
- 11. Why should I care?
- 12. 3 Classes of audio applications • Sequencer class - Latency does not matter • Music player : No one cares about latency. • Sequencer / Digital Audio Workstation : Able to compensate for the latency. • Instrument class - Latency may matter • Possible to “adapt to the latency”, just like a real instrument. • UI button sounds • Rhythm game class - Latency affects user experience greatly! Music is now tied to the gameplay. • Music games without response sound : compensate for latency is possible. • Music games with response sound : either perfect judgement with wrong response sound, or early judgement with in-time response sound.
- 13. Looper FL Studio Mobile Korg Gadget
- 14. Garage Band Korg iMS-20
- 15. Taiko no Tatsujin Groove Coaster Beatmania IIDX
- 17. Each device do “prefer” something • Native Sampling Rate • Older mostly 44000Hz, newer phones moved to 48000Hz • Optimal Buffer Size • The lower the better latency-wise. Bad phone cannot handle small buffers • Low Latency Feature (true / false) • Indicates a continuous output latency of 45 ms or less • Pro Audio Feature (true / false) • Indicates a continuous round-trip latency of 20 ms or less
- 18. Each device do “prefer” something Native Sampling Rate : 44100Hz Optimal Buffer Size : 640 Low Latency : False Pro Audio : False Native Sampling Rate : 44100Hz Optimal Buffer Size : 240 Low Latency : False Pro Audio : False Native Sampling Rate : 48000Hz Optimal Buffer Size : 192 Low Latency : True Pro Audio : True Go download a test app at https://superpowered.com/latency to see yours!
- 21. Introduction to all the API options! MediaPlayer SoundPool AudioTrack (Java) AudioTrack (C++) “Tracks” OpenSL ES AAudio Thread Thread Thread HAL Java C++ Hardware Abstraction Layer
- 22. Introduction to all the API options! MediaPlayer SoundPool AudioTrack (Java) AudioTrack (C++) “Tracks” OpenSL ES AAudio Thread Thread Thread HAL Java C++ Hardware Abstraction Layer
- 23. Introduction to all the API options! MediaPlayer SoundPool AudioTrack (Java) AudioTrack (C++) “Tracks” OpenSL ES AAudio Thread Thread Thread HAL Java C++ Hardware Abstraction Layer Let’s start from the lowest level So we know what higher level APIs ultimately maps to.
- 24. AudioTrack (C++) No matter what, it must comes down to this! • Our important question : How differently Unity used the AudioTrack than our “naive” native audio playing that results in that much latency?
- 25. A short while after Unity starts up…
- 27. Track Audio Stream Mixer Thread Audio Stream
- 29. Fast Native Sampling Rate : 44100Hz Optimal Buffer Size : 240 Low Latency : False Pro Audio : False
- 30. Mixer Threads • Fast Mixer • Up to 7 fast tracks • Mix normal mixer’s submix • Track attenuation (volume) • NO : • Resampling • Effects • Normal Mixer • Up to 32 tracks • Can play any sampling rate by sample rate conversion + effects Mixer Thread Fast Mixer Thread Normal Mixer Thread Normal Mixer Thread
- 31. 48000 Hz Mixer Thread 44100Hz 96000 Hz 44100Hz Sampling rate problem
- 33. adb shell dumpsys media.audio_flinger
- 34. Example Give me 15 tracks of 48000Hz, Buffer size 196 Native Sampling Rate : 48000Hz Optimal Buffer Size : 192 Low Latency : True Pro Audio : True
- 36. adb shell dumpsys media.audio_flinger
- 37. Phone
- 38. Your game !
- 39. How Unity achieve concurrency with just 1 AudioTrack ? • FMOD Mixer • Virtual tracks
- 40. (Normal) Mixer Thread24000 Hz FMOD Mixer (Latency!) 24000 Hz ? 44100 Hz 48000 Hz 22050 Hz (Normal) Track • Must wait until the end of frame to summarize `audioSource.Play()` (Latency!) • Calculate `AudioMixerGroup` buses and effects (Unity 5.0 +) (Latency!)
- 42. MediaPlayer SoundPool AudioTrack (Java) AudioTrack (C++) “Tracks” OpenSL ES AAudio Thread Thread Thread Java C++ Unity startup Usually gets normal track with 24000Hz rate (Latency!) Usually gets fast track with phone’s rate
- 43. OpenSL ES • An open source set of OpenGL-style audio commands. Implementers are free to maps to anything. • It maps to `AudioTrack` (C++) on Android. • Possible to get fast track.
- 44. “Project wilhelm” git clone https://android.googlesource.com/platform/frameworks/wilhelm
- 45. AudioTrack (Java) • `new AudioTrack()` = or • Still must feed audio stream. • Possible to get fast track. • `new AudioTrack()` x32 = crash
- 46. SoundPool • `new SoundPool()` does not instantiate any track yet. • Dynamically instantiate tracks as you play. (Can set a limit) Possible to get a fast track. • Get a track index back on every play. • Supports loading a file, storing multiple audio inside, loop, pause, resume, etc.
- 47. MediaPlayer • Cannot get fast track. • Full-blown media player with video support. • Not good for latency.
- 48. Fun experiment : Crashing Unity audio
- 50. Unity 2019.1.0a7
- 53. Latency wasted on bad AudioTrack
- 55. Buffer Size
- 57. ?
- 58. Buffer Underrun • Lower ring buffer size equals better latency, but with a risk of running out of data. • Exporting to PC build with Best Latency easily cause buffer underrun. • Exporting to Android with Best Latency usually works but I know a case that does not work.
- 59. Thank you!
