This report analyzes the global market for Power System in Package (PSiP) dc-dc converter modules. It forecasts strong growth in the PSiP market from $65 million in 2011 to $284 million in 2016 due to factors like increasing demand from communications and computers. PSiP devices could replace solutions like voltage regulators and switching converters by offering higher efficiency and power density. The report also examines technology trends, competitive landscape, and market opportunities for PSiP products in various applications.

1. DC-DC Converter ICs: Power System in Package, Worldwide Technology
Trends, Forecasts and Competitive Environment, First Edition
http://www.aarkstore.com/reports/DC-DC-Converter-ICs-Power-System-in-Package-Worldwide-
Technology-Trends-Forecasts-and-Competitive-Environment-First-Edition-170260.html
This report provides a detailed and quantitative analysis of the global market for Power Sistem in
Package (PSiP) dc-dc converter modules. In many instances, unit sales, dollar sales and pricing
trends are discussed. See the listing of Figures for a complete description of the Tables included
in this unique and extensive analysis.
Topics covered include:
Definitions and Factors Driving Adoption
System Maker Demand Characteristics
IC Developments and Packaging Trends
Materials Challenges
Application Demand Characteristics
Worldwide PSiP Forecasts
Commercial Development
Competitive Overview
PSiP products are encroaching certain dc-dc converter IC markets and could replace traditional
solutions over the next five years. The total Worldwide PSiP dollar market is projected to grow
from approximately $65 million in 2011 to $284 million in 2016, a compound annual growth rate
(CAGR) of 34.4%. High growth rates are expected for all the application segments targeted by
companies making PSiP products.
The engineering innovations that have led to PSiP, PCiP and PwrSoC designs will have an
impact on different levels and functions of existing dc-dc power converter ICs and modules.
PSiP and PCiP (and eventually PwrSoC) products are expected to encroach on the current levels
occupied by LDOs, switching regulators, and controllers/FETs.
The best opportunities are in communications and computers, where unit CAGRs are expected
to range between 35% and 50% between 2011 and 2016; and revenue CAGRs will be around
23% to 38% over the forecast period. Industrial applications will see good growth, as well,
around 55% for unit sales and 44% for dollar sales.
The best smaller markets will have even faster unit growth, but this is due to very low starting
bases. These include automotive, military/aerospace and medical applications, which will see
growth between 50% and 100%. Most of these applications will not see significant revenue until
2013, however.
“Power System in Package” is a term that encompasses several new package styles that could
replace certain existing dc-dc converter IC solutions in the future. The bulk of this report focuses
on “Power Supply in Package” (PSiP) designs, which are highly integrated micro-modules and
the most commercially advanced, although still considered an emerging solution. It also includes

2. “Power Supply on Chip” (PwrSoC), which is a complete switch-mode dc-dc converter solution
integrated onto a single piece of silicon (not yet commercially available); and “Power Converter
in Package” (PCiP), where some components are integrated, but other components are external.
PSiP devices could replace LDOs, for instance, since they can address space constraint
challenges while tripling power efficiency in ultra-low-noise environments. They could also
replace noisy dc-dc switching regulators with ultra-quiet, high-efficiency dc-dc converters and
miniaturize traditional discrete dc-dc converters.
This report identifies the functions that require the specific benefits offered by
PSiP/PCiP/PwrSoC products; and then identifies the applications that need these functions,
which are presently being met by LDOs, switching regulators, and so on. Due to pricing
constraints, however, these products are expected to be a very small portion of the overall dc-dc
converter IC market, but their share is growing.
No true commercial PwrSoC products currently exist, so the forecasts presented are for
PSiP/PCiP-type products. But these functions and applications could be met by future PwrSoC
products, as well. Darnell Group believes that looking at these technologies based on the
functions that the components perform opens up the commercial potential for PwrSoC, PSiP and
PCiP products. For example, an isolation barrier is typical in many applications, but this function
may be performed with multiple technologies. Capacitors are used for filtering and energy
storage, which can also be addressed in other ways.
Looking at PwrSoC, PSiP and PCiP technologies from a function integration perspective, as
opposed to a component integration perspective, also opens up the application markets where
these devices can be used, since the limitations of components integration may no longer apply.
Alternative solutions for these applications can be considered, and some companies are already
looking at this kind of redefinition in designing products. Not all of these solutions are cost-
effective yet, but they are expected to be over the coming years.
At the present time, most PSiP/PCiP solutions are being directed at the lower input voltage
segments. This is expected to change over the course of the forecast period, with products being
used in higher input voltage applications. While PSiPs are intended to primarily compete with
non-isolated dc-dc converter modules, PwrSoCs are expected to compete with both modules and
IC-based solutions.
Printed-circuit-board-based dc-dc converter modules are dominant at current levels of 5A and
more, and are less common at lower current levels. PSiPs are the more “mature” technology, are
commercially available, and are becoming more cost-competitive. PSiP-style products are not a
new trend, but they are expected to be the “advance guard” for PwrSoC products. Most
companies Darnell spoke to see a growing market for PSiP-style devices, including system
makers. PwrSoC still faces issues with cost and other economic factors, so adoption is expected
to be sporadic and in “niche” applications, such as computer distributed point-of-load, mobile
devices, and applications where ultrahigh-power density is required.
Since no true PwrSoC commercial products exist yet, this report focuses on companies that are

3. either making PSiP products, or are developing technologies or researching innovative solutions
that are expected to further the PwrSoC market. The applications targeted by companies making
PSiP products include high-performance computer applications, such as servers; telecom
applications; and mobile devices, such as tablets and smartphones. Energy harvesting was also
cited as a “definite market,” along with “some industrial.” Although not included specifically in
these forecasts, PwrSoC is projected for small products and low-current applications.
Original equipment manufacturers (OEMs) frequently drive trends and changes in power supply
designs. The same dynamics are expected for PwrSoC. Intel sees “the start of a revolution in
power delivery and power management for SoCs and high performance applications.” Part of
this is “combining” power delivery and power management in applications ranging from
performance servers to small consumer electronic devices. Intel says, “The trend in platform
power needs to shrink, become more efficient, and be more cost-effective.”
With system makers driving power trends and prices coming down, the PSiP (and related
products) market is expected to grow significantly enough in the next few years to provide good
“early adopter” opportunities for companies with the foresight to take advantage of them.
