Data strucer , stack , Queue,

1. DATA STRUCTURES
shahab mohamad
1

2. Aims:
1. We want what is the data structures.
2. We want what is the stack.
3. What is the queue and type of queue.
2

3. Topic :
1. Introduction.
2. Stack Data Structure.
3. Queue Data Structure.
4. Circular Queue Data Structure.
3

4. 1. Introduction
Is a particular way of storing and organizing data in a computer so
that it can be used efficiently.
 There are two major categories:
• Static Structures
• Dynamic Structures
• Each has its own set of advantages and disadvantages.
4

5. Static Data Structures vs. Dynamic Data Structures
• Static Data structure:
–Is given a fixed area of memory which it can operate within.
 It is not possible to expand this fixed size in the run time. So that,
locations of each element is fixed and known by the program.
• Dynamic data structure :
 Has an area where it can operate. However, this size of the area is
flexible, not fixed as it was with static data structures.
 It is possible to expand or contract the area as required, by adding
or removing elements from data structure.
 Example: a static array and a dynamic linked list. 5

6. 2. Stack Data Structure
Stack: A data structure in which the elements are added and
removed from one end only; a Last In First Out (LIFO) data
structure.
6
push
pop

7. A last in, first out (LIFO) abstract data type and data
structure.
Push: the push operation adds a new item to the top of the stack
insert number 5
insert number 6
7
5
6
5
7
6
5
Insert number 7
8
7
6
5
Insert number 8

8. 7
6
5
8
Coutnumber8andremove
6
5
Coutnumber7andremove
5
Coutnumber6
andremove
Coutnumber5
andremove
Pop : The pop operation removes an item from the top
of the stack.

9. 3. Queue Data Structure
A first in, first out (FIFO) abstract data type and data
structure.
Enqueue : We call the insert operation on a queue EnQueue.
Dequeue: And the delete operation DeQueue.
9
Enqueue
Dequeue

10. Enqueue and dequeue :
10
5
dequeue
6
5
dequeue
dequeue
enqueue
6
enqueue

11. 4. Circular Queue Data Structure
“first in first out”.
– Insertion can be made only at the end (tail).
– Deletion can be made only at the front (head).
11

12. Example
12
DCBA
FDCBA

13. References
1. DATA STRUCTURES USING C++
SECOND EDITION : D.S. MALIK
2.‫البيانات‬ ‫هياكل‬ ‫مفصل‬ ‫الشرح‬
‫الكاتب‬:‫عبدالقادر‬ ‫داود‬ ‫ناصيف‬ ‫خالد‬.
3. Programming with 469 solved problems
Dr . Nassir H. salman
13

14. Questions?
Your time to ask questions..
14
