CURRICULUM VITAE
Personal Data
Firstname Chetan Kumar
Lastname Ramachandrappa Jayaram
Company P3 consulting engineering Private Ltd.
E-Mail Chetandevanga.j07@gmail.com
Professional Education
09/2006 - 06/2010 SHIRDI SAI ENGINEERING COLLEGE BANGALORE, KARNATAKA
B. E. (Mechanical Engineering)
used/gained Skills
 Presentation Techniques
 3D Modelling
Professional Experience
Since 01/2012 P3 consulting engineering Pvt. Ltd.
Airbus Quality Gate
Project #1
Period Since 01/2015
Project Name A350 ESI WORK PACKAGE
Customer Airbus Deutschland GmbH, Hamburg
Industry Aviation Industry
Role In Project -900 & -1000 Sec19 Zone lead
Project Description Responsible for DO Quality check for ATA 928 (3D, F3D & 920 Frontier Drawings) and
handover to TAP as per DRP (Drawing Release Planning).
Responsibilities:-
1. Create imade tickets and manage (from T000 till T999 Phase) for ATA928 CI’s to start
with design for respective MSN’s.
2. Conduct synchro with ME,DO,LAB,SSCI to reduce quality issues and to find Root cause.
3. Responsible for taking decision whether the raised finding needs to be reworked or has
to go for deviation.
4. Follow up of each DS from Supplier with respect to DRP as Administrative Task
5. Responsible to analyse and coordinate with TAP for Technical and Critical Issues.
6.Organizing Trainings for Designer and Checkers technically how to solve particular issue
with possible solutions.
used/gained Skills  iMade
 TreND
 CATIA V5 Drafting
 PDMLink System View A350
 CATIA V5 DMU Navigator
 PropTool
 Catia V5

2. Page2/7
 DMU Trouble
 Assignment Database (ADB)
 VPM A350
 Catia V5 Electrics
 DQN-SAP
 Referential in Configuration
 ICC/CADB
 Problem Solving and Improvement: Quality and Other Approaches
Project #2
Period 01/2014 - 12/2014
Project Name NEW CROWN PLATEAU A350XWB-900
Customer Airbus Deutschland GmbH, Hamburg
Industry Aviation Industry
Role In Project -900 Sec 13/14 Zone lead FWD UD
Project Description Responsible for Handover of Interface Plate ATA928 CI's to AIRBUS with a high quality
without skipping delivery dates.
Responsibilities:-
1. Harness ATA929 design in MAT A,B,C for A350 including with inputs CR,TRS,DQN.
2. Responsible for taking decision whether the raised finding needs to be reworked or has
to go for deviation.
3. Follow up of each DS from Supplier with respect to DRP as Administrative Task
4. Responsibility of team handling and managing the work load to team members and guide
with possible solution for critical situations.
used/gained Skills  Problem Solving and Improvement: Quality and Other Approaches
 PDMLink System View A350
 CATIA V5 Assembly Design
 iMade
 TreND
 TrEsti (Treatment Estimation Tool)
 Harness Morphology Viewer (HMV)
 PropTool
 CATIA V5 DMU Navigator
 Referential in Configuration
 Catia V5
 Catia V5 Electrics
 Presentation Techniques
 Assignment Database (ADB)
 Requirements Based Engineering
 VPM A350
 ICC/CADB
 DQN-SAP
 Check-List-Database (CLDB)
Project #3
Period 09/2013 - 01/2014
Project Name Electrical Equipment connections 2D Creation
Customer Jet aviaton
Industry Aviation Industry
Role In Project Team Member (full time)
Project Description Electrical Drawing creation for Equipment installation inside the aircraft.
Responsibilities:-
1. Analyse the input and create the Equipment Electrical drawing.

3. Page3/7
2. Creation of Drawing using AUTO CAD.
3. IQC the Drawings done and deliver the drawing with the responsibility.
used/gained Skills  Problem Solving and Improvement: Quality and Other Approaches
 AutoCAD
Project #4
Period 06/2013 - 08/2013
Project Name Airbus A400M ATA 879 Drawing creation and 2D Check
Customer Airbus Deutschland GmbH, Bremen on behalf of P3Voith Aerospace GmbH
Industry Aviation Industry
Role In Project Team Member (full time)
Project Description Creation of 879 Drawings for the Electrical Harness program A400M for Harness
Manufacturing Drawings by validating M879 Design solution with respect to TDD and SIDP
rules.
Responsibilities:-
1. Creation of Overview and detail drawings of electrical systems for A400M .
2. Check for item numbers, annotations, sleeve protection information like (EN6049-
007/EN6049-008/EN6049-009)and length information as per 879 2D Design Rules.
3. Being responsible till the BU get released for the AIRBUS signatures from all responsible
authorities mainly ME,DMU etc.,
used/gained Skills  Check-List-Database (CLDB)
 iShare
 Catia V5
 CATIA V5 Drafting
 iMade
 Catia V5 Electrics
 CATIA V5 DMU Navigator
 P3 Process Management Database (PMDB) – Work Flow Management
 Design Quality Check (QC1/MUI Check)
 Primes A400M
 Bundle Tracker
 Problem Solving and Improvement: Quality and Other Approaches
Project #5
Period 04/2013 - 05/2013
Project Name Airbus A400MATA 879 TL Check 3D Check
Customer Airbus GmbH Bremen
Industry Aviation Industry
Role In Project Team Member (full time)
Project Description Project involves checking of DS for Non-conformity for program A400M for Electrical
systems Harness validating all the design solution with respect to TDD and SIDP rules.
Responsibilities:-
1. Loading the ATA 879 and checking the routing design with respect to ATA 878.
2. Quality check for the DS with respect to TDD and SIDP rules.
3. Analyse for clashes, segregation and rework for the same.
used/gained Skills  Problem Solving and Improvement: Quality and Other Approaches
 Data Quality Check (QC1/MUI Check)
 iShare
 TreND
 Referential in Configuration
 CATIA V5 DMU Navigator
 Bundle Tracker

4. Page4/7
 P3 Process Management Database (PMDB)
 Primes A400M
 Check-List-Database (CLDB)
 iMade
 Catia V5
 PropTool
Project #6
Period 12/2012 - 03/2013
Project Name Airbus A400M PILOT PROJECT(HMV)
Customer Airbus Deutschland GmbH, Bremen on behalf of P3Voith Aerospace GmbH
Industry Aviation Industry
Role In Project Team Member (full time)
Project Description Project involves creation of 879 Drawings for the Electrical Harness using TAI Drawings
program A400M for Harness Manufacturing Drawings validating all the design solution with
respect to TDD and SIDP rules.
Responsibilities:-
1. Analyising TAI 2D Drawings and create new Layout for all MSN 7 VB‘s using Harness
Morphology Viewer software.
2. Place the Position Markers in 2D using CATIA V5 application..
3. Add Item Numbers, length and OBB/HBB information according to 879 2D Design Rules.
4. Interacting with Team Lead for quality and to achieve Drawing delivery on time.
used/gained Skills  Presentation Techniques
 Primes A400M
 TrEsti (Treatment Estimation Tool)
 Referential in Configuration
 Catia V5 Electrics
 Requirements Based Engineering
 iShare
 Data Quality Check (QC1/MUI Check)
 Catia V5
 Problem Solving and Improvement: Quality and Other Approaches
 Proposal Preparation
 Bundle Tracker
 ATA Chapter 87 (Wiring - Electrical and Electronic Common Installation – Military)
 Harness Morphology Viewer (HMV)
 PropTool
 P3 Process Management Database (PMDB)
Project #7
Period 08/2012 - 11/2012
Project Name Airbus A380 Harness Installation 3D Check
Customer AIRBUS A380
Industry Aviation Industry
Role In Project Team Member (full time)
Project Description Electrical Wiring harness Routing / Installation (L928 & L929) check in 3D for routing ,
Installation, Manufacturing feasibilities.
Responsibilities :-
1. Clash & Segregation Analysis (TDD & SIDP)
2. Functional , Harness Properties, Method, Feasibility, Design Rules, Fix Bracket, Inegration
& Product Structure Checks
3. Quality Control
4. Pilot Execution (Offshore - Onsite Model)
5. Offshore team Buildup-Training

5. Page5/7
6. Good knowledge on Sheet Metal and Surface design.
used/gained Skills  VPM A380
 TreND
 Catia V5
 Data Quality Check (QC1/MUI Check)
 DMU Trouble
 ATA Chapter 92 (Electrical Power Multiplexing)
 CATIA V5 DMU Navigator
 Referential in Configuration
 Product View (VPM-CATIA)
 Problem Solving and Improvement: Quality and Other Approaches
 Catia V4
 iMade
Project #8
Period 01/2012 - 07/2012
Project Name Harness Installation Drawing 2D Check
Customer AIRBUS A380
Industry Aviation Industry
Role In Project Team Member (full time)
Project Description Electrical Wiring harness Installation Drawing (L928 DRW) check.
Responsibilities :-
1. Input study, DEX
2. Drawing, BOM & ECN Check
3. Quality Control, Rework/Rejection Analysis
used/gained Skills  iMade
 ATA Chapter 92 (Electrical Power Multiplexing)
 Referential in Configuration
 Catia V5 Electrics
 VPM A380
 ZAMIZ
 CATIA V5 DMU Navigator
 Division dVise Mockup 2000i
 Catia V5
 Catia V4
 Data Quality Check (QC1/MUI Check)
11/2010 - 09/2011 Infotech Enterprises Limited, Hyderabad, INDIA
WORKING AS ASSISTANT DESIGN ENGINEER
Project #1
Period 12/2010 - 09/2011
Project Name TOOL DESIGN
Customer BOEING COMMERCIAL AEROPLANES
Industry Aviation Industry
Role In Project Assistant Engineer
Project Description Working on TOOL DESIGN to assemble the large tools related to aerospace domain as well
as large jigs and fixtures and recreate the parts as per client requests and Aero-structure of
a new variant of Boeing-787 Dreamliner. Projects done on Design data conversions and
Design revisions of the Boeing 737, 767 and 777 programs.
Good knowledge on convertion of the data and making 3D model as per Customer
requirement and updating same in Drafting with BOM and DRW using GD&T(ASMEY14.5M-
1994).
Work responsibilities:

6. Page6/7
• To create 3D model and Structures assembly by keeping V4 model of CATIA as reference.
• Detailing and creation of manufactured drawings for aircraft components. Orientation of
these parts in the assembly at their Critical positions.
• Modelling of standard parts according to customer design standards using customer
design manuals and instantiating those parts in the assembly.
• Creating BOM for the assembly and installation drawing for aircrafts using GD&T standard
ASMEY14.5M-1994.
used/gained Skills  CATIA V5 Assembly Design
 Tool Design
 ENOVIA VPM
 creation of technical specifications
 Catia V5
 CATIA V5 Part Design
 CATIA V5 Drafting
 CATIA V5 - Mechanical Design
07/2010 - 10/2010 ACCORD LASER MACHINING PVT. LTD.
Working as CAD,CAM Engineer.
Project #1
Period 07/2010 - 10/2010
Project Name CAD/CAM
Customer BUHLER, HYVA, BEML, Karnataka ENGG., HAL etc.,
Industry Automobile Industry
Role In Project CAD/CAM ENGINEER
Project Description Working as a leading Laser m/c programmer and designer for Automotive HMV and
Mechanical machines namely HMV Lorry(Ashok Leyland), Cranes-VOLVO(Hyva), etc.,
Responsibilities:
1. Responsible for quality metal cutting through design.
2. Improve machine cutting quality by modification in SIGMA NEST programming.
3.Planning the workers and operators to get maximum production per day.
used/gained Skills  AutoCAD
 Autodesk Inventor
Skills
Name Exp. in Years
Skills 3D Modelling 2.00 Years
ATA Chapter 87 (Wiring - Electrical
and Electronic Common Installation –
Military)
0.60 Years
ATA Chapter 92 (Electrical Power
Multiplexing)
3.50 Years
Data Quality Check (QC1/MUI Check) 3.50 Years
creation of technical specifications 0.80 Years
Presentation Techniques 5.00 Years
Problem Solving and Improvement:
Quality and Other Approaches
2.10 Years
Proposal Preparation 0.30 Years
Requirements Based Engineering 0.60 Years
Tool Design 0.80 Years

7. Page7/7
IT-Skills Assignment Database (ADB) 3.00 Years
AutoCAD 0.70 Years
Autodesk Inventor 0.30 Years
Bundle Tracker 0.70 Years
CATIA V5 - Mechanical Design 0.80 Years
CATIA V5 Assembly Design 1.10 Years
CATIA V5 DMU Navigator 4.00 Years
CATIA V5 Drafting 1.40 Years
CATIA V5 Part Design 0.80 Years
Catia V4 0.90 Years
Catia V5 4.50 Years
Catia V5 Electrics 1.80 Years
Check-List-Database (CLDB) 0.70 Years
DMU Trouble 0.70 Years
DQN-SAP 0.60 Years
Division dVise Mockup 2000i 0.60 Years
ENOVIA VPM 0.80 Years
Harness Morphology Viewer (HMV) 0.60 Years
ICC/CADB 0.60 Years
P3 Process Management Database
(PMDB)
0.70 Years
PDMLink System View A350 2.00 Years
Primes A400M 0.70 Years
Product View (VPM-CATIA) 0.30 Years
PropTool 1.10 Years
Referential in Configuration 2.00 Years
TrEsti (Treatment Estimation Tool) 0.60 Years
TreND 1.10 Years
VPM A350 3.00 Years
VPM A380 0.90 Years
ZAMIZ 0.60 Years
iMade 2.00 Years
iShare 0.70 Years
Trainings
Name Training Date
CATIA V5 AI Methods 03/11/2013
Primes A400M End to End Process 05/28/2013
