This Slides about Comparitve Analysis of different Algorithm Strategies.

1. Algorithm Strategies
Presented By M.Talha
MCS-13-08

2. Algorithms Strategy in Assignment
Decrease and Conquer
Greedy Approach
Backtracking
Transform and Conquer

3. Roadmap of Every Strategy
 Definition
 Types
 Example
 Advantages
 Disadvantages
 Algorithm
 Working
 Complexity

4. Decrease and Conquer
Definition
 _Change an instance into one smaller instance of the problem.
 _ Solve the smaller instance.
 _ Convert the solution of the smaller instance into a solution for the larger
Instance.

5. Decrease and Conquer
 Decrease by a Constant
 insertion sort
 graph traversal algorithms (DFS and BFS)
 topological sorting
 Decrease by a Constant Factor
 The Fake-coin problem
 Variable-size decrease
 Euclid’s algorithm

6. Decrease and Conquer
 Advantages
 Solve Smaller Instance
 Take less time
 Use for shortest path
 Disadvantages
 Depends on efficiency of sorting

7. Breadth-first search Algorithm
Definition
Breadth-first search (BFS) is an algorithm for traversing or
searching tree or graph data structures. It starts at the tree
root (or some arbitrary node of a graph, sometimes referred
to as a `search key'[1]) and explores the neighbor nodes first,
before moving to the next level neighbors.

8. Algorithm of BFS
 Procedure bfs (v)
 q: = make queue ()
 Enqueue (q, v)
 Mark v as visited
 While q is not empty
 v = dequeue (q)
 Process v
 for all unvisited vertices v' adjacent to v
 Mark v' as visited
 enqueue(q,v')

9. Order in which the nodes are expanded

10. Complexity
Θ (V2) if represented by an adjacency table,
Θ (|V| + |E|) if represented by adjacency lists

11. Greedy Approach
 Greedy algorithms are simple and straightforward.
 They are shortsighted in their approach in the sense that they take decisions on
the basis of information at hand without worrying about the effect these decisions
may have in the future.
 They are easy to invent, easy to implement and most of the time quite efficient.
 Many problems cannot be solved correctly by greedy approach.
 Greedy algorithms are used to solve optimization problems

12. Uses of Greedy Approach
 Greedy algorithms are often used in ad hoc mobile networking to efficiently
route packets with the fewest number of hops and the shortest delay
possible.
 They are also used in machine learning,
 business intelligence (BI),
 artificial intelligence (AI) and
 programming.
 Making Change Algorithm
 Huffman Encoding Algorithm

13. Greedy Approach
 Advantages :
 Very Large number of Feasible Solution.
 Easy to Implement.
 Disadvantages :
 It is much Slower.
 Does not give optimum result for all problems.

14. Huffman Encoding
 Huffman code is a particular type of optimal prefix code that is commonly
used for lossless data compression.

 The process of finding and/or using such a code proceeds by means of
Huffman codding.
 The output from Huffman's algorithm can be viewed as a variable-length code
table for encoding a source symbol (such as a character in a file).
http://en.wikipedia.org/wiki/Huffman_coding

15. Huffman Encoding Algorithm
 procedure Huffman(f)
 Input: An array f[1 _ _ _ n] of frequencies
 Output: An encoding tree with n leaves
 let H be a priority queue of integers, ordered by f
 for i = 1 to n: insert(H; i)
 for k = n + 1 to 2n 􀀀 1:
 i = deletemin(H); j = deletemin(H)
 create a node numbered k with children i; j
 f[k] = f[i] + f[j]
 insert(H; k)
http://en.wikipedia.org/wiki/Huffman_coding

16. Working of the Huffman Encoding Algorithm
http://en.wikipedia.org/wiki/Huffman_coding

17. Complexity
 we use a greedy O(n*log(n))
 http://www.siggraph.org/education/materials/HyperGraph/video/mpeg/mpe
gfaq/huffman_tutorial.html

18. Knapsack Problem
 You have a knapsack that has capacity (weight) W.
 You have several items 1 to n.
 Each item Ij has a weight wj and a benefit bj.
 You want to place a certain number of copies of each item
Ij in the knapsack so that :
 The knapsack weight capacity in not exceeded .
 the total benefits is maximal.
http://en.wikipedia.org/wiki/Knapsack_problem#Applic
ations

19. Knapsack Problem
http://en.wikipedia.org/wiki/Knapsack_problem#/medi
a/File:Knapsack.svg

20. Knapsack Problem Variants
 0/1 knapsack Problem
 The item cannot be divided.
 Fractional knapsack problem
 For instance, items are liquid or powders
 Solvable with a greedy algorithm
http://en.wikipedia.org/wiki/Knapsack_problem#Applic
ations

21. Greedy Knapsack - Fractional
 Much Easier
 For item Ij, let ratioj=bj/wj. This gives you the
benefit per measure of weight.
 Sort the items in descending order of rj.
 If the next item cannot fit into the knapsack
,break it and pick it partially just to fill the
knapsack.
http://en.wikipedia.org/wiki/Knapsack_problem#Applic
ations

22. Greedy Knapsack Algorithm
 P and W are arrays contain the
profit and weight n objects
ordered such that
p[i]/w[i]=>p[i+1]/w[1+i] that is in
decreasing order , m is the
knapsack size and x is the solution
vector.
 GreedyKnapsack(m,n)
• For(i=0;i<n;i++) {
• X[i]=0; }
• Int total=m;
• For (i=0; i<n; i++) {
• If(w[i] < = total){
• X[i]= 1;
• Total= total + w[i]; }
• Else
• X[i] = total / w[i];
• } // end Greedyknapsack
http://java90.blogspot.com/2012/02/knapsack-
problem-in-java.html

23. Example - Greedy Knapsack
Item A B C D
Benefit 50 140 60 60
weight 5 20 10 12
Ratio = B/W 10 7 6 5
•Example: Knapsack Capacity W = 30 and
http://www.radford.edu/~nokie/classes/360/greedy.ht
ml

24. Solution
All of A, all of B, and ((30-25)/10) of C (and none of D)
Weight: 5 + 20 + 10*(5/10) = 30
Value: 50 + 140 + 60*(5/10) = 190 + 30 = 220
http://www.radford.edu/~nokie/classes/360/greedy.ht
ml

25. Analysis
 If the items are already sorted into descending order of pi/wi
 Then the for-loop takes a time in O(n).
 Therefore , the Total time including the sort is in O(n log n).
http://java90.blogspot.com/2012/02/knapsack-
problem-in-java.html

26. Backtracking
 Backtracking is a technique for systematically trying all paths through a state
space.
 Backtracking search begins at the start state and pursues a path until it
reaches either a goal or a “dead end.”
 If it finds a goal, it quits and returns the solution path.
 If it reaches a dead end, it “backtracks” to the most recent node on the path
having unexamined siblings and continues down one of these branches,
en.wikipedia.org/wiki/Backtracking

27. Backtracking
 Backtracking is an important tool for solving
 constraint satisfaction problems, such as
 crosswords,
 verbal arithmetic,
 Sudoku,
 and many other puzzles.
 8 Queen Puzzle Algorithm is an example of Backtracking
en.wikipedia.org/wiki/Backtracking

28. Backtracking
 Advantages:
 Quick test
 Pair Matching
 Following real life Concept
 Disadvantages :
 Not widely Implemented
 Cannot Express Left Recursion
 More Time and Complexity
http://www.cl.cam.ac.uk/~mr10/backtrk.pdf

29. Eight queens puzzle
 The eight queens puzzle is the problem of placing eight chess
queens on an 8×8 chessboard so that no two queens threaten
each other.
 Thus, a solution requires that no two queens share the same
row, column, or diagonal.
http://en.wikipedia.org/wiki/Eight_queens_puzzle

30. Eight queens puzzle Algorithm
 Function backtrack;
 Begin
 SL: = [Start]; NSL: = [Start]; DE: = []; CS: = Start; % initialize:
 While NSL ≠ [ ] do % while there are states to be tried
 Begin
 If CS = goal (or meets goal description) then return SL; % on success,
return list of states in path.
 If CS has no children (excluding nodes already on DE, SL, and NSL) then
 Begin
 While SL is not empty and CS = the first element of SL do

31. Eight queens puzzle Algorithm
 Begin
 Add CS to DE;
 Remove first element from SL;
 Remove first element from NSL;
 CS: ~ first element of NSL:
 End
 Add CS to SL;
 End

32. Eight queens puzzle Algorithm
 Else begin
 Place children of CS (except nodes already on DE, SL, or NSL) on NSL;
 CS: = first element of NSL;
 Add CS to SL;
 End
 End;

33. Eight queens puzzle Algorithm
http://www.codeproject.com/Articles/806248/Eight-
Queens-Puzzle-Tree-Algorithm

34. Complexity
 The running time of your algorithm is at most N(N−1)(N−2)⋯(N−K+1), i.e.,
N!/(N−K)!. This is O(NK), i.e., exponential in K
 http://www.chegg.com/homework-help/questions-and-answers/poor-man-s-
n-queens-problemn-queens-arranged-n-x-n-chessboard-way-queen-checks-
queen-queen-q1009394
